Niko 340-00015 User manual

340-00015 / 340-00018
1
PM340-00015R13395 nv Niko sa Industriepark West 40, BE-9100 Sint-Niklaas, Belgium — tel. +32 3 778 90 00 — fax +32 3 777 71 20 — e-mail: support@niko.be — www.niko.eu NL/FR
Lees de volledige handleiding voor installatie en ingebruikneming. Bewaar deze handleiding
zorgvuldig voor later gebruik.
Referentiecode Omschrijving Max. W tatcPrimaire
stroom
340-00015 25 W, klemmen PRI en SEC, IP20 25 W -10°C — + 40°C 70°C 188 mA
340-00018 25 W, draden PRI en SEC, IP65 25 W -10°C — + 40°C 75°C 188 mA
1. OMSCHRIJVING
Deze voedingen zijn geschikt voor het voeden van leds. Deze 25W-voedingen zijn geschikt voor het voeden
van 10 monochrome ledstrips van Niko of 5 RGB-ledstrips van Niko.
De uitgangsspanning van 24 Vdc is stabiel, heeft een enge tolerantie en een hoog rendement. De totale
aangesloten belasting mag max. 25 W bedragen.
De voeding 340-00015 is bestemd voor binnentoepassingen en de voeding 340-00018 voor
buitentoepassingen.
De voedingen voldoen aan de veiligheidsnorm EN61347-2-13, de EMC-normen EN61547, EN55015,
EN61000-3-2 en EN61000-3-3 en de performantienorm EN62384.
Beveiliging: De voedingen zijn beveiligd tegen overbelasting en oververhitting.
2. MONTAGE EN AANSLUITING
- Voor bevestiging aan een wand is aan de bovenzijde van de voedingen een oog voorzien (max. diameter:
4,5 mm).
- Voor montage van de voeding 340-00015, zie fig. 1. Voor montage van de voeding 340-00018, zie fig. 2.
- Om de voedingen in te bouwen, heb je een opening met een diameter van minstens 55 mm en een
inbouwhoogte van minstens 100 mm nodig (fig. 3).
- Respecteer de minimale afstanden rondom de voeding (fig. 4).
- Om een goede werking te kunnen waarborgen, is een optimale koeling vereist (fig. 5).
- Koppel de uitgangsdraden van twee voedingen niet parallel (fig. 6).
- Hou de voedingsdraden (PRI) en de uitgangsdraden (SEC) gescheiden (fig. 7).
- Zorg dat de aansluitingen L en N bij voedingen met dubbele ingangsklemmen correct aangesloten zijn (fig. 8).
- Het gebruik van 1,5mm²- en 2,5mm²-aders is toegestaan onder bepaalde voorwaarden: als je
gebruikmaakt van de doorlusfunctie van de voeding 340-00015, moet een automaat van 10 A deze kring
beveiligen en is het niet toegelaten om stopcontacten in deze kring op te nemen.
- Hou bij inbouw rekening met de toegelaten tc-temperatuur. Voor de tc-meetpunten, zie fig. 9.
- De voeding 340-00018 heeft een IP65-beschermingsgraad. Om deze beschermingsgraad te garanderen,
moet je de aansluiting maken in een aftakdoos met min. dezelfde IP-graad.
3. VERKLARING VAN SYMBOLEN
: onafhankelijke transformator
: geschikt voor montage op brandbare materialen
: toestel met beveiliging tegen oververhitting (beveiliging van temperatuur)
: voor inbouw in meubelen
: beschermklasse II
ta: maximale omgevingstemperatuur
tc: maximale temperatuur van de behuizing
PRI: primair
SEC: secundair
IP: beschermingsgraad
λ: arbeidsfactor
4. WAARSCHUWINGEN VOOR INSTALLATIE
- De installatie moet worden uitgevoerd door een erkend installateur en volgens de geldende voorschriften.
- Deze handleiding moet aan de gebruiker worden overhandigd. Het moet bij het dossier van de elektrische
installatie worden gevoegd en worden overgedragen aan eventuele nieuwe eigenaars. Bijkomende
exemplaren zijn verkrijgbaar via de website of supportdienst van Niko. Op de Niko website is altijd de
meest recente handleiding van het product terug te vinden.
- Tijdens de installatie moet rekening gehouden worden met (niet-limitatieve lijst):
- de geldende wetten, normen en reglementen.
- de stand van de techniek op het moment van de installatie.
- deze handleiding die alleen algemene bepalingen vermeldt en moet worden gelezen in het kader van
elke specifieke installatie.
- de regels van goed vakmanschap.
Dit product voldoet aan alle toepasselijke Europese richtlijnen en verordeningen. Indien van toepassing, vind
je de EG-verklaring van overeenstemming met betrekking tot dit product op www.niko.eu.
5. NIKO SUPPORT
Heb je twijfel? Of wil je het product omruilen in geval van een eventueel defect? Neem dan contact op met je
