Neoway N77 User manual

EVK User Guide
Issue 1.0 Date 2021-01-23

N77 EVK User Guide
Copyright
Copyright © Neoway Technology Co., Ltd.
ii
Copyright © Neoway Technology Co., Ltd 2021. All rights reserved.
No part of thisdocument may bereproduced or transmitted in any form orby any means withoutprior written
consent of Neoway Technology Co., Ltd.
is the trademark of Neoway Technology Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
This document provides guide for users to use N77.
This document is intended for system engineers (SEs), development engineers, and test engineers.
THIS GUIDE PROVIDES INSTRUCTIONS FOR CUSTOMERS TO DESIGN THEIR APPLICATIONS.
PLEASE FOLLOW THE RULES AND PARAMETERS IN THIS GUIDE TO DESIGN AND COMMISSION.
NEOWAY WILL NOT TAKE ANY RESPONSIBILITY OF BODILY HURT OR ASSET LOSS CAUSED BY
IMPROPER OPERATIONS.
THE INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE DUE TO
PRODUCT VERSION UPDATE OR OTHER REASONS.
EVERY EFFORT HAS BEEN MADE IN PREPARATION OF THIS DOCUMENT TO ENSURE ACCURACY
OF THE CONTENTS, BUT ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS
DOCUMENT DO NOT CONSTITUTE A WARRANTY OF ANY KIND, EXPRESS OR IMPLIED.
Neoway provides customers complete technical support. If you have any question, please contact your
account manager or email to the following email addresses:
[email protected]
[email protected]
Website: http://www.neoway.com

N77 EVK User Guide
Table of Tables
Copyright © Neoway Technology Co., Ltd.
iii
Contents
1 Overview....................................................................................................6
2 EVB Functions...........................................................................................7
3 EVB Interfaces and Buttons ......................................................................9
3.1 Power Supply Interface................................................................................................................ 9
3.2 Communication Interfaces ........................................................................................................... 9
3.3 Antenna Interfaces ..................................................................................................................... 10
3.4 SIM Card Interfaces ....................................................................................................................11
3.5 Buttons ....................................................................................................................................... 12
3.6 Pin Headers................................................................................................................................ 12
4 Starting the Module .................................................................................14
5 Commissioning the Module .....................................................................17
5.1 Through USB-to-Serial Interface................................................................................................ 17
5.2 Through USB Interface .............................................................................................................. 18

N77 EVK User Guide
About This Document
Copyright © Neoway Technology Co., Ltd.
iv
About This Document
Scope
This document is applicable to the N77 series.
Audience
This document is intended for system engineers (SEs), development engineers, and test engineers.
Change History
Issue
Date
Change
Changed By
1.0
2020-11
Initial draft
Wu Xinxing
Conventions
Symbol
Indication
This warning symbol means danger. You are in a situation that could cause fatal
device damage or even bodily damage.
Means reader be careful. In this situation, you might perform an action that could
result in module or product damages.
Means note or tips for readers to use the module

N77 EVK User Guide
About This Document
Copyright © Neoway Technology Co., Ltd.
v
Related Documents
Neoway_N77-CA_Datasheet
Neoway_N77-CA_Product_Specifications
Neoway_N77-CA_AT_Commands_Mannual
Neoway_N77-CA_EVK_User_Guide

N77 EVK User Guide
Chapter 1 Overview
Copyright © Neoway Technology Co., Ltd.
6
1 Overview
N77 EVB is designed to commission the N77 module. It provides the power supply interface, USB-to-
Serial interface, USB interface, SIM card interface, antenna interface, startup (PWRKEY_N) button,
download (USB_BOOT) button, and other peripheral interfaces. You can connect it to a power supply
and a computer to commission the module.
N77 EVK provides the following accessories.
⚫N77 EVB (excluding the N77 module)
⚫N77 module
⚫Others (antenna or other accessories)

N77 EVK User Guide
Chapter 2 EVB Functions
Copyright © Neoway Technology Co., Ltd.
7
2 EVB Functions
Figure 2-1 N77 EVB

