Nilfisk-Advance MC 6P User manual

MC 6P
SERVICE MANUAL

SM_MC_6P Ver.2.0_2021
Preface
This service manual contains detailed description of the main repair work on the cold HPW
MC 6P.
Repair work requires a suitable testing workplace with the necessary water and power supply.
If operating errors are evident, refer the customer to the operating instructions.
A fault in the cleaner can have several causes as described in the section on troubleshooting.
Refer to the illustrated spare parts lists during repairs. They show the assembly position and the
sequence in which the individual components should be assembled.
See ”Technical Service Bulletin (TSB) sheets. They include information on technical
modifications that have been made after this repair manual was printed.
”Technical Service Bulletin” sheets are also valid as a supplement to the spare parts list until
publication of a new edition.
Repair manuals and ” Technical Service Bulletin” sheets should be available at the site
where repairs are carried out.
It is not permitted to give them to third parties.
Use original Nilfisk spare parts only.

A.
B.
C.
D.
E.
F.
G.
H.
I. Special tools /Spare parts
Wiring diagrams
Adjustment / Test
Service / Repair
Troubleshooting
Function
Construction
Technical data
Safety instructions
55
48-54
45-47
38-44
35-37
26 -34
19 -25
5-18
4

SM_MC_6P Ver.2.0_2021
Safety instructions
4
A
For your own safety
ESD measures
(electrostatic discharge)
Observe valid safety regulations
for electrical equipment. In
particular, observe the following
regulations:
IEC 60335-2-79
EN 60335-2-79
Additionally:
Also see national regulations
Before using the cleaner, always
read the operating instructions
and keep them readily available.
Only allow the high pressure
Repair work should be carried
out by persons instructed in
electrical installations or by
trained electricians only.
Take the following ESD precautions before carrying out any
repairs to the electronics:
• Touch the earth conductor before repairing the cleaner
( to discharge electrostatic charge from your body ).
• Wear wrist band if necassary.
• Use a conductive floor covering or a conductive table cover.
• Never touch the printed circuit board or electronic components
( always hold on to plastic ).
• Transport electronic components in conductive packaging
( e.g. ESD bag ).

Technical data
SM_MC_6P Ver.2.0_2021 5
B
Item number: 107146750 MC 6P-2300/5.0 FA 230/1/60 US
Service manual data
PUMP:
Pressure ppump @ Qnom bar 155
Pressure pgun @ Qnom bar 130
Retaining/opening pressure bar
Flow Qnom l/min (gpm) 16,8 (4,4)
Suction height dry m (ft.) 1 (3)
Suction height primed m (ft.) 2,5 (8)
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 6,02
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,73
ELECTRIC:
Electrical data V/ph/Hz 230V/1ph/60Hz
Current @ V1A28
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1740
Electric diagram item number - 106420563
UNIT DATA:
Nozzle Size - NT 0680
Max. inlet temperature (suction) °C (°F) 50 (122)
Max. inlet temperature (primed) °C (°F) 70 (158)
Max. inlet temperature (pressure fed) °C (°F) 80 (176)
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C (°F) 40 (104)
Gun Type - ERGO 2000 STD INCL. SWIVEL NILFISK
Lance primary/secondary - 101406108/None
High pressure hose - DN10 x 15m - Black
Sound power typeplate dBA 88
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 30
Protection Class - IPX5
Weight - Machine incl. standard acc. kg (lb) 90 (198)
Size - Machine alone LxWxH (mm) 775x570x1020
Detergent suction % (+/-)6

Technical data
SM_MC_6P Ver.2.0_2021 6
B
Service manual data
PUMP:
Pressure ppump @ Qnom bar 239
Pressure pgun @ Qnom bar 219
Retaining/opening pressure bar
Flow Qnom l/min 15,65
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 400V/3ph/50Hz
Current @ V1A15,5
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420552
UNIT DATA:
Nozzle Size - NT 0475
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - ERGO 2000 STD INCL. SWIVEL NILFISK
Lance primary/secondary - 101406108/None
High pressure hose - DN10 x 10m - Black
Sound power typeplate dBA 93
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 16
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 89
Size - Machine alone LxWxH (mm) 775x570x1020
Detergent suction % (+/-)6
Item number: 107146751 MC 6P-250/1100 FA 400/3/50 EU