groothandel of de Niko supportdienst:
• België: +32 3 778 90 80
• Nederland: +31 183 64 06 60
Contactgegevens en meer informatie vind je op www.niko.eu onder de rubriek “Hulp en advies”.
6. GARANTIEBEPALINGEN
- De garantietermijn bedraagt vier jaar vanaf leveringsdatum. Als leveringsdatum geldt de factuurdatum van
aankoop van het product door de consument. Als er geen factuur voorhanden is, geldt de productiedatum.
- De consument is verplicht Niko schriftelijk te informeren over het gebrek aan overeenstemming, en dit
uiterlijk binnen de twee maanden na vaststelling.
- In geval van een gebrek aan overeenstemming heeft de consument enkel recht op een kosteloze herstelling
of vervanging van het product, wat door Niko bepaald wordt.
- Niko is niet verantwoordelijk voor een defect of schade als gevolg van een foutieve installatie, oneigenlijk of
onachtzaam gebruik, een verkeerde bediening, transformatie van het product, onderhoud in strijd met de
onderhoudsvoorschriften of een externe oorzaak zoals vochtschade of schade door overspanning.
- De dwingende bepalingen in de nationale wetgeving over de verkoop van consumptiegoederen en de
bescherming van consumenten in landen waar Niko rechtstreeks of via zuster- of dochtervennootschappen,
filialen, distributeurs, agenten of vaste vertegenwoordigers verkoopt, hebben voorrang op bovenstaande
bepalingen.
Veuillez lire le mode d’emploi entièrement avant l’installation et la mise en service. Veuillez
conserver ce mode d’emploi afin de pouvoir le consulter ultérieurement.
Code de
référence Description W max. tatcCourant
primaire
340-00015 25 W, terminaux PRI et SEC, IP20 25 W -10°C — + 40°C 70°C 188 mA
340-00018 25 W, fils PRI et SEC, IP65 25 W -10°C — + 40°C 75°C 188 mA
1. DESCRIPTION
Ces alimentations sont appropriées pour l’alimentation des LED. Ces alimentations 25 W conviennent pour
l’alimentation de 10 barrettes de LED monochromes de Niko ou de 5 barrettes de LED RVB de Niko.
La tension de sortie de 24 Vdc est stable, possède une tolérance étroite et un rendement élevé. La charge
totale raccordée peut s’élever à 25 W max.
L’alimentation 340-00015 est destinée aux applications intérieures, l’alimentation 340-00018 est destinée
aux applications extérieures.
Les alimentations satisfont à la norme de sécurité EN61347-2-13, aux normes CEM EN61547, EN55015,
EN61000-3-2 et EN61000-3-3 et à la norme de performance EN62384.
Protection: Les alimentations sont protégées contre la surcharge et la surchauffe.
2. MONTAGE ET RACCORDEMENT
- Pour la fixation à un mur, un œillet de fixation est prévu sur la partie supérieure des alimentations
(diamètre maximum: 4,5 mm).
- Pour le montage de l’alimentation 340-00015, voir fig. 1. Pour le montage de l’alimentation 340-00018,
voir fig. 2.
- Pour incorporer les alimentations, vous avez besoin d’une ouverture avec un diamètre d’au moins 55 mm
et d’une hauteur d’incorporation d’au moins 100 mm (fig. 3).
- Respectez les distances minimales autour de l’alimentation (fig. 4).
- Afin de pouvoir garantir un bon fonctionnement, un refroidissement optimal est exigé (fig. 5).
- Ne branchez pas les fils de sortie de deux alimentations en parallèle (fig. 6).
- Gardez les fils d’alimentation (PRI) et les fils de sortie (SEC) séparés (fig. 7).
- Veillez à ce que les raccordements L et N avec double bornes d’entrée soient correctement raccordés aux
alimentations (fig. 8).
- L’utilisation de fils 1,5 mm² et 2,5 mm² est autorisée sous certaines conditions: si vous faites usage de la
fonction de transmission en boucle de l’alimentation 340-00015, un automate de 10 A doit protéger ce
circuit et il est interdit d’intégrer des prises de courant à ce circuit.
- Lors de l’incorporation, tenez compte de la température tcautorisée. Pour les points de mesure tc, voir
fig. 9.
- L’alimentation 340-00018 possède un degré de protection IP65. Pour garantir ce degré de protection,
vous devez effectuer le raccordement dans une boîte de dérivation avec au minimum le même degré IP.
3. EXPLICATION DES SYMBOLES
: transformateur indépendant ta: température ambiante maximale
