Networker TS790 Assembly instructions

TS790 & TS900
10 - 56 Zone Intruder Alarm
Control Panels
Installation & Programming
Manual
123
456
789
ENT 0ESC
A B C
OMIT AREA
POWER BUSY
123
456
789
ENT 0ESC
A B C
OMIT AREA
Engineers menu 1
Select Option :-
123
456
789
ENT 0ESC
A B C
OMIT AREA
POWER BUSY
123
456
789
ENT 0ESC
A B C
OMIT AREA
POWER FUNCTION

Contents
Overview
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 1
System Architecture . . . . . . . . . . . . . . . . . . . 1
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . 1
Remote Keypads . . . . . . . . . . . . . . . . . . . . . 2
32 Character LCD (TS900.REM). . . . . . . . . 2
8 Character Starburst (TS790.STAR) . . . . . . 2
4 Character LED (TS700.REM) . . . . . . . . . . 2
Remote Arming Station (TS700.ARM) . . . . 2
TS900 NODE . . . . . . . . . . . . . . . . . . . . . . . . . 2
ID Node (TS900.IDNODE). . . . . . . . . . . . . . . . 2
TS700 LEC . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Specifications. . . . . . . . . . . . . . . . . . . . . . . . 2
General. . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Electrical. . . . . . . . . . . . . . . . . . . . . . . . . . 2
Physical. . . . . . . . . . . . . . . . . . . . . . . . . . . 2
System Installation
Cable Routing . . . . . . . . . . . . . . . . . . . . . . . 3
Node Network Wiring (TS900 Only) . . . . . . . . 3
Remote Network Wiring . . . . . . . . . . . . . . . . 4
Combined Network Wiring (TS900) . . . . . . . . 4
Control Panel Installation . . . . . . . . . . . . . . . 5
Control Panel PCB Layout. . . . . . . . . . . . . . . 6
Connection Terminals & Indicators . . . . . . . 7
Mains Connection . . . . . . . . . . . . . . . . . . . . 8
Battery Connection . . . . . . . . . . . . . . . . . . . 8
Remote Keypads . . . . . . . . . . . . . . . . . . . . . 8
TS900 LCD Remote Keypad . . . . . . . . . . . 8
TS790 Star Remote Keypad . . . . . . . . . . . 8
TS700 LED Remote Keypad . . . . . . . . . . . 9
TS700 Remote Arming Station . . . . . . . . . 9
Installation Procedure. . . . . . . . . . . . . . . . 9
Engineer’s Keypad . . . . . . . . . . . . . . . . . . . . 10
TS900 Node Installation (TS900 Only) . . . . . . 10
TS900 Node Layout. . . . . . . . . . . . . . . . . . . . 11
TS700 Lec Installation . . . . . . . . . . . . . . . . . . 12
Wiring Detection Circuits . . . . . . . . . . . . . . . 12
Double Pole . . . . . . . . . . . . . . . . . . . . . . . 12
End Of Line . . . . . . . . . . . . . . . . . . . . . . . . 13
External Sounder Connections . . . . . . . . . . . 13
Installing an External Sounder from a Node14
Auxiliary Tamper. . . . . . . . . . . . . . . . . . . . . . 14
Extension Loudspeakers. . . . . . . . . . . . . . . . 14
Digicom/RedCARE Installation. . . . . . . . . . . 15
Plug-on Digicom Installation . . . . . . . . . . . . 15
Plug-on digi-Modem Installation . . . . . . . . . 15
Output Modules Installation (CPA6.OM) . . . 16
Connecting a Printer . . . . . . . . . . . . . . . . . . 16
Using the CPA6 Printer . . . . . . . . . . . . . . . 16
Using the DATAC / RS232 Printer. . . . . . . . 16
Programmable Outputs. . . . . . . . . . . . . . . . 17
Control Panel Outputs . . . . . . . . . . . . . . . 17
Node Outputs . . . . . . . . . . . . . . . . . . . . . 17
Remote Keypads & TS700.LECs. . . . . . . . 17
Installing a Monitored Power Supply . . . . . . 18
Pre Power-Up Checks . . . . . . . . . . . . . . . . . 18
Initial Power-Up . . . . . . . . . . . . . . . . . . . . . . 18
Power-Up Checks . . . . . . . . . . . . . . . . . . . . 19
NVM Defaults. . . . . . . . . . . . . . . . . . . . . . . . 19
Engineer’s Menu 1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 21
Menu contents . . . . . . . . . . . . . . . . . . . . 21
Panel Outputs . . . . . . . . . . . . . . . . . . . . . . . 22
Digicom Outputs . . . . . . . . . . . . . . . . . . . . . 22
Digicom Channels . . . . . . . . . . . . . . . . . . . 22
Programmable Output Types . . . . . . . . . . . 22
Program Circuits . . . . . . . . . . . . . . . . . . . . . 25
Circuit Types. . . . . . . . . . . . . . . . . . . . . . . 25
Circuit Attributes. . . . . . . . . . . . . . . . . . . . 26
System Timers . . . . . . . . . . . . . . . . . . . . . . . 27
Setting Modes . . . . . . . . . . . . . . . . . . . . . . . 30
Do System Print . . . . . . . . . . . . . . . . . . . . . . 30
Remote Reset Algorithm . . . . . . . . . . . . . . . 31
Configuration. . . . . . . . . . . . . . . . . . . . . . . . 31
Goto User Menu 1 . . . . . . . . . . . . . . . . . . . . 33
Menu contents . . . . . . . . . . . . . . . . . . . . 33
View Location Text (LCD Only) . . . . . . . . . . . 34
Engineer's Menu 2
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 35
Menu Contents . . . . . . . . . . . . . . . . . . . . 35
View Circuits. . . . . . . . . . . . . . . . . . . . . . . . . 36
Set System Time. . . . . . . . . . . . . . . . . . . . . . 36

