SAFETY, ENVIRONMENTAL, AND REGULATORY INFORMATION
FDT-16040
Field Diagnostic Tester for ECU Test System 24U
Read this document and the documents listed in the Additional Resources section about installation, configuration, and operation of this product before you
install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to
requirements of all applicable codes, laws, and standards.
Notice The FDT-16040 is intended for operation only in conjuction with the ECU Test System. Refer to the ECU Test System documentation for
more information about using this product.
Icons
Notice Take precautions to avoid data loss, loss of signal integrity, degradation of performance, or damage to the product.
Caution Take precautions to avoid injury. Consult the product documentation for cautionary statements when you see this icon printed on the
product. Cautionary statements are localized into French for compliance with Canadian requirements.
Safety
Caution Observe all instructions and cautions in the user documentation. Using the product in a manner not specified can damage the product and
compromise the built-in safety protection. Contact your NI services personnel if your product is damaged.
Attention Suivez toutes les instructions et respectez toutes les mises en garde de la documentation d'utilisation. L'utilisation du produit de toute autre
façon que celle spécifiée risque de l'endommager et de compromettre la protection de sécurité intégrée. Contactez le personnel des services techniques
NI si votre produit est endommagé.
Caution The product is designed for non-hazardous live signals. You must ensure that all signals connected to the product are isolated from
hazardous live circuits and no unsafe voltages are present at the product inputs. Voltages that exceed the specifications could result in damage to the
product.
Attention Le produit est conçu pour les signaux en direct non dangereux. Vous devez vous assurer que tous les signaux connectés au produit sont
isolés des circuits dangereux sous tension et qu'aucune tension dangereuse n'est présente à ses entrées. Des tensions supérieures à celles mentionnées
dans les spécifications peuvent endommager le produit.
Caution Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.
Attention Risque d'explosion si la pile est remplacée par un type de pile incorrect. Reportez-vous à la documentation de l'appareil sur ni.com/
manuals pour obtenir des informations sur le remplacement, l'élimination et le recyclage de sa pile.
Safety Compliance Standards
This product is designed to meet the requirements of the following electrical equipment safety standards for measurement, control, and laboratory use:
• IEC 61010-1, EN 61010-1
• UL 61010-1, CSA C22.2 No. 61010-1
Note For safety certifications, refer to the product label or the Product Certifications and Declarations section.
EMC Guidelines
This product was tested and complies with the regulatory requirements and limits for electromagnetic compatibility (EMC) as stated in the ECU Test System
specifications. These requirements and limits are designed to provide reasonable protection against harmful interference when the product is operated in its
intended operational electromagnetic environment.
This product is intended for use in commercial and light-industrial locations. However, harmful interference may occur in some installations, when the product
is connected to a peripheral device or test object other than the ECU Test System, or if the product is used in residential areas. To minimize interference with
radio and television reception and prevent unacceptable performance degradation, install and use this product in strict accordance with the instructions in the
ECU Test System documentation.
Furthermore, any changes or modifications to the product not expressly approved by NI could void your authority to operate it under your local regulatory
rules.

EMC Notices
Refer to the following notices for cables, accessories, and prevention measures necessary to ensure the specified EMC performance.
Notice For EMC declarations and certifications, and additional information, refer to the Product Certifications and Declarations section.
Notice Changes or modifications to the product not expressly approved by NI could void your authority to operate the product under your local
regulatory rules.
EMC Standards
This product meets the requirements of the following EMC standards for electrical equipment for measurement, control, and laboratory use:
• EN 61326-1 (IEC 61326-1): Class A emissions; Basic immunity
• EN 55011 (CISPR 11): Group 1, Class A emissions
• AS/NZS CISPR 11: Group 1, Class A emissions
Korean Standards
• K11: Emissions
• KN 61000-6-2: Immunity
Note Group 1 equipment (per CISPR 11) is any industrial, scientific, or medical equipment that does not intentionally generate radio frequency
energy for the treatment of material or inspection/analysis purposes.
Note In the United States, Class A equipment is intended for use in commercial, light-industrial, and heavy-industrial locations. In Europe, Australia,
and New Zealand (per CISPR 11) Class A equipment is intended for use in non-residential locations.