: adapté pour être monté sur des matériaux combustibles tc: température maximale du boîtier
: appareil équipé d’une protection contre la surchauffe PRI: primaire
(protection contre la température) SEC: secondaire
: pour le montage dans un meuble IP: degré de protection
: classe de protection II λ: facteur de puissance
4. MISES EN GARDE CONCERNANT L’INSTALLATION
- L’installation doit être effectuée par un installateur agréé et dans le respect des prescriptions en vigueur.
- Ce mode d’emploi doit être remis à l’utilisateur. Il doit être joint au dossier de l’installation électrique et être
remis aux nouveaux propriétaires éventuels. Des exemplaires supplémentaires peuvent être obtenus sur le
site Internet ou auprès du service support de Niko. Sur le site Internet de Niko, vous trouverez toujours le
mode d’emploi le plus récent du produit.
- Il y a lieu de tenir compte des points suivants pendant l’installation (liste non limitative):
- les lois, les normes et les réglementations en vigueur.
- l’état de la technique au moment de l’installation.
- ce mode d’emploi qui stipule uniquement des dispositions générales et doit être lu dans le cadre de
toute installation spécifique.
- les règles de l’art.
Ce produit est conforme à l’ensemble des directives et règlements européens applicables. Le cas échéant,
vous trouverez la déclaration CE de conformité relative à ce produit sur le site www.niko.eu.
5. SUPPORT DE NIKO
En cas de doute ou si vous voulez échanger le produit en cas de défaut éventuel, veuillez prendre contact avec
votre grossiste ou avec le service support de Niko:
• Belgique: +32 3 778 90 80
• France: +33 820 20 66 25
Vous trouverez les coordonnées et de plus amples informations sur le site www.niko.eu, sous la rubrique “Aide
et conseils”.
6. DISPOSITIONS DE GARANTIE
- Le délai de garantie est de quatre ans à partir de la date de livraison. La date de la facture d’achat par le
consommateur est considérée comme la date de livraison. En l’absence de facture, la date de fabrication
est valable.
- Le consommateur est tenu de prévenir Niko par écrit de tout défaut de conformité, dans un délai maximum
de deux mois après constatation.
- En cas de défaut de conformité, le consommateur peut uniquement prétendre à la réparation gratuite ou au
remplacement gratuit du produit, selon l’avis de Niko.
- Niko ne peut être tenu pour responsable d’un défaut ou de dégâts résultant d’une installation fautive, d’une
utilisation impropre ou négligente, d’une commande erronée, d’une transformation du produit, d’un entretien
contraire aux consignes d’entretien ou d’une cause externe telle que de l’humidité ou une surtension.
- Les dispositions contraignantes de la législation nationale ayant trait à la vente de biens de consommation et
à la protection des consommateurs des différents pays où Niko procède à la vente directe ou par
l’intermédiaire d’entreprises sœurs, de filiales, de succursales, de distributeurs, d’agents ou de
représentants fixes, prévalent sur les dispositions susmentionnées.
340-00015 / 340-00018
2
DE/EN nv Niko sa Industriepark West 40, BE-9100 Sint-Niklaas, Belgium — tel. +32 3 778 90 00 — fax +32 3 777 71 20 — e-mail: support@niko.be — www.niko.eu PM340-00015R13395
Gebrauchsanleitung vor Montage und Inbetriebnahme vollständig durchlesen. Bewahren Sie diese
Gebrauchsanleitung sorgfältig für einen späteren Gebrauch auf.
Referenzcode
Beschreibung Max. W tatc
Primärer
Strom
340-00015 25 W, Primär- und Sekundärklemmen, IP20 25 W -10°C — + 40°C 70°C 188 mA
340-00018 25 W, Primär- und Sekundärdrähte, IP65 25 W -10°C — + 40°C 75°C 188 mA
1. BESCHREIBUNG
Diese Netzteile dienen zur Stromversorgung von LEDs. Mit diesen 25-W-Netzteilen können entweder 10
monochrome LED-Streifen von Niko oder 5 RGB-LED-Streifen von Niko versorgt werden.
Die Ausgangsspannung von 24 Vdc ist stabil, hat einen engen Toleranzbereich und einen hohen
Wirkungsgrad. Die gesamte angeschlossene Last darf max. 25 W betragen.
Das Netzteil 340-00015 ist für den Innenraumbereich vorgesehen, das Netzteil 340-00018 ist für den
Einsatz im Außenbereich vorgesehen.