Set System Date. . . . . . . . . . . . . . . . . . . . . . 36
Change Passcode . . . . . . . . . . . . . . . . . . . 36
Chime Circuits. . . . . . . . . . . . . . . . . . . . . . . 37
Alter 24Hr Group . . . . . . . . . . . . . . . . . . . . . 37
Print System Log. . . . . . . . . . . . . . . . . . . . . . 37
Configure Wards . . . . . . . . . . . . . . . . . . . . . 37
Log Event Codes. . . . . . . . . . . . . . . . . . . . . 38
View System Log . . . . . . . . . . . . . . . . . . . . . 38
Log Event Codes. . . . . . . . . . . . . . . . . . . . . 39
Log Event Codes. . . . . . . . . . . . . . . . . . . . . 40
Reset User Code 1. . . . . . . . . . . . . . . . . . . . 40
Start Call Back . . . . . . . . . . . . . . . . . . . . . . . 40
Engineers Menu 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 41
Menu Contents . . . . . . . . . . . . . . . . . . . . 41
Time Switches . . . . . . . . . . . . . . . . . . . . . . . 42
Part Set Groups . . . . . . . . . . . . . . . . . . . . . . 43
Part Set Group Operation . . . . . . . . . . . . 43
Code Set Groups. . . . . . . . . . . . . . . . . . . . . 43
Code Set Group Operation. . . . . . . . . . . 43
Engineers Name (LCD Only) . . . . . . . . . . . . 44
Part Set Text (LCD Only) . . . . . . . . . . . . . . . . 44
Circuit Text (LCD Only) . . . . . . . . . . . . . . . . . 44
Custom Text Menu (LCD Only). . . . . . . . . . . 44
Reset Message . . . . . . . . . . . . . . . . . . . . 44
Banner Message . . . . . . . . . . . . . . . . . . . 44
Location Text . . . . . . . . . . . . . . . . . . . . . . 45
Printer Header . . . . . . . . . . . . . . . . . . . . . 45
Part Set Banner. . . . . . . . . . . . . . . . . . . . . 45
Node Outputs . . . . . . . . . . . . . . . . . . . . . . . 45
Built In Tests . . . . . . . . . . . . . . . . . . . . . . . . . 45
Current Consumption . . . . . . . . . . . . . . . 45
Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . 46
View Circuit Resistance (LCD Only) . . . . . 46
Test Digi Outputs . . . . . . . . . . . . . . . . . . . 46
View Inactive Circuits. . . . . . . . . . . . . . . . . . 46
Custom Outputs A & B. . . . . . . . . . . . . . . . . 47
Custom Output - Example 1 . . . . . . . . . . 47
Custom Output - Example 2 . . . . . . . . . . 47
Custom Output - Example 3 . . . . . . . . . . 47
Modem Options (LCD Only). . . . . . . . . . . . . 48
Call Back No.1. . . . . . . . . . . . . . . . . . . . . 48
Call Back No.2. . . . . . . . . . . . . . . . . . . . . 48
Call Back No.3. . . . . . . . . . . . . . . . . . . . . 48
Modem Password . . . . . . . . . . . . . . . . . . 48
Modem Site No.. . . . . . . . . . . . . . . . . . . . 48
Program Digicom . . . . . . . . . . . . . . . . . . 48
Reset Digicom . . . . . . . . . . . . . . . . . . . . . 50
Appendices
Point ID Extended Reporting . . . . . . . . . . . . . 51
Resetting the Engineers passcode . . . . . . . . 51
Domestic Part-Set Application Example. . . . 53
Defining Part-Set buttons to Omit a Ward . 53
Defining Part-Set buttons to Arm a Ward(s) 54
Commercial Part-Set Application. . . . . . . . . 56
Key Point Application Example. . . . . . . . . . . 56
Time Switch Application Example. . . . . . . . . 57
Alarm Abort & Confirmation . . . . . . . . . . . . . 57
Alarm Abort Operation . . . . . . . . . . . . . . . 57
Sequential Confirmation Operation . . . . . 57
Text Editing Keys . . . . . . . . . . . . . . . . . . . . . . 58
Cursor Types . . . . . . . . . . . . . . . . . . . . . . . 58
Common Key Sequences . . . . . . . . . . . . 58
Setup New Users . . . . . . . . . . . . . . . . . . . . . . 59
User Types . . . . . . . . . . . . . . . . . . . . . . . . . 59
Notes ..............................61
Engineers Menus. . . . . . . . . . . . . . . . . . . . . . 62
User Menus . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Overview
Introduction
The TS790 and TS900 alarm control systems have
been designed to suit medium to large installation
sites. The TS900 system can be expanded from 10
to 56 zones, whereas the TS790 is expandable
from10to16 zones.Bothsystemsfeature “up”and
“down” line loading, allowing the system to be
remotely programmed or interrogated via the
telephone line and a P.C.
Complex site requirements such as multi-ward
setting can be achieved, as both systems are
capable of being broken down into 4 separately
controlled areas (Wards) so that the premises or
parts of the premises can be controlled
independently.
System Architecture
Control Panel
The control panel is the controlling unit for the
system, it has a power supply and connections for
a standby battery. It has the following facilities:
l 8 programmable detection circuits
l Bell and strobe outputs
l 4 programmable outputs (1 x Voltage free
contacts and 3 high current transistorised)
l 8 programmable digicom/RedCARE outputs
l A connector for a Menvier plug-on digicom or
digi-Modem
l Extension loudspeaker output
l All system program information and the 700
event log is stored in a removable non-volatile
memory (NVM)
TS900
NODE
2 Outputs
8 Zones
TS900
NODE
2 Outputs
8 Zones
TS900
NODE
2 Outputs
8 Zones
TS900
NODE
2 Outputs
8 Zones
TS900
NODE
2 Outputs
8 Zones
CONTROL
PANEL
TS900 NODE
NETWORK
TS900 ID NODE TS900
NODE
2 Outputs
8 Zones
30 ID Zones
8 Outputs
(Two Options)
REMOTE
KEYPAD
or LEC
1 Outputs
2 Zones
REMOTE
KEYPAD
or LEC
1 Outputs
2 Zones
REMOTE
KEYPAD
or LEC
1 Outputs
2 Zones
REMOTE
KEYPAD
or LEC
1 Outputs
2 Zones
REMOTE
NETWORK
(8 Zones)
Printer
Speaker
CPA6.OM
AUX 12V
Plug-on
Digicom/Modem
Bell output
Strobe output
Digi outputs 1 - 8
Outputs 1 - 4
Figure 1. TS790 & TS900 System Architecture
TS790 & TS900 Installation Manual Overview
1

