Nice BiDi-WiFi Product manual

Nice
BiDi-WiFi
BiDi-WiFi radio interface
EN - Instructions and warnings for the INSTALLER
  toinstallandcongureNicecontrolunits

2 – ENGLISH
ENGLISH
Translation of the original instructions in full
CONTENTS
GENERAL SAFETY WARNINGS AND
PRECAUTIONS
1
1 GENERALSAFETYWARNINGSANDPRECAUTIONS
a
CAUTION! – This manual contains important in-
structions and warnings for personal safety. Care-
fully read all parts of this manual. If in doubt, sus-
pend installation immediately and contact the Nice
Technical Assistance.
a
CAUTION! – Important instructions: keep this man-
ual in a safe place to enable future product mainte-
nance and disposal procedures.
a
CAUTION! – All installation and connection oper-
ations must be performed exclusively by suitably
qualied and skilled personnel with the unit discon-
nected from the mains power supply.
–This product may only be used indoors or protected from
weather conditions by control unit’s housing.
–Do not open the device protection housing as it contains
non-serviceable electrical circuits.
–The product packing materials must be disposed of in
compliance with local regulations.
–Neverapplymodicationstoanypartofthedevice.Op-
erationsotherthanthosespeciedmayonlycausemal-
functions. The manufacturer declines all liability for dam-
agecausedbymakeshiftmodicationstotheproduct.
–Never place the device near to sources of heat and never
exposetonakedames.Theseactionsmaydamagethe
product and cause malfunctions.
–This product is not intended for use by people (including
children) with reduced physical, sensory or mental capa-
bilities or who lack experience and knowledge, unless
they have been given supervision or instruction concern-
ing the use of the product by a person responsible for
their safety.
–Make sure that children do not play with the product.
–Check the warnings in the instruction manual for the mo-
tor that the BiDi-WiFi is connected to.
–Handle the product with care, being sure not to crush,
knock or drop it in order to avoid damage.
1 GENERAL SAFETY WARNINGS AND PRECAUTIONS . . . . . 2
2 PRODUCT DESCRIPTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 List of constituent parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.1 Pre-installation checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.2 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4 LED SIGNALS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5 FULL RESET. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.1 Full reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.2 Firmware reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6 TECHNICAL SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . 5
7 PRODUCT DISPOSAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

ENGLISH – 3
PRODUCT DESCRIPTION
2
2 PRODUCTDESCRIPTION
The BiDi-WiFi accessory is a device that – by means of WiFi com-
munication – allows for controlling the movement and status of
Gate&Door-type Nice automations compatible with the BusT4.
a
CAUTION! – Any use other than that specied here-
in or in environmental conditions other than those
stated in this manual is to be considered improper
and is strictly forbidden!
2.1 LIST OF CONSTITUENT PARTS
Figure 1shows the main parts making up the BiDi-WiFi.
A B C D
E
1
AData Connection LED
BPAIRING button
CRESET button
DPower LED
EControl Unit CONNECTOR
INSTALLATION
3
3 INSTALLATION
3.1 PRE-INSTALLATION CHECKS
a
The installation must be carried out by qualied
personnel in compliance with the current legisla-
tion, standards and regulations, and with the in-
structions provided in this manual.
a
CAUTION! – If the BusT4 connection is used for the
IBT4N interface, BiDi-WiFi cannot be connected to
the control unit.
Before proceeding with the product’s installation, it is necessary to:
–check that you have a Nice automation control unit of the Gate&-
Door catalogue equipped with BUS T4 connector (IBT4N). Con-
trol unit with phone connector RJ11 are not supported by Bi-
Di-WiFi (“Figure 2“)
RJ11
2
–you have a smartphone with Android 6.0.2 or higher
–youhaveinstalledandconguredtheapplicationMyNice Pro
on the smartphone, you can download the App from Play Store.
3.2 INSTALLATION
To install BiDi-WiFi:
–disconnect the power supply from the automation’s control unit
(“Figure 3“)
–all LEDs on the automation’s control unit should be off before
continuing
OFF
3
–if present, remove the plastic pre-cut element (A) from the IBT4N
connector and check that there are no burrs (“Figure 4“)
A
4