Die Netzteile entsprechen den Sicherheitsanforderungen der Norm EN61347-2-13, den EMC-Normen
EN61547, EN55015, EN61000-3-2 und EN61000-3-3 und der Betriebsnorm EN62384.
Schutzvorrichtung: Die Netzteile sind gegen Überlast und Übertemperatur geschützt.
2. MONTAGE UND ANSCHLUSS
- Zur Wandbefestigung ist an der Oberseite der Netzteile eine Befestigungsöse vorgesehen (max.
Durchmesser: 4,5 mm).
- Zur Montage des Netzteils 340-00015, siehe Abb. 1. Zur Montage des Netzteils 340-00018, siehe Abb. 2.
- Um die Netzteile einzubauen, sind eine Öffnung mit einem Durchmesser von mindestens 55 mm und eine
Einbauhöhe von mindestens 100 mm erforderlich (Abb. 3).
- Ein minimaler Freiraum rund um das Netzteil ist einzuhalten (Abb. 4).
- Um eine einwandfreie Funktion zu garantieren, ist eine optimale Belüftung erforderlich (Abb. 5).
- Die Ausgangskabel von zwei Netzteilen dürfen nie parallel geschaltet werden (Abb. 6).
- Die Netzanschlusskabel (PRI) und die Ausgangskabel (SEC) müssen getrennt verlegt werden (Abb. 7).
- Es ist dafür zu sorgen, dass die Anschlüsse L und N bei den Netzteilen mit doppelten Eingangsklemmen
korrekt angeschlossen sind (Abb. 8).
- Der Einsatz von 1,5-mm²- und 2,5-mm²-Leitern ist unter bestimmten Vorraussetzungen zugelassen:
Wird die Stromversorgung der Netzteile 340-00015 durchgeschliffen, so muss ein Sicherungsautomat
von 10 A diesen Stromkreis absichern und ist es nicht zulässig Steckdosen in diesen Stromkreis mit
einzubeziehen.
- Die zulässige tc-Temperatur muss beim Einbau berücksichtigt werden. Siehe Abb. 9 zur Festlegung der
tc-Messpunkte.
- Das Netzteil 340-00018 hat eine Schutzart IP65. Um diese Schutzart zu garantieren, muss der
Anschluss in einer Abzweigdose mit mindestens der gleichen IP-Art ausgeführt werden.
3. ERLÄUTERUNG DER SYMBOLE
: unabhängiger Transformator SEC: Sekundär
: zur Montage an entflammbaren Materialien geeignet IP: Schutzart
: Gerät mit Schutz gegen Überhitzung (Temperaturschutz) λ: Leistungsfaktor
: für den Einbau in Möbeln
: Schutzklasse II
ta: maximale Umgebungstemperatur
tc: maximale Gehäusetemperatur
PRI: Primär
4. WARNHINWEISE FÜR DIE INSTALLATION
- Die Installation darf ausschließlich von einer Elektrofachkraft unter Berücksichtigung der geltenden
Vorschriften ausgeführt werden.
- Diese Gebrauchsanleitung muss dem Benutzer ausgehändigt werden. Die Gebrauchsanleitung ist den
Unterlagen der elektrischen Anlage beizufügen und muss auch eventuellen neuen Besitzern ausgehändigt
werden. Zusätzliche Exemplare erhalten Sie über die Website von Niko oder über den Kundendienst von
Niko. Die neueste Version der Gebrauchsanleitung erhalten Sie immer auf der Niko-Website.
- Beachten und berücksichtigen Sie bei der Installation unter anderem folgende Punkte:
- die gültigen Gesetze, Normen und Richtlinien.
- den Stand der Technik zum Zeitpunkt der Installation.
- die in dieser Gebrauchsanleitung aufgeführten Anweisungen, wobei diese Gebrauchsanleitung nur
allgemein gültige Bestimmungen enthält, die für jede Anlage spezifisch angewendet werden müssen.
- die allgemein anerkannten Regeln fachmännischer Arbeit.
Dieses Produkt erfüllt alle anwendbaren europäischen Richtlinien und Verordnungen. Die für dieses Produkt
zutreffende EG-Konformitätserklärung erhalten Sie gegebenenfalls unter www.niko.eu.
5. NIKO UNTERSTÜTZUNG
Bei Zweifel oder falls Sie bei einem eventuellen Defekt des Produkts noch Fragen bezüglich des Umtausches
haben, dann nehmen Sie bitte Kontakt auf mit dem Kundendienst von Niko (Belgien: +32 3 778 90 80) oder
wenden Sie sich an Ihren Großhändler. Kontaktdaten und weitere Informationen erhalten Sie im Internet unter
www.niko.eu in der Rubrik “Unterstützung und Beratung”.
6. GARANTIEBEDINGUNGEN
- Der Garantiezeitraum beträgt vier Jahre ab Lieferdatum. Als Lieferdatum gilt das Rechnungsdatum
zum Zeitpunkt des Kaufs durch den Endverbraucher. Falls keine Rechnung mehr vorhanden ist, gilt das
Produktionsdatum.
- Der Endverbraucher ist verpflichtet, Niko schriftlich über einen Produktmangel innerhalb von zwei Monaten
nach dessen Feststellung zu informieren.