Remote Keypads
Up to 4 remote keypads can be connected to the
control panel. Each remote keypad has two
detection circuits and a single switched -ve
output. There are four types of remote keypads
that can be used:
32 Character LCD (TS900.REM)
The TS900 remote keypad has a backlit 32
character super-twist Liquid Crystal Display (LCD)
and a backlit tactile rubber keypad. When using
the LCD Keypads the text for user codes, part
setting modes and circuit identification can be
programmed to make the operation and
programming of the system easier.
8 Character Starburst (TS790.STAR)
The TS790 remote keypad has a backlit 8
character starburst display (LCD) and a backlit
tactile rubber keypad.
4 Character LED (TS700.REM)
The TS700 remote keypad has a 4 character LED
display and backlit tactile rubber keypad. When
using the LED remote keypads, text can not be
programmed but all other system functions are
available.
Remote Arming Station (TS700.ARM)
The Remote Arming Station only allows setting and
unsetting of the system. The unit has two indicator
LEDs, the “Power LED” and a programmable
“Function LED” (the “Function LED” may be
programmed as “Fault” or “Area Set” etc.).
TS900 NODE
The TS900 Node provides eight programmable
detection circuits and two programmable outputs
(Can only be used on the TS900).
ID Node (TS900.IDNODE)
The TS900 ID NODE can be used as an alternative
to the standard TS900 Node. It provides a single ID
DetectorLoopforconnectionto30IDdevicesand
8 programmable outputs. Several configuration
options allowittobeusedonitsownor withexisting
TS900 Nodes. (Can only be used on the TS900.)
TS700 LEC
The Local Expansion Card (LEC) provides two
programmable detection circuits and one
programmable output.
Specifications
General
Zones TS790 - 10 to 16
TS900 - 10 to 56
Expansion 2 zone LECs and/or Keypads
8 zone Nodes (TS900 only)
30 zone ID Nodes (TS900 only)
Outputs (Panel) 12 + 8 via plug-on digicom
Keypad types 32 Character LCD
8 Character Starburst LCD
4 Character 7-segment LED
LED Arming station
Electrical
Mains Input 230 ±10% 50Hz ±5%
Control Panel 220mA (normal)
300mA (alarm)
Battery 12V 7Ah Sealed Lead Acid
Power Supply TS790 - 1.0A
TS900 - 1.5A
LCD keypad 40mA (normal) 50mA (alarm)
Starburst keypad 50mA (normal) 60mA (alarm)
LED keypad 60mA (normal) 70mA (alarm)
Arming Station 30mA (normal) 40mA (alarm)
TS900 Node 60mA (normal) 60mA (alarm)
ID Node 80mA (with 1 device)
160mA (with 30 devices)
TS700 LEC 30mA (normal) 30mA (alarm)
Physical
Control panel 335(W) x 265(H) x 85(D)mm
4.7Kg
Remote Keypads 130(W) x 130(H) x 30(D) mm
280g
Nodes (all types) 128(W) x 182(H) x 34(D) mm
370g
TS700 LEC 142(W) x 82(H) x 36(D) mm
213g
Environment -10 to 55°C
Overview TS790 & TS900 Installation Manual
2

System Installation
Cable Routing
When installing cables, the following should be
noted:
+Screened cable may prove necessary if the
Network is run adjacent to cables that
produce R.F. or are switching high current
loads, e.g., mains, telephone, computer.
+EnsurethatallNetworkanddetectioncircuit
cables are kept clear of mains supply
cables, telephone cables, R.F. cables and
cables supplying bells or sounders.
+Mains power supply cables to the system
must be connected to an un-switched
fused spur that cannot be accidentally
switched off, and must enter the housing via
its own cable entry point.
+In larger installations it may prove necessary
to fit remote power supplies to overcome
excessive voltage drops in the cable runs. It
is recommended that the Menvier 519XB is
used in these instances as it can be fault
monitored by the control panel.
Node Network Wiring (TS900 Only)
Nodes require a 4 core cable for interconnection,
and may be connected in a “daisy-chain” or “star”
configuration. The distance between each Node
must not exceed 100 metres. Power for detectors
is provided by the Aux +/- terminals. On
installations that utilise the Node outputs to drive
sounders and strobes it may be necessary to fit a
remote power supply (Figure 2) to prevent over
loading of the control panel power supply.
Control Panel Node
Node
Node
Network
Node Node
IN OUT
AUX
IN OUT
AUX
AUX
AUX
12V
-
+
IN OUT
AUX
IN OUT
AUX
Node
100m
I/D=1 I/D=2
Power For
Detectors Power For Detectors Power For Detectors
Power For
Detectors
Remote PSU
(519 XB)
Power For
Detectors
I/D=3
I/D=5
I/D=4
A
B
F
G
A
B
F
G
A
B
F
G
A
B
F
G
A
B
F
G
A
B
F
G
A
B
F
G
A
B
F
G
A
B
F
G
A
B
F
G
A
B
F
G
100m 100m 100m
Figure 2. TS900 Node Network Wiring
TS790 & TS900 Installation Manual System Installation
3

