Nexa Pilatus Porter PC-6 User manual

PILATUS PORTER
PC-6
MONTAGEANLEITUNG
INSTRUCTION MANUAL
SPECIFICATIONS
Wingspan 1580mm
Length 1160mm
Electric Motor 870 Watt (PULSAR 60)
Glow Engine .46 2-T / .70 4-T
Radio 5 Channel / 5 Servos
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,
die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen Bei unsachgemäßer Verwendung kann
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstützung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
TECHNISCHE DATEN
Spannweiter 1580mm
Lange 1160mm
Elektroantrieb 870 Watt (PULSAR 60)
Verbrennerantrieb 7.5cc 2-T / 11cc 4-T
Fernsteuerung 5 Kanal / 5 Servos
46 Class
52 Class
(2T engine)
(4T engine)
Or Electric equivalent
Radio control model / R/C Flugmodel

.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
1.5mm
AB
!
CA
L/R
Assemble left and right
sides the same way.
X
Drill holes using the stated
size of drill
(in this case 1.5 mm Ø)
Use epoxy glue
Take particular care here Hatched-in areas:
remove covering
film carefully
Not included.
These parts must be
purchased separately
Check during assembly that these
parts move freely, without binding
Apply cyano glue
SILICON
EPOXY A
EPOXY B
CA
Epoxy Glue (30 minutes type)
Silicon Glue
Cyanoacrylate Glue
Sekundenkleber
Epoxy-Klebstoff (30min)
Minimum 5 channel radio
for airplane
.52 cu.in (8.5cc)
Extension cord
.46 cu.in. (7.5cc)
REQUIRED FOR OPERATION (Purchase separately)
Minimum 5 Kanal
Fernsteuerung
Servoverlangerungskabel
BENOTIGTE KOMPONENTEN (Nicht im Lieferumfang enthalten)
Propeller 11x8 for electric motor / 11x6 for glow engine
Luftschraube 11x8 fur Elektromotor / 11x6 fur Verbrennungsmotor
Brushless Motor
PICHLER BOOST 40
Brushless ESC
Brushless Regler
Battery / Flugakku LEMONRC 3700-11.1V
Silikonkleber
Tool Required/ Erfoderliches Werkzeug
The pre-covered film on ARF kit may wrinkle due to variations of temperature.
Store model in a cool and dry place for awile.
Then, staring with low heat, you may carefully use a hair dryer to smooth out wrinkels.
Die Bespannung des Modells kann durch Temeratureinflusse erschlaffen oder Falten
werfen z.b bei zu starker Sonnenenstrahlung oder Hitze.
Stellen Sie das Modell zunachst an einen kuhlen Platz fur eine bestimmte Zeit. Danach
konnen Sie versuchen die restlichen Falten vorstichtig mit einem Haartrockner zu behandeln.
!
CONVERSION TABLE
1.0mm = 3/64”
1.5mm = 1/16”
2.0mm = 5/64”
2.5mm = 3/32”
3.0mm = 1/8”
4.0mm = 5/32”
5.0mm = 13/64”
6.0mm = 15/64”
10mm = 13/32”
12mm = 15/32”
15mm = 19/32”
20mm = 51/64”
25mm = 1”
30mm = 1-3/16”
45mm = 1-51/64”

L/R
Plastic control horn
2x20mm screw
Linkage Stopper set
............................2
...................4
.....................2
X
X
2mm
2x20mm screw
Gestängeanschluss
1.2mm O Alenk-Gestange
BOTTOM - VIEW / Unteransicht
Cut here for standard servo
CA
CA
6mm wooden
dowel
6mm wooden dowel x4
Magnetic hatch
1
2
Note: The hole for the Linkage stopper installation
is pre-drilled at factory
CA
Thin CA
Thin CA
Thin CA
B
B: 8-10mm

In case of 4T engine
In case of 2T engine
Align the mark on both mounts
with the center mark on the fire-wall
!
AA’
Align the engine center with
fire-wall marked line (A=A’)
FRONT VIEW
Viertaktmotoren Zweitaktmotoren
Motorträger
Engine mount
Align the engine center with
fire-wall marked line (A=A’)
A
A’
FRONT VIEW FRONT VIEW
In case of 4T engine
Using the four 3x20mm
screws securing the engine
to the engine-mount
B
B=107~110mm
D
.....4
.............4
4x25mm screw
Blind-nut
.....4
3x20mm screw
.............4
3mm nut
3mm washer
.............4 4mm washer
.............4
5mm
!
Align the mark on both
mounts with the center
mark on the fire-wall
4x25mm screw
Schraube
4mm
Motorträger
D
3Note: The Pilot seater can move for the engine-mount
and servos installation is easily.
18mm wooden washer..........4
18mm wooden
washer