- Im Falle eines Mangels hat der Endverbraucher nur Recht auf kostenlose Reparatur oder Ersatz des
Produkts. Eine Entscheidung darüber obliegt allein Niko.
- Niko ist nicht für Mängel oder Schäden verantwortlich, die durch fehlerhafte Installation, nicht
bestimmungsgemäßen oder unsachgemäßen Gebrauch, durch falsche Bedienung, Anpassen/Ändern des
Produktes, infolge von unsachgemäßer Wartung entgegen den Wartungsvorschriften oder die sich aus
äußeren Umständen, wie beispielsweise infolge Feuchtigkeit oder Überspannung, ergeben.
- Zwingende Vorschriften der nationalen Gesetzgebung bezüglich des Verkaufs von Konsumgütern und zum
Verbraucherschutz haben vor den obigen Bestimmungen Vorrang in den Ländern, in denen Niko direkt oder
über seine Neben- oder Tochtergesellschaften, Filialen, Vertriebsstellen, Agenten oder über feste Vertreter
verkauft.
Read the complete manual before carrying out the installation and activating the system. Keep
the manual for future reference.
Reference
code Description Max. W tatcPrimary
current
340-00015 25 W, PRI and SEC terminals, IP20 25 W -10°C — + 40°C 70°C 188 mA
340-00018 25 W, PRI and SEC wires, IP65 25 W -10°C — + 40°C 75°C 188 mA
1. DESCRIPTION
These power supplies are suitable for powering LEDs. These 25 W power supplies are suitable for powering
10 Niko monochrome LED strips or 5 Niko RGB LED strips.
The output voltage of 24 Vdc is steady, has a restricted tolerance and a high output. The max. total
connected load is 25 W.
Power supply 340-00015 is designed for indoor applications, power supply 340-00018 is designed for
outdoor applications.
The power supplies comply with the safety norm EN61347-2-13, the EMC norms EN61547, EN55015,
EN61000-3-2 and EN61000-3-3 and the performance norm EN62384.
Protections: The power supplies are protected against overload and overheating.
2. MOUNTING AND CONNECTION
- At the top of the power supply, an eyelet (max. diameter: 4.5 mm) is provided for wall mounting.
- For the mounting of power supply 340-00015, see fig. 1. For the mounting of power supply
340-00018, see fig. 2.
- Flush mounting the power supplies requires an opening with a diameter of at least 55 mm and a flush-
mounting height of at least 100 mm (fig. 3).
- Observe the minimal free space around the power supply (fig. 4).
- For a good functioning of the appliance, optimum cooling is required (fig. 5).
- Do not connect the output wires of two power supplies in parallel (fig. 6).
- Keep the power supply wires (PRI) and the output wires (SEC) separated (fig. 7).
- Make sure the L and N connections are correctly connected in case of power supplies with double input
terminals (fig. 8).
- The use of 1.5 mm² and 2.5 mm² wires is only allowed under certain conditions: if you use the looping
function of power supply 340-00015, a 10 A automat has to protect the circuit and socket outlets are not
allowed in this circuit.
- When flush mounting, take the allowed tctemperature into account. For the tcmeasuring points, see fig. 9.
- Power supply 340-00018 has an IP65 protection degree. To be able to guarantee this protection degree,
the connections have to be made in a connection box with at least the same IP degree.
3. EXPLANATION OF SYMBOLS
: independent transformer
: suitable for mounting on combustible materials
: appliance with protection against overheating (protection against temperature)
: for building into furniture
: protection class II
ta: maximum ambient temperature
tc: maximum temperature of the housing
PRI: primary
SEC: secondary
IP: protection degree
λ: power factor
4. WARNINGS REGARDING INSTALLATION
- The installation should be carried out by a registered installer and in compliance with the statutory
regulations.
- This manual should be presented to the user. It should be included in the electrical installation file, and it
should be passed on to any new owners. Additional copies are available on the Niko website or via the Niko
support service. The latest manual for this product is available on the Niko website at any time.
- During installation, the following should be taken into account (non-exhaustive list):
