Nexa P-38 Lightning User manual

Radio control model
Wingspan approx. 83 in.
Fuselage length approx. 57.5 in.
Glow Engine 7.45cc 2T /11.5cc 4T (x2)
Electric Motor 870 Watt Brushless motor x2
Radio 6 Channel / 11 Servos
INSTRUCTION MANUAL
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of control and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.

Silicone tube
.46 - .50 cu.in.(x2)
7.45cc (x2)
.60 - .70 cu.in (x2)
10cc - 11.5cc (x2)
SILICON
EPOXY A
EPOXY B
CA
GLUE
Silicon Glue Epoxy ( 5min-Typ)
Cyanoacrylate Glue
Needle nose Pliers Awl
Scissors
Wire Cutters
Hex Wrench
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
Sander
Hobby knife
Phillip screw driver
REQUIRED ITEMS
Minimum 6 channel radio
for airplane / 7 standard
servos / 4 mini servos
1.5mm
AB
!
CA
L/R
Assemble left and right
sides the same way.
X
Drill holes using the stated
size of drill
(in this case 1.5 mm Ø)
Use epoxy glue
Take particular care here Hatched-in areas:
remove covering
film carefully
Not included.
These parts must be
purchased separately
Check during assembly that these
parts move freely, without binding
Apply cyano glue
If exposed to direct sunlight and / or heat, wrinkles can appear. Storing the model in
a coll place will let the wrinkles disappear. Otherwise, remove wrinkles in covering
film with a hairdryer, starting with low temperature. You can fix the corners by using
a hot iron.
Read through the manual before you begin, so you will have an overall idea of what to do.
CONVERSION TABLE
1.0mm = 3/64”
1.5mm = 1/16”
2.0mm = 5/64”
2.5mm = 3/32”
3.0mm = 1/8”
4.0mm = 5/32”
5.0mm = 13/64”
6.0mm = 15/64”
10mm = 13/32”
12mm = 15/32”
15mm = 19/32”
20mm = 51/64”
25mm = 1”
30mm = 1-3/16”
45mm = 1-51/64”
Electric Set up 1:
2X Dualsky XM5050EA-7 610Kv motors.
2X Dualsky XC8018BA 80A ESC, 100A burst
2X Dualsky XP45004EX 4S, 35C, 4500mAh Lipo
2X Prop: 14x9 x3-blade Master Airscrew
Approx Weight: 1600grams / 3.6lbs
Electric Setup 2:
2X Dualsky XM5060EA-6 470Kv motors.
2X Castle Creations Edge 100AMP ESC
2X Dualsky XP45005EX 5S, 35C, 4500mAh Lipo
2X Prop: 16x10 x3-blade Master Airscrew
Approx Weight: 2200grams / 4.8 lbs
Aileron x2 Elevator x2 Rudder x2 Nose gear x1
Flap x4 Throttle x2 (Glow engine)
Extension cord for aileron servos: 70cm(x2)
Extension cord for center flap servo: 30cm(x2)
Extension cord for retract servos: 50cm(x3)
Extension cord for Rx battery pack: 30cm(x1)
Extension cord for Elevator servos: 50cm(x2)
Extension cord for outer flap servo: 50cm(x2)
Extension cord for Rudder servo: 50cm(x2)
Extension cord for Throttle servo (glow engine): 50cm(x2)

Install the push rod connector onto the
outer-most hole of the flap servo arm.
Move the flap servo arm a few times to make sure it move
freely with out any binding.
Connector
........2
Nylon cable tie
(included)
Servo mount
Flap servo (mini. servo)
-Turn the center wing over.
-Turn the four screws and move the hatch out of the wing.
-Place the flap servo onto the servo mount with the flap push rod installed
as shown.
-Using the pencil, trace around the servo, where it meets the servo mount.
Connector (included)
Remove the servo out of the wing.
Place the servo onto the adhesive tap as shown.
With the pencil, trace around the servo, where it
meets the adhesive tape.
Adhesive tape
(included)
Adhesive tape
Servo mount
Pencil line.
Adhesive tape
Peel the bottom cover
Peel the top cover
With the scissors, cut along the pencil line
1A
1B
1C
1D
1E
1F
1G
1H
1I
Flap push rod
3mm screw
Do the same way with the flaps on the left and the right wing
1-Center wing: Flap servo

Note: Do not close the hatches in this time
2-Center wing
CENTER WING - Top-view
Adhesive tape (keep the
extension in place)
Cut away the covering for
the extension cord exit
CENTER WING
Bottom-view
The center wing with the flaps in closed position.
The center wing with the flaps in opened position.

