Nexcom KPPC 1521A User manual

NEXCOM International Co., Ltd.
NEXCOM International Co., Ltd.
Published April 2018 www.nexcom.com
Intelligent Platform & Services Business Unit
Kiosk Panel PC
KPPC 1521A/1821A/2121A
User Manual

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. ii KPPC 1521A/1821A/2121A User Manual
Content
Contents
Preface
Copyright ............................................................................................. iv
Disclaimer.............................................................................................. iv
Acknowledgements ............................................................................... iv
Regulatory Compliance Statements........................................................ iv
Declaration of Conformity...................................................................... iv
RoHS Compliance ................................................................................... v
Warranty and RMA ................................................................................ vi
Safety Information ................................................................................. ix
Installation Recommendations................................................................ ix
Safety Precautions................................................................................... x
Technical Support and Assistance........................................................... xi
Conventions Used in this Manual........................................................... xi
Global Service Contact Information........................................................xii
Package Contents.................................................................................xiv
Ordering Information .............................................................................xv
Chapter 1: Product Introduction
KPPC 1521A/1821A/2121A Series ..........................................................1
Specifications..........................................................................................2
Knowing Your KPPC Series......................................................................4
Rear Top..............................................................................................4
Rear Bottom........................................................................................5
Rear ....................................................................................................6
Mechanical Dimensions...........................................................................7
KPPC 1521A........................................................................................7
KPPC 1821A........................................................................................8
KPPC 2121A........................................................................................9
Chapter 2: Jumpers and Connectors
Before You Begin ..................................................................................10
Precautions ..........................................................................................10
Jumper Settings ....................................................................................11
Locations of the Jumpers and Connectors.............................................12
Jumpers................................................................................................13
Clear RTC RAM .................................................................................13
LVDS1 Panel Voltage Selection Jumper...............................................13
AT/ATX Mode Select..........................................................................14
Chassis Intrusion Jumper ...................................................................14
COM2 Ring/+5V/+12V Select ............................................................15
Inverter1 Voltage Select.....................................................................15
Brightness Select ...............................................................................16
Connector Pin Definitions .....................................................................17
Internal Connectors...........................................................................17
Chassis Fan Connector...................................................................17
4-pin DC-In Power Connector ........................................................17
Serial Port Connectors....................................................................18
LVDS Connector.............................................................................18
LCD Panel Power Connector ..........................................................19
System Panel Connector.................................................................19
PS/2 Keyboard/Mouse Connector...................................................20

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. iii KPPC 1521A/1821A/2121A User Manual
Content
Serial ATA 6.0Gb/s Connectors.......................................................20
SATA Power Connector..................................................................21
BIOS Programmable Connector......................................................21
Digital I/O Connector .....................................................................22
Internal Audio Connectors .............................................................22
USB 2.0 Connectors.......................................................................23
Block Diagram .................................................................................24
Chapter 3: System Setup
Installing an SSD Storage Drive..............................................................25
Installing a Mini PCIe Module................................................................29
Installing an M.2 (2280) Module ...........................................................31
Installing Mounting Clips (Optional) ......................................................33
Chapter 4: BIOS Setup
About BIOS Setup.................................................................................34
When to Configure the BIOS.................................................................34
Default Configuration...........................................................................35
Entering Setup......................................................................................35
Legends................................................................................................35
BIOS Setup Utility..................................................................................37
Main .................................................................................................37
Advanced..........................................................................................38
Chipset..............................................................................................45
Security .............................................................................................47
Boot..................................................................................................48
Save & Exit ........................................................................................48

