Nidec PG-100B Series User manual

ThankyouforpurchasingNIDECCOPALELECTRONICS
CORP.product.
Inordertousetheproductcorrectlyandmostappropriately,
please completely read this manual before use and keep it
forfuturereference.
1
Thiscautionmarkindicatesachanceofphysicaldamagestotheuserand/ortheproduct
ifitisusedimproperlyand/orincorrectly.Thedamagecanbesubstantial.
HANDYMANOMETER
PG-100B
Series
ImportantInformationandWarnings
OperatingPrecautions
（1）Theapplicablemediaaregases/liquidscompatiblewithSUS316L.
MaterialsofthepressureportareSUS316LwhilethoseoftheattachmentareSUS316andSUS304.Sopleasebecarefulaboutcompatibilitywith
applicablemedia.
Useofcorrosivefluidsmaycauseinjuryand/ormalfunctionofproducts.
Inaddition,theproductisnotexplosive-proof.Neveruseflammablefluidasmedia.
（2）Maintainthemeasuringpressurewithinthepressurerangeasstatedinspecifications.
Pressuresexceedingthemaximumpressureratingmaycauseproductfailure.
（3）Becarefulnottoletanyliquidinsidethemainproduct.
Liquidleakonthepressureportmaycauseproductfailure.Sopleasebecarefultoremovefluidscompletelybeforedetachingrelevantfittingand/or
tubefromthepressureport.
（4）Becarefulnottomixforeignmaterialsinthepressureport.
Mixingaforeignmaterialintheportmaycauseproductfailureorairleakage.Ifthereisapossibilityofmixingforeignmaterialsintotheport,use
theproductwithafilter.
（5）Beawareofpossibilitiesofaccidentsrelatedtothestrap.
Swingingtheproductintentionallyintheairbyholdingthestrapmayresultinunexpectedaccidents,injuryorproductdamage.Besuretousethe
productwithitsmainbodygrippedfirmly.
（6）Becarefulnottogiveexternalshockstotheproducts.
Externalshockssuchashittinganddroppingmaycauseproductfailure.
（7）Installationofattachments
Wheninstallinganattachmenttothepressureport,thetighteningtorqueshouldbesetataround1N・m.Makesuretouse“insertring”（attachment）
whenyoupourliquidintoatubeconnectedwith“one-touchfitting”（attachment）.
（8）Attentionforanalogoutputfunctionusing.
NovoltageorsignalshouldbeappliedtotheCALterminalbythafaultywiring.Failuretoheedthiswarningmayresultinproductmalfunctionor
damagetothemainbody.
Moreover,donotlosethebatterycoverwhentheanalogoutputfunctionisused.
（9）Cautionforhandlingofprotectcover
Theprotectcoverismadeofsiliconrubber.Neverusefluidsasmediawhicharenotcompatiblewiththesiliconrubber.Themainpurposeofthe
protectcoveristopreventliquidleakintothemainbodywhentheattachmentandtubearedetachedfromtheproduct.Itdoesnʼtserveasdrip-proof,
sopleasewipeoffincaseanyliquidleaktakesplace.
●The product is not explosion-proof. Do not use the product in designated areas where
explosion-proofspecificationisrequired.
●Theproductisnotdrip-proof/dust-proof.
●Theproductisdesignedformeasurementofintendedarticlesanddoesnotfeaturecontrol
functionsthatensuresecurity,suchaspreventionofaccidents.
InstructionManual
Ver.2.1
CAUTION
HeadOffice:Nishi-ShinjukuPrimeSquare,
7-5-25Nishi-Shinjuku,Shinjuku-ku,Tokyo160-0023,Japan
https://www.nidec-copal-electronics.co
Forinquiriesregardingtheproduct,pleasecontact:

2
BundledItems
ModelNumberDesignation
MaintenancePrecautions
（1）Periodicmaintenancecheckshouldbecarriedout.
Makesuretheproductoperatesnormallybeforeusing.Unexpectedeventmaycauseproductfailureandaffectitsbasicfunction..
（2）Donotdisassembleormodifytheproduct.
Unauthorizeddisassemblyormodificationmayresultinamalfunction.Theproductwarrantydoesnotcoverfailurescausedbydisassemblyand/or
modificationoftheproduct.
（3）ThebatteriesusedareAAAmanganesedrycellsorAAAalkalinedrycells.
Useofbatteriesotherthanasstatedabovemaycauseproductfailure.
（4）Insertthebatteriestocontactthecorrectpositiveandnegativeterminals.