Aileron servo hatch with servo installed
(standard servo using)
Flap pushrod
RIGHT WING - Bottom-view
To be connected the extension with the aileron servo cord before attach the hatch to the wing
Note: the aileron extension must 700mm long or use two 300mm long.
.............2
.......4
2x30mm screw
Servo mount Flap push rod
Note: the connector is
turn-down
Note: the connector is
turn-down
Connector
Connector
........4
3-Outer wing
3A
From Step 3B to Step 3I, follow the
procedure as described in the
1-Center wing: Flap servo section
Aileron servo
X
1.5mm
!
Set all screws securely. If they come
off during flight you will lose control
of your plane.
3B
3C
90o
Aileron servo adjust.
SILICON

.............2
.......4
2x30mm screw
2mm
Silicon sealer
2x175mm rod / clevis .........2
CA
Thin CA
Outer Wing - Bottom view
Push the wooden dowel to the hole on the rib
as show. Ensure that the dowel is rectangular
with the rib.
Secure it in place using the thin CA glue.
Outer Wing - Top view
4-Outer wing: Aileron control horn, Linkage, dowel.

19x317mm aluminum tube
12x182mm aluminum tube
Do the same way with the other side
of the center wing.
Slide the aluminum tube into the left and right
side of the center wing.
19x317mm aluminum tube
12x182mm aluminum tube
......................2
...2
Bottom-view
CENTER WING
Bottom-view
CENTER WING
5- Joining the Wing

Carefully, slide the left wing to meet the center wing
Aileron extension
4x20mm screw
Secure the outer wing in place using 4x20mm screw
4x20mm screw
.....2
.............2
!Check the ailerons and flaps functions move in the correct before attach all hatches to the bottom of the wing.
6- Joining the Wing

!
5.5mm
L/R
Align the mark on both
mounts with the center
mark on the balk head.
! Engine thrust on balk head
is already adjust at factory
................8
Blind-nut
A
A
B
B=B’
B’
Align the mark on both
mounts with the center
mark on the balk head.
3x25...(8)
Washer....(8)
Nut 3mm..(8)
Secure the engine to the engine
mount using four 3x25mm screws
Insert the Z-bend into the hole on the throttle
lever of engine.
Note: It may be easier to temporarily remove
the control arm from the carburetor to insert the
Z- bend
C
C= 132 ~ 134mm
4x30mm screw
..8
.............8
BB’
132~134mm
SIDE-VIEW
TOP
BOTTOM
7-Engine mounts
8- Glow Engine
7A
7B
L/R

X
Filler tube
Rubber
stopper
To engine
Aluminum stopper Aluminum
cap
To muffler
TOP
BOTTOM
Using a aluminum motor mounting plate as a template,
mark the plywood motor mounting plate where the four
holes are to be drilled.
Remove the aluminum motor mounting plate and drill a 1/8”(3mm) hole through the
plywood at each of the four marks marked .
Note: The aluminum motor mounting included with electric motor set.
5x70mm..8
5mm nut..24
washer...32
5mm
3mm
Align the mark on the motor
mounting plate with the
center mark on the balk head.
X
Firewall
132~134mm
B’
B
B=B’
SIDE-VIEW
L/R
10-Electric Motor
9-Fuel tank
FDP
FDP
CA
Installing the Lipo Battery
Stand
FUSELAGE - Top view
8A
8B
8C
9A
Fuselage - Top view
9B
9C (In case of electric motor using)
L/R
11-Battery Stand

Throttle servo tray
Rudder servo
Elevator servo
Note: Turn the throttle servo tray for
other engine if needed.
RIGHT FUSELAGE - Top view
Connector
.........6
14-Servos
30x4mm nylon bolt
............4
Secure the Battery hatch in place
using the 4x30mm nylon bolt.
CA
11A
CA
Lipo Battery stand
9D
L/R
Fuselage - Bottom view
Battery hatch
Cut away only
the covering
4x30mm nylon bolt
.........2
12-Battery Stand
13-Battery Hatch
L/R
L/R

Throttle servo
Rudder servo
Elevator servo
Elevator Pushrod
Throttle pushrod
RIGHT FUSELAGE - Top view
Rudder Pushrod
15mm
2 mm
CA
L/R
.............2
.......4
2x30mm screw
16-Rudder
L/R
15-Linkages
2x950mm rod / Clevis
....4

Cut away onlly the covering
ABS “balance” HORIZONTAL STABILIZER
2 mm
ABS “balance”
.............2
.......4
2x30mm screw
Top-view
17-Horizontal Stabilizer
Horizontal stabilizer
LEFTFUSELAGE RIGHTFUSELAGE
19-Horizontal Stabilizer
RIGHT FUSE.
LEFT FUSE.
6x60mm wooden dowel
................4
12x108mm aluminum tube
....2
L/R
Secure the aluminum
tube and wooden dowel
in place using Thin CA glue
Aluminum tube
Wooden dowel
6x60mm
CA
12x108mm
Wooden dowel
6x60mm
18-Horizontal Stabilizer
A=8mm
A
A
B=60mm
B
A=8mm
A
A
B=60mm
B
CA