Remote Network Wiring
Devices on the “Remote Network” require a 6 core
cable for interconnection, and may be
connected in a “star” or “daisy-chain”
configuration. The distance to the furthest device
from the control panel must not exceed 100
metres. Power for detectors are provided by the A
and B terminals (Figure 3).
Combined Network Wiring (TS900)
On some installations it may be desirable to have
a remote keypad connected after the Nodes. This
can be achieved by using an eight core cable
from the control panel and connector strips within
the Node and remote keypads (Figure 4).
Remote
Network
Spare Core
Control Panel
Power For
Detectors Power For Detectors Power For
Detectors Power For
Detectors
I/D=2I/D=1 I/D=3 I/D=4
Remote
Keypad
or LEC
A B C D E
Remote
Keypad
or LEC
A B C D E
Remote
Keypad
or LEC
A B C D E
Remote
Keypad
or LEC
A B C D E
A
B
C
D
E
100 Meters (Max.)
Figure 3. TS790 & TS900 Remote Network Wiring
Remote
Keypad
or LEC
Node
Network
Remote
Network
Control Panel
Power For
Detectors Power For Detectors
Power For
Detectors
C
D
E
IN OUT
AUX 12V
Node
I/D=2
A
B
F
G
A
B
F
G
IN OUT
AUX 12V
Node
A B C D E
I/D=1
A
B
F
G
A
B
F
G
A
B
F
GIN OUT
AUX 12V
Node
I/D=3
A
B
F
G
A
B
F
G
100 Meters (Max.)
100m
Connector Strips
Figure 4. TS900 Combined Network Wiring
System Installation TS790 & TS900 Installation Manual
4

Control Panel Installation
Proceed as follows:
1. Open the control panel by removing two
screws from the front cover. Remove the cover
by sliding it up slightly todisengage the bottom
clip, disconnect the earth bonding cable from
the spade connection on the front cover, then
lift clear.
2. Notethepositionofthecableentriesasfollows:
(a) Plastic cable entries and 20mm knock-outs
top and bottom for trunking.
(b) Eight 20mm cable entries for detection,
alarm and remote keypad cables.
(c) A 20mm cable entry for mains (240V)
above the mains input terminal block on
the right hand side of the control panel
back box.
+The mains cable must enter the control
panel through its own cable entry and
must not be mixed with other cables.
3. Holdthecontrolpanelback boxintherequired
position (keyhole to the top) and mark the
centre of the keyhole position. Remove the
back box, drill and plug the hole.
4. Screw a No 10 screw into the plugged hole.
Re-position the back box and mark the
remaining four securing holes. Remove the
back box, drill and plug the holes.
5. Re-position the back box and pass all cables
into the base via the trunking holes or
knockouts, grommeting as appropriate.
6. Secure the back box using not less than 30mm
x No 10 screws through the four dished 5mm
holes.
7. If required install and connect the following:
(a) Stand alone digicom or RedCARE STU.
(b) Plug-on digicom type DC54, DC58 or
DC58M.
(c) Output modules type CPA6.OM.
(d) Printer type DATAC or serial RS232 via a
printer adapter (MPA).
(e) Relay module type RM.3A.
+When replacing the cover, always
ensure that the earth bonding lead is
connected to the spade connection
on the front cover.
Key-hole mounting Lid tamper Mains cable entry
Mains fused
terminal block
Mains
transformer
Printed Circuit Board (PCB)Earth bonding lead
(connected to front cover)
Space for a 7 Ah
lead acid battery
20mm cable
entries
Figure 5. TS790 & TS900 Control Panel Layout
TS790 & TS900 Installation Manual System Installation
5

Control Panel PCB Layout
OUTPUT MODULE PRINTER
1 AMP
NODE SUPPLY
REMOTE
KEYPAD
JP3
DIGI-MODEM
FACTORY
RESET
Node Network
connection terminals
(TS900 Only)
Auxiliary 12V
Auxiliary 12V
Remote
keypad
Network
connections
Programmable
Detection
Circuits 1 - 8
Digicom Outputs
Programmable @ 100mA
12V Digicom Power
Line Fault Input (12V = Fault)
Auxiliary Tamper
Extension loudspeaker
External sounder
connections
21V A.C. from mains
transformer
Earth connection
Panel Outputs
O/P 1 = Change over contacts
O/P 2 = Switched -ve @ 500mA
O/P 3 = Switched +ve @ 500mA
O/P 4 = Switched +ve @ 500mA
Z1 Z2 Z3 Z4 Z5 Z6 Z7 Z8
T1 T2 T3 T4 T5 T6 T7 T8
CIRCUIT 1 CIRCUIT 2 CIRCUIT 3 CIRCUIT 4 CIRCUIT 5 CIRCUIT 6 CIRCUIT 7 CIRCUIT 8
RR
JP5
JP6
SPEAKER
VOLUME
NOVRAMS
AUX 12V
BELL 12V
1 AMP
BATTERY FAULT
POWER
ON
EARTH
TRG
-STB
-TR- H/O
-H/O
+SPK
+AUX
TAMP LINE
FLT +DC
1 2 3 4
DIGITAL COMMUNICATOR
5 6 7 8 AUX
A
REMOTE NETWORK
B C D E
+4 +3 -2 A
NODE NETWORK
OUTPUT 1
-- OUTPUTS --
BGF
N/O N/CCOM
0V 12V
0V 12V
POWER
A. C.
V
1 AMP
FS3
FS4
JP1JP4
JP2
ENGINEERS REMOTE
U2 U3
Figure 6. TS790 & TS900 Main PCB
System Installation TS790 & TS900 Installation Manual
6

