OPERATING INSTRUCTIONS
NI 9866
1-Port, LIN Module
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9866 Operating Instructions 2 ni.com
These operating instructions describe how to use the National
Instruments (NI) 9866 module. For information about installing,
configuring, and programming your system, refer to your system
documentation. The NI 9866 module requires the latest NI-XNET
software to be installed. The latest version of the NI-XNET
software is at ni.com/downloads.
Note The safety guidelines and specifications in this
document are specific to the NI 9866. The other
components in your system may not meet the same safety
ratings and specifications. Refer to the documentation for
each component in your system to determine the safety
ratings and specifications for the entire system.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments 3 NI 9866 Operating Instructions
Safety Guidelines
Caution Do not operate the NI 9866 in a manner not
specified in the user manual or operating instructions.
Product misuse can result in a hazard. You can
compromise the safety protection built into the product if
the product is damaged in any way. If the product is
damaged, return it to National Instruments for repair.
Hot Surface This icon denotes that the component may be
hot. Touching this component may result in bodily injury.
Safety Guidelines for Hazardous Locations
The NI 9866 is suitable for use in Class I, Division 2, Groups A, B,
C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4 and
Ex nA IIC T4 hazardous locations; and nonhazardous locations
only. Follow these guidelines if you are installing the NI 9866 in a
potentially explosive environment. Not following these guidelines
may result in serious injury or death.
Caution Do not disconnect I/O-side wires or connectors
unless power has been switched off or the area is known
to be nonhazardous.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9866 Operating Instructions 4 ni.com
Caution Do not remove modules unless power has been
switched off or the area is known to be nonhazardous.
Caution Substitution of components may impair
suitability for Class I, Division 2.
Caution For Zone 2 applications, install the
CompactRIO system in an enclosure rated to at least
IP 54 as defined by IEC 60529 and EN 60529.
Caution For Zone 2 applications, install a protection
device between the LIN signals and the NI 9866 LIN
pins. The device must prevent the LIN Port-to-COM
voltage from exceeding 55 V if there is a transient
overvoltage condition.
Special Conditions for Safe Use in Europe
This equipment has been evaluated as Ex nA IIC T4 equipment
under DEMKO Certificate No. 07 ATEX 0626664X. Each module
is marked II 3G and is suitable for use in Zone 2 hazardous
locations.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments 5 NI 9866 Operating Instructions
Wiring the NI 9866
The NI 9866 has one 9-pin male D-Sub connector that provides
connections to a LIN bus.
The port has two common pins (COM) that are internally
connected to the module’s isolated reference and serve as the
reference ground for LIN signal. You can connect the LIN bus
reference ground to one or both COM pins. The port also has an
optional shield pin, SHLD, that you can connect to a shielded LIN
cable. Connecting SHLD may improve signal integrity and EMC
performance in a noisy environment.
Caution You must use a UL listed ITE power supply
marked LPS with the NI 9866.
The NI 9866 requires an external power supply of +8 to +18 V to
operate. Supply power to the NI 9866 VSUP pin from the LIN bus.
Note Power on VSUP is required for LIN operation.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9866 Operating Instructions 6 ni.com
The NI 9866 pinout is listed in Table 1.
Table 1. Pin Assignments for the NI 9866
Connector Pin Signal
1No Connection (NC)
2NC
3COM
4NC
5SHLD
6COM
7LIN
8NC
9 VSUP
6
7
8
9
1
2
3
4
5
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments 7 NI 9866 Operating Instructions
Cabling Requirements for NI 9866
This section deals with cabling specifications, termination
resistors, cable lengths, and the number of LIN nodes that can exist
in a system.
Cable Specifications
LIN cables should meet the physical medium requirement of a bus
RC time constant of 5 µs. For detailed formulas for calculating this
value, refer to the Line Characteristics section of the LIN
specification. Belden cable (3084A) and other unterminated
CAN/Serial quality cables meet these requirements and should be
suitable for most applications.
Cable Lengths
The maximum allowable cable length is 40 m, per the LIN
specification.