N77 EVK User Guide
Chapter 2 EVB Functions
Copyright © Neoway Technology Co., Ltd.
8
N77 EVB function description
No.
Function
Description
1
N77 module
Supports LTE-FDD, LTE-TDD, WCDMA, and GSM
communications.
2
Power supply interface
Power supply voltage for the module is 5V.
Note that the output current of the module should be at
least 3.0 A.
3
Power switch
Used to control the power supply for the EVB.
4
SIM1 card slot
5
SIM2 card slot
6
USB interface
Used to transmit AT commands and download firmware.
7
USB-to-UART2 interface
Used for AT transmission.
8
USB-to-UART1 interface
Used to capture log messages from the module.
9
MAIN_ANT
Main antenna interface of the module.
The operating frequency bands the antenna supports
should cover the bands that N77 supports.
10
DIV_ANT
Diversity antenna interface of the module.
The operating frequency bands the antenna supports
should cover the bands that N77 supports.
11
RESET button
Used to start the module.
12
PWRKEY_N button
Used to start the module.
13
USB_BOOT button
Used to download firmware
14
SLEEP pin header
Used to enable the module to enter sleep mode.
15
UART2 flow control pin header
Reserved
16
PWRKEY_P pin header
Used to start the module.
17
ADC1 pin header
Reserved

N77 EVK User Guide
Chapter 3 EVB Interfaces and Buttons
Copyright © Neoway Technology Co., Ltd.
9
3 EVB Interfaces and Buttons
N77 EVB can only be powered by the external power supply. It uses the Micro-USB cable to perform
data communications. The following provides the power supply methods and communication methods
of the EVB.
3.1 Power Supply Interface
The N77 EVB can be supplied power in two methods:
⚫Connect the power supply interface to an external power source through a 5V power supply
adapter.
⚫Connect the solder pads to a 5V regulated power source through wires.
Note that the output current of the module should be at least 3.0 A.
Figure 3-1 Power Supply Interface
The power source supplies voltage to the module directly through solder pads. Use a black alligator clip to clamp
the GND solder pad and a red alligator clip to clamp the DC 5V solder pad as shown in the figure above.
Do NOT connect the pads reversely. Otherwise, the module will be burned and cannot be repaired.
3.2 Communication Interfaces
All communication interfaces of N77 EVB use the Micro-USB cable to transmit AT commands.

N77 EVK User Guide
Chapter 3 EVB Interfaces and Buttons
Copyright © Neoway Technology Co., Ltd.
10
Figure 3-2 Micro-USB cable
Communication methods of N77 EVB
⚫Connect the USB interface to your computer; it is used for firmware download and AT
communications.
⚫Connect the USB-to-UART2 interface to your computer; it is used for only AT communications.
⚫Connect the USB-to-UART1 interface to your computer; it is used to capture log messages from
the module.
Figure 3-3 N77 USB interfaces
3.3 Antenna Interfaces
N77 EVB provides a main antenna interface (right) and a diversity antenna interface (left).
Note that the operating frequency bands the antenna supports should cover the bands that N77
supports.

N77 EVK User Guide
Chapter 3 EVB Interfaces and Buttons
Copyright © Neoway Technology Co., Ltd.
11
Figure 3-4 Antenna interfaces
3.4 SIM Card Interfaces
N77 EVB provides two kinds of SIM card connectors that can be automatically adapted to the 1.8V/3.0V
SIM card.
SIM1 card connector is a flip-open type card slot.
Figure 3-5 SIM2 card slot
SIM2 card connector is a push-push type card slot that supports hot-swapping.
Figure 3-6 SIM2 card slot

N77 EVK User Guide
Chapter 3 EVB Interfaces and Buttons
Copyright © Neoway Technology Co., Ltd.
12
3.5 Buttons
N77 EVB provides 3 buttons: RESET, PWRKEY_N, and USB_BOOT, As shown in the figure below.
Buttons
Function
How to use
RESET
Start button
Press the button after the N77 EVB is powered.
PWRKEY_N
Start button
Press the button after the N77 EVB is powered.
USB_BOOT
Firmware
download
Press the button and do not release it and then turn the
power switch to the ON side; the module will enter download
mode. Short connect the first and second pins from the right
of the pin header before using this button.
3.6 Pin Headers
N77 EVB provides 5 pin header positions for PWRKEY_P, SLEEP, BOOT, UART2 flow control, and
ADC1.
Pin Header
How to use
Figure
PWRKEY_P
Short connect the pin header and the module will start
automatically after the EVB is powered.
SLEEP
Configure the functions of sleep mode for the module
through the AT+ENPWRSAVE=<n> command.
⚫T+ENPWRSAVE=<0>
Disable the module to enter sleep mode.
⚫AT+ENPWRSAVE=<1>