Horizontal stabilizer
3x15mm screw
3x15mm screw
WING
6x40 Nylon bolt
TOP
RIGHT / LEFT FUSELAGE (TAIL BOOM) Side-view
6x40 Nylon bolt
.....4
L/R
RIGHT / LEFT WING SHIELD
Trial fit the fuselage-top shield onto the wing,
If necessary, sand the edge of the
fuselage-top shield until this is achieved.
WING
2.mm
3x15mm screw
2.mm drill bit
Aluminum tube
20A Drill through both the balsa
block and aluminum tube
Balsa block
TOP
Note: The holes on the bottom of the Horizontal stabilizer
are pre-drilled at factory
20-Horizontal Stabilizer
21-Installing the wing
22-Installing the wing shield
Secure the wing shield in place using 2.2x12mm screws
20B
L/R
2x8mm screw
.........14
RIGHT / LEFT FUSELAGE (TAIL BOOM) Side-view

WING
FIBER GLASS MAIN FUSELAGE
FIBER GLASS
COCKPIT
2mm
10mm
FIBER GLASS MAIN FUSELAGE
6x50mm plastic bolt
....1
23-Installing the main fuselage
24-Installing the cockpit
Secure the cockpit in place
using 2x8mm screws
25-Cowling
Secure the cowl in place using
2.5x12mm screws
2.5x12mm screw
...........8
LR
Note: The “L” Cowl for LEFT fuselage and
“R” Cowl for RIGHT fuselage (looking from
REAR to FRONT and TOP view).
COWL
BOTTOM VIEW
COWL
BOTTOM VIEW
Gear door
26-Gear door
26A
CA
Hinge 26B
2x8mm screw
.........11
2x8mm
2x8mm 2x8mm
2x8mm
2x8mm

Gear door
ALL GEAR DOORS
IN CLOSED POSITION
Fuselage
Fuselage
Cotton thread
(not include)
Spring (not include) ALL GEAR DOORS
IN OPENED POSITION
(RETRACT LANDING GEAR IN RETRACTED POSITION) (RETRACT LANDING GEAR IN EXTENDED POSITION)
Spring (not include)
Cotton thread
(not include)
Gear door
Cotton thread
(not include)
Note: you can find the
same spring in old
ball-point pen
Fuselage Fuselage
Gear door
GEAR DOOR
IN OPENED
POSITION
CA
Frame
Hinge
Frame
CA
CA
Gear door
27-Gear door
27A
27B

Gear door
(main fuselage)
Cotton thread
(not include)
Spring (not include)
Gear door
Bottom-view
Balsa block
(not include)
CA
CA
CA
CA
28-Gear door
28A
28B
28C
28D

2x8mm screw
2x8mm screw
1.2mm
1.2mm
...................6
Cotton thread
(not include) GEAR DOOR IN CLOSED POSITION
(NOSE RETRACT LANDING GEAR
IN RETRACTED POSITION)
GEAR DOOR IN OPENED
POSITION
(RETRACT LANDING GEAR IN
EXTENDED POSITION)
Hinge
Fuselage
side
Gear door
CA
GEAR DOOR
IN OPENED
POSITION
Cotton thread
30-Canopy
Putt Putt Maru version
Note: Cut out the stickers and apply them in the proper area. Do not peel the backing paper off all at once.
Peel off one corner of the backing and cut off with scissors. Arrange sticker on model and when satisfied adhere the corner without
backing.
Carefully peel back the rest of the backing while at the same time adhering the rest of the sticker.
Try not to make air bubbles, if there are some, carefully puncture sticker (center of bubble) but not model surface with the tip of the knife
or sharp pin and
squeeze out the air. At curves stretch sticker and apply a little heat so that no ceases occur. Cut off the excess that is produced.
U
R
A
M
T
T
U
P
T
T
U
P
T
T
U
P
T
T
U
P
U
R
A
M
“Putt Maru” decal is
only for one side
Kill-mark only
for one side
31-Decal
29-Gear door

1,2,3,4
Fuel cap sticker (for all versions)
“Skidoo”decal is
only for one side
L/R
Kill-mark only
for one side
32-Decal
Skidoo version
IMPORTANT:
Please do not clean your model with pure alcohol, gasoline or strong sloven, only use
kerosene or liquid soap with water or use glass cleaner to clean on surface of your model
to keep the colour not fade.

CA
33-Installing the guns
115 ~ 120mm
The ideal C.G. position is 115 ~ 120mm
behind the leading edge.
115~120mm
WING ROOT
8~10mm
8~10mm
30~35mm
10~12mm
10~12mm
25~30mm
AILERON
FLAP
ELEVATOR
RUDDER
25~30mm
Position for
right diagram.
Position for right diagram.
WARNING: Never fly before checking
the Cg’s required position.
34-Balance
35-Control ranges