X
To muffler
Filler tube
To engine
Rubber
stopper
Cap
Stopper
After confirming the direction . Insert and
tighten the screw.
4mm
zum Motor
Überlauf
Tanken
FRONT-VIEW
4mm
5/32”
! Align with the marks
3mm
1/8”
1
34
Plywood motor mounting plate
Aluminum motor
mounting plate
2
Sperrholztrager Platten Vorderansicht
An den Markierungen ausrichten
! Align with the marks
An den Markierungen ausrichten
Sperrholztrager Platten zusammenkleben, wie
gezeigt ausrichten und Locher bohren.
Motor nach untenstehendem Schema einbauen.
Fur optimale Leistung empfehlen wir folgende
Komponenten:
-Brushless-Motor PICHLER BOOST 40
-Brushless Regler PICHLER ESC-60
-LiPO Akku LEMONRC 3700-11,1V
-Luftschraube 11x8
For maximum performance, we recommended the following:
-Brushless-Motor PICHLER BOOST 40
-Brushless Regler PICHLER ESC-60
-LiPO Battery LEMONRC 3700-11,1V
-Luftschraube 11x8
Montagekreuz aus
Alu (nicht enthalten)
Checking for leaks - block the vents and blow into
the feed if in doubt submersing the tank in a blow
of water will show up any problems.
Blow
Water
Carefully install the fuel tank to ensure that they will not
shift during flight (secure the fuel tank in place using foam padding).
5A
- Using a plywood motor mounting plate as a template, mark
the fire wall where the four holes are to be drilled (1).
- Using a aluminum motor mounting plate as a template, mark the
plywood motor mounting plate where the four holes are to be drilled (3).
- Remove the aluminum motor mounting plate and drill a 1/8”(3mm) hole
through the plywood at each of the four marks marked (4).
- Remove the plywood motor mounting plate and drill a 13/64”(5mm)
hole through the fire-wall at each of the four marks marked (2).
4
5
5B
5C
5D

Firewall
107~110mm
B’
B
B=B’
A
A=A’
A’
TOP-VIEW / Draufsicht
SIDE-VIEW / Seitenansicht
Motorspant
Note the side thrust for motor!
Sturz und Zug beachten!
X4 X16
X12 X4
6A 6B
6E
6C 6D
6

Trim the cowling so it will
match your engine
3x8mm screw
..............4
Blechschraube
FUSELAGE - TOP VIEW / UNTERANSICHT
Secure foam padding with rubber bands or tape
(must be purchased separately)
Receiver and battery
Rudder servo
X
Pushrod
3mm set Screw
2 mm
Linkage Stopper set
.....................3
.....................3
3mm set screw
Akku &
Empfänger
in Schaum lagern
Rudergestänge
Gestängeanschluss
Seitenruderservo
Madenschraube M3
Madenschraube M3
Falls ein Verbrennungsmotor eingebaut
wird mu die Motorhaube entsprechend
dem Zylinder ausgeschnitten werden.
Li-po
battery
Akku Kiettband
aus dem PICHLER
Sortiment
Best.Nr. C4739
Battery seat bell
Tipp
Throttle servo
(in case of gaz engine)
To rudder
control horn
7
8
Elevator
servo area
2 mm
2 mm

Nylon strap
3x12mm screw
3mm set screw
Kunststoffstreifen
Madenschraube M3
4mm Main landing
gear
2.5mm landing
gear
Aluminum tube
Stopper (metal)
Collar
Collar
Stellring
Fahrwerksdraht
Hauptfahrwerk
9
Note: All holes on the bottom of
the fuselage are pre-drilled at
factory.
Note: The hole on the
left (and right) side of
the fuselage is pre-drilled
at factory
3x12mm screw
......................12
Nylon strap
...................5
Stopper (metal)
...................2
Kunststoffstreifen 4mm collar...4
..2
Main landing gear (4mm)....2
Landing gear (2.5mm)........2
Hauptfahrwerk
Fahrwerksdraht

