NED SUCL2025T3 User manual

User’s Manual
Line Scan Camera
Type:SUCL2025T3
NIPPON ELECTRO-SENSORY DEVICES CORPORATION

NED
SUCL2025T3 UME-0017-08
2
For Customers in U.S.A.
This equipment has been tested and found to comply with the limits for a Class A digital
device, in accordance with Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference, in which case the user will be required to correct
the interference at his or her own expense.
For Customers in the EU
This equipment has been tested and found to comply with the essential requirements of
the EMC Directive 2004/108/EC, based on the following specifications applied:
EU Harmonised Standards
EN55022:2010 Class A
EN61000-6-2:2005
Warning
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Directive on Waste Electrical and Electronic Equipment (WEEE)
Please return all End of Life NED products to the distributor from whom the product was
purchased for adequate recycling and / or disposal. All costs of returning the Product to
NED are borne by the shipper.

NED
UME-0017-08 SUCL2025T3
3
Introduction
Thank you for purchasing NED’s Line Scan Camera. We look forward to your continued
custom in the future.
For safety use
For your protection, please read these safety instructions completely before operating
the product and keep this manual for future reference.
The following symbols appear next to important information regarding safe product
handling.
Safety precaution
Never disassemble or modify this product, unless otherwise
specified to do so in this manual.
When hands are wet, avoid handling this product and do not
touch any of the connection cable pins or other metallic components.
Do not operate this product in an environment that is exposed to rain or other severe
external elements, hazardous gases or chemicals.
If the product is not to be used for an extended period of time, as a safety precaution,
always unplug the connection cable from the camera unit.
If the product installation or inspection must be executed in an overhead location,
please take the necessary measures to prevent the camera unit and its components
from accidentally falling to the ground.
If smoke, an abnormal odor or strange noise is emitted from the camera unit, first turn
OFF power, then unplug the cable from the camera unit.
This product is not intended for use in a system configuration built for critical
applications.
Warning
If the product is not handled properly, this may result in
serious injury or possible death.
Caution
If the product is not handled properly, this may result in
physical injury or cause property damage.
Warning

NED
SUCL2025T3 UME-0017-08
4
Instructions before use
Only operate this product within the recommended environmental temperature range.
Use only the specified power source and voltage rating.
Do not drop this product. Avoid exposure to strong impact and vibrations.
Install the camera unit in a well-ventilated environment, in order to prevent the camera
from overheating.
If the camera must be installed in an environment containing dust or other particles,
take required measures to protect the camera unit from dust adhesion.
Do not unplug the cable while power is being supplied to the camera unit. To prevent
product damage, always shut down the power supply before unplugging the power
cable.
When the surface of the camera window becomes dirty due to dust or grime, black
smudges appear in the displayed image. Use an air blower to remove the dust particles.
Dip a cotton swab into ethanol alcohol and clean the camera window. Be careful not to
scratch the glass.
Use of non-infrared lighting such as a daylight fluorescent lamp is recommended. If
halogen lighting is employed, always install an infrared filter into your system
configuration.
Please note that exposure to long wavelength light outside of the sensors visible optical
range can affect the image.
Sensitivity may fluctuate depending on the spectral response level of the light source. In
cases like this, changing the light source to one with a different spectral response level
may reduce this problem. Moreover, this irregular sensitivity can be completely lost by
using 4.11 pixel correction function. Please refer to 4.11 pixel correction function for
details.
If the CCD is continually exposed to bright light which would exceed the CCD saturation
for a long time, the colour filter may become faded. As far as possible, the sensor
should be protected from light except when in use.
For stabilized image capturing, turn ON the power supply and execute aging for ten to
twenty minutes before actually using the camera unit.
Do not share the power supply with motor units or other devices that generate noise
interference.
Do not disconnect the camera while rewriting the embedded memory.
When you change the exposure mode that is set at the NED factory, input control signal
(CC1) from the capture board.