- the statutory laws, standards and regulations.
- the technology currently available at the time of installation.
- this manual, which only states general regulations and should therefore be read within the scope of
each specific installation.
- the rules of proper workmanship.
This product complies with all of the relevant European guidelines and regulations. If applicable, you can find
the EC declaration of conformity regarding this product at www.niko.eu.
5. NIKO SUPPORT
In case of doubt or for the specific exchange procedure in case of a possible defect, contact the Niko support
service in Belgium at +32 3 778 90 80 or your wholesaler/installer. Contact details and more information can
be found at www.niko.eu under the “Help and advice” section.
6. GUARANTEE PROVISIONS
- The period of guarantee is four years from the date of delivery. The delivery date is the invoice date of purchase
of the product by the consumer. If there is no invoice, the date of production applies.
- The consumer is obliged to inform Niko in writing about the non-conformity, within two months after stating the
defect.
- In case of a non-conformity, the consumer only has the right to a product repair or replacement free of charge,
which shall be decided by Niko.
- Niko shall not be held liable for a defect or damage resulting from incorrect installation, improper or careless
use, incorrect operation, transformation of the product, maintenance that does not adhere to the maintenance
instructions or an external cause, such as damage due to moisture or overvoltage.
- The compulsory regulations of the national legislation concerning the sale of consumer goods and the
protection of the consumer in the countries where Niko sells, directly or via sister companies, subsidiaries, chain
stores, distributors, agents or permanent sales representatives, take priority over the above-mentioned rules
and regulations.
340-00015 / 340-00018
3
PM340-00015R13395 nv Niko sa Industriepark West 40, BE-9100 Sint-Niklaas, Belgium — tel. +32 3 778 90 00 — fax +32 3 777 71 20 — e-mail: support@niko.be — www.niko.eu SK
Pred inštaláciou a spustením systému si prečítajte celý návod. Návod uschovajte pre budúce
použitie.
Odkaz Popis Max W tatc
Primárny
prúd
340-00015 25 W, primár-svorky, sekundár-svorky, IP20 25 W -10°C — + 40°C 70°C 188 mA
340-00018 25 W, primár-vodiče, sekundár-vodiče, IP65 25 W -10°C — + 40°C 75°C 188 mA
1. POPIS
Tieto napájacie zdroje sú vhodné na napájanie LED diód. Tieto 25 W napájacie zdroje sú vhodné na
napájanie 10 monochromatických LED pásov Niko alebo 5 RGB LED pásov Niko.
Výstupné napätie 24 Vdc je stabilné, má obmedzenú toleranciu a výstup je pod prúdom. Maximálne
celkové pripojené zaťaženie je 25 W.
Napájací zdroj 340-00015 je navrhnutý na použitie v interiéri, 340-00018 je navrhnutý na použitie v
exteriéri.
Napájacie zdroje spĺňajú bezpečnostnú normu EN61347-2-13, EMC normy EN61547, EN55015,
EN61000-3-2 a EN61000-3-3 a výkonovú normu EN62384.
Zabezpečenie: Napájacie zdroje sú chránené pred preťažením a prehriatím.
2. MONTÁŽ A ZAPOJENIE
- Na hornej strane napájacieho zdroja sa nachádza otvor (max. priemer: 4,5 mm) na montáž na stenu.
- Pri inštalácii napájacieho zdroja 340-00015 pozri obr. 1. Pri inštalácii napájacieho zdroja 340-00018
pozri obr. 2.
- Zapustená montáž napájacích zdrojov vyžaduje otvor s priemerom najmenej 55 mm a výšku zapustenej
montáže najmenej 100 mm (obr. 3).
- Dodržte minimálny voľný priestor okolo napájacieho zdroja (obr. 4).
- Aby zariadenie fungovalo dobre, je nevyhnutné optimálne chladenie (obr. 5).
- Nepripájajte výstupné vodiče dvoch napájacích zdrojov paralelne (obr. 6).
- Dbajte, aby vodiče napájacích zdrojov (PRI) a výstupné vodiče (SEC) boli oddelené (obr. 7).
- Uistite sa, že v prípade napájacích zdrojov s dvojitými vstupnými svorkami sú konektory L a N správne
pripojené (obr. 8).
- Použitie 1,5 mm² a 2,5 mm² vodičov je dovolené len za určitých podmienok: ak sa používa funkcia
jednoduchého obvodu napájacieho zdroja 340-00015, obvod musí byť chránený 10 A poistkou a zásuvky
v tomto obvode nie sú povolené.