Connection Terminals & Indicators
The main PCB has the following “Jumper Plugs” (JP)
and indicator LEDS:
JP1 PRINTER
This 6-pin plug is used for connecting to
either a CPA6.P printer or a standard RS232
printer via the MPA printer adaptor.
JP2 ENGINEERS REMOTE
An Engineers remote keypad may be
temporally connected to this 6-pin plug to
allow programming and testing to be
carried out at the control panel.
JP4 DIGI-MODEM
A plug-on digicom or digi-Modem may be
connected to this 7-pin plug to allow panel
alarm information to be transferred to a
central station. The digi-Modem is used for
remote communication and programming
via a P.C. The PCI lead also connects to this
plug when using the P.C. for direct
communication with the control panel.
JP4 OUTPUT MODULE
Output Modules type CPA6.OM may be
connected to this 5-pin plug, and are used
to provide switched -ve outputs to
LEDs/relays etc. The outputs may be
programmed such that they will mimic
circuit activations or activate only when a
circuit causes an alarm condition.
JP5 RR
If the panel is programmed as “Engineer
Reset”, shorting the “Remote Reset” (RR) pins
afteranalarm conditionwillcausethepanel
to reset. These pins could be connected to
the “Control” output on a RedCARE STU so
that the central station may provide a
“Remote Reset” facility.
JP6 FACTORY RESET)
If these pins are shorted during power-up all
system parameters are reset to their factory
default settings. If the engineer’s passcode
is lost or forgotten it can be reset to 1234
without loosing any other program data. The
procedure for resetting the engineer’s
passcode is described on page 51.
VR1 SPEAKER VOLUME
When an extension loudspeaker is
connected to the control panel terminals
the volume of the advisory tones may be
adjusted using this control.
+Alarm tones are always at full volume.
U2/3 NOVRAMS
A removable non-volatile memory (NVM)
device that stores all system program
parameters and the 700 log events. The
event log can be expanded to 1800 events
when the second NVM(U2) is fitted. Order
code PP5.MEMKIT (5 x NVMs).
LED1 POWER ON
This LED indicates that the system power
(mains or battery) is healthy.
LED2 BATTERY FAULT
Ifthesystembatteryisincorrectlyconnected
to the control panel or the battery voltage
level is below 4 Volts then the “Battery Fault”
LED will illuminate. The fault LED will only
extinguish when the battery has been
correctly connected or replaced.
V SYSTEM CURRENT CONSUMPTION
The system current consumption may be
calculated bymeasuringtheVoltage across
this test point on the main PCB. Using a
Voltmeter set to a low Voltage range
measure the Voltage across the test point
and multiply the reading by 10 to give the
Total system current consumption i.e., a
reading of 70mV = 700mA.
TS790 & TS900 Installation Manual System Installation
7

Mains Connection
The mains supply is connected to a 3 way "Euro
Type" fused terminal block, which is fitted with a
315mA fuse. All electrical connections should be
carried out by a qualified electrician and must
comply with the current IEE regulations.
+To comply with european regulations the
supply should be fed from a readily
accessible disconnect device, e.g.
un-switched fused spur fitted.
+When making mains connections it should
be ensured that if the cable slips in such a
way as to place a strain on the conductors,
the protective earthing conductor will be
the last to take the strain.
Battery Connection
A 7Ah battery must be fitted to the system to allow
it to function during a mains fail condition. The
TS790/TS900 isequipped witha“Battery Protection”
circuit so that if a battery is accidentally reverse
connected or its voltage is below 4V, the “Battery
Fault” LED illuminates. To clear the fault simply
reconnect or replace the battery as appropriate.
Remote Keypads
Four types of remote keypads can be used on the
system, however, only the TS900 remote keypad
can be used for programming text information.
Any combination of remote keypad may be used
on the same system if desired.
TS900 LCD Remote Keypad
The TS900 remote keypad has a 32 character
back-lit Liquid Crystal Display (LCD).
TS790 Star Remote Keypad
The TS790 remote keypad has a 8 character
back-lit starburst Liquid Crystal Display (LCD).
L
E
N
To transformer
FUSE 315mA
Figure 7 Mains Supply Connections
2 Detection
circuits
Programmable output
switched -ve
@100mA
I/D
Selector
Tamper
Switch A B
REMOTE
I/D
1
23
4
ENG
C D E
O/P-
CIRCUIT B CIRCUIT A
ZB ZA
TB TA
Remote network
connections
LCD Module
DISABLED WARD SOUNDER
CONTROL
Figure 8 TS900 Remote Keypad Layout
Programmable output
switched -ve
@ 100mA
Remote network
connections
= Disabled
2 Detection
circuits
'ENT'
Key Disable
WARD SOUNDER
CONTROL
DISABLE
I/D
Selector
Tamper
Switch A B
REMOTE
I/D
1
23
4
ENG
C D E
O/P-
CIRCUIT B CIRCUIT A
ZB ZA
TB TA
LCD Module
Figure 9 TS790 Star Remote Keypad Layout
System Installation TS790 & TS900 Installation Manual
8

