Overview

1. Overview

The Nokia Xpress-onTM GPS shell allows you to use your Nokia 5140 phone for GPS

(Global Positioning System) navigation in outdoor activities. The Nokia Xpress-on

GPS shell includes a GPS receiver and two JavaTM applications called GPS and

Travel guide.

This user’s guide describes how to install the upper and lower part of

the Nokia Xpress-on GPS shell and how to use these two applications.

Read this user’s guide carefully before using the Nokia Xpress-on GPS shell. In

addition to this user’s guide, read also the user’s guide of your Nokia 5140 phone,

which provides important safety and maintenance information.

Check www.nokia.com/support or your local Nokia Web site for additional

information, downloads and services related to your Nokia product.

■Introduction to GPS

GPS is a worldwide radio navigation system that includes 24 satellites and their

ground stations that monitor the operation of the satellites.

A GPS terminal (such as the GPS receiver in the Nokia Xpress-on GPS shell)

receives low-power radio signals from the satellites and measures the travel time

of the signals. From the travel time, the GPS receiver can calculate its location to

the accuracy of metres.

The GPS receiver in the Nokia Xpress-on GPS shell takes its power from the phone

battery. Note that using the GPS receiver may drain the phone battery faster.

Note: The Global Positioning System

The Global Positioning System (GPS) is operated by the United States government,

which is solely responsible for accuracy and maintenance of the system.

The accuracy of location data can be affected by adjustments to GPS satellites

made by the United States government and is subject to change with the United

States Department of Defense civil GPS policy and the Federal Radionavigation

Plan. Accuracy can also be affected by poor satellite geometry.

Availability and quality of GPS signals may be affected by buildings and natural

obstacles as well as weather conditions. The GPS receiver should only be used

outdoors to allow reception of GPS signals.

Therefore, GPS should not be used for precise location measurement and you

should never rely solely on location data from the GPS receiver. This GPS receiver

does not support location of the phone by emergency operators.

■GPS application and Travel guide application

You can operate the GPS receiver of the Nokia Xpress-on GPS shell using the GPS

or Travel guide application.

GPS application

The GPS application is a GPS navigation tool that does not require a connection to

the GSM phone network.

Overview

Travel guide application

The Travel guide application allows you to use a network service that shows your

location on a map and allows you to plan your trip and find points of interests.

To use the Travel guide application, you need to be connected to the GSM phone

network and to the GPRS (general packet radio service) or HSCSD (high speed

circuit switched data) network service.

To use the GPRS or HSCSD network service, define the browser settings in the

Services menu of your Nokia 5140 phone, and check which browser settings are

currently used by the Travel guide application: press Menu in standby mode, and

select Applications, Collection, and Select application, scroll to Travel guide, press

Options, and select Connect via. For more information, see the user’s guide of your

Nokia 5140 phone.

For the availability of the GPRS or HSCSD service, related fees, and appropriate

settings, contact your network operator or service provider.

Note: Virtually all digital cartography is always inaccurate and incomplete to

some extent. Never rely solely on the cartography provided for use in this device.

2. Installation

Note: Before removing the cover, always switch off the power and disconnect the

charger and any other device. Avoid touching electronic components while

changing the covers. Always store and use the device with the covers attached.

To install the shell and its two applications:

1. Install the upper and lower part of the

Nokia Xpress-on GPS shell as instructed in

the user’s guide of your Nokia 5140 phone.

The GPS receiver is located inside the lower

part of the shell (blue area in the picture).

2. Switch on the phone.

The GPS receiver automatically installs the

Cover browser application into the Collection submenu of the Applications

menu in your phone.

3. To install the GPS or Travel guide application, select Cover browser in the

Collection submenu, and select GPS or Travel guide. The application is added to

the Collection submenu. You can install both applications if you like. The

installation takes several minutes.

If you first install one of these applications but later want to install the other

one as well, use the Cover browser application.

Installation

If you want to receive GPS waypoints as text messages, select Cover browser in

the Collection submenu, and select the related application to install it.

4. When using the Nokia Xpress-on GPS shell for the first time or when it has not

been used in the last 14 days, start the GPS or Travel guide application and

keep the phone in place outdoors, with a clear view of the sky, for 15 to 30

minutes to acquire GPS almanac data from at least four satellites. The almanac

data is basic information about the orbits of the GPS satellites. This

information is required for GPS navigation.

Getting a GPS connection after this initial connection may take from a couple

of seconds up to several minutes. Availability and quality of GPS signals may be

affected by buildings and natural obstacles as well as weather conditions.

■Using the GPS receiver

When using the GPS receiver that is inside the lower part

of the Nokia Xpress-on GPS shell, do not cover the area

marked with blue in the picture. The antenna of the GPS

receiver is located in this area.

Hold the phone upright in your hand at an angle of about

45 degrees, with a clear view of the sky.

3. Using the GPS application

To use the GPS application, press Menu in standby mode, and select Applications,

Collection, and Select application. Scroll to GPS, and press Open or . Scroll to

the main screen that you want to use, and press Select.