Technical data
SM_MC_6P Ver.2.0_2021 7
B
Item number: 107146752 MC 6P-180/1300 FA 400/3/50 EU
Service manual data
PUMP:
Pressure ppump @ Qnom bar 168
Pressure pgun @ Qnom bar 140
Retaining/opening pressure bar
Flow Qnom l/min 18,7
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 400V/3ph/50Hz
Current @ V1A13,3
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420552
UNIT DATA:
Nozzle Size - NT 0700
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - ERGO 2000 STD INCL. SWIVEL NILFISK
Lance primary/secondary - 101406108/None
High pressure hose - DN10 x 10m - Black
Sound power typeplate dBA 90
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 16
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 86
Size - Machine alone LxWxH (mm) 775x570x1020
Detergent suction % (+/-)6

Technical data
SM_MC_6P Ver.2.0_2021 8
B
Item number: 107146754 MC 6P-180/1300 FA 220-440/3/60 EXPT
Service manual data
PUMP:
Pressure ppump @ Qnom bar 172
Pressure pgun @ Qnom bar 144
Retaining/opening pressure bar
Flow Qnom l/min 18,8
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 220V/3ph/60Hz
Current @ V1A24,7
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1740
Electric diagram item number - 106420556
UNIT DATA:
Nozzle Size - NT 0700
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - ERGO 2000 STD INCL. SWIVEL NILFISK
Lance primary/secondary - 101406108/None
High pressure hose - DN10 x 10m - Black
Sound power typeplate dBA 90
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 30
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 87
Size - Machine alone LxWxH (mm) 775x570x1020
Detergent suction % (+/-)6

Technical data
SM_MC_6P Ver.2.0_2021 9
B
Item number: 107146755 MC 6P-170/1600 FA 400/3/50 EU
Service manual data
PUMP:
Pressure ppump @ Qnom bar 162
Pressure pgun @ Qnom bar 120
Retaining/opening pressure bar
Flow Qnom l/min 23,5
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 400V/3ph/50Hz
Current @ V1A15
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420552
UNIT DATA:
Nozzle Size - NT 0950
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - ERGO 2000 STD INCL. SWIVEL NILFISK
Lance primary/secondary - 101406108/None
High pressure hose - DN10 x 10m - Black
Sound power typeplate dBA 90
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 16
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 89
Size - Machine alone LxWxH (mm) 775x570x1020
Detergent suction % (+/-)5

Technical data
SM_MC_6P Ver.2.0_2021 10
B
Item number: 107146758 MC 6P-250/1100 FAXT 400/3/50 EU
Service manual data
PUMP:
Pressure ppump @ Qnom bar 240
Pressure pgun @ Qnom bar 210
Retaining/opening pressure bar
Flow Qnom l/min 15,3
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 400V/3ph/50Hz
Current @ V1A15,3
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420552
UNIT DATA:
Nozzle Size - NT 0475
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - ERGO 2000 STD INCL. SWIVEL NILFISK
Lance primary/secondary - 101406108/101406119
High pressure hose - DN10 x 15m - Black
Sound power typeplate dBA 93
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 16
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 96
Size - Machine alone LxWxH (mm) 930x570x1020
Detergent suction % (+/-)6