Insertion of the battery in the wrong direction may induce rupture or electrolyte leakage of the battery, resulting in product failure. When the
productisintendednottobeusedforalongperiodoftime,removethebatteryfromitinordertopreventelectrolyteleakage.
（5）Stainsontheproductshouldbewipedoffwithasoft,drycloth.
Stainsontheproductshouldbewipedoffwithaclothimmersedinaneutraldetergentdilutedwithwaterandsqueezedwell;drywithasoftcloth.At
thistime,becarefulnottoallowtheneutraldetergentsolutiontoenterthepressureportand/ormainbody.Infiltrationoftheneutraldetergentmay
causeproductfailure.
（6）Cautionforstorageofprotectcover
Pleasestoretheprotectcoverinacoolanddarkplaceifitistobestored.Ultravioletraysexposuremaymakethequalityofthecoverdeteriorate.
Pleasereplacetheprotectcoverwithnewoneincasecolorofitchangesorthevisibilityofthedisplaydeteriorates.
⑴Modelnumber ：PG−100
⑵Availablemedia ：Ｂ（Gases/LiquidscompatiblewithSUS316L）
⑶Pressurerange ：102R,103R,and102A.
⑷Indicationunit ：Blank（kPa）
Ｍ（MPa）
Ｈ（mmHg）＊
Ｗ（Withunitswitchingfunction）＊＊
⑸Inspectionreport：Blank（Notattached）
Ｘ１（Inspectionreportattached）
Ｘ２（Inspectionreportandcalibrationcertificateattached）
⑹Certificate ：Blank（Notattached）
Ｔ（Traceabilitycertificateattached）
＊ …Forparticularapplication.Theapplicationisnecessaryforbuyingthismodel.
＊＊…Foreignsales.Theapplicationisnecessaryforbuyingthismodel.
・Attachments※
One-touchfitting：SSC6-M5       1piece
Insertring ：WR0640       1piece
・Strap           1piece
・Operatinginstructions（Thismanual）       1sheet
・AAAdrycell（Theservicelifeofthebatteriesthatcomewiththeproductisnotguaranteed.） 2cells
・Protectcover（withproduct）1piece
※Refertoamaker'shomepageforthedetailsofanattachment. NIHONPISCOCO.,Ltd.：http://www.pisco.co.jp/
ＰＧ−100Ｂ−103Ｒ−ＭＸ1Ｔ
⑴ ⑵ ⑶ ⑷ ⑸ ⑹

3
Specifications
NameofEachPart
POWER HOLD
UPSET
ZERO
MODE
COPALELECTRONICS
HANDYMANOMETER
LIQUIDTYPE
PG-100B-103R
BATTERY:1.5V×2LR03,R03
RANGE:-100〜1000kPa
Don'tsupplyoverrangepressure.
MADEINJAPAN
CAUTION
SERIAL:0L5001
O.SET
LOBAT
in.mmHgAqpsi
HOLD
bar MkPa
＊OnlyWtypecanswitchalldisplayunit.
＊＊Out-of-specificationwhentheanalogoutputfunctionisused.
Model
Pressurerange
Type
Ratedpressure
Max.pressure
Indicationsystem
Resolution
Indicationunit
Function
Indicationaccuracy（at25℃）
Indicationaccuracy（
at25±25℃ ）
Availablemedia
Operatingtemp.
Operatinghumidity
Drivingpower
Pressureport
IPprotection
Outerdimensions
Weight
Batteryservicelife
Analogoutput（at25℃）
Powersupply
Outputvoltage
Outputaccuracy
PG-100B
3-1/2-digitLCD
1digit
kPa,MPa,mmHg,in.Hg,mmAq,psi,bar＊
Zeroadjustment,Hold,Offset,Autopoweroff,Unitswitching
±0.5%F.S.±2digits
Gases/LiquidscompatiblewithSUS316L
0℃to50℃（Nofreezing）
15to85%RHorbelow（Nocondensing）
3VDC,AAAdrycellx2
M5femalescrew（P=0.8）
IP40（IECstandards）＊＊
5 5（ W ）× 1 6 . 9（ D ）× 1 1 0 （ H ）
Approx.100g
Approx.1,000hours
5±0.5VDC,5mAmaximum,Externalsupply
±1.000V
±10mV（Indicatedvaluestandard）
102A
Absolute
103R102R
±2.0%F.S.±2digits±1.0%F.S.±2digits
0〜100kPaabs.
（
mmHgundisplayable ）
200kPaabs.