Cut away only the film on the
bottom of the horizontal stabilizer
Cut away only the
film both the left
and right side
AB
AB
Elev. / Rudd.
Plastic control horn
AA’
A=A’
BB’
B=B’
Plastic control horn
and back plate
2x12mm screw
.....1
...........2
WARNING! Securely glue together.
If coming off during flights, you lose
control of your airplane which leads
to accidents !
FUSELAGE - REAR - BOTTOM VIEW
SIDE VIEW
2 mm
2x12mm screw
FUSELAGE - TOP-VIEW
AUFSICHT
BOTTOM
TOP
Bespannfolie an den
Klebestellen vorsichtig
entfernen.
FUSELAGE - TOP-VIEW
AUFSICHT
Fuhren Sie die Verklebungen mit gro ter
Sorgfalt aus.
* WARNING: When removing any covering from
the airframe, please ensure that you secure the
cut edge with CA or similar cement. This will
ensure the covering remain tight.
* WARNING: When removing any covering
from the airframe, please ensure that you
secure the cut edge with CA or similar
cement. This will ensure the covering
remain tight.
.......4
3x15mm screw
.......4
10
11A 11B
11
12

AB
Plastic control horn
and back plate
2x12mm screw
.....2
...........4
CA
2 mm
FUSELAGE - REAR - BOTTOM VIEW / UNTERSICHT
2x12mm screw
Rudder servo
Seitenruder servo
Collar / Gewindestift
....................1
2x12mm screw / schraube
................4
Gewindestift
2mm ID collar
Spornrad
30mm
15A 15B
13
Elevator servo
Hohenruder servo
2x12mm screw
14
15

1- Slide the aluminum tube throughout the fuselage as shown.
2- Secure the aluminum tube in place with thin CA glue, ensuring that the
aluminum tube is accurately aligned : A=A’ (very important)
AA’
Carefully slide the wing halves to the fuselage, ensuring that they are accurately aligned, Firmly press the
two halves together.
CA CA
Thin CA
16
16A
16B

3x3mm
set screw
Linkage Stopper set
.....................4
CA
CA
CA
WARNING: Never fly your model without wing brace installed
because the wing of your model may be break when you fly
with high speed or a strong wind.
Note: all holes (2 holes)
on the surface of the top
of the wing are pre-drilled
at factory.
RIGHT
WRONG
5/64”
2mm
2.mm drill bit
Aluminum
tube inside 3x15mm screw
TOP 18A
Secure the wing in place
using 3x15mm screw.
3mm aluminum tube
17
18B
18
Note: All holes for the wing brace
installation are pre-drilled at factory

Note: Cut out the stickers and apply them in the proper area. Do not peel the backing paper off all at once.
Peel off one corner of the backing and cut off with scissors. Arrange sticker on model and when satisfied
adhere the corner without backing.
Carefully peel back the rest of the backing while at the same time adhering the rest of the sticker.
Try not to make air bubbles, if there are some, carefully puncture sticker (center of bubble) but not model
surface with the tip of the knife or sharp pin and squeeze out the air. At curves stretch sticker and apply a little
heat so that no ceases occur. Cut off the excess that is produced.
L/R
1
L/R
CA
2
WHITE SCHEME
L/R
Sticker
Sticker
CA
Antenna (plastic)
VQA037W
VQA037Y / VQA037W / VQA0371
Sticker
VQA0371
3G
EL
Sticker
VQA0371
BIRD VERSION
19
Cut away only
the covering
20

AB
Sticker
SWISS VERSION
VQA0362
Sticker
ALP VERSION
VQA0374
21
Sticker
Sticker
TURBOLENZA

70 ~ 75mm
20mm
10mm
10mm
10mm
Aileron
Rudder
Elevator
10mm
20mm
Querruderausschlag
Hohenruderausschlag
Seitenruderausschlag
Do not try to fly an out-of balance model!
Uberprufen Sie vor dem Flug den Schwerpunkt.
22
WARNING !
Do not put in a large-than recommended engine. A bigger engine does not necessarily mean better performance.
IMPORTANT: Please do not clean your model with pure alcohol, only use liquid soap with water or use glass cleaner
to clean on surface of your model to keep the colour not fade.
IN CASE OF FLOATING USING
X
Note: The landing gear for floating not included
This part must be purchased separately
Floats available as an option! (No. C4682)
Schwimmer als Sonderzubehör erhältlich! (Best.Nr.C4682)
X
Floats mounting (plywood)
Rear floats mounting
is pre-assembled
23