Number of LIN Devices
The maximum number of devices on a LIN bus is 16, per the LIN
specification.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9866 Operating Instructions 8 ni.com
Termination Resistors
LIN cables require no termination, as nodes are terminated at the
transceiver. Slave nodes typically are pulled up from the LIN bus
to VBat with a 30 kΩresistance and a serial diode. This
termination usually is integrated into the transceiver package. The
master node requires a 1 kΩresistor and serial diode between the
LIN bus and VBat. On NI-XNET LIN products, master
termination is software selectable; you can enable it in the API
with the NI-XNET Session Interface:LIN:Termination property.
NI 9866 Hardware Overview
The NI 9866 has one full-featured LIN port that is isolated from
the other modules in the system. The port has a LIN controller
that is fully compliant with the LIN 1.3/2.0/2.1/2.2 Specification.
The port also has an NXP TJA1028 LIN transceiver that is fully
compatible with the LIN 1.3/2.0/2.1/2.2 and SAE J2602 standard
and supports baud rates up to 20 kbps.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments 9 NI 9866 Operating Instructions
Figure 1. NI 9866 Hardware Overview
Specifications
The following specifications are typical for the range –40 to 70 °C
unless otherwise noted.
LIN Characteristics
Transceiver........................................ NXP TJA1028
Max baud rate ................................... 20 kbps
LIN bus lines voltage........................ –40 to +40 VDC
Ext Pwr
Supply
Required
Rx
Tx
LIN
Controller LIN
LIN
Transceiver
Rx
Tx
COM
Vsup
+
_
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9866 Operating Instructions 10 ni.com
Supply voltage range (VSUP .............. +8 to +18 VDC normal
operation, –0.3 to +40 V
absolute limits
MTBF ............................................... Contact NI for Bellcore
MTBF or MIL-HDBK-217F
specifications
Power Requirements
Power consumption from chassis .....1 W max (active mode)
Thermal dissipation (at 70 °C).......... 1.25 W max (active mode)
Physical Characteristics
Caution If you need to clean your NI 9866, wipe it with
a dry towel. The product must be completely dry and free
from contaminants before you return it to service.
Weight............................................... Approx. 144 g (5.0 oz)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments 11 NI 9866 Operating Instructions
Safety
Maximum Voltage1
Connect only voltages that are within these limits.
Port-to-COM..................................... –40 to +40 VDC max,
Measurement Category I
Measurement Category I is for measurements performed on
circuits not directly connected to the electrical distribution system
referred to as MAINS voltage. MAINS is a hazardous live electrical
supply system that powers equipment. This category is for
measurements of voltages from specially protected secondary
circuits. Such voltage measurements include signal levels, special
equipment, limited-energy parts of equipment, circuits powered by
regulated low-voltage sources, and electronics.
Caution Do not connect to signals or use for
measurements within Measurement Categories II, III,
or IV.
1 The maximum voltage that can be applied or output between any port or VSUP
terminal and a COM terminal without creating a safety hazard.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9866 Operating Instructions 12 ni.com
Isolation Voltages
Port-to-earth ground
Withstand.................................... 1000 Vrms, verified by a 5 s
dielectric withstand test
Continuous ................................. 60 VDC,
Measurement Category I
Safety Standards
This product meets the requirements of the following standards of
safety for electrical equipment for measurement, control, and
laboratory use:
• IEC 61010-1, EN 61010-1
• UL 61010-1, CSA 61010-1
Note For UL and other safety certifications, refer to the
product label or the Online Product Certification section.
Hazardous Locations
U.S. (UL) .......................................... Class I, Division 2,
Groups A, B, C, D, T4;
Class I, Zone 2,
AEx nA IIC T4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments 13 NI 9866 Operating Instructions
Canada (C-UL) ................................. Class I, Division 2,
Groups A, B, C, D, T4;
Class I, Zone 2,
Ex nA IIC T4
Europe (DEMKO)............................. Ex nA IIC T4
Environmental
Refer to the installation instructions for the chassis you are using
for more information about meeting these specifications.
Operating temperature ...................... –40 to 70 °C
Storage temperature .......................... –40 to 85 °C
Ingress protection.............................. IP 40
Operating humidity........................... 10 to 90% RH,
noncondensing
Storage humidity............................... 5 to 95% RH, noncondensing
Pollution Degree (IEC 60664) .......... 2
Maximum altitude............................. 2,000 m
Indoor use only.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9866 Operating Instructions 14 ni.com
Shock and Vibration
To meet these specifications, you must panel mount the
CompactRIO system.