The GPS application includes the following main screens: Satellites, Trip

computer, Route guidance, Waypoints, Routes, Tracking, and Settings.

The screen name is shown at the top of the screen. The screens of the GPS

application and their functions are described in this chapter.

You can exit the application by pressing .

■Viewing information about satellites

The Satellites screen shows the following information: date, time, geographical

coordinates of your current location, status of the GPS receiver, available

satellites, and GPS accuracy.

Note that getting a GPS connection may take from a couple of seconds up to

several minutes. Availability and quality of GPS signals may be affected by

buildings and natural obstacles as well as weather conditions.

Using the GPS application

Information shown on the Satellites screen

• The date and time fields show the current date and time that the GPS receiver

has received from the GPS satellites. The date and time are shown in GMT

(Greenwich Mean Time) format.

• The latitude and longitude fields below the date and time fields show your

current location as geographical coordinates in WGS84 format (WGS84 is a

geographical coordinate system). The correct coordinates are shown only if the

GPS receiver is receiving the needed positioning information from GPS

satellites.

• The status of the GPS receiver is shown below the latitude and longitude fields.

Wait until the GPS receiver is ready for navigation before you start using it.

• The GPS accuracy field (next to the GPS receiver status field) shows an

estimate of how accurately the GPS receiver can show your current location.

• The diagram below the GPS receiver status and GPS accuracy fields shows up

to 12 satellites in view (as satellite IDs) and the signal strength of each

satellite. The better the signal strength, the stronger the signals received from

the satellite.

If the signal strength of a satellite is poor, the satellite and its ID are indicated

by gray color. The GPS receiver does not use GPS positioning information

received from this kind of satellite.

If the signal strength of the satellite is good, the satellite and its ID are

indicated by black color. The GPS receiver uses GPS positioning information

received from this kind of satellite.

If you press any selection key on the Satellites screen, you can select Mark

position to save the coordinates of your current location as a waypoint (landmark)

or Main menu to return to the main menu of the GPS application.

Saving a waypoint (Mark position)

With the Mark position function you can save the coordinates of your current

location as a waypoint for later use. Key in a name for the waypoint, press OK, key

in a comment about the waypoint, and press Save on the Comments screen.

When the coordinates and comments are shown, press Done to return to the main

screen, or press Options to edit or delete the waypoint, send it as a text message

(network service) to a device that supports the Nokia Landmark Specification, or

navigate to the waypoint on the Route guidance screen (Go to).

■Viewing information about the current trip

The Trip computer screen allows you to view the following information about the

current trip: course, speed, altitude, average speed, maximum speed, timer,

odometre, maximum altitude, and minimum altitude.

To reset a single information field, scroll to the desired field, and press the middle

selection key. This function is only available for fields that show accumulating

information.

Using the GPS application

Information shown on the Trip computer screen

• The course indicator at the top of the screen shows the direction where you are

heading. The course is indicated by red arrows in the centre of the field. N

stands for north, S for south, E for east, and W for west.

If the current course cannot be shown, the course indicator briefly shows the

last known course and then disappears from the screen.

• The Speed field shows the current speed. If the speed is very low, it is indicated

by <1.

The speed is not shown if the GPS receiver cannot determine it.

• The Altitude field shows the approximate altitude of your current location. If

the location is below sea level, a negative value is shown.

The altitude is not shown if the GPS receiver cannot determine it.

• The Average speed or Avg. speed field shows your average speed. If you stop,

the GPS receiver continues to calculate this speed. The longer you stay still, the

lower the average speed will be.

If the current average speed cannot be shown, the last saved average speed is

shown instead.

• The Maximum speed or Max. speed field shows your maximum speed after the

last reset of the speed counter.

If the current maximum speed cannot be shown, the last saved maximum

speed is shown instead.

• The Timer field shows the time that has elapsed since the last reset of the

timer. The timer continues to run even if the GPS receiver cannot receive

signals from the GPS satellites.

The timer is reset if you exit the GPS application.

• The Odometre field shows the distance that you have covered since the last

reset of the odometre.

If the current distance cannot be shown, the last saved distance is shown

instead.

• The Maximum altitude or Max. altitude field shows the altitude of your highest

location since the last reset of the altitude meter.

If the current maximum altitude cannot be shown, the last saved maximum

altitude is shown instead.

• The Minimum altitude or Min. altitude field shows the altitude of your lowest

location since the last reset of the altitude meter.

If the current minimum altitude cannot be shown, the last saved minimum

altitude is shown instead.

Functions accessible by pressing the Options key

If you press Options on the Trip computer screen, you can select from the

following functions:

•Change fields - You can define which functions are shown on the Trip

computer screen. Scroll to the field whose function you want to change, press

Select, scroll to the desired option, and press Select.

Using the GPS application

•Change view - You can define how many fields (2, 4, or 6) are shown on the

Trip computer screen.

•Reset all - You can reset all the fields to their original values.

•Restore defaults - You can reset the Trip computer screen to its default view.

The values on the Trip computer screen will not be reset.

•Mark position - You can save your current location as a waypoint. For more

information, see Saving a waypoint (Mark position) on page 14.

