www.n enkamper.com Taper™ Base
CONFERENCE TABLE AND VOX FORUM®
I N S T A L L A T I O N G U I D E
FLAT HEAD HEX OCKET A EMBLY
4 mm and 5 mm - 2" x 1/4" - 20 and threaded collar.
Joins rails together.
FLAT HEAD HEX OCKET BOLT
4 mm - 5/8" x 1/4" - 20.
Joins bases to rail.
ALLAN KEY
mall 4 mm
For hex socket assembly, to join rails together.
For installing bases to rails.
For installing mounting plate to top.
Large 5 mm
For hex socket assembly, to join rail together.
H AR DWA R E PA R T L I T
WOODEN PLINE
1/8" x 7/8" x (24" - varies).
Inserts into the edge of multiple segment tops.
MOUNTING PLATE
1/4" x 3" x 4".
Fixes rail to top.
TIGHT JOINT FA TENER
3 piece assembly plus 1 tightening rod.
FLAT HEAD HEX OCKET BOLT
4 mm - 1" x 1/4" - 20.
Joins mounting plate to top.
Joins single leg to top.
WIRE MANAGEMENT “U” CLIP
Grey AB plastic.
Used to secure wires to support rail.

12
A E MB LI NG U PP OR T R A IL AT TA C HI NG B A E T O R AI L
AT TA CH IN G BA E TO R AI L “ALTE RN AT E” FI NI HE D BA E A EMB LY
•Large conference tables incorporate support rails in multiple segments.
•Position and assemble connecting joints as shown.
• Matching joints are number coded (circular labels).
• Required hardware: 2" x 1/4" - 20 flat head hex socket assembly.
•Tighten joint, aligning marks as shown.
•Certain table shapes require rails to be assembled at different angles
(as marked).
•Place bases on top of rails aligning the holes in the base with factory
installed thread locations in the rails.
•Attach and tighten bases to rails.
•Required hardware: 5/8"x1/4"- 20 flat head hex socket bolt.
34
Assembly for round/square and square wave shaped tables.
• Place bases on top of rails aligning the holes in the base with factory
installed thread locations in the rails.
• Attach and tighten bases to rails.
• Required hardware: 5/8" x 1/4" - 20 flat head hex bolt.
• Flip base assembly over.
• Place the top on the table and install as described in #5 and #6.
• Position top to align threaded inserts of top with holes in leg (as shown).
• Fix with required hardware: 1" x 1/4" - 20 flat head hex bolt.
• Flip assembly over to apply top.
• Position and level the base.

JOINING MULTIPLE PIECE TOP
AT TA CH IN G BA E TO T OP IN TA LL IN G VO X FO RU M ®
78
56
•Position multiple section tops with matching identification numbers
onto rails.
•Insert wooden spline into the groove at the seam.
•Insert ball fitting, align with tight joint bolt.
• tart the thread.
•lide tops together, align the top.
•Insert tight joint collar.
• Tighten ball fitting, hand tight.
• Insert the mounting plate into the top groove of the rail.
• lide the plate to align threaded inserts of top with holes
in mounting plate.
• Required hardware: 1" x 1/4" - 20 flat head hex bolt.
• Unpack the Forum box and retrieve the swivel latches.
• Carefully thread plastic thumbscrews into inserts around the square
hole in the top.
• Position Forum in opening and carefully ease up into the square hole.
• Rotate the swivel catches and tighten the thumb screw fasteners.
Note: detailed installation instructions are included with all Vox Forums.

WIRE MANAGEMENT ACCE ORIE
9 10
WIRE MANAGEMENT - TRIP WIRE MANAGEMENT - “U” CLIP
•Using wire management “U” clips, store and route cables to bases
along the rail.
•Begin by mounting adhesive wire management strip behind Forum
position, or where required.
•Insert cables in 1 of 3 channels.
11
• To bring cabling from the under side of the top to the floor, wire
management accessories can also be used.
• A variety of models are available.
• Instructions for installing wire management accessories are packaged
with each accessory.
V.1 04/03 632001