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. iv KPPC 1521A/1821A/2121A User Manual
Preface
PrefaCe
Copyright
This publication, including all photographs, illustrations and software, is
protected under international copyright laws, with all rights reserved. No
part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without the prior written consent from NEXCOM
International Co., Ltd.
Disclaimer
The information in this document is subject to change without prior notice and
does not represent commitment from NEXCOM International Co., Ltd. However,
users may update their knowledge of any product in use by constantly checking
its manual posted on our website: http://www.nexcom.com. NEXCOM shall
not be liable for direct, indirect, special, incidental, or consequential damages
arising out of the use of any product, nor for any infringements upon the rights
of third parties, which may result from such use. Any implied warranties of
merchantability or fitness for any particular purpose is also disclaimed.
Acknowledgements
KPPC 1521A/1821A/2121A is a trademark of NEXCOM International Co.,
Ltd. All other product names mentioned herein are registered trademarks of
their respective owners.
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class A devices and
describes how to keep the system CE compliant.
Declaration of Conformity
FCC
This equipment has been tested and verified to comply with the limits for
a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area
(domestic environment) is likely to cause harmful interference, in which
case the user will be required to correct the interference (take adequate
measures) at their own expense.
CE
The product(s) described in this manual complies with all applicable
European Union (CE) directives if it has a CE marking. For computer systems
to remain CE compliant, only CE-compliant parts may be used. Maintaining
CE compliance also requires proper cable and cabling techniques.

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. vKPPC 1521A/1821A/2121A User Manual
Preface
RoHS Compliance
NEXCOM RoHS Environmental Policy and Status
Update
NEXCOM is a global citizen for building the digital
infrastructure. We are committed to providing green
products and services, which are compliant with
European Union RoHS (Restriction on Use of Hazardous Substance in
Electronic Equipment) directive 2011/65/EU, to be your trusted green
partner and to protect our environment.
RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1%
or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or
1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.
In order to meet the RoHS compliant directives, NEXCOM has established
an engineering and manufacturing task force to implement the introduction
of green products. The task force will ensure that we follow the standard
NEXCOM development procedure and that all the new RoHS components
and new manufacturing processes maintain the highest industry quality
levels for which NEXCOM are renowned.
The model selection criteria will be based on market demand. Vendors and
suppliers will ensure that all designed components will be RoHS compliant.
How to recognize NEXCOM RoHS Products?
For existing products where there are non-RoHS and RoHS versions, the
suffix “(LF)” will be added to the compliant product name.
All new product models launched after January 2013 will be RoHS compliant.
They will use the usual NEXCOM naming convention.

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. vi KPPC 1521A/1821A/2121A User Manual
Preface
Warranty and RMA
NEXCOM Warranty Period
1. NEXCOM makes products in accordance with the Industry standard and,
NEXCOM warrants that all the Industry-grade IPC and System products
will be free from defect in neither material nor workmanship for twenty-
four (24) months from the day of invoice issued.
2. For NEXCOM Panel PC product lines (the APPC, MPPC and KPPC series),
they are also guaranteed against defect in materials and workmanship
for the period of twenty-four (24) months in their motherboard design.
For 3rd party parts, it follows with original suppliers’ standard: 12 months
for battery pack and LCD, 24 months for adaptor / add on modules
(including GSM module, RFID module, and antenna).
3. If NEXCOM determines customer’s warranty claim is valid, NEXCOM
will repair or replace product(s) without additional charge for parts and
labor. An extended Warranty Program will extend the warranty period of
the product accordingly.
Warranty Coverage
The warranty applies only to products manufactured or distributed by
NEXCOM and its subsidiaries. This warranty covers all the products/
shipments except for:
1. Any claimed defect, products that have been repaired or modified by
persons who have not been authorized by NEXCOM or, products which
have been subjected to misuse, abuse, accident, improper installation,
or usage not in accordance with the product instruction. NEXCOM
assumes no liability as a consequence of such events under the term of
this warranty.
One example is the replacement of Tablet’s or Hand-held’s LCD display
due to scratching stains or other degradation; these will not be covered
under this warranty.
2. Damages caused by customers’ delivery/shipping of the product
or, product failure resulted from electrical power/voltage shock, or,
installation of parts/components which are not supplied/approved by
NEXCOM in advance.
3. Third-party products:
a. Software, such as the device drivers,
b. External devices such as HDD, printer, scanner, mouse, LCD panel,
battery, and so on,
c. Accessory/parts that were not approved by NEXCOM and,
d. Accessory/parts were added to products after they were shipped
from NEXCOM.
Product will be treated as “Out of Warranty “ if:
a. It expires the warranted 24 months period from the day it was purchased.
b. It had been altered by persons other than an authorized NEXCOM
service person or, which have been subjected to misuse, abuse, accident,
or improper installation.
c. It doesn’t have the original NEXCOM Serial Number labeling for
NEXCOM’s warranty period identification or, tracking.