TS700 LED Remote Keypad
The TS700 remote keypad has a 4 character LED
display.
TS700 Remote Arming Station
The TS700 remote arming station only has two
indicator LED's, a power LED and aprogrammable
function LED which follows the programmable
output.
Installation Procedure.
+Always ensure that all power (mains
and battery) is removed before
making any connections to the
remote keypad.
1. Separate the cover and base by using a
screwdriver to push 2 of the clips (top or
bottom) inward from the base indents, then lift
thecoverassembly,notingthat thePCB isfixed
to the under side of the cover.
2. Hold the base in position (keyhole to the top)
and mark the three securing holes, drill and
plug the wall as required. Pass all the cables
into the base via the cable entry points as
appropriate and secure the base to the wall.
3. Connect “Remote Network” and detection
circuit cables to the appropriate terminals, see
Figure 8.
4. Set the I/D selector jumper link to the required
position:
I/D Selector Circuit A Circuit B Panel
Output
1 09 10 5
2 11 12 6
3 13 14 7
4 15 16 8
ENG/NULL N/A N/A N/A
l No two remote keypads or LECs should
have the same I/D.
l If the I/D is set to “ENG” the remote keypad
will function as an Engineer’s keypad
allowing it to be plugged onto the control
panel so that system programming and
testing may be carried out (see Engineer’s
Keypad).
5. If the remote keypad has a "ENT" key
enabled/disable link it can be used to limit the
functionality of the remote keypad. If the "ENT"
key is enabled the remote keypad can be
used to set/unset and access all user menus.
If the "ENT" key is disabled the remote keypad
can only be used to set and unset the system.
6. If the remote keypad has a “Ward Sounder
Control”link itcanbeusedtomaketheremote
keypad sounder follow the programmable
output. When the link is set to the disabled
2 Detection
circuits
Programmable output
switched -ve
@100mA
I/D
Selector
Tamper
Switch A B
REMOTE
I/D
1
23
4
ENG
C D E
O/P-
CIRCUIT B CIRCUIT A
ZB ZA
TB TA
Remote network
connections
LED Module
DISABLED WARD SOUNDER
CONTROL
DISABLED
'ENT' KEY
Figure 10 TS700 Remote Keypad Layout
Tamper
Switch
2 detection
circuits
Programmable output
switched -ve
@100mA
I/D
Selector
A B
REMOTE
I/D
1
23
4
DISABLED
DISABLED
WARD SOUNDER
CONTROL
'ENT' KEY
ENG
C D E
O/P-
CIRCUIT B CIRCUIT A
ZB ZA
TB TA
Remote network
connections
Figure 11 TS700 Arming Station Layout
TS790 & TS900 Installation Manual System Installation
9

position the sounder responds as normal.
When the link is set to the enabled position the
sounder is only enabled when the remote
keypad programmable output is active. For
example,tomakethekeypadwardrespective
for ward A, program the output on the remote
keypad to "Sounder Control A" (type 064) and
set the "Ward Sounder Control" link to the
enabled position.
7. Finally clip the remote keypad cover onto the
base being careful not to trap any cables or to
obstruct the tamper switch.
Engineer’s Keypad
Normally all system programming will be carried
out from one of the installed remote keypads,
however sometimes it may be more convenient
to program the system at the control panel. This
can be achieved by using an “Engineers Keypad”
which is temporarily plugged on to the control
panel (JP2). To convert astandard remote keypad
to an “Engineers Keypad” an Engineer’s interface
lead is required which can be obtained from your
supplier (P/No. NETEKI).
TS900 Node Installation (TS900 Only)
The TS900 NODE allows the facility to add an extra
eight programmable detection circuits and two
programmable outputs. The Nodes are
connected on the “Node Network” and up to five
may be connected to the TS900 system.
+Always ensure that all power (mains
and battery) is removed before
making any connections to the Node.
1. Separate the cover and base by using a
screwdriver to push 2 of the clips (left or right)
inwardfromthebaseindents,thenliftthecover
clear.
2. If the Node is being fitted inside the control
panel you may remove the Node PCB from its
base and secure it tobase of the control panel
usingself adhesive feet.Ifrequired,the tamper
switch may also be disabled by fitting the
jumper link across JP2, see Figure 13.
3. If the Node is being fitted outside the control
panel, hold the base in position and mark the
four securing holes. Drill and plug the wall as
required, then pass all cables into the base via
the cable entry points as appropriate. Secure
thebaseto thewallusingtheappropriatefixing
screws.
4. Connect “Node Network” cables and
detection circuit cables to the appropriate
terminals, see Figure 13.
5. Set the I/D selector jumper link to the required
position:
Node I/D
12345
C
I
R
C
U
I
T
S
A17 25 33 41 49
B18 26 34 42 50
C19 27 35 43 51
D20 28 36 44 52
E21 29 37 45 53
F22 30 38 46 54
G23 31 39 47 55
H24 32 40 48 56
OPs +A 1 3 5 7 9
-B 2 4 6 8 10
l No two NODES should have the same I/D.
l The NODE I/D selector DOES NOT have to
be set sequentially but it is advisable so as
to aid fault finding and programming.
6. Finally clip the Node cover onto the base
being careful not to trap any cables or to
obstruct the tamper switch.
Control Panel
To TS900
Remote
Keypad
A (Red)
A
AUX
12V 0V
ENGINEERS REMOTE
JP2
C (Yellow)
BB (Black)
CD (White)
DE (Blue)
E7 Way 0.1" Molex
connector
Figure 12 Engineer's Keypad Connections
System Installation TS790 & TS900 Installation Manual
10

TS900 Node Layout
A B F G A B F G
AUX 12V
AUX 12V
500mA
NODE I/D
JP2
ZA
ZH
ZG
ZF
ZE
ZC ZD
ZB
CIRCUIT A
CIRCUIT H
CIRCUIT G
CIRCUIT F
CIRCUIT E
CIRCUIT C CIRCUIT D
CIRCUIT B
TA
TH
TG
TF
TE
TC TD
TB
JP2 FITTED = NO TAMPER
Fit jumper-link to disable
tamper switch
Tamper switch
I/D selector
Programmable
detection
circuits A - D
From previous
Node
Mains power indicator
On = mains on
Flashing = mains off
Auxiliary 12V output
(for powering detectors) Programmable outputs: [A+] = switched +ve @100mA
[B -] = switched -ve @100mA
To next Node
Programmable
detection
circuits E - H
Auxiliary 12V
fuse (500mA)
1
2
3
4
5
A B
O/P
NETWORK IN NETWORK OUT
+ + - - -+
Figure 13 TS900 Node Layout
TS790 & TS900 Installation Manual System Installation
11

