Uplift Desk UPLIFT 971 Quick setup guide

1
UPLIFT Desk 1-800-349-3839
ELECTRIC HEIGHT ADJUSTABLE DESK
UPLIFT 971 Height Adjustable Desk
MAKE SURE NO OBSTACLES ARE IN THE DESK’S PATH AND
ALL CORDS ARE OF APPROPRIATE LENGTH FOR DESK
TRAVEL. FAILURE TO COMPLY WITH OR OBSERVE ALL
ASSEMBLY, SAFETY, AND OPERATION INSTRUCTIONS AND
WARNINGS REGARDING THE USE OF THIS PRODUCT MAY
RESULT IN SERIOUS PROPERTY DAMAGE OR BODILY INJURY.
IMPORTANT:
Any user or installer of desk base must study this manual carefully.
If this desk is sold, please provide the manual to the buyer.
CAUTION
!
DIRECTIONS FOR ASSEMBLY AND USE
90.014.01.0088v.B

2
UPLIFT Desk 1-800-349-3839
TABLE OF CONTENTS PAGE
1. SAFETY AND WARNINGS 2
2. USAGE 2
3. SETUP AND INSTALLATION 2
4. PARTS LIST 3
5. ASSEMBLY INSTRUCTIONS 4
6. TECHNICAL SPECIFICATIONS 6
7. TROUBLESHOOTING GUIDE 6
1. SAFETY AND WARNINGS
• Inappropriate use of this product may cause property or bodily injury.
• Check surroundings on all sides before using the desk. Body parts and property
can be crushed if trapped between an immobile obstacle and the desk’s range of motion.
• Ensure the length of power cords are accounted for when operating the desk. Monitors,
computers, speakers, anything with a cord that is not long enough for the desk’s range
of motion could be pulled down or have its wires broken. Items pulled off the desk
may cause other items to fall.
• Please provide this operation to any users, installers, or support personnel operating
the product.
2. USAGE
This height adjustable desk has an electric motor and is designed for use in dry work areas only.
The desk height is adjustable so that it can be positioned at the most ergonomically suitable height. These
desks are designed only for the purposes included in this manual. They should not be used
in environments with high humidity or dampness. Any other use is at user’s risk.
Do not move around, crawl or lie under the desk frame. Do not sit or stand on the desk frame.
Children should never use the desk unless they are supervised by adults.
Liability: Under no circumstances does the manufacturer accept warranty claims or liability claims
for damages caused from improper use or handling of the desk frame other than that which
is described in this operation manual.
3. SETUP AND INSTALLATION
Once the desk has been assembled, adjust the feet so that the desk is level and does not shift its position.
After this, connect the desk to the 110v outlet and the desk is ready for use.
Check that no cables can get jammed.
Choose a placement for the desk that’s a safe distance from window frames, radiators, furniture etc. so
that people do not get stuck or trapped by the desk.
Do not place any objects that are taller than 20” underneath the desk.
After it has been assembled, when moving the desk, DO NOT lift the desk by the desktop. Lifting
this way can stress the fasteners connecting the desk base to the desktop. Lower the desk completely and
lift the desk by grabbing the top of the desk base or by removing the desktop rst.

3
UPLIFT Desk 1-800-349-3839
4. PARTS LIST
Qty 4
Leveling
Studs
(pre-installed)
Qty 2
Wires
Qty 1 power cord
Qty 1 connecting cable
Components
Tools Required
Qty 12
M6 x 16
Machine
Screws
Qty 6
M5 x 20
Pan Head
Screws
Qty 7
M5 x 16
Pan Head Screws
Hardware
Allen Wrench
(included) Tape Measure Philips Head Screwdriver, and/or Power Drill
Please count all pieces before disposing of any carton or packing material. Use a padded or carpeted
area for assembly to avoid damage. For ease and safety, we recommend two people for assembly.
Part # Description Qty
Lifting Column 1
Feet (right & left) 2
Foot Center Assembly 1
Power Supply 1
Switch 1
Leveling Studs 4
Wires (Power & Connector wires) 2
M6 x 16 Machine Screws 12
M5 x 20 Pan Head Screws 6
M5 x 16 Pan Head Screws 7
Cable Clips 3
1
2
3
4
5
6
7
8
9
10
11
Qty 1
Power
Supply
Feet-
Qty 1 Left,
Qty 1 Right
Qty 1
Foot Center
Assembly
Qty 1
Switch
1
4
567
8
Qty 3
Cable
Clips
9
10 12
Qty 1
Lifting
Column
23
1
2
23
8