- Pri zapustenej montáži berte do úvahy povolenú teplotu tc. Pre meracie body tcpozri obr. 9.
- Napájací zdroj 340-00018 má stupeň ochrany IP65. Aby bolo možné zaručiť túto ochrannú triedu,
pripojenia treba vykonať v rozbočovači s minimálne rovnakým stupňom ochrany IP.
3. VYSVETLENIE SYMBOLOV
: nezávislý transformátor
: vhodné pre namontovanie na horľavé materiály
: zariadenie s ochranou proti prehriatiu (tepelná ochrana)
: pre zabudovanie do nábytku
: ochrana triedy II
ta: maximálna teplota okolia
tc: maximálna teplota povrchu transformátora
PRI: primárny
SEC: sekundárny
IP: stupeň ochrany
λ: záťažový faktor
4. UPOZORNENIA TÝKAJÚCE SA INŠTALÁCIE
- Inštaláciu musí vykonať kvalifikovaný odborník v súlade s platnými predpismi.
- Tento návod musí byť odovzdaný užívateľovi. Musí byť súčasťou dokumentácie o elektrickej inštalácii a musí
byť odovzdaný každému novému užívateľovi. Ďalšie kópie návodu sú dostupné na web stránke Niko alebo
cez služby zákazníkom. Najnovší návod na inštaláciu tohto výrobku je k dispozícii na internetových stránkach
Niko.
- Počas inštalácie je potrebné brať do úvahy nasledovné (neobmedzuje sa iba na nasledovný zoznam):
- aktuálne zákony, normy a vyhlášky.
- aktuálny stav technológie v čase inštalácie.
- tento návod, ktorý obsahuje iba všeobecné pravidlá, je potrebné použiť s ohľadom na špecifiká každej
inštalácie.
- pravidlá správnej inštalácie.
Tento výrobok spĺňa všetky relevantné Európske predpisy a nariadenia. V prípade potreby nájdete príslušné ES
vyhlásenie o zhode na www.niko.eu.
5. NIKO TECHNICKÁ PODPORA
Ak máte otázky, obráťte sa na zastúpenie firmy Niko (Slovenská republika: +421 2 63 825 155) alebo váš
veľkoobchod. Ďalšie informácie a kontakty nájdete na stránke www.niko.eu v sekcii “Pomoc a podpora”.
6. ZÁRUČNÉ PODMIENKY
- Záručná doba je štyri roky od dátumu dodávky. Za dátum dodávky sa považuje dátum fakturácie alebo
vydania iného daňového dokladu zákazníkovi. Ak takýto doklad nie je k dispozícii, platí dátum výroby.
- Zákazník je povinný písomnou formou informovať Niko o poruche do dvoch mesiacov od jej objavenia.
- V prípade poruchy výrobku má zákazník nárok na bezplatnú opravu alebo výmenu (na základe posúdenia
firmy Niko).
- Niko nenesie zodpovednosť za poruchu alebo poškodenie spôsobené nesprávnou inštaláciou, nesprávnym
alebo nedbalým použitím, prepravou výrobku, nesprávnou údržbou, alebo vonkajšími vplyvmi ako sú zvýšená
vlhkosť či prepätie.
- Záväzné zákony národnej legislatívy, týkajúce sa predaja tovaru a ochrany zákazníka platné v krajinách, kde
sa predávajú výrobky Niko, priamo alebo cez sesterské či dcérske spoločnosti, reťazce, distribútorov, agentov
alebo stálych predajných zástupcov, sú nadriadené vyššie uvedeným pravidlám a nariadeniam.
340-00015 / 340-00018
4
nv Niko sa Industriepark West 40, BE-9100 Sint-Niklaas, Belgium — tel. +32 3 778 90 00 — fax +32 3 777 71 20 — e-mail: support@niko.be — www.niko.eu PM340-00015R13395
min. 40 mm
SUPPLY
min. 40 mm
min. 20 mm
L
N
SUPPLY
L
N
SUPPLY
LED
L
N
SUPPLY
LED
Fig./Abb./Obr. 3
Fig./Abb./Obr. 2
Fig./Abb./Obr. 4
Fig./Abb./Obr. 5
Fig./Abb./Obr. 7
Fig./Abb./Obr. 6
Fig./Abb./Obr. 8
Doorverbinding / Repiquage / Durchverbindung / Input looping / Vstupná slučka:
max. 8 x 340-00015
min.100 mm
min. 55 mm
Fig./Abb./Obr. 9
tc
19,32 mm
3,13 mm
tc
41,42 mm
4,42 mm
tc 8,72 mm
5 mm
tc
19,37 mm
1,88 mm
1. Kabels aansluiten
2. Draadtrekontslasting vastzetten
3. Afschermkap monteren om 230V-klemmen af te schermen
1. Raccordement des câbles
2. Fixation du mécanisme de relâchement de la tension du câble
3. Branchement du couvercle de blindage aux terminaux de 230 V
1. Anschließen der Kabel
2. Montieren der Kabelzugentlastungsvorrichtung
3. Montieren der Schutzabdeckung für die 230-V-Klemmen
1. Connecting the cables
2. Fixing the cable tension release mechanism
3. Fitting the cover shielding the 230 V terminals
1. Pripojenie vodičov
2. Montáž mechanizmu na odľahčenie ťahu káblov
3. Montáž krytu chrániaceho 230 V svorky
3
1
2
Fig./Abb./Obr. 1
340-00015
340-00015
PRI/SEC: 2 x 1,5 mm2/ 1 x 2,5 mm2
340-00018
340-00018
PRI/SEC: 2 x 1 mm2/ 2 x 0,75 mm2