NED
UME-0017-08 SUCL2025T3
5
Product Warranty
Warranty Period
The product warranty period, as a general rule, is two years from purchase; however for
detailed conditions please contact the sales representative for your region/country.
However, in some cases due to the usage environment, usage conditions and/or
frequency of use, this warranty period may not be applicable.
Warranty Scope
Product repair will be performed on a Return To Manufacturer basis. On-site
maintenance will incur additional charges.
If defects in material or workmanship occur during the warranty period, the faulty part
will be replaced or repaired by us free of charge. Return shipping charges must be paid
by the sender. However, the following cases fall outside of the scope of this warranty:
Exclusions from Warranty Coverage
We will under no circumstances assume responsibility for the following cases: damage
caused by fire, earthquake, other acts of a third party, other accidents, negligent or
intentional misuse by the user, or other usage under extraordinary circumstances.
Damages (e.g. loss of business profits, business interruption, etc.) resulting from use or
non-use.
Damages caused by use other than as described in this document.
Damages resulting from malfunction due to a connected device.
Damages resulting from repairs or modifications performed by the customer.
Fault Diagnosis
As a general rule, in the first instance fault diagnosis should take the form of a
telephone call or an email to enable us to assess the circumstances of the malfunction.
However, depending on the customer’s requests, we, or our agent, may require an
additional fee for this service.
Exclusion of Liability for Compensation for Missed Opportunities
Regardless of whether within the warranty period or not, our warranty does not cover
compensation for missed opportunities for our customers, or our customers’ customers,
caused by a fault of our products, nor for damage to products other than our own, or
related business.

NED
SUCL2025T3 UME-0017-08
6
Note about Product Usage
This product has been designed and manufactured as a general-purpose product for
general industry. In applications expected to be life-critical or safety-critical, the installer
or user is requested to install double or triple failsafe systems.
Repair Service Outline
The cost of dispatching engineers etc. for repair service is not included in the price of
purchased and supplied goods. On request, arrangements can be made separately.
Scope of Repair Service
The above assumes business dealings and usage to take place in the customer’s
region / country. In cases of business dealings and/or usage outside the customer’s
region/country, separate consultation is required.

NED
UME-0017-08 SUCL2025T3
7
Table of Contents
1 Product Outline.............................................................................................................10
1.1 Features......................................................................................................................................10
1.2 Applications ...............................................................................................................................10
1.3 Image Sensor .............................................................................................................................11
1.4 Performance Specifications.....................................................................................................11
2 Camera Setting and Optical Interface .........................................................................14
2.1 Setting Camera ..........................................................................................................................14
2.2 Fixing Camera............................................................................................................................14
2.3 Camera dimension.....................................................................................................................14
2.4 Optical Interface.........................................................................................................................15
3 Hardware........................................................................................................................16
3.1 Camera Connection...................................................................................................................16
3.2 Input / Output Connectors and Indicator................................................................................17
3.3 Connectors / Pin Assignments / Cables..................................................................................18
3.4 Power Supply.............................................................................................................................21
4 Camera Control.............................................................................................................22
4.1 Flow of Camera Control............................................................................................................22
4.1.1 Command Overview.............................................................................................................22
4.1.2 Command Format (PC to Camera Transmission).............................................................22
4.1.3 Reply Format (Camera to PC Transmission) ....................................................................22
4.1.4 Camera Control Commands ...............................................................................................23
4.1.5 Memory Setup Values (Factory Settings)..........................................................................25
4.2 Details on Commands...............................................................................................................25
4.2.1 Setting Analog Gain.............................................................................................................25
4.2.2 Setting Digital Offset............................................................................................................26
4.2.3 Exposure Mode ....................................................................................................................26
4.2.4 Line Delay .............................................................................................................................26
4.2.5 Setting Output Signals (Setting Data Format)..................................................................26
4.2.6 Memory Initializing (Initializing Camera Settings)............................................................27
4.2.7 Memory Load (Readout the Camera setting from the flash memory)............................27
4.2.8 Memory Save........................................................................................................................27
4.2.9 Generating Test Pattern.......................................................................................................27
4.2.10 Readout the Operation Status..........................................................................................28
4.2.11 Adjusting automatic white balance..................................................................................28
4.2.12 Execute auto white balance function...............................................................................28
4.2.13 Memory Save......................................................................................................................29
4.2.14 Pixel Correction Data Save...............................................................................................29
4.2.15 Pixel Correction Reference Setting..................................................................................29
4.2.16 Pixel Correction Mode.......................................................................................................29