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. vii KPPC 1521A/1821A/2121A User Manual
Preface
RMA that NEXCOM has determined not to be covered by the warranty will
be charged the NEXCOM Standard Repair Fee for the repairing. If a RMA is
determined to be not repairable, customer will be notified and product(s)
may be returned to customer at their request; a minimum service fee may
be charged however.
NEXCOM Return Merchandise Authorization (RMA) Procedure
For the RMA (Return Merchandise Authorization) shipment, customer
is responsible for packaging and shipping the product to the designated
NEXCOM service sites, with shipping charges prepaid by the customer. The
original NEXCOM shipping box should be used whenever possible. NEXCOM
shall pay for the return of the product to the customer’s location. In case of
expedited shipping request, an extra service charge shall be assessed and
the customer is responsible for this extra return shipping charge.
1. Customers should enclose the “NEXCOM RMA Service Form” with the
returned products.
2. Customers need to write down all the information related to the problem
on the “ NEXCOM RMA Service Form “ when applying for the RMA
service; information will help to understand the problem, including the
fault description, on-screen messages, and pictures if possible.
3. Customers could send back the faulty product with or without the
accessories and key parts such as the CPU and DIMM. If the key parts are
included, please be noted clearly within the return form. NEXCOM takes
no responsibility for the parts which are not listed in the return form.
4. Customers hold the responsibility to ensure that the packing of defective
products is durable enough to be resistant against further damage due
to the transportation; damage caused by transportation is treated as “
Out of Warranty “ under our Warranty specification.
5. RMA product(s) returned by NEXCOM to any location other than the
customer registered delivery address will incur an extra shipping charge,
the customer is responsible for paying the extra shipping charges, duties,
and taxes of this shipment.
Product Repairing
1. NEXCOM will repair defective products covered under this limited
warranty that are returned to NEXCOM; if products do prove to be
defective, they will be repaired during their warranty period unless other
warranty terms have been specified.
2. NEXCOM owns all parts removed from repaired products.
3. NEXCOM will use parts made by various manufacturers in performing
the repair.
4. The repaired products will be warranted subjected to the original
warranty coverage and period only.
5. For products returned as defective but, proved to be no defect/fault after
the RMA process, NEXCOM reserves the right to claim for a NDF (No
Defect Found) Service Charge.
6. NEXCOM will issue RMA Report which included Repair Detailed
Information to the customer when the defective products were repaired
and returned.
7. In addition to the above, NEXCOM may authorize Independent/Third-
party suppliers to repair the defective products for NEXCOM.

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. viii KPPC 1521A/1821A/2121A User Manual
Preface
Out Of Warranty Service
There will be a service charge from NEXCOM for the “Out Of Warranty”
product service; they are the Basic Diagnostic Service Fee and the Advanced
Component Replacement Fee respectively. And, if the product can not be
repaired, NEXCOM will either return the product to the customer or, just
scrap it, followed by customer’s instruction.
1. Testing and Parts Replacement
NEXCOM will have the following Handling Charges for those OoW
products that returned:
a. Basic Labor Cost and Testing Fee: as Table listed.
b. Parts Fee: NEXCOM will charge for main IC chipsets such as the N.B.,
S.B., Super-IO, LAN, Sound, Memory, and so on.
c. 3rd-party Device Fee: products replacement for CPU, DIMM, HDD,
Chassis, and UPS.
2. Out of Warranty product will have a three months warranty for the fixed
issues. If the product failed with different problem within 3 months, they
will still incur the service charge of “Out of Warranty”.
3. Out of Warranty “products will not be repaired without a signed PI from
the customer, the agreement of the repair process.
Add-on card, 3rd Party Device and board level repair cost higher than
new product prices, customer can abandon to sign PI to repair and,
please contact with sales to buy new products.