This manual suits for next models

1

Other Niko Power Supply manuals

Niko 340-00050 User manual

Niko

Niko 340-00050 User manual

Niko 10-805-01 User manual

Niko

Niko 10-805-01 User manual

Niko 550-00010 User manual

Niko

Niko 550-00010 User manual

Niko 10-806 User manual

Niko

Niko 10-806 User manual

Niko 10-801 User manual

Niko

Niko 10-801 User manual

Niko 10-806-01 User manual

Niko

Niko 10-806-01 User manual

Niko 10-801 User manual

Niko

Niko 10-801 User manual

Niko 350-70985 User manual

Niko

Niko 350-70985 User manual

Niko 67-710 User manual

Niko

Niko 67-710 User manual

Niko 10-880 User manual

Niko

Niko 10-880 User manual

Popular Power Supply manuals by other brands

DOTLUX 5334 quick start guide

DOTLUX

DOTLUX 5334 quick start guide

VOLTCRAFT WS-PS2001 operating instructions

VOLTCRAFT

VOLTCRAFT WS-PS2001 operating instructions

KEBCO combivert R6-S instruction manual

KEBCO

KEBCO combivert R6-S instruction manual

Merit MEGATOUCH FORCE Series Replacement instructions

Merit

Merit MEGATOUCH FORCE Series Replacement instructions

Medistrom Pilot-12 plus user manual

Medistrom

Medistrom Pilot-12 plus user manual

Ametek Sorensen DHP Series Operation manual

Ametek

Ametek Sorensen DHP Series Operation manual

GW Instek PSH series user manual

GW Instek

GW Instek PSH series user manual

Extreme Networks RPS installation guide

Extreme Networks

Extreme Networks RPS installation guide

StarTech.com ATXPOW500DF Instruction guide

StarTech.com

StarTech.com ATXPOW500DF Instruction guide

Selec RPS480-24-CE Operating	 instruction

Selec

Selec RPS480-24-CE Operating instruction

Be Cool BC296NCM manual

Be Cool

Be Cool BC296NCM manual

Tesla TI500 GPU-24 user manual

Tesla

Tesla TI500 GPU-24 user manual

Kenwood PS-511S operating manual

Kenwood

Kenwood PS-511S operating manual

Apevia ATX-AS500W user manual

Apevia

Apevia ATX-AS500W user manual

Meyer Sound MPS-482HP operating instructions

Meyer Sound

Meyer Sound MPS-482HP operating instructions

hager TXA112 installation instructions

hager

hager TXA112 installation instructions

Siemens SINAMICS S120 user manual

Siemens

Siemens SINAMICS S120 user manual

PS Audio Quintessence Power Center Owner's reference

PS Audio

PS Audio Quintessence Power Center Owner's reference

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
