Nokia 02719B5 User manual

Nokia Bluetooth Headset BH-216
9215317/1.0
10
9
1
2
3
6
4
8
5
7
Copyright © 2009 Nokia. All rights reserved.
9215317/2.0
Copyright © 2009 Nokia. All rights reserved.
9215317/2.0

Copyright © 2009 Nokia. All rights reserved.
13
11 12

3
Copyright © 2009 Nokia. All rights reserved.
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares
that this BH-216 product is in compliance
with the essential requirements and other
relevant provisions of Directive 1999/5/
EC. A copy of the Declaration of
Conformity can be found at
http://www.nokia.com/phones/
declaration_of_conformity/.
© 2009 Nokia. All rights reserved.
Nokia, Nokia Connecting People and the
Nokia Original Accessories logo are
trademarks or registered trademarks of
Nokia Corporation. Nokia tune is a sound
mark of Nokia Corporation. Other product
and company names mentioned herein
may be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or
storage of part or all of the contents in
this document in any form without the
prior written permission of Nokia is
prohibited.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Nokia operates a policy of ongoing
development. Nokia reserves the right to
make changes and improvements to any
of the products described in this
document without prior notice.
To the maximum extent permitted by
applicable law, under no circumstances
shall Nokia or any of its licensors be
responsible for any loss of data or income
or any special, incidental, consequential
or indirect damages howsoever caused.
The contents of this document are
provided "as is". Except as required by
applicable law, no warranties of any kind,
either express or implied, including, but
not limited to, the implied warranties of
merchantability and fitness for a
particular purpose, are made in relation to
the accuracy, reliability or contents of this
document. Nokia reserves the right to
revise this document or withdraw it at any
time without prior notice.
The availability of particular products may
vary by region. Please check with your
Nokia dealer for details.

4
Copyright © 2009 Nokia. All rights reserved.
Export controls
This device may contain commodities,
technology or software subject to export
laws and regulations from the US and
other countries. Diversion contrary to law
is prohibited.
Introduction
With the Nokia Bluetooth Headset
BH-216, you can make and answer
calls hands-free with your
compatible mobile device.
Read this user guide carefully before
using the headset. Also, read the
user guide for the device that you
connect to the headset.
This product may contain small
parts. Keep them out of the reach of
small children. The surface of this
device is nickel-free.
Bluetooth wireless technology
Bluetooth wireless technology
allows you to connect compatible
devices without cables. The headset
and the other device do not need to
be in line of sight, but they should
be within 10 metres (33 feet) of
each other. Connections may be
subject to interference from
obstructions, such as walls, or other
electronic devices.
The headset is compliant with the
Bluetooth Specification 2.1 + EDR
supporting the following profiles:
Headset Profile 1.1 and Hands-Free
Profile (HFP) 1.5. Check with the
manufacturers of other devices to
determine their compatibility with
this device.

5
Copyright © 2009 Nokia. All rights reserved.
Get started
The headset contains the following
parts shown on the title page:
power key (1), volume key (2),
answer/end key (3), earpiece (4),
indicator light (5), charger
connector (6), earloop (7), and
microphone (8).
Before using the headset, you must
charge the battery and pair the
headset with a compatible device.
Parts of the device are magnetic.
Metallic materials may be attracted to
the device. Do not place credit cards or
other magnetic storage media near the
device, because information stored on
them may be erased.
Charge the battery
Before charging the battery,
carefully read “Battery and charger
information”.
Warning: Use only
chargers approved by
Nokia for use with this
particular model. The use of
any other types may
invalidate any approval or
warranty, and may be
dangerous.
When you disconnect the power cord
of any accessory, grasp and pull the
plug, not the cord.
1. Connect the charger to a wall
outlet.
2. Connect the charger cable to the
charger connector. The red
indicator light is displayed
during charging. Charging the
battery fully may take up to
1 hour and 15 minutes.
3. When the battery is fully
charged, the green indicator
light is displayed. Disconnect the

6
Copyright © 2009 Nokia. All rights reserved.
charger from the headset, then
from the wall outlet.
The fully charged battery has power
for up to 6 hours of talk time or up
to 160 hours of standby time.
To check the battery charge when
the headset is not connected to a
charger, press the power key when
the headset is switched on. If the
indicator light is green, the charge
level is sufficient. If the light is
orange, you may need to recharge
the battery soon. If the light is red,
recharge the battery.
When the battery charge is low, the
headset beeps every 5 minutes and
the red indicator light flashes.
Switch on or off
To switch on, press and hold the
power key for about 5 seconds. The
headset beeps, and the green
indicator light is displayed. The
headset tries to connect to the last
connected device.
To switch off, press and hold the
power key for about 2 seconds. The
headset beeps, and the red indicator
light is briefly displayed. If the
headset is not connected to a device
within about 30 minutes, it
switches off automatically.
Pair and connect the headset
1. Ensure that your mobile device
is switched on and the headset is
off.
2. Press and hold the power key (for
about 8 seconds) until the green
indicator light starts to flash
quickly.
3. Within about 3 minutes, activate
Bluetooth connectivity on the
mobile device, and set it to
search for Bluetooth devices.