−100〜1000kPa
（ mmHgundisplayable ）
1500kPa
−100〜100kPa
（−750〜750mmHg）
200kPa
Pressurerange
102R
103R
102A
Unitswitchingfunction（Onlyfor−Wmodel）
mmHg
○
−
○
in.Hg
○
○
○
psi
○
○
○
bar
○
○
○
mmAq
−
−
−
MPa
○
○
○
kPa
○
○
○
“−”meansundisplayable.
Gauge
AAADryCell（2cells）
・Unitindication
・
Pressureindication
LCD
PressurePort
M5×0.8
Screwdepth:5
Nameplate
ZEROButton
・Zeroadjustment
・
Offset/Cancellation
・ Underswitchingmode:
"SELECT"
HOLDButton
・
Hold/Cancellation
・ Underswitchingmode:
"ENTER"
Attachment
POWERButton
・ Turningpower
ON/OFF
FunctionIndication
・ ForOffset: 
"O.SET"
・ Forbatterylow:
"LOBAT"
・ForHold:
"HOLD"

4
OperationMethod/FunctionalExplanation
LIQUIDTYPE
MODE
ZERO
SET UP
HOLDPOWER
kPa
HOLD
LIQUIDTYPE
MODE
ZERO
SET UP
HOLDPOWER
kPa
O.SET
LIQUIDTYPE
MODE
ZERO
SET UP
HOLDPOWER
kPa
［InsertionofBatteries］
Slidethebatterycoveronthebackoftheproductbodydownwardtoopenthecover.Insertthebatteriesinthedirection
asillustrated,checkthatthebatteriesarecorrectlyandfirmlyinplace,andslidethebatterycoveragaintoclose.
［OperationMethod］
（1）TurningthepowerON
With the power turned off, press the  POWER  button under open air atmospheric pressure, and check that the
minimumdigitforthepressureindicationiswithin0±10digits.（Forthepressurerange“102A”,100（kPaabs.）will
bedisplayedwhenthepowerbuttonisturnedonunderatmosphericpressure.）
（2）Zeroadjustment
Afterturningon thepower,if adifferenceis detectedbetweenthe zerovaluesin openairatmospheric pressure,
press the  ZERO  button for three seconds or longer and performs the zero adjustment.（The zero adjustment
functionisinvalidin102Arange,becauseitisbasedonanabsolutevacuum.）
（3）Measurement
Whenpressureisapplied,themeasuredvalueisdisplayedontheLCD.
（4）TurningthepowerOFF
Withthepowerturnedon,pressthePOWERbuttontoturnoffthepower.Whentheautopowerofffunctionis
activated,thepoweristurnedoffaccordingtothepresettime.
［FunctionalExplanation］
（1）Hold
When pressure is applied, the measured
valueisdisplayed.PresstheHOLDbutton
to retain the pressure value displayed at
thattime.Atthistime,the“HOLD”mark
isdisplayedontheLCD.Pressthebutton
againtocancelthehold.
（2）Offset
When the pressure exceeds ±1%FS, press
the  ZERO  button for three seconds or
longer to enable subsequent indication of
variations with the zero value set to 0. At
thistime,“0.SET” isdisplayedon theLCD.
PresstheZERObuttonforthreeseconds
or longer again to return the indication to
the previous display.（The offset function is
invalidin102Arange,becauseitisbasedon
anabsolutevacuum.）
（3）Switchingofautopowerofffunction
With the power turned off, press the
POWERbuttonforonesecondorlonger
while pressing the  HOLD  button to set
themodetotheswitchingmodeoftheauto
poweroff function.Choose themode from
fourmodesincluding[“P3”:3min.],[“P20”:
20min.],[“PAt”:20min.afterthepressure
reacheszero],and[“PoF”:Disabled].
Press the  ZERO  button to select the
mode and press the  HOLD  button to
enterthemode. Whiletheswitching mode
isactivated,ifanybuttonoperationisnot
made for 20 seconds, the mode shifts to
themeasurementmodeatthepresetvalue
displayedatthattime.Intheinitialstate,
[“P3”:3min.]isset.
（4）Unitswitchingfunction（Onlyfor−Wmodel）
With the power turned off, press the
POWER  button for one second or longer
while pressing the  HOLD  button to set
themodetotheunitswitchingmode.While
the unit indication is blinking, press the
ZERObuttontoselectthemodeandpress
theHOLDbuttontoenterthemode.
