NEUTRIK opticalCON DUO User manual

HANDLING INSTRUCTION
®
opticalCON DUO Maintenance
|
R
R
www.neutrik.com
BDA 520

CAUTION: Laser radiation, do not look directly into beam of light!
Inspection & Dry cleaning (using FOCD-DC125)
Disconnect both cable ends for safety reasons.
Invisible laser radiation may be emitted from
disconnected fibers or connectors. Do not stare into
beams or view directly with optical instruments.
Remove dust cap from the connector (A) and mount
NEUTRIK FOCD-STD inspection tool on it until it is
locked (B).
Prepare the optical fiber video probe with the
correlate tip (C).
Under the following QR-code you can find a list with
The sealing shutter mechanism of the opticalCON avoids contamination of the LC ferrule locked inside.
®
The dust-proof design reduces maintenance intervals to a minimum; if nevertheless necessary,
follows the maintenance procedure below to avoid damages on the due to inpropes cleaning.
2
C
1.
1.1
1.2
1.3
optical fiber Microscope
B
Service tool (FOCD-STD)
BDA 520
A. Connector Cleaning / Inspection
Intervall: every 500 matings recommended
Tools: Ÿ NEUTRIK DUO service Tool (FOCD-STD)
®
Ÿ Dry Cleaner 1.25 mm (FOCD-DC125)
Ÿ optical fiber video probe
A
opticalCON
LC tip
opticalCON
I HANDLING INSTRUCTION
®
opticalCON DUO

opticalCON
D
opticalCON
3
During inspection procedure, make sure that
each ferrule is completely free of dust.
As a reference the ferrule has to look as
illustrated on Picture B.
BDA 520
Dry Cleaner 1.25 mm (FOCD-DC125)
opticalCON
E
Insert the video probe tool into our NEUTRIK FOCD-
STD service tool (D).
To inspect the LC ferrule surface focus the video
probe by rotating the focus wheel (E).
Clean the LC surface with the Dry Cleaner 1.25 mm
over the NEUTRIK DUO service tool.
Push back and forth the dry cleaner to start the
cleaning procedure (F). An endless lint free tape
removes dust particle on the ferrule surface of the LC
connector.
Check the condition of the LC ferrule surface again
and if necessary repeat step 7.
1.4
1.5
1.6
1.7
1.8
F
Picture A: Picture B:
I HANDLING INSTRUCTION
®
opticalCON DUO

G
opticalCON
After the cleaning procedure unlock the NEUTRIK
inspection tool (G).
Wet cleaning using lint-free wipes
Press forward the twist prevention and untight the
connector bushing and remove carefully the insert of
the connector housing.
Inspect the LC connectors with a video probe tool.
Fold a lint free wipe into a square with one drop of
cleaning fluid. Be sure that a portion of the wipe
remains dry.
Wipe slightly the ferrule tip in the cleaning fluid
moistened portion of the wipe. Immediately repeat
this wiping action on the dry section of the wipe to
remove any residual alcohol.
Dispose the wipe. NEVER REUSE A WIPE.
Inspect the connector again with a video probe tool.
Repeat the process if necessary.
After the cleaning procedure slide the connector
insert back into the connector housing. Align the key
on the insert to the cutout of the metal housing.
Screw both connector parts togehter.
1.9
2.
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
I HANDLING INSTRUCTION
®
opticalCON DUO
4 BDA 520
cleaning fluid
FOCD-CFFOCD-DW

- 5 -
B. Chassis Cleaning
Dry cleaning using FOCD-DC125
Remove Dust cap. Insert the stick of the cleaning
device.
Make sure that the insertion position is on the
bottom of the LC connector hole in order to hit the
sealing shutter release bar.
Push the outer shell to start cleaning the LC
connector end face.
A “pop” sound indicates end of cleaning process.
Remove the cleaning device and put dust cap over
the stick.
Wet cleaning using lint-free wipes
Inspect the LC connectors with a video probe tool.
Fold a lint free wipe into a square with one drop of
cleaning fluid. Be sure that a portion of the wipe
remains dry.
Wipe slightly the ferrule tip in the cleaning fluid
moistened portion of the wipe. Immediately repeat
this wiping action on the dry section of the wipe to
remove any residual alcohol.
Dispose the wipe. NEVER REUSE A WIPE.
Inspect the connector again with a video probe tool.
Repeat the process if necessary.
1.
1.1
1.2
1.3
1.4
2.
2.1
2.2
2.3
2.4
2.5
2.6
BA
N
E
U
T
I
K
R
Dry Cleaner
(FOCD-DC125)
Tools: Ÿ Dry Cleaner 1.25 mm (FOCD-DC125)
Ÿ 99% isopropyl alcohol (IPA) or
cleaning fluid (FOCD-CF)
Ÿ Lint free wipes (FOCD-DW)
Ÿ Video probe (CAS-FOCD)
1.1
1.2
Draft. Nr.: BDA 520 V2 Update: 2020-01-07 I
www.neutrik.com
Neutrik AG LI T: +423 / 237 24 24 F: +423 / 232 53 93
Neutrik USA Inc. USA T: +1 704 / 972 3050 F: +1 704 / 438 9202
( )
Neutrik UK Ltd. UK T: +44 1983 / 811 441 F: +44 1983 / 811 439
Neutrik Vertriebs GmbH DE / NL / AT/DK T: +49 8131 / 280 890 F: +49 8131 / 280 830
Neutrik France FR T: +33 1 / 4131 6750 F: +33 1 / 4131 0511
Neutrik Tokyo Ltd. JP T: +81 3 / 3663 4733 F: +81 3 / 3663 4796
Neutrik Hong Kong Ltd. HK T: +852 / 2687 6055 F: +852 / 2687 6052
Neutrik India Pvt. Ltd. IND T: +91 / 982 05 43 424 F: +91 / 22 26163 540
R
Data subject to change without prior notice. 2020 NEUTRIK . NEUTRIK are registered trademark of Neutrik AG. ALL RIGHTS RESERVED.
® ®
©
I HANDLING INSTRUCTION
®
opticalCON DUO
cleaning fluid
FOCD-CFFOCD-DW
Find more details of opticalCON
on www.neutrik.com.
