NEUTRIK EtherCon Receptacle NE8FDY-C6 User manual

NE8FDY-C6
EtherCon Receptacle
®
-1-
B
A
E
Assembly Instructions
40 mm
Twist the
screen
8-7 4-5
6-3
2-1
8-7
4-5
6-3
2-1
S-FTP SF-UTP F-UTP
8-9 mm
C D
F
Cable tie
2. Trimming!
1. Position the
cable!
1. 2. 3. 4. 5.
Cable preparation
Shielding
Cable pairs separation Cable mount
Position wires acc. label Fix wires

Data subject to change without prior notice. 2007 NEUTRIK . ALL RIGHTS RESERVED.©®
R
N E U T I K R
R
CONNECTING THE WORLD
NEUTRIK AG NEUTRIK Zürich AG NEUTRIK (UK) Ltd. NEUTRIK USA INC. NEUTRIK Tokyo Ltd. NEUTRIK France NEUTRIK Vertriebs GmbH
Liechtenstein Switzerland Great Britain USA Japan France Germany / Netherlands / Austria
Tel.: [phone] Tel.: [phone] Tel.: [phone] Tel.: [phone] Tel.: [phone] Tel.: [phone] Tel.: [phone]
Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone]
www.neutrik.com
Draft. Nr.: BDA 188
Update:
/3102M1561
09.02.2007
-2-
G H
Break out!
Cut!
K
I J
Press
down!
Snap in
Hang up!
Note for Right-Angel Version
Working steps same as above.
Except:
Step B - References
Step G - The cable outlet must not be
interrupted.
to step B and bend
the reinforcement metal right
angle below.
1.
2.
Cover assembly Connect the screen
Assembly the adapter Grounding option
Assembly the chassis
Please fix the cable additionally.Attention: Before assembly secure the housing in the device.
B
G
Insert until it
snaps in
Insert contact only if screen should
be connected to front panel
LFinish