■Following a route

On the Route guidance screen, you can follow the route that you have activated

on the Routes screen or navigate to the waypoint that you have activated using

the Go to option of the Mark position function (available on several screens).

The screen shows the following information: course, bearing, next waypoint,

speed, and distance to the next waypoint.

• The blue course arrow indicates the direction where you are heading. The

direction is indicated by N (north), S (south), E (east), and W (west).

The yellow bearing arrow indicates the direction where you should be heading

to reach the next waypoint.

To reach the next waypoint, adjust your direction so that the two arrows point

to the same direction.

If the GPS receiver cannot receive the needed positioning information from

GPS satellites, the Next: and Dist. to next fields are empty, and a question mark

is shown in the middle of the screen.

Tip: You can also use the Route guidance screen as a compass if you

have not activated a route but the GPS receiver is receiving the

needed positioning information from GPS satellites. In this case, the

screen shows the current course and speed when you are on the

move.

• The Next field shows the next waypoint. The phone shows a note when you are

approaching or reaching the waypoint.

• The Speed field shows the current speed.

• The Dist. to next field shows the distance to the next waypoint.

If you press any selection key on the Route guidance screen, you can select

Deactivate route if you do not want the Route guidance screen to show the

bearing arrow and the next waypoint, or you can select Mark position to save your

current location as a waypoint (see Saving a waypoint (Mark position) on page

14).

■Managing waypoints

On the Waypoints screen you can view, search, add, and delete waypoints. The

waypoints shown in this screen are also available in the Travel guide application.

•Find - You can search for previously saved waypoints by their distance to your

location (Nearest) or by their name (By name).

If you selected Nearest, the GPS receiver shows the nearest waypoints and the

distance of each waypoint to your current or last known location. If you

selected By name, key in the first letters of the waypoint name, and press Find.

Using the GPS application

To view the coordinates of a found waypoint and the comments about it, scroll

to the waypoint, and press Details. You can press Options to edit or delete the

waypoint, send it as a text message (network service) to a device that supports

the Nokia Landmark Specification, or navigate to the waypoint on the Route

guidance screen (Go to).

•Add - You can save the coordinates of the current location as a waypoint

(Current position) or define the coordinates manually (Manually).

If you selected Manually, key in a name for the waypoint, press OK, key in the

coordinates in WGS84 format, press OK, key in a comment about the waypoint,

and press Save.

When the coordinates and comment are shown, you can press Options, for

example, to send the waypoint as a text message (network service) to a device

that supports the Nokia Landmark Specification or navigate to the waypoint

on the Route guidance screen (Go to).

•Delete - You can remove previously saved waypoints one by one or all at once.

The waypoints are removed both from the GPS and Travel guide application.

•Memory status - You can view how much memory is available to save

waypoints.

Receiving a waypoint as a text message

When you receive a waypoint as a text message, the phone shows a related note

in standby mode. To view and save the waypoint, press Show, scroll to the

waypoint, press Details, press Options, and select Save.

You can send waypoints, for example, in the Satellites screen (see Saving a

waypoint (Mark position) on page 14) and Waypoints screen.

■Managing and activating routes

On the Routes screen, you can search, add, and delete routes, and activate them

for navigation. A route is a list of waypoints.

You can create a new route by adding the desired waypoints into a list. When the

route is complete, you can activate it in order to view it on the Route guidance

screen.

•Find - You can search for a previously saved route by its name. Key in the route

name, and press Find, or press to view all the saved routes. Scroll to the

desired route, and press Details to view the waypoints of the route, the

distance of each waypoint to the previous one, and the total length of the

route.

If you press Options, you can select

•Activ. to view the route on the Route guidance screen. When the route is

shown on the Route guidance screen, you can select Deactivate route to

hide the route.

•Reverse to follow the route in reverse direction and view the route on the

Route guidance screen.

•Edit to modify or delete the route. If you press Options in the waypoint list,

you can view the details of the selected waypoint, delete the waypoint,

Other manuals for Xpress-on

This manual suits for next models

Table of contents

Popular Cell Phone Accessories manuals by other brands

OtterBox

OtterBox defender user manual

Infinite Peripherals

Infinite Peripherals Infinea X DF quick start guide

Mophie

Mophie juice pack H2PRO user manual

Privoro

Privoro Safecase quick start guide

noisehush

noisehush N620 user manual

Hohem

Hohem iSteadyMobile Plus user manual

LifeProof

LifeProof FRE owner's manual

Glovii

Glovii BG2XR manual

Ram Mounts

Ram Mounts IntelliSkin manual

Razer

Razer Phone Cooler Chroma manual

Techcare Technology

Techcare Technology TEP207 user manual

SwiftCam

SwiftCam M3s Startup guide

HTC

HTC Media Link HD user guide

Audio Ape

Audio Ape Remote instruction manual

Aluratek

Aluratek APC02B quick start guide

SCORPION

SCORPION ERS 2 installation instructions

Moza

Moza NANO SE user manual

Samsung

Samsung MULTI CLIP A200 manual