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. ix KPPC 1521A/1821A/2121A User Manual
Preface
Installation Recommendations
Ensure you have a stable, clean working environment. Dust and dirt can get
into components and cause a malfunction. Use containers to keep small
components separated.
Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
▪A Philips screwdriver
▪A flat-tipped screwdriver
▪A grounding strap
▪An anti-static pad
Using your fingers can disconnect most of the connections. It is recommended
that you do not use needle-nose pliers to disconnect connections as these
can damage the soft metal or plastic parts of the connectors.
Safety Information
Before installing and using the device, note the following precautions:
▪Read all instructions carefully.
▪Do not place the unit on an unstable surface, cart, or stand.
▪Follow all warnings and cautions in this manual.
▪When replacing parts, ensure that your service technician uses parts
specified by the manufacturer.
▪Avoid using the system near water, in direct sunlight, or near a heating
device.
▪The load of the system unit does not solely rely for support from the
rackmounts located on the sides. Firm support from the bottom is highly
necessary in order to provide balance stability.
▪The computer is provided with a battery-powered real-time clock circuit.
There is a danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer’s instructions.

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. xKPPC 1521A/1821A/2121A User Manual
Preface
Safety Precautions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a stable surface during installation. Dropping it or
letting it fall may cause damage.
7. The openings on the enclosure are for air convection to protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting
the equipment to the power outlet.
9. Place the power cord in a way so that people will not step on it. Do not
place anything on top of the power cord. Use a power cord that has been
approved for use with the product and that it matches the voltage and
current marked on the product’s electrical range label. The voltage and
current rating of the cord must be greater than the voltage and current
rating marked on the product.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical
shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b.Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d.The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. Do not place heavy objects on the equipment.
16. The unit uses a three-wire ground cable which is equipped with a third
pin to ground the unit and prevent electric shock. Do not defeat the
purpose of this pin. If your outlet does not support this kind of plug,
contact your electrician to replace your obsolete outlet.
17. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. xi KPPC 1521A/1821A/2121A User Manual
Preface
Technical Support and Assistance
1. For the most updated information of NEXCOM products, visit NEXCOM’s
website at www.nexcom.com.
2. For technical issues that require contacting our technical support team or
sales representative, please have the following information ready before
calling:
– Product name and serial number
– Detailed information of the peripheral devices
– Detailed information of the installed software (operating system,
version, application software, etc.)
– A complete description of the problem
– The exact wordings of the error messages
Warning!
1. Handling the unit: carry the unit with both hands and handle it with care.
2. Maintenance: to keep the unit clean, use only approved cleaning products
or clean with a dry cloth.
Conventions Used in this Manual
Warning:
Information about certain situations, which if not observed,
can cause personal injury. This will prevent injury to yourself
when performing a task.
CAUTION!
CAUTION!CAUTION! Caution:
Information to avoid damaging components or losing data.
Note:
Provides additional information to complete a task easily.

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. xii KPPC 1521A/1821A/2121A User Manual
Preface
Global Service Contact Information
Headquarters
NEXCOM International Co., Ltd.
9F, No. 920, Chung-Cheng Rd.,
ZhongHe District, New Taipei City, 23586,
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
www.nexcom.com
America
USA
NEXCOM USA
2883 Bayview Drive,
Fremont CA 94538, USA
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com
Asia
Taiwan
NEXCOM Intelligent Systems
Taipei Office
13F, No.920, Chung-Cheng Rd.,
ZhongHe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
NEXCOM Intelligent Systems
Taichung Office
16F, No.250, Sec. 2, Chongde Rd.,
Beitun Dist.,
Taichung City 406, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
Japan
NEXCOM Japan
9F, Tamachi Hara Bldg.,
4-11-5, Shiba Minato-ku,
Tokyo, 108-0014, Japan
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom-jp.com
China
NEXCOM China
Floor 5, No.4, No.7 fengxian middle Rd.,
(Beike Industrial Park), Haidian District,
Beijing, 100094, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. xiii KPPC 1521A/1821A/2121A User Manual
Preface
Europe
United Kingdom
NEXCOM EUROPE
10 Vincent Avenue,
Crownhill Business Centre,
Milton Keynes, Buckinghamshire
MK8 0AB, United Kingdom
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.eu
Italy
NEXCOM ITALIA S.r.l
Via Lanino 42,
21047 Saronno (VA), Italia
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcomitalia.it
NEXCOM Shanghai
Room 603/604, Huiyinmingzun Plaza Bldg., 1,
No.609, Yunlin East Rd.,
Shanghai, 200333, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM Surveillance Technology Corp.
Room202, Building B,
the GuangMing Industrial Zone Zhonghua Rd.,
Minzhi Street, Longhua District,
Shenzhen 518131, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM United System Service
Hui Yin Ming Zun Building Room 1108,
Building No. 11, 599 Yunling Road, Putuo District,
Shanghai, 200062, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. xiv KPPC 1521A/1821A/2121A User Manual
Preface
Package Contents
Before continuing, verify that the KPPC 1521A/1821A/2121A series package
that you received is complete. Your package should have all the items listed
in the following table.
KPPC 1521A/1821A/2121A Series
Item Name Qty
1 12V 60W power adapter w/o power cord 1
2 SSD Bracket 2
Power Adapter
SSD Bracket
Panel Mounting Clips x12
KPPC 1521A/1821A/2121A Series (Optional)
Item Name Qty
1 Panel Mounting Clips x12 (P/N: 88YK0212100X0) 12