TS700 LEC Installation
The TS700 LEC (Local Expansion Card) is
connected to the “Remote Network” and provides
two additional programmable detection circuits
and a programmable output. The “Remote
Network” may have up to three LECs connected,
as the system will always require at least one
remote keypad.
+Always ensure that all power (mains
and battery) is removed before
making any connections to the LEC.
1. Remove thecoverfrom thebase andcarefully
remove the PCB.
2. If the LEC isbeing fitted inside the control panel
you may remove the LEC PCB from its base
andsecureittobaseofthe controlpanelusing
self adhesive feet. If required, the tamper
switch may also be disabled by fitting the
jumper link across JP2, see Figure 14.
3. If the LEC is being fitted outside the control
panel, hold the base in position and mark the
two securing holes. Drill and plug the wall, then
passallcablesintothebaseviathecableentry
points. Secure the base to the wall using the
appropriate fixing screws.
4. Connect “Remote Network” cables and
detection circuit cables to the appropriate
terminals, see Figure 14.
5. Set the I/D selector jumper link to the required
position:
I/D Selector Circuit A Circuit B Panel
Output
1 09 10 5
2 11 12 6
3 13 14 7
4 15 16 8
NULL N/A N/A N/A
l No two LECs or remote keypads should
have the same I/D.
l DO NOT set the I/D selector to the “NULL”
position.
6. Finally clip the LEC cover onto the base being
careful not to trap any cables or to obstruct the
tamper switch.
Wiring Detection Circuits
All detection circuits may be wired as "End Of Line"
(EOL) or "Double Pole" (DP). Both methods can be
used on the same equipment.
Double Pole
The DP method requires the following:
l The detector alarm and tamper contacts are
connected to the zone and tamper terminals
respectively.
l The combined alarm and tamper loop
resistance must be less than 100 Ohms.
l The maximum number of detection devices
allowed in a circuit is ten.
l Normally open devices such as pressure pads
and exit terminator buttons are connected
between the zone and tamper terminals.
l If the detection circuit is not used links can be
fitted across the zone and tamper loops or
programmed as Not Used.
Network
connections
Programmable
output
switched -ve
@100mA
Tamper switch
Fit jumper-link to
disable tamper switch
CABLE ENTRY
CABLE ENTRY
Programmable
detection circuits
I/D selector
CCT B
E D CB
LEC I/D
A
1 2 3 4
NULL
JP2
TAMPER = JP2 NOT FITTED
NO TAMPER = JP2 FITTED
CCT A
TA
TB ZA
ZB
O/P
Figure 14 TS700 LEC Layout
System Installation TS790 & TS900 Installation Manual
12

End Of Line
The EOL method requires the following:
l The detector alarm contacts must have a 4K7
shunt resistor fitted.
l A 2K2 End of Line (EOL) resistor must be fitted
at the point in the circuit furthest from the
control panel.
l Loop resistance with the EOL resistor shorted
must be less than 100 Ohms.
l The maximum number of detection
devices allowed in a circuit is ten.
l Normally open devices such as pressure
pads and exit terminator buttons are
connected across outer terminals
l If the detection circuit is not used links can
befittedacrossthezoneandtamperloops
or programmed as Not Used.
External Sounder Connections
The following terminals have been provided to
allow connections to an external sounder:
H/O - This is used to provide a permanent -ve
hold off to external sounders, strobes etc.
H/O + This is used to provide a permanent +ve
hold off to external sounders, strobes etc.
It is protected by a 1 Amp fuse (Bell 12V).
TR - This is the negative tamper return
connection from the siren or bell.
STB - This is the strobe output which will switch to
0V on alarm and is rated at 500mA.
Connecttheothersideofthestrobeto the
H/O +.
TRG - This is the bell trigger output which will
switch to 0V on alarm and is rated at
500mA. This output can be programmed
for SAB or SCB operation, as follows:
SAB: TRG - will switch to 0V on alarm and
will provide a maximum of 500mA.
SCB: TRG - will provide a negative hold
off (500mA), which is removed on alarm.
Alarm
Tamper
CIRCUIT A
ZA
TA
CIRCUIT A
ZA
TA
CIRCUIT A
ZA
TA
Alarm
Tamper
Max. 10 devices per circuit
Wiring N.O. devices (Exit Terminators)
Alarm
Tamper
500 meters or 100 Ohms
Figure 15 Double Pole Wiring
500 meters or 100 Ohms
Alarm
Alarm
Tamper
Max. 10 devices per circuit
Wiring N.O. devices (Exit Terminators)
Tamper
4K7 = Yellow, Violet, Red
2K2 = Red, Red, Red
Alarm
Tamper
4K7
4K7
4K7
2K2
2K2
2K2
CIRCUIT B
ZB
TB
CIRCUIT B
ZB
TB
CIRCUIT B
ZB
TB
Figure 16 End of Line Wiring
TS790 & TS900 Installation Manual System Installation
13

Installing an External Sounder from a Node
The TS900 Node has two programmable outputs,
these can be utilised to drive an external sounder.
However, it is recommended that a remote power
supply is fitted next to the Node in order to provide
sufficient power for the external sounder. A relay
module such as the Menvier RM3A is also required
to drive the external sounder. The figure below
shows the connection details.
Auxiliary Tamper
These two terminals provide tamper protection to
auxiliarydevices suchaspowersupplies,extension
loudspeakers etc. If they are not used they must
be linked out.
Extension Loudspeakers
Up to two extension loudspeakers can be
connected across the [SPK+] and [H/O-] terminals
on the control panel PCB. The volume for the
loudspeaker is controlled by VR1"Speaker
Volume".
Aux
12V
RLY 2
COIL -
COIL -
SPARE 1
SPARE 2
TAMPER
RM3A SAB
MODULE
REMOTE
POWER
SUPPLY
NODE SPARE 3
SPARE 4
STROBE-
STROBE +
TAMPER OUT
TAMPER IN
TRIGGER
+12V
0V
TAMPER
CIRCUIT X
Program circuit
as: NIGHT
ZX
TX
COIL +
COIL + RLY 2
COM
COM
N/O
N/O
N/C
N/C
RLY 1
RLY 1
12V
0V
+
-
A+
B-
Figure 17 External Sounders Connection - Node
1 x 16 Ohm Loudspeaker
2 x 16 Ohm Loudspeakers
SPK+
H/O -
SPK+
H/O -
Figure 18 Loudspeaker Connections
Typical
External Sounder
Control
Panel
H/O + 12V +
H/O - 0V
Tamper In
TR -
STB - Tamper Out
TRG - Strobe +ve
Strobe -ve
Trigger -ve
Figure 19 External Sounder Connections
System Installation TS790 & TS900 Installation Manual
14