Operating vibration,
random (IEC 60068-2-64.................. 5 grms, 10 to 500 Hz
Operating shock
(IEC 60068-2-27).............................. 30 g, 11 ms half sine,
50 g, 3 ms half sine,
18 shocks at 6 orientations
Operating vibration,
sinusoidal (IEC 60068-2-6) .............. 5 g, 10 to 500 Hz
Electromagnetic Compatibility
This product meets the requirements of the following EMC
standards for electrical equipment for measurement, control, and
laboratory use:
• EN 61326 (IEC 61326): Class A emissions; Basic immunity
• EN 55011 (CISPR 11): Group 1, Class A emissions
• AS/NZS CISPR 11: Group 1, Class A emissions
• FCC 47 CFR Part 15B: Class A emissions
• ICES-001: Class A emissions
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments 15 NI 9866 Operating Instructions
Note For the standards applied to assess the EMC of this
product, refer to the Online Product Certification section.
Note For EMC compliance, operate this product
according to the documentation.
CE Compliance
This product meets the essential requirements of applicable
European Directives as follows:
• 2006/95/EC; Low-Voltage Directive (safety)
• 2004/108/EC; Electromagnetic Compatibility Directive
(EMC)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9866 Operating Instructions 16 ni.com
Online Product Certification
Refer to the product Declaration of Conformity (DoC) for
additional regulatory compliance information. To obtain
product certifications and the DoC for this product, visit ni.com/
certification, search by model number or product line, and
click the appropriate link in the Certification column.
Environmental Management
NI is committed to designing and manufacturing products in an
environmentally responsible manner. NI recognizes that
eliminating certain hazardous substances from our products is
beneficial to the environment and to NI customers.
For additional environmental information, refer to the NI and the
Environment Web page at ni.com/environment. This page
contains the environmental regulations and directives with which
NI complies, as well as other environmental information not
included in this document.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments 17 NI 9866 Operating Instructions
Waste Electrical and Electronic Equipment (WEEE)
EU Customers At the end of the product life cycle, all
products must be sent to a WEEE recycling center. For
more information about WEEE recycling centers,
National Instruments WEEE initiatives, and
compliance with WEEE Directive 2002/96/EC on
Waste and Electronic Equipment, visit
ni.com/environment/weee.
⬉ᄤֵᙃѻક∵ᶧ᥻ࠊㅵ⧚ࡲ⊩ ˄Ё೑ RoHS˅
Ё೑ᅶ᠋ National Instruments ヺড়Ё೑⬉ᄤֵᙃ
ѻકЁ䰤ࠊՓ⫼ᶤѯ᳝ᆇ⠽䋼ᣛҸ (RoHS)DŽ݇Ѣ
National Instruments Ё೑ RoHS ড়㾘ᗻֵᙃˈ䇋ⱏᔩ
ni.com/environment/rohs_chinaDŽ(For information
about China RoHS compliance, go to ni.com/
environment/rohs_china.)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9866 Operating Instructions 18 ni.com
Where to Go for Support
The National Instruments Web site is your complete resource for
technical support. At ni.com/support you have access to
everything from troubleshooting and application development
self-help resources to email and phone assistance from
NI Application Engineers.
National Instruments corporate headquarters is located at
11500 North Mopac Expressway, Austin, Texas, 78759-3504.
National Instruments also has offices located around the world to
help address your support needs. For telephone support in the
United States, create your service request at ni.com/support
and follow the calling instructions or dial 512 795 8248. For
telephone support outside the United States, visit the Worldwide
Offices section of ni.com/niglobal to access the branch office
Web sites, which provide up-to-date contact information, support
phone numbers, email addresses, and current events.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© 2011–2012 National Instruments. All rights reserved.
373710B-01 Apr12
LabVIEW, National Instruments, NI, ni.com, the National Instruments corporate logo, and the Eagle logo are
trademarks of National Instruments Corporation. Refer to the Trademark Information at ni.com/trademarks
for other National Instruments trademarks. Other product and company names mentioned herein are trademarks or
trade names of their respective companies. For patents covering National Instruments products/technology, refer
to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the
National Instruments Patent Notice at ni.com/patents. Refer to the Export Compliance Information at
ni.com/legal/export-compliance for the National Instruments global trade compliance policy and
how to obtain relevant HTS codes, ECCNs, and other import/export data.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