（5）Batteryreplacementtiming
Whenthebatteryvoltageislow,“LOBAT”
is displayed on the LCD. Replace the
batteries.ThebatteriesaretwoAAAdry
cells. The used batteries should be
discarded according to the instructions of
the respective local governments. After
replacingthebatteries,besuretoperform
the zero adjustment.（See Operation
Method(2).Butexcluding102Arange.）
（6）Excessivepressureerror
When pressure exceeding 130% of the
rated pressure is applied, the indication
will start to blink. Check the source
pressure, and use the product within the
rangeoftheratedpressures.
barpsiin.
LIQUIDTYPE
MODE
ZERO
SET UP
HOLDPOWER
M kPammHgAq
LIQUIDTYPE
kPa
LOBAT
R03,LR03
Withthepower
turnedOFF,
pressHOLDand
POWERforone
secondorlonger.
Withthepower
turnedOFF,
pressZEROand
POWERforone
secondorlonger.
《UnitSwitchingFunction》（Onlyfor−Wmodel）
《SwitchingofAutoPowerOFFFunction》
︽
OperationMode
︾
（1）3minutes
（2）20minutes
（3）
20minutesafterthe
pressurereacheszero
（4）Disabled
ZERObutton:SELECT
HOLDbutton:ENTER
ZERObutton:SELECT
HOLDbutton:ENTER
（1）kPa
（2）MPa
（3）mmHg
（4）in.Hg
（5）mmAq
（6）psi
（7）bar

5
Pressurerange
102R
103R
102A
Ratedpressure［kPa］
−100.0〜100.0
−100〜1000
0.0〜100.0※
Outputvoltage［V］
−1.000〜1.000
−0.100〜1.000
0.000〜1.000 ※Unit：kPaabs.
Topview
Protectcover
LOBAT
MkPabar
HOLD
psi
O.SET
in.mmHgAq
LIQUIDTYPE
HANDYMANOMETER
COPALELECTRONICS
MODE
ZERO
SET UP
HOLD POWER
6 1
Connector
Manufacturer
JSTMfg.Co.,Ltd.
Housing
ZHR-6
Contact
SZH-002T-P0.5
SZH-003T-P0.5
Wiregauge
AWG28〜26
AWG32〜28
ConnectorNo.
１
２
３
４
５
６
Description
Externalpowerinput（5V）
Analogoutputterminal（±1V）
GND
CAL
CAL
CAL
AnalogFunction
Attachmentofprotectcover
Openthebatterycoveronthebackofthemainbodyandinsertthepre-wiredconnectoraccordingtothetableshownbelow.Afterapplyingexternalpower,
pressthePOWERbuttontoturnonthepower.Besuretousetheproductwiththebatteriesremoved.Themodewillnotswitchtotheanalogoutput
modeunlessthebatteriesareremoved.
Analogvoltageasindicatedwillbeoutputtotheanalogoutputterminal.
Pressurerange,ratedpressureandoutputvoltageareshowntothetablebelow.
NovoltageorsignalshouldbeappliedtotheCALterminalsinceitisforadjustmentuseonly.
Failuretoheedthiswarningmayresultinproductmalfunctionordamagetothemainbody.
Pleaseattachtheprotectcovertothemainbodyfromtop
side（the side of pressure port）to the end completely. Be
careful about the front side of the cover. Strap canʼt be
attachedwiththeprotectcoveronthemainbody.
PeriodicalCalibration
Ifyouwouldliketocalibrationrequest,pleasecontactthesalesofficewhereyoupurchased.
Warranty
Thewarrantyperiodfortheproductshallbeoneyear.Afailureduetocausesattributedtodesignormanufacturingdefectsduringtheperiodoneyear
fromthedateofdeliveryshallberepairedorreplacedfreeofcharge.However,theterm“warranty”hereinreferredtoshallimplythewarrantyforthe
productunitonly,anddamagesfromfailureoftheproductshallbeexcluded.Thefollowingshallbeexcludedfromthewarranty:
⑴FailureordamagecausedbyimproperuseandcarelessoperationinviolationoftheOperatingInstructions.
⑵Failureordamagecausedbyinappropriatemodification,adjustment,orrepair.
⑶FailureordamagecausedbyactsofGod,fire,orotherunavoidableaccidents.
⑷Replacementofaccessories(cables,etc.)andsuppliesthatcomewiththeproduct.
[Note]
CopyingorreprintingtheentireorpartoftheOperatingInstructionsshallbeprohibitedexceptwhereexceptionstocopyrightlawsapply.Furthermore,
descriptionsstatedintheOperatingInstructionsaresubjecttochangewithoutpriornotice.