4 – ENGLISH
–insert BiDi-WiFi into the IBT4N connector (B) of the control unit
(“Figure 5“)
B
5
a
Caution! If BiDi-WiFi is inserted incorrectly, it may
permanently damage the control unit!
–power the automation’s control unit (“Figure 6“)
ON
6
–Wait for the Data Connection LED (A)tostartashing(“Figure
7“)
–congure BiDi-WiFi through smartphone application MyNice
Pro, following the instructions contained in the relevant instruc-
tion manual that can be downloaded from this "link".
–thecongurationiscompletewhenDataConnectionLED(A) is
xedgreen(“Figure 7“).
A
7
LED SIGNALS
4
4 LEDSIGNALS
In the event of BiDi-WiFimalfunctions, the LEDs(A) and (D) can
lightuporstartashing.(“Figure 8“).
A
D
8
The “Table 1” shows the meanings of the LED signals.
Table 1
LED SIGNALS
Status
Data
Connection
LED (A)
Status
Power LED (D) State duration Description
OFF OFF Fixed BiDi-WiFi off.
Lit green Lit green Fixed
BiDi-WiFi
conguredand
smartphone
connected.
Lit orange Lit green Fixed
BiDi-WiFi
conguredbut
smartphone not
connected.
Flashing
green
Lit green Fixed
BiDi-WiFi is
notcongured.
Use smartphone
application to
perform the
accessory
conguration.
OFF Lit green Fixed
BiDi-WiFi was
notcongured
within 30 minutes
of switching on.
Switch off and
on the accessory
to retry the
conguration.
Flashing
orange
Flashing
orange
Transitory
(about 1
minute)
BiDi-WiFi update
in progress.
-Lit red Fixed
System error.
Contact the
Nice Technical
Assistance.
Lit red - Fixed
Wi-Fi module
error. Contact the
Nice Technical
Assistance.
Flashing red - Fixed
Conguration
error. Contact the
Nice Technical
Assistance.

ENGLISH – 5
FULL RESET
5
5 FULLRESET
5.1 FULL RESET
BiDi-WiFi can be completely reset to delete all the settings (users
settings,loglesandWi-Ficonguration).Todothis:
–press and hold the RESET button (C) for at least 10 seconds: all
theLEDswillashred
–release the RESET button (C). BiDi-WiFi device will restart (“Fig-
ure 9“).
C
9
5.2 FIRMWARE RESET
Youcanrestorethepreviousrmwareversionanddeleteallset-
tings(userssettings,loglesandWi-Ficonguration).Todothis:
–keeping inserted the |e|null device, power on the control unit with
the RESET button (C)pressed. Data Connection LED (A)willash
red
–press and hold the RESET button (C) for at least 10 seconds.
DataConnectionLEDwillstopashing
–Release the RESET button (C) (“Figure 10“).
C
A
10
TECHNICAL SPECIFICATIONS
6
6 TECHNICALSPECIFICATIONS
l
All technical specications stated in this section re-
fer to an ambient temperature of 20°C (± 5°C). Nice
S.p.A. reserves the right to apply modications to
the product at any time when deemed necessary,
without altering its functions and intended use.
Table 2
TECHNICAL SPECIFICATIONS
Description Technical specication
Product name BiDi-WiFi
Power supply 12-24Vc
Max. power input 1.2 W
Tipo interfaccia WIFI con
antenna interna
802.11b/g/n – 2.4GHz
client / AP (P < 20 dBm EIRP)
Wi-Fi security OPEN/WEP/WPA-PSK/WPA2-PSK
Bluetooth® v4.2 BR/EDR/BLE
Operating temperature -20°C ... +50°C
Storage temperature -25°C ... +70°C
Humidity 15% - 85%
Dimensions (WxDxH) 43,9 x 27,5 x 21 mm
Weight 15 g
Protection rating (IP) 40
PRODUCT DISPOSAL
7
7 PRODUCTDISPOSAL
l
This product is an integral part of the operator and
must therefore be disposed of with it.
Aswiththeinstallation,onlyqualiedpersonnelmustdismantlethe
product at the end of its life.
This product is composed of different types of materials. Some
of these materials can be recycled; others must be disposed of.
Please enquire about the recycling or disposal systems in place in
your local area for this type of product.
a
WARNING
Some parts of the product may contain polluting or
dangerous substances. If not disposed of correctly,
these substances may have a damaging effect on
the environment and human health.
l
As indicated by the symbol shown
here, this product must not been
disposed of with household
waste. Separate the waste for dis-
posal and recycling, following the
methods stipulated by local reg-
ulations, or return the product to
the seller when purchasing a new
product.
a
WARNING
Local regulations may impose heavy penalties if
this product is not disposed of in compliance with
the law.

www.niceforyou.com
Nice SpA
Via Callalta, 1
31046 Oderzo TV Italy
[email protected]
IDV0785A00EN_27-11-2020