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. xv KPPC 1521A/1821A/2121A User Manual
Preface
Ordering Information
The following information below provides ordering information for the
KPPC 1521A/1821A/2121A series.
Barebone
• KPPC 1521A (P/N: 10YK0152100X0)
15.6“ LED backlight touch panel PC with Intel®Celeron®N3060 Processor,
w/ VGA and DVI-D, 2 x GbE LAN, 4 x USB 3.0, 1 x USB 2.0, 5 x Serial Port,
1 x Line Out, 1 x Mic in.
• 12V 60W power adapter w/o power cord
• SSD Bracket x2 (P/N: 5061700832X00)
• KPPC 1821A (P/N: 10YK0182100X0)
18.6“ LED backlight touch panel PC with Intel®Celeron®N3060 Processor,
w/ VGA and DVI-D, 2 x GbE LAN, 4 x USB 3.0, 1 x USB 2.0, 5 x Serial Port,
1 x Line Out, 1 x Mic in.
• 12V 60W power adapter w/o power cord
• SSD Bracket x2 (P/N: 5061700832X00)
• KPPC 2121A (P/N: 10YK0212102X0)
21.5“ LED backlight touch panel PC with Intel®Celeron®N3060 Processor,
w/ VGA and DVI-D, 2 x GbE LAN, 4 x USB 3.0, 1 x USB 2.0, 5 x Serial Port,
1 x Line Out, 1 x Mic in.
• 12V 60W power adapter w/o power cord
• SSD Bracket x2 (P/N: 5061700832X00)
Optional
• Memory DDR3L 1600MHz
4GB (P/N: 729BM04G18X00/729BM04G60X00)
8GB (P/N: 729BM08G10X00/729BM08G28X00)
• 2.5” SSD SATA 6.0Gb/s
64GGB (P/N: 73SE064G40X00/73SE064G42X00)
128GB (P/N: 73SE128G38X00/73SE128G47X00)
256GB (P/N: 73SE256G14X00/73SE256G22X00)
• M.2 2280 SSD SATA 6.0Gb/s, MLC 64GB (P/N: 73ND064G03X00)
• Panel Mounting Clips x12 (P/N: 88YK0212100X0)

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. 1
Chapter 1: Product Introduction
KPPC 1521A/1821A/2121A User Manual
ChaPter 1: ProduCt IntroduCtIon
Key Features
▪Intel®Celeron®Processor N3060
▪(1366x768), P-Cap multi-Touch display (KPPC 1521A/1821A)
▪FHD (1920x1080), P-Cap multi-Touch display (KPPC 2121A)
▪Support VGA, DVI-D, GbE LAN x2, COM x5, USB 3.0 x4, Line-out/Mic-in x1
▪Mounting support: Panel/Wall/Stand/VESA
▪Metal housing with robust aluminum IP65 compliant front bezel for harsh
environment
▪Fanless Design
KPPC 1521A/1821A/2121A Series
Overview