Technical data
SM_MC_6P Ver.2.0_2021 11
B
Item number: 107146759 MC 6P-180/1300 FAXT 400/3/50 EU
Service manual data
PUMP:
Pressure ppump @ Qnom bar 172
Pressure pgun @ Qnom bar 138
Retaining/opening pressure bar
Flow Qnom l/min 18,7
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 400V/3ph/50Hz
Current @ V1A14
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420552
UNIT DATA:
Nozzle Size - NT 0700
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - ERGO 2000 STD INCL. SWIVEL NILFISK
Lance primary/secondary - 101406108/101406119
High pressure hose - DN10 x 15m - Black
Sound power typeplate dBA 90
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 16
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 93
Size - Machine alone LxWxH (mm) 930x570x1020
Detergent suction % (+/-)6

Technical data
SM_MC_6P Ver.2.0_2021 12
B
Item number: 107146760 MC 6P-180/1300 FAXT 230-400/3/50 NO
Service manual data
PUMP:
Pressure ppump @ Qnom bar 172
Pressure pgun @ Qnom bar 138
Retaining/opening pressure bar
Flow Qnom l/min 18,7
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 230V/3ph/50Hz
Current @ V1A24,5
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420556
UNIT DATA:
Nozzle Size - NT 0700
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - ERGO 2000 STD INCL. SWIVEL NILFISK
Lance primary/secondary - 101406108/101406119
High pressure hose - DN10 x 15m - Black
Sound power typeplate dBA 90
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 25
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 93
Size - Machine alone LxWxH (mm) 930x570x1020
Detergent suction % (+/-)6

Technical data
SM_MC_6P Ver.2.0_2021 13
B
Item number: 107146761 MC 6P-170/1600 FAXT 400/3/50 EU
Service manual data
PUMP:
Pressure ppump @ Qnom bar 167
Pressure pgun @ Qnom bar 120
Retaining/opening pressure bar
Flow Qnom l/min 23
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 400V/3ph/50Hz
Current @ V1A15,5
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420552
UNIT DATA:
Nozzle Size - NT 0950
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - Spray gun ERGO 3000
Lance primary/secondary - 106403014/101406119
High pressure hose - DN10 x 15m - Black
Sound power typeplate dBA 90
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 16
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 96
Size - Machine alone LxWxH (mm) 930x570x1020
Detergent suction % (+/-)5

Technical data
SM_MC_6P Ver.2.0_2021 14
B
Item number: 107146765 GERNI POSEIDON 6-65 FA 415/3/50 AU
Service manual data
PUMP:
Pressure ppump @ Qnom bar 168
Pressure pgun @ Qnom bar 140
Retaining/opening pressure bar
Flow Qnom l/min 18,7
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 415V/3ph/50Hz
Current @ V1A13,3
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420552
UNIT DATA:
Nozzle Size - NT 0700
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - ERGO 2000 ST GUN W. HOSE SWIVEL - GERNI
Lance primary/secondary - 101406134/None
High pressure hose - DN10 x 10m - Black
Sound power typeplate dBA 90
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size A20
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 86
Size - Machine alone LxWxH (mm) 775x570x1020
Detergent suction % (+/-)6

Technical data
SM_MC_6P Ver.2.0_2021 15
B
Item number: 107146766 MC 6P-250/1100 FA 415/3/50 GERNI
Service manual data
PUMP:
Pressure ppump @ Qnom bar 239
Pressure pgun @ Qnom bar 219
Retaining/opening pressure bar
Flow Qnom l/min 15,65
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 415V/3ph/50Hz
Current @ V1A15,5
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420552
UNIT DATA:
Nozzle Size - NT 0475
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - ERGO 2000 ST GUN W. HOSE SWIVEL - GERNI
Lance primary/secondary - 101406134/None
High pressure hose - DN10 x 10m - Black
Sound power typeplate dBA 93
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size A20
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 89
Size - Machine alone LxWxH (mm) 775x570x1020
Detergent suction % (+/-)6