NED
SUCL2025T3 UME-0017-08
8
4.2.17 Setting Pixel Readout Direction.......................................................................................30
4.3 Digital Processing flow in FPGA..............................................................................................30
4.4 Startup.........................................................................................................................................30
4.5 Saving and Loading Camera Settings.....................................................................................31
4.6 Serial Communication Settings ...............................................................................................31
4.7 Video Output Format.................................................................................................................32
4.8 Exposure Mode and Timing Chart...........................................................................................33
4.8.1 Free Run Exposure Mode....................................................................................................33
4.8.2 External Trigger Exposure Mode (Ext Edge).....................................................................34
4.8.3 External Trigger (Ext Level) Mode......................................................................................35
4.8.4 External Trigger Exposure Mode (Ext Edge 1, 2) .............................................................36
4.9 Setting Offset .............................................................................................................................37
4.10 Setting Gain..............................................................................................................................38
4.11 Test Pattern...............................................................................................................................38
4.12 Automatic White Balance Function.......................................................................................39
4.12.1 Note about Optical Adjustment...........................................................................................39
4.12.2 Optical Condition Setting ....................................................................................................39
4.12.3 Automatic White Balance Adjustment................................................................................40
4.13 Pixel Correction Function.......................................................................................................41
4.13.1 Command Settings ............................................................................................................42
4.13.2 Method of operation ..........................................................................................................43
5 Confirming Camera Settings........................................................................................44
5.1 Before Power-on........................................................................................................................44
5.2 After Power-on ...........................................................................................................................45
5.3 During Operation.......................................................................................................................47
6 Sensor Handling Instructions......................................................................................48
6.1 Electrostatic Discharge and the Sensor .................................................................................48
6.2 Protecting Against Dust, Oil and Scratches...........................................................................48
6.3 Cleaning the Sensor Window...................................................................................................48
7 Troubleshooting............................................................................................................49
7.1 No Image.....................................................................................................................................49
7.2 Noise on Image..........................................................................................................................51
7.3 Camera becomes hot ................................................................................................................53
8NCCtrl............................................................................................................................54
8.1 Overview.....................................................................................................................................54
8.2 System Requirements...............................................................................................................54
8.3 Installaton...................................................................................................................................55
8.4 Uninstall......................................................................................................................................55
8.5 Operation....................................................................................................................................55
8.5.1 General description .............................................................................................................55

NED
UME-0017-08 SUCL2025T3
9
8.5.2 Starting NCCtrl .....................................................................................................................55
8.5.3 Open the control setting file...............................................................................................56
8.5.4 Selecting interface and Timeout setting............................................................................57
8.5.5 Connect.................................................................................................................................60
8.5.6 Disconnect and exit program.............................................................................................60
8.5.7 Check the contents of communication..............................................................................60
8.5.8 Export Parameters to text file.............................................................................................60
8.5.9 Import Parameters from text file ........................................................................................61
8.6 Control........................................................................................................................................61
8.6.1 Gain and Offset ....................................................................................................................62
8.6.2 Clock, Video output, Video shift, Exposure mode............................................................63
8.6.3 Exposure time ......................................................................................................................63
8.6.4 Binning..................................................................................................................................63
8.6.5 Camera Memory...................................................................................................................63
8.6.6 Calibration.............................................................................................................................64
8.6.7 Level Correction...................................................................................................................64
8.6.8 Test Pattern...........................................................................................................................64
8.6.9 Line Delay .............................................................................................................................65
8.7 Software Upgrades....................................................................................................................65
8.7.1 NCCtrl upgrades...................................................................................................................65
8.7.2 Adding/Replacing control setting file................................................................................65
8.7.3 Adding/Replacing the interface Plug-in.............................................................................65
8.8 Data Transmission Programming............................................................................................66
8.9 NCCtrl Troubleshooting............................................................................................................66
8.9.1 You can not change the exposure time with NCCtrl........................................................66
8.10 Attention on use.......................................................................................................................66
9 Others ............................................................................................................................67
9.1 Notice..........................................................................................................................................67
9.2 Contact for support...................................................................................................................67
9.3 Product Support ........................................................................................................................68
Revision History.................................................................................................................69