4
UPLIFT Desk 1-800-349-3839
5. ASSEMBLY INSTRUCTIONS
A. First, lay out all components and hardware
to ensure that you have all the parts listed on the
components list.
Assemble the base foot by sliding the left
and right feet (Part #2) onto the Foot Center
Assembly (Part #3).
Using four (4) M6x16 Machine Screws
(Part #8) for each foot, attach the feet
to the Foot Center Assembly (Part #3).
B. Turn the Lifting Column (Part #1) upside down
and place the assembled base foot so the holes line up.
Secure in place with four (4) M6 x 16 Machine Screws (Part #8)
C. Note: If you have ordered the UPLIFT 975,
please see the enclosed addendum,
then proceed to Step D.
Your desktop may or may not be pre-drilled.
Please check both sides of the desktop
for pre-drilled holes before placing
the desk base on it!
Place the desktop atop the base and secure
with six (6) M5 x 20 Pan Head Wood Screws
(Part #9). Double-check that the included
wood screws are not too long for your desktop
and won’t puncture the surface when screwed
all the way in.
8
1
9
Base:
three in front,
three in back
2 2
3
8

5
UPLIFT Desk 1-800-349-3839
D. Adjust the Leveling Studs (Part #6)
on the feet as needed.
E. Connect the Switch (Part #5) to the Power Supply (Part #4) with the Connecting Wire (Part #7).
Connect the Power Cord to the Power Supply (Part #4).
Attach the Switch (Part #5) to the underside of the desktop
with four (4) M5x16 Pan Head Screws (Part #10).
Use the adhesive-backed Cable Clips (Part #11)
to secure the Connecting Wires, so they don’t sag.
F. Plug the Power Cord into a 110v outlet.
IMPORTANT! You must RESET the desk prior to use:
1- Press and hold the down button
for 20 seconds, the desk will
lower all the way, slightly rise,
and then stop moving to signal
the end of the reset.
2- Release the DOWN button.
Your desk is now ready to use!
4
5
7 7
10

6
UPLIFT Desk 1-800-349-3839
6. TECHNICAL SPECIFICATIONS
Height Range 26.6” - 44.7”
Travel Speed 0.8” per second (varies, slowest w/ maximum load)
Weight Capacity 165 lbs.
Duty Cycle 10%, Max. 2 mins on, 18 mins off
Soft Start/Stop
Adjustable leveling studs
CAUTION:
- MAKE SURE ALL CORDS ARE APPROPRIATE LENGTH FOR DESK TRAVEL.
- ALSO ENSURE THAT NO OBSTACLES ARE IN THE DESK’S PATH
AND THE DESKTOP IS NOT TOUCHING ANY WALLS.
7. TROUBLESHOOTING
- - Reset Instructions - -
If experiencing problems when trying to raise or lower the desk:
• Unplug the power cord and hold the down key for 20 seconds.
• Plug the power cord back in.
• Press and hold the down button for 20 seconds, the desk will lower all the way, slightly rise,
and then stop moving to signal the end of the reset. Release the down button.
• You may need to do this if the desktop is ever unplugged or loses power.
If the desk seems to be uneven, you may need to adjust the leveling studs at the bottom of the base.
Keep children away from electric height-adjustable desks,
control units and handsets. There is a risk of injury and electric shock
This product is designed with a duty cycle of 10%
(2 min. on, 18 min. off)
In the event of a power outage or if the power cord is unplugged,
a manual reset may be necessary (see Reset Instructions above)
Do not open any of the components: Lifting Columns, control box, or
handset. There is a danger of electric shock
Keep all electrical components away from liquids
i
i

7
UPLIFT Desk 1-800-349-3839
UPLIFT Desk 975 Addendum
The UPLIFT Desk 975 has the same base as the UPLIFT 971 but the 975 comes with its own specially-made
desktop. The UPLIFT 975 desktop comes with metal screw inserts, so the included machine screws should
be used to attach it. Do not use wood screws.
Fully assemble the Desk Base according to the the UPL971 assembly instructions.
- Turn the assembled Desk Base right-side up.
- Place your Desktop on top of the Desk Base, lining up the threaded metal screw inserts with the holes on
the Desk Base.
- Secure the Desktop to the Desk Base with the six M5x20 machine screws provided. Tighten the screws
with the 4mm Allen wrench provided.
