NEUTRIK opticalCON DRAGONFLY NKO2SMW-XP Series User manual

Unscrew the male connector`s anti-kink
boot.
Remove the male connector`s front
housing.
u We will need this male connector
later for mount into the panel.
Place the pulling tool (FORP-XP to be
ordered separately) on the male
connector.
Screw the pulling tool on the male
connector.
Pull the cable using the pulling tool to
the panel on which male connector
should be mounted. A snap hook can be
attached.
A
B
C
D
E
A
B
C
E
D
RASSEMBLY INSTRUCTION
®
opticalCON DRAGONFLY
|
Cable Assembly NKO2SMW-XP-*
FOPR-XP
SNAP HOOK
Page 1BDA 632
1 Assembly of the pulling tool FORP-XP
Pulling tool:
FORP-XP

®
ASSEMBLY INSTRUCTION - opticalCON DRAGONFLY NKO2SMW-XP-*
I
Plug side / Device
A
B
D
3x *
C
2 Chassis male assembly and panel mounting
Page 2BDA 632
* USE FOLLOWING SCREWS:
M3 DIN 912 or
UNC 4-40 PAN HEAD
Unscrew the pulling tool.
Insert the front housing into the panel
cutout as described below and screw the
connector to the front housing.
Position the large O-ring from the
backside onto the chassis.
Place a small O-ring in the screw hole
Position the small O-rings onto the
remaining 3 screws*.
Mount the chassis on the panel.
Push the mounting eye into the slot.
Important: the O-ring is underneath.
First position the screw without O-ring
in the hole together with the mounting
eye.
Secondly mount the other 3 screws and
tighten all screws with 70 Ncm.
Position the connector housing into the
front housing and tighten lightly.
A
B
C
D
E
F
F
SCNO2MW-XP
max. Torque 70 Ncm
E

www.neutrik.com
Neutrik AG LI T: +423 / 237 24 24 F: +423 / 232 53 93
Neutrik USA Inc. USA T: +1 704 / 972 3050 F: +1 704 / 438 9202
( )
Neutrik UK Ltd. UK T: +44 1983 / 811 441 F: +44 1983 / 811 439
Neutrik Vertriebs GmbH DE / NL / AT/DK T: +49 8131 / 280 890 F: +49 8131 / 280 830
Neutrik France FR T: +33 1 / 4131 6750 F: +33 1 / 4131 0511
Neutrik Tokyo Ltd. JP T: +81 3 / 3663 4733 F: +81 3 / 3663 4796
Neutrik Hong Kong Ltd. HK T: +852 / 2687 6055 F: +852 / 2687 6052
R
Draft. Nr.: BDA 632 V2 Update: 2021-12-16
I IData subject to change without prior notice. 2021 NEUTRIK . NEUTRIK are registered trademark of Neutrik AG. ALL RIGHTS RESERVED.
® ®
©
Tighten the connector with the open-
end wrench.
Wrench size: 19 mm
Torque: 10 Nm
Close the chassis with the sealing cover.
When the connectors are mated, the
sealing cover can be put together with
the cable connector cover to keep the
interior clean.
Find more details on
www.neutrik.com
GG
®
ASSEMBLY INSTRUCTION - opticalCON DRAGONFLY NKO2SMW-XP-*
I
CAUTION:
Laser radiation, do not look directly into beam of light!
LASER