NED
SUCL2025T3 UME-0017-08
10
1 Product Outline
1.1 Features
readout(25MHz)
High resolution(2098 pixels)
Single power source DC12V for operation
Easy connection with a variety of frame grabber boards via Camera Link interface
Easy control of gain / offset / video output (8-/10-bit) with external software.
High responsivity and low noise
Flat-field correction - minimizes lens vignetting, non-uniform lighting and sensor
FPN and PRNU
Low power consumption (on the current NED camera)
Auto white balance
Free run exposure time control
Scan Direction Switching
Test pattern
RGB line delay
1.2 Applications
Inspection of Transparent panels and PCBs
Inspection of high speed moving objects
Flat panel display inspection
Inspection of glass and sheet-like objects
Printed circuit board inspection
This camera utilizes an Intelligent Transportation System
Outdoor surveillance

NED
UME-0017-08 SUCL2025T3
11
An example of Visual Inspection of PCBs is shown below.
LED incident
lighting
PCB pattern
Power
Supply
Figure 1-2-1 Visual Inspection of PCBs
1.3 Image Sensor
The camera uses a CCD sensor with a maximum data rate of 25MHz to acquire high
responsivity and superior quality images.
The pixel size is 14μm x 14μm. It outputs 2098 pixels data through 25MHz.
1.4 Performance Specifications
The Performance Specifications are shown below. Unless otherwise specified, the data
shown is when the camera is operating at the maximum scan rate.
Applicable Work
COB, BGA and MCM printed circuit boards
Performance
1. Maximum board size: 100mm×200mm
2. Resolution: 35μm
3. Inspection time: less than 30 seconds
Unit Configuration
1. Camera: Color line scan camera 2098 pixel
2. Controller: Dedicated software for PC system
3. Size: L930 x D500 x H500 (mm)
Applicable Fields
Inspection of patterns on film PCBs

NED
SUCL2025T3 UME-0017-08
12
Table 1-4-1 Performance Specifications
Items
Specifications
Number of Pixels
2098 x 3
Pixel Size H x V (μm)
14 x 14 (R-G G-B distance each 112μm)
Sensor Length (mm)
29.372
Spectral Responsivity (nm)
See Figure 1-4-1
Data Rate (MHz)
25 (fixed)
Maximum Scan Rate
(μs) / [kHz]
92.4 / [10.82]
Note: Please don’t set exposure time less than 92.4μs in
External Trigger (electronic shutter opening) mode. Because
it is impossible to right capture. (See Figure Timing Chart)
Saturation Exposure (lx/s)
(typically)
0.125
Responsivity (typically)
Analog 5V Conversion Sensitivity
25 (V/[lx/s])
*When shipping Ta=25°C, by Daylight Fluorescent Light]
Analog 5V Conversion Sensitivity
Gain Adjustable Range (dB)
0 to about 22
Offset Adjustable Range (DN)
8 bit：0 to about 15 DN
10 bit：0 to about 63 DN
Video output
Format
Camera Link Base line 24bit-RGB
Camera Link Medium line 30bit-RGB
Protocol
Camera Link Base Configuration
Camera Link Medium Configuration
PRNU
(Photo Response Non Uniformity)
Typically 5 %
Random Noise
20DN (minimum gain 10 bit)
Control Input
CC1, 2: External Trigger Signal [start signal]
CC3,4: Not in use
Serial communication control
SerTC, SerTFG
Master clock (MHz)
50 (internal clock)
Connectors
Data/Controller
3M: MDR26 [Camera Link]
Power Supply
Hirose: HR10G (4Pin)
Lens Mount
Nikon mount
Operating Temperature (˚C)
*No Condensation
0 to 50
Power Supply Voltage (V)
DC12 [+/-5%]
Consumption Current (mA)
(typically)
350