Environmental Guidelines
Notice This product is intended for use in indoor applications only.
Environmental Characteristics
Temperature
Operating 5 °C to 40 °C
Storage 0 °C to 60 °C
Humidity
Operating 20% to 80%, noncondensing
Storage 10% to 80%, noncondensing
Pollution Degree 2
Maximum altitude 2,000 m
Environmental Management
NI is committed to designing and manufacturing products in an environmentally responsible manner. NI recognizes that eliminating certain hazardous
substances from our products is beneficial to the environment and to NI customers.
For additional environmental information, refer to the Commitment to the Environment web page at ni.com/environment. This page contains the environmental
regulations and directives with which NI complies, as well as other environmental information not included in this document.
Waste Electrical and Electronic Equipment (WEEE)
EU Customers At the end of the product life cycle, all NI products must be disposed of according to local laws and regulations. For more
information about how to recycle NI products in your region, visit ni.com/environment/weee.
Battery Directive, Recycling, and Replacement
Cd/Hg/Pb
Battery Directive For more information about compliance with the EU Battery Directive 2006/66/EC about Batteries and Accumulators and Waste
Batteries and Accumulators, visit ni.com/environment/batterydirective.
The product may contain one or multiple replaceable batteries in the incorporated products or components. Products containing lithium must be disposed of or
recycled in accordance with all local laws and site regulations.
This product may contain one or multiple batteries in the incorporated products or components. If you need to replace the battery in an NI-branded product or
component, refer to user manual for the incorporated product or component for battery replacement instructions. You can find documentation for NI-branded
products and components online at ni.com/manuals. For third-party products or components, refer to the manufacturer’s website for battery replacement
instructions.
2| ni.com | FDT-16040 Safety, Environmental, and Regulatory Information

电子信息产品污染控制管理办法（中国 RoHS）
中国客户 National Instruments 符合中国电子信息产品中限制使用某些有害物质指令(RoHS)。关于 National Instruments 中国 RoHS 合规性信
息，请登录 ni.com/environment/rohs_china。(For information about China RoHS compliance, go to ni.com/environment/
rohs_china.)
Power Requirements
Input power
Nominal 12 VDC and 24 VDC
Maximum 20 W
Input power receptacle ECU Test System, J22
Physical Characteristics
Dimensions
Width 446 mm (17.6 in.)
Depth 409 mm (16.1 in.)
Height 187 mm (7.4 in.)
Weight 10.8 kg (23.8 lbs)
CE Compliance
This product meets the essential requirements of applicable European Directives, as follows:
• 2014/30/EU; Electromagnetic Compatibility Directive (EMC)
• 2011/65/EU; Restriction of Hazardous Substances (RoHS)
Export Compliance
This product is subject to control under the U.S. Export Administration Regulations (15 CFR Part 730 et. seq.) administered by the U.S. Department of
Commerce's Bureau of Industry and Security (BIS) (www.bis.doc.gov) and other applicable U.S. export control laws and sanctions regulations. This product
may also be subject to additional license requirements of other countries' regulations.
Additionally, this product may also require export licensing before being returned to NI. The issuance of a Return Material Authorization (RMA) by NI does
not constitute export authorization. The user must comply with all applicable export laws prior to exporting or re-exporting this product. See ni.com/legal/
export-compliance for more information and to request relevant import classification codes (e.g. HTS), export classification codes (e.g. ECCN), and other
import/export data.
Product Certifications and Declarations
Refer to the product Declaration of Conformity (DoC) for additional regulatory compliance information. To obtain product certifications and the DoC for NI
products, visit ni.com/product-certifications, search by model number, and click the appropriate link.
Additional Resources
Visit ni.com/manuals for more information about your product, including specifications, pinouts, and instructions for connecting, installing, and configuring
your system.
Worldwide Support and Services
The NI website is your complete resource for technical support. At ni.com/support, you have access to everything from troubleshooting and application
development self-help resources to email and phone assistance from NI Application Engineers.
Visit ni.com/services for information about the services NI offers.
Visit ni.com/register to register your NI product. Product registration facilitates technical support and ensures that you receive important information updates
from NI.
NI corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504, USA. For up-to-date contact information for your
location, visit ni.com/contact.