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. 2
Chapter 1: Product Introduction
KPPC 1521A/1821A/2121A User Manual
Specifications
Panel
KPPC 1521A
▪LCD size: 15.6”, 16:9
▪Resolution: 1366 x 768
▪Luminance: 400 cd/m²
▪Contrast ratio: 500
▪LCD color: 16.7M
▪Viewing angle: 80(U), 80(D), 85(L), 85(R)
▪Backlight: LED
KPPC 1821A
▪LCD size: 18.5”, 16:9
▪Resolution: 1366 x 768
▪Luminance: 250 cd/m²
▪Contrast ratio: 1000
▪LCD color: 16.7M
▪Viewing angle: 80(U), 80(D), 85(L), 85(R)
▪Backlight: LED
KPPC 2121A
▪LCD size: 21.5”, 16:9
▪Resolution: FHD, 1920 x 1080
▪Luminance: 250 cd/m²
▪Contrast ratio: 3000
▪LCD color: 16.7M
▪Viewing angle: 89(U), 89(D), 89(L), 89(R)
▪Backlight: LED
Touchscreen
▪Ten points P-Cap (projected capacitive touch)
▪Light transmission: 86%
▪Interface: USB
▪Anti-scratch surface: 7H hardness
System
▪CPU: Intel®Celeron®Processor N3060, up to 2.48GHz, Cache 2 MB L2
▪Memory: 1x DDR3L 1600MHz SO-DIMM, up to 8GB, Non-ECC,
Un-buffered
▪Graphics: Intel®HD Graphics 400
▪BIOS: AMI BIOS
▪Expansion: 1 x Mini-PCIe, 1 x M.2 (2280)
Storage device
▪1 x 2.5” SATA SSD 6.0Gb/s
▪1 x M.2 M-key (2280)
Power Requirements
▪Single power 12V DC input
Front I/O
▪Power on/off button
▪1 x USB 2.0
Rear I/O
▪2 x GbE LAN Realtek RTL8111G
▪4 x USB 3.0
▪1 x DVI-D
▪1 x VGA

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. 3
Chapter 1: Product Introduction
KPPC 1521A/1821A/2121A User Manual
▪4 x RS232
▪1 x RS232/422/485
▪1 x HD AUDIO Line-out/Line-in/Mic-in
▪1 x 12V DC-In Lockable Power Jack
Mechanical & Environment
▪IP protection: IP65 Panel front side
▪Mounting: panel/wall/VESA 100mm x 100mm
▪Operating temperature: 32° to 122°F (0°C to 50°C)
▪Storage temperature: -4°F to 140°C (-20°C to 60°C)
▪Operating humidity: 10%~90% relative humidity, non-condensing
▪Dimension:
– 417.80 (W) x 318.80 (H) x 66.25 (D) mm (KPPC 1521A)
– 490.80 (W) x 320.60 (H) x 65.15 (D) mm (KPPC 1821A)
– 562.40 (W) x 382.40 (H) x 65.35 (D) mm (KPPC 2121A)
▪Weight:
– 6.2kg (KPPC 1521A)
– 6.8kg (KPPC 1821A)
– 8.7kg (KPPC 2121A)
Operating System
▪Windows 10 IoT 64-bit
▪Windows 8.1 64-bit
▪Windows 7 32/64-bit
Certificate
▪EMC & Safety
▪CE/FCC Class A

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. 4
Chapter 1: Product Introduction
KPPC 1521A/1821A/2121A User Manual
Knowing Your KPPC Series
Rear Top
Power Switch
Press to power-on or power-off the panel PC.
USB 2.0
Used to connect USB 2.0/1.1 devices.
HDD LED
Indicates the hard drive activity of the system.
Power switch
USB 2.0
HDD LED

Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved. 5
Chapter 1: Product Introduction
KPPC 1521A/1821A/2121A User Manual
Rear Bottom 12V DC Input
Used to plug a DC power cord.
COM1 to COM5
Serial ports to connect with compatible serial devices.
VGA
Used to connect an analog VGA monitor.
DVI-D
Used to connect a DVI-D interface monitor.
LAN
Dual Gigabit LAN port to connect the system to a local area network.
USB 3.0
USB 3.0 ports to connect the system with USB 3.0/2.0 devices.
Line-out
Used to connect a headphone or a speaker.
Mic-in
Used to connect an external microphone.
VGA
12V
DC Input
COM 5
COM 3
COM 4LAN
COM 1
Mic-in
Line-out
DVI-D
COM 2
USB 3.0