NED
UME-0017-08 SUCL2025T3
13
Size W x H x D (mm)
64×70×116 [except base holder]
Mass (g)
Under 470 [except base holder about 145g]
Additional Functions
1. Auto white balance
2. Pixel correction
3. RGB line delay
4. Free run exposure time control
5. Exposure control
6. Gain / Offset Control
7. 8 or 10 bit Video Output
8. Scan Direction Switching
9. Test Pattern Output
The spectral Responsivity is shown below.
１００
８０
６０
４０
２０
０
Relative Responsivity （％）
Wavelength （ｎｍ）
３５０ ４５０ ５５０ ６５０ ７５０ ８５０
ＲＧ
Ｂ
（Ｔａ＝２５℃）
Figure 1-4-1 Spectral Responsivity
Device structure is shown below.
Ｂ
Ｇ
Ｒ
112μm 112μm
14μｍ
14μｍ
2098
1
SUCL2025T3 pixel array

NED
SUCL2025T3 UME-0017-08
14
2 Camera Setting and Optical Interface
2.1 Setting Camera
The M4 screws on the front panel can be used to set the camera.
2.2 Fixing Camera
Use the M4 screw holes (4 places at the front) to fix the camera.
If using the front panel M4 mounting holes, the screw length for fixing the camera should
be less than 12mm at the front.
No X-, Y-axis orientation and tilt adjustment mechanism is available. Please provide an
adjustment mechanism yourself as necessary.
2.3 Camera dimension
The dimensions for the cameras are shown below.
３Ｍ
NIPPON ELECTRO-SENSORY DEVICES CORP.
MADE IN JAPAN
CAMERA LINK
DC 12V
SCAN
CL1 CL2
70
64.00
50.00
70.00
50.08
59.00
46.50 110.00
３Ｍ
40.00
40.00
1/4"-20UNC Depth 6
8-M4 Depth 6
40.00
FB
4-M4 Depth 6
cap bolt
Nikon F Mount
(6.00)
Power Supply Connector
MDR26 Connector
Ｍｅｄｉｕｍ side
DC +12V power
Supply indicator
MDR26
Connector
Ｂａｓｅ side
Figure 2-3-1 Dimensions(Nikon F Mount)

NED
UME-0017-08 SUCL2025T3
15
2.4 Optical Interface
The amount and wavelengths of light required to capture useful images depend on the
intended use. Factors include the property, speed, the object’s spectral characteristics,
exposure time, the light source characteristics, the specifications of the acquisition
system and so on.
The exposure amount (exposure time x light amount) is the most important factor in
getting desirable images. Please determine the exposure amount after studying what is
most important to your system.
Keep these guidelines in mind when setting up your light source:
LED light sources are relatively inexpensive, provide a uniform field and longer life
span compared to other light sources. However, they also require a camera with
excellent sensitivity.
Halogen light sources generally provide very little blue relative to infrared light (IR).
Fiber-optic light distribution systems generally transmit very little blue light relative
to IR.
Metal halide light sources are very bright but have a shorter life span compared to
other light sources.
Generally speaking, the brighter light sources, the shorter life span.
CCD image sensors are sensitive to infrared (IR). We recommend using daylight color
fluorescent lamps that have low IR emissions. If you use a halogen light source, to
prevent infrared from distorting the images use an IR cutoff filter that does not transmit IR
wavelengths.