Technical data
SM_MC_6P Ver.2.0_2021 16
B
Item number: 107146773 MC 6P-120/1950 FA 400/3/50 EU
Service manual data
PUMP:
Pressure ppump @ Qnom bar 115
Pressure pgun @ Qnom bar 84
Retaining/opening pressure bar 140 +5 / - 0
Flow Qnom l/min 30,5
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 400V/3ph/50Hz
Current @ V1A15
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420552
UNIT DATA:
Nozzle Size - NT 1500
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - High Flow Spray Handle
Lance primary/secondary - 101406108/None
High pressure hose - DN10 x 10m - Black
Sound power typeplate dBA 90
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 16
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 89
Size - Machine alone LxWxH (mm) 775x570x1020
Detergent suction % (+/-)-

Technical data
SM_MC_6P Ver.2.0_2021 17
B
Item number: 107146774 MC 6P-120/1950 FAXT 400/3/50 EU
Service manual data
PUMP:
Pressure ppump @ Qnom bar 120
Pressure pgun @ Qnom bar 84
Retaining/opening pressure bar 140 +5 / - 0
Flow Qnom l/min 30,5
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 400V/3ph/50Hz
Current @ V1A15,5
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420552
UNIT DATA:
Nozzle Size - NT 1500
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - High Flow Spray Handle
Lance primary/secondary - 101406108/101406119
High pressure hose - DN10 x 15m - Black
Sound power typeplate dBA 90
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 16
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 96
Size - Machine alone LxWxH (mm) 775x570x1020
Detergent suction % (+/-)-

Technical data
SM_MC_6P Ver.2.0_2021 18
B
Item number: 107146775 MC 6P-120/1950 FA 230-400/3/50 NO
Service manual data
PUMP:
Pressure ppump @ Qnom bar 115
Pressure pgun @ Qnom bar 84
Retaining/opening pressure bar 140 +5 / - 0
Flow Qnom l/min 30,5
Suction height dry m1
Suction height primed m2,5
Pump type - NA6
Number of pistons - 4
Pump piston type - Full Ceramic
Cylinder stroke mm 0
Pump oil type - Castrol Alphasyn T 150
Pump oil amount per pump l0,95
ELECTRIC:
Electrical data V/ph/Hz 230V/3ph/50Hz
Current @ V1A25
Current limiter A-
High voltage test voltage V1500
HV insulation resistance min. MΩ1
Earth circuit resistance max. Ω0,2
Speed rpm 1450
Electric diagram item number - 106420552
UNIT DATA:
Nozzle Size - NT 1500
Max. inlet temperature (suction) °C 50
Max. inlet temperature (primed) °C 70
Max. inlet temperature (pressure fed) °C 80
Max. water inlet pressure bar 10
Min. water inlet pressure bar 1
Max. ambient temperature °C 40
Gun Type - High Flow Spray Handle
Lance primary/secondary - 101406108/None
High pressure hose - DN10 x 10m - Black
Sound power typeplate dBA 90
Vibration ISO 5349 Lance 1 m/s2<1,5; +/-1
Cleaning Impact kg-force
Fuse size AC 32
Protection Class - IPX5
Weight - Machine incl. standard acc. kg 89
Size - Machine alone LxWxH (mm) 775x570x1020
Detergent suction % (+/-)-

Construction
SM_MC_6P Ver.2.0_2021 19
C
Overview MC 6P
Lance
Lance holder top
Water inlet + Filter
ON / OFF switch
Lance holder bottom
Water outlet
Pressure gauge
View for oil container
Detergent valve
Detergent Bottles
Cabinet lock
MC 6P Cabinet & frame parts
Water/pressure regulator

Construction
SM_MC_6P Ver.2.0_2021 20
C
Pressure gauge
By-pass system
Cylinder head
Water outlet
Water inlet/Filter
Electrical box
Water regulation
D-bearing cover
Detergent valve
ON-OFF switch
Pump oil lid
Pump oil container
Cylinder block
Overview MC 6P
”0” = Stop
”I”= ON
”M”= Manual. Manual means the Auto Start/Stop system is elimina-
ted. This is used if the pump is used on suction and not on
pressurized water supply.