Digicom/RedCARE Installation
Astandalone digitalcommunicator,RedCARESTU
or Paknet interface card can be connected to the
control panel using the following connections:
Digicom Outputs 1 to 8
These are the programmable digicom output
connections. They are normally at +12V and
switch to 0V when active. The outputs can be
inverted so that they switch from 0V to +12V when
active (see System Configuration on page 31).
Each output willsource 5mA inthe +12V condition
and sink 100mA in the 0V condition.
+DC POWER
This provides the +12V power to the digicom. This
output is un-fused and therefore should only be
used if the digicom is fitted inside the control
panel. The 0V supply for the digicom/STU can be
picked up from any of the auxiliary 0V terminals.
LINE FLT
When this input is switched to +12V, a “Line Fault”
condition is generated. A “Line Fault” condition In
the unset mode will cause a “Chime” type tone to
be generated every minute, which can be
silenced by entering any valid passcode. A “Line
Fault” condition In the set mode will cancel the
“Bell Delay”.
Plug-on Digicom Installation
A plug-on digital communicator DC54 or DC58
may be fitted inside the control panel to allow
alarm status information to be transferred to a
dedicated central station. The unit should be fitted
in accordance with the installation instructions
supplied with it and connected to the control
panel plug DIGI-MODEM (JP3) using the lead
provided with the unit, see Figure 21. The NVM
within the digicom can be programmed via the
control panel, see page 48.
Plug-on digi-Modem Installation
A plug-on digi-modem DC58M may be fitted
inside the control panel to allow remote
interrogation and programming via a personal
computer (PC). It will also function as a standard
digicom (if required). The unit should be fitted in
accordance with the installation instructions
supplied with it and connected to the control
panel plug DIGI-MODEM using the lead provided
with the DC58M. The NVM within the digi-modem
can be programmed via the control panel, see
page 48. The modem data is also programmed
via the control panel.
Control
Panel 3GSTU
1
1
+DC POWER
Program
As:-
Open (060)
Alarm (005)
PA (006)
Fire (007)
LINE FLT
AUX 0V
2
2
3
3
4
4
5
TB1
Channel Inputs are
Programmed as
Positive Removed
TB2 TB3 TB4
Control Line
Fault RPS
5
6
6
7
7
0V
NO NO NO
NC NC NC
8
8
C C
C
A+ A+ A+ A+ V+
Figure 20 3GSTU RedCARE Connections
Connect to JP7
DIGI-MODEM
Plug-on digicom / digi-modem
A
B
BC
B.T. master jack ( Type NTE5
user accessible connections )
A(5) = White / Blue ring
BC(3) = Blue / White ring
B(2) = Orange / White ring
Telephone cable
(Type 1/0.5mm CW1308)
6
6
5
5
4
4
3
3
2
2
1
1
Figure 21 DC54/DC58 Connections
TS790 & TS900 Installation Manual System Installation
15

Output Modules Installation (CPA6.OM)
Output Modules (CPA6.OM) can be used to
provideasetof outputstoLEDsorrelaystoindicate
either circuit alarm activations or circuit mimic
activations. The first output module connected to
the system will indicate circuits 1 to 8, the next
modules will indicate circuits 9 to 16 etc. Output
modules are normally fitted inside the equipment
they are controlling and may be positioned up to
500 metres away from the main panel. The output
module should be used and connected in
accordance with the instructions provided with it.
Connecting a Printer
The TS790/900 supports two type of printers, the
CPA6 printer (no longer available) and any
standard RS232printer.When usingaRS232printer
aDCI/MPAprinteradaptorwillberequired.Menvier
Security supply a DATAC printer kit which consists of
a portable RS232 printer, charger unit and
DCI/MPA adaptor.
Using the CPA6 Printer
1. Plug the CPA6 printer directly on to the PRINTER
plug (JP1) on the main control panel PCB.
2. Theprinter willprint-outaheader,whenfinished
the system program details and event log can
be printed.
3. When finished unplug the printer. If the printer
is left connected events will be printed as and
when they occur.
Using the DATAC / RS232 Printer
1. Plug the DCI/MPA on to the PRINTER plug (JP1)
on the main control panel PCB.
2. Plug the other end of the DCI/MPA into the
DATAC or RS232 printer.
3. In order for the printer to work correctly ensure
the printer is set to the following:
Baud rate = 4800
Parity = None
Start bits = 1
Stop bits = 2
Data bits = 8
DTR = Normal
4. When set-up correctly the system program
details and event log can be printed.
5. WhenfinishedunplugtheMPA/DCI.Iftheprinter
is left connected events will be printed as and
when they occur.
PL1
1k Resistors
LED's
1 2 3 4 5 6 7
+12V IN
+12V OUT
+12V OUT
8
PL2
To next OM
Connect to plug
labelled OUTPUT
MODULE
100m
Figure 22 Output Module Connections
DC58M
Telephone
Network
V21.
Modem
Alarm Receiving
Centre
TS790/900 Control
Panel
Figure 23 DC58M Digi-modem Schematic
System Installation TS790 & TS900 Installation Manual
16