NED
SUCL2025T3 UME-0017-08
16
3 Hardware
3.1 Camera Connection
(1) Camera Link cables shall be used to connect the camera unit with the frame grabber
board.
Use two cables of the same length and the same manufacturer. If you use asymmetric
Camera Link cables, connect the camera with the connector labeled as ”Camera side”.
(2) Connect with a power supply.
Use a power cable to connect the camera with the power source for the camera. Insert
the plug end of the cable into the camera. Attach the opposite end (loose wires) to the
power unit.
Other than the above, a personal computer, a frame grabber board, a photographic lens,
a photographic lens mount, a light source and an encoder are necessary, depending on
the situation.
PC
Camera Link
Frame Grabber Board
Line sensor camera Camera Link Cable
3M:14B26-SZLB-xxx-0LC
Power Cable
Camera Power
supply
DC+12V 15W
DGP-10 (10m)
Figure 3-1-1 Connections between Camera and Frame Grabber Board and Power Supply
There are two connectors available for the Camera Link Medium Configuration board.
Always check the frame grabber board specifications before making connections.

NED
UME-0017-08 SUCL2025T3
17
<Note: Choosing the appropriate Camera Link cable length >
According to the Camera Link Specification, the maximum cable length is 10m. But the
maximum cable length to be able to transfer data depends on the type of cable
performance and clock speed. The actual maximum transmission distance becomes less
than 10m at faster clock speeds, though the transmission distance of 10m is feasible at
slower clock speeds.
The following table shows values being calculated in accordance with the Camera Link
Specification 2007.Version1.2, using a typical cable (14B26-SZLB-xxx-0LC from 3M) and
frame grabber board (Solios from Matrox). Please choose the appropriate Camera Link
cable type and length for your application. We recommend you perform a connection test in
advance.
Table 3-1-1 calculated value of maximum cable length
3.2 Input / Output Connectors and Indicator
The layout of input /output connecters and the indicator lamp are as follows.
+12V Power Supply Indicator
Power Supply Connector
Panel（output check terminal）
MDR26 Connector
Ｂａｓｅ side
MDR26 Connector
Ｍｅｄｉｕｍ side
Figure 3-2-1 Input/Output Connectors and Indicator
Solios model
clock speed (MHz)
maximum cable length(m)
SOL 6M CL E*
(20~66MHz)
40
9.8
66
8.0
SOL 6M FC E*
(20~85MHz)
75
7.6
85
5.8

NED
SUCL2025T3 UME-0017-08
18
3.3 Connectors / Pin Assignments / Cables
This camera uses the Medium Configuration (8 bit output) of the Camera Link interface
standard. The figure shown below shows the interface for the camera and a typical
implementation for the frame grabber interface in the case of Medium Configuration.
Figure 3-3-1 Camera / Frame Grabber Interface
28 28
Frame Grabber BoardCamera
26-pin MDR Connector CL1
ＣＣ１（control input）
Cable
ＳｅｒＴＣ
ＳｅｒＴＦＧ
CK60MHz(8060SA)
Ｃhannel Ｌink Ｂus
ＬＶＡＬ，ＦＶＡＬ
ＤＶＡＬ，ＳＰ
ＰｏｒｔＡ～Ｃ
ＣＣ２
ＣＣ３
ＣＣ４
X1±
X0±
X2±
X3±
XClk±
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
SerTFG±
SerTC±
CC1±
CC2±
CC3±
CC4±
26-pin MDR Connector
X1±
X0±
X2±
X3±
XClk±
SerTFG±
SerTC±
CC1±
CC2±
CC3±
CC4±
LVDS_DRIVER(NS)
DS90CR285MTD
equivalent
LVDS_DRIVER/
RECEIVER(NS)
DS90LV019TM
equivalent
LVDS_RECEIVER(NS)
DS90LV048AT
equivalent
LVDS_RECEIVER(NS)
DS90CR286MTD
recommended
LVDS_DRIVER/
RECEIVER(NS)
DS90LV019TM
recommended
LVDS_DRIVER(NS)
DS90LV047AT
recommended
28 28
26-pin MDR Connector CL2
Cable
Ｃhannel Ｌink Ｂus
ＬＶＡＬ，ＦＶＡＬ
ＤＶＡＬ，ＳＰ
ＰｏｒｔＤ～Ｆ
Y1±
Y0±
Y2±
Y3±
YClk±
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
100Ω
terminated
100Ω
terminated
26-pin MDR Connector
Y1±
Y0±
Y2±
Y3±
YClk±
LVDS_DRIVER(NS)
DS90CR285MTD
equivalent
LVDS_RECEIVER(NS)
DS90CR286MTD
recommended
CK40MHz(8040SA_6040SA)
CK40MHz(8040SA_6040SA)
CK60MHz(8060SA)