N77 EVK User Guide
Chapter 3 EVB Interfaces and Buttons
Copyright © Neoway Technology Co., Ltd.
13
Set the SLEEP pin to active low; short connect the
2 and 3 pins to trigger sleep mode.
⚫AT+ENPWRSAVE=<2>
Set the SLEEP pin to active high; short connect the
1 and 2 pins to trigger the sleep mode.
BOOT
Short connect the 1 and 2 pins before using the
USB_BOOT button.
UART2 flow
control
This pin header is used for RTS and CTS functions; it is
reserved for UART2. Leave this pin floating.
ADC1
This pin header is used for voltage acquisition (0.1 V to
1.3 V). Leave this pin floating.
Only 1.08 V voltage acquisition pins (1 and 2) and 1.2 V
voltage acquisition pins (2 and 3) are reserved.

N77 EVK User Guide
Chapter 4 Starting the Module
Copyright © Neoway Technology Co., Ltd.
14
4 Starting the Module
Follow the steps below to start the module.
Step 1: Insert a SIM card into the module.
Step 2: Supply power to the N77 EVB; see Chapter 3.1 .
Step 3: Turn the power switch to the On side to supply power to the module.
The POWER indicator (red) turns on after the EVB is powered.
Step 4: Press the PWRKEY_N or RESET button for over 1 second to start the module.
During the startup process, the POWER (red), STATUS (green), and RING (green) indicators are on.

N77 EVK User Guide
Chapter 4 Starting the Module
Copyright © Neoway Technology Co., Ltd.
15
The POWER (red), and RING (green) indicators light on after the module starts.

N77 EVK User Guide
Chapter 4 Starting the Module
Copyright © Neoway Technology Co., Ltd.
16
The LIGHT (green) indicator lights on after the SIM card of the module registers to the network.

N77 EVK User Guide
Chapter 5 Commissioning the Module
Copyright © Neoway Technology Co., Ltd.
17
5 Commissioning the Module
5.1 Through USB-to-Serial Interface
Step 1: Install the serial port drivers.
1. Decompress the driver package.
2. Double-click PL2303G_130_20190311 and follow the wizard to install the drivers.
Step 2: Ensure whether the drivers are installed properly and correctly.
Connect the N77 EVB through the USB-to-UART2 interface to your computer with a USB cable.
⚫If the Device Manager interface displays “Profile PL2303GC USB Serial COM Port”, the serial
port can be read properly.
⚫If the serial port drivers are not installed properly, the Device Manager interface displays the
yellow exclamation mark.
Contact Neoway FAE if you cannot install the serial port drivers properly according to the steps mentioned
above.
Step 3: Start the Neo_ComTool tool to commission N77. You can also use another serial port tool.
1. Configure the tool.
⚫Select the port number corresponds to Profile PL2303GC USB Serial COM Port in the
ComNum box .

N77 EVK User Guide
Chapter 5 Commissioning the Module
Copyright © Neoway Technology Co., Ltd.
18
⚫For other settings, configure them according to the figure below.
2. After all settings are completed, right-click Open COM.
3. Send any AT command to the module through the serial port tool, such as "AT" for baud rate
adaptive operation.
When the serial port displays OK, the serial port functions.
4. Commission the module through the serial-port tool.
5.2 Through USB Interface
Step 1: (Optional) disable driver signature enforcement of your computer.
On Windows 8 or Windows 10, you need to disable driver signature enforcement before installing the
USB drivers. If your computer runs a Win7 OS, skip this step.
Step 2: Install the USB drivers.
1. Decompress the USB driver package.
The USB driver for the N77 module may be different depending on the software version.
2. Double-click DPInst and follow the wizard to install the drivers.

N77 EVK User Guide
Chapter 5 Commissioning the Module
Copyright © Neoway Technology Co., Ltd.
19
Right-click Install this driver software anyway as shown in the figure below during the installation
process.
Step 3: Ensure whether the USB drivers are installed properly.
Connect the N77 EVB through the USB interface to your computer with a USB cable.
⚫If the USB drivers are installed properly, the Device Manager interface displays “Neoway AT
Port”.

N77 EVK User Guide
Chapter 5 Commissioning the Module
Copyright © Neoway Technology Co., Ltd.
20
⚫If the USB drivers are not installed properly, the Device Manager interface displays the yellow
exclamation mark as shown in the figure below.
Step 4: Start the Neo_ComTool tool to commission N77 (You can also use another serial port tool).
1. Configure the tool.
⚫Select the port number corresponds to Neoway AT Port in the ComNum box.
⚫For other settings, configure them according to the figure below.