NED
UME-0017-08 SUCL2025T3
19
Set the LVDS, Channel Link receiver side to 100-ohm termination.
With the driver side of LVDS, even if not used, do not make it open but set the logic to H
or L.
Figure 3-3-2 Circuit of LVDS
The camera has 26-pin MDR connectors for control signals of Camera Link, data
signals and serial communications. The camera also has a 4-pin HIROSE connector for
power supply.
Figure 3-3-3 Camera Link Connector
Half pitch (miniature half ribbon) shape
Locking screw (UNC #4-40) type
+
-
100Ω
+
-
Driver Receiver
H or L
1
14
2
15
3
16
11
24
12
25
13
26

NED
SUCL2025T3 UME-0017-08
20
Table 3-3-1 Camera Link Connector (26-pin MDR Connector) pin assignments
CL1 (Base Configuration) CL2 (Medium or Full Configuration)
Explanation of Signals
Inner Shield: Shield cable (GND)
X0+, X0-…X3+, X3-: Data output (Channel Link)
Xclk+,Xclk- : Clock output for above data output synchronization (Channel Link)
Y0+, Y0-…Y3+, Y3-: Data output (Channel Link)
Yclk+,Yclk- : Clock output for above data output synchronization (Channel Link)
SerTC+, SerTC- : Serial data input (LVDS)
SerTFG+, SerTFG- : Serial data output (LVDS)
CC1+,CC1- : External synchronous signal input (LVDS) *When using External Trigger
CC2+,CC2- : Not in use (LVDS) *When using External Trigger
CC3+,CC3- : Not in use (LVDS)
CC4+,CC4- : Not in use (LVDS)
Camera Link compatible cable
14B26 - SZLB - xxx - 0LC by 3M (or equivalent)
To avoid uncoupling of cable connectors during power on, make sure to clamp them with
locking screws.
Do not unplug the cable while power is being supplied to the camera.
No
NAME
No
NAME
I/O
1
Inner Shield
14
Inner Shield
2
X0-
15
X0+
Out
3
X1-
16
X1+
Out
4
X2-
17
X2+
Out
5
Xclk-
18
Xclk+
Out
6
X3-
19
X3+
Out
7
SerTC+
20
SerTC-
In
8
SerTFG-
21
SerTFG+
Out
9
CC1-
22
CC1+
In
10
CC2+ Not in use
23
CC2-Not in use
In
11
CC3- Not in use
24
CC3+ Not in use
In
12
CC4+ Not in use
25
CC4- Not in use
In
13
Inner Shield
26
Inner Shield
No
NAME
No
NAME
I/O
1
Inner Shield
14
Inner Shield
2
Y0-
15
Y0+
Out
3
Y1-
16
Y1+
Out
4
Y2-
17
Y2+
Out
5
Yclk-
18
Yclk+
Out
6
Y3-
19
Y3+
Out
7
N.C
20
N.C
8
N.C
21
N.C
9
N.C
22
N.C
10
N.C
23
N.C
11
N.C
24
N.C
12
N.C
25
N.C
13
Inner Shield
26
Inner Shield