7
Copyright © 2009 Nokia. All rights reserved.
4. Select the headset from the list
of found devices.
5. If necessary, enter the passcode
0000 to pair and connect the
headset to your device. In some
devices, you may need to make
the connection separately after
pairing.
When the headset is connected to
your device and is ready for use, the
green indicator light flashes slowly.
You can pair the headset with up to
eight devices, but you can connect
it to only one device at a time.
To manually connect the headset to
the last used device, switch the
headset off and on, or press and
hold the answer/end key for about 2
seconds.
You may be able to set your device
so that the headset connects to it
automatically. To activate this
feature in a Nokia device, change
the paired device settings in the
Bluetooth menu.
Basic use
Change the earpad
The headset may be provided with
different sized earpads. Select the
earpad that fits the best and is the
most comfortable for your ear.
To change the earpad, pull the
current earpad from the earpiece,
and push the new earpad into place,
with the narrower end first (12).

8
Copyright © 2009 Nokia. All rights reserved.
Place the headset on the ear
Gently push the earpiece against
your ear.
You can rotate the earpad to keep
the headset securely in the ear (13).
For example, if you use the headset
on the right ear, you may need to
rotate the earpad to the right for
the best fit. If you wear an earring,
ensure that it is not accidentally
attached to the earpad.
To use the headset with the earloop,
attach the earloop to it (11). To
detach the earloop, gently pull it
from the headset. Slide the earloop
behind your ear (9), and point the
headset towards your mouth (10).
Push or pull the earloop to set its
length.
Calls
To make a call, use your mobile
device in the normal way when the
headset is connected to it.
To redial the number you last called
(if your device supports this feature
with the headset), when no call is in
progress, press the answer/end key
twice.
To activate voice dialling (if your
device supports this feature with
the headset), when no call is in
progress, press and hold the answer/
end key for about 2 seconds.
Proceed as described in the user
guide of your device.
To answer or end a call, press the
answer/end key. To reject a call,
press this key twice.
To adjust the volume, press the
volume key up or down.

9
Copyright © 2009 Nokia. All rights reserved.
To mute or unmute the microphone,
press the middle of the volume key.
When the microphone is muted, the
green indicator light flashes twice
about every 5 seconds.
To switch a call from the headset to
a compatible device, press and hold
the answer/end key for about 2
seconds, or switch off the headset.
To switch the call back to the
headset, press and hold the answer/
end key for about 2 seconds, or
switch on the headset.
Turn lights on or off
By default, the indicator lights are
on in all situations. To turn the
lights off in some situations (for
example, during a call or when the
headset is connected to a mobile
device) or back on, press and hold
the power key and the answer/end
key for about 2 seconds when the
headset is connected to a device.
Turning the lights off increases the
standby time.
Clear settings or reset
To delete the pairings from the
headset when it is switched off,
press and hold the power key and
the answer/end key (for about 6
seconds) until the red and green
indicator lights start to alternate.
To reset the headset if it stops
functioning, even though it is
charged, connect the headset to a
charger while you press and hold
the power key. The reset does not
clear the pairing settings.
Troubleshooting
If you cannot connect the headset
to your compatible device, check
that the headset is charged,
switched on, and paired with your
device.

10
Copyright © 2009 Nokia. All rights reserved.
Battery and charger information
This device has an internal,
nonremovable, rechargeable battery.
Do not attempt to remove the battery
from the device as you may damage
the device. This device is intended for
use when supplied with power from
the following chargers: AC-3, AC-4,
AC-5, AC-8, and DC-4. The exact
charger model number may vary
depending on the type of plug. The
plug variant is identified by one of the
following: E, EB, X, AR, U, A, C, or UB.
The battery can be charged and
discharged hundreds of times, but it
will eventually wear out. Recharge
your battery only with Nokia approved
chargers designated for this device.
Use of an unapproved charger may
present a risk of fire, explosion,
leakage, or other hazard.
If a battery is being used for the first
time or if the battery has not been used
for a prolonged period, it may be
necessary to connect the charger, then
disconnect and reconnect it to begin
charging the battery. If the battery is
completely discharged, it may take
several minutes before the charging
indicator light is displayed.
Unplug the charger from the electrical
plug and the device when not in use.
Do not leave a fully charged battery
connected to a charger, since
overcharging may shorten its lifetime.
If left unused, a fully charged battery
will lose its charge over time.
Always try to keep the battery between
15°C and 25°C (59°F and 77°F).
Extreme temperatures reduce the
capacity and lifetime of the battery. A
device with a hot or cold battery may
not work temporarily. Battery
performance is particularly limited in
temperatures well below freezing.

11
Copyright © 2009 Nokia. All rights reserved.
Do not dispose of batteries in a fire as
they may explode. Batteries may also
explode if damaged.
Never use any charger that is damaged.
Important: Battery talk
and standby times are
estimates only and depend
on network conditions,
features used, battery age
and condition,
temperatures to which
battery is exposed, and
many other factors. The
amount of time a device is
used for calls will affect its
standby time. Likewise, the
amount of time that the
device is turned on and in
the standby mode will
affect its talk time.

12
Copyright © 2009 Nokia. All rights reserved.
Care and maintenance
Your device is a product of superior
design and craftsmanship and should
be treated with care. The following
suggestions will help you protect your
warranty coverage.
• Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits. If
your device does get wet, allow it to
dry completely.
• Do not use or store the device in
dusty, dirty areas. Its moving parts
and electronic components can be
damaged.
• Do not store the device in hot areas.
High temperatures can shorten the
life of electronic devices, damage
batteries, and warp or melt certain
plastics.
• Do not store the device in cold
areas. When the device returns to
its normal temperature, moisture
can form inside the device and
damage electronic circuit boards.
• Do not attempt to open the device.
• Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and fine
mechanics.
• Do not use harsh chemicals,
cleaning solvents, or strong
detergents to clean the device.
• Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
These suggestions apply equally to
your device, charger, or any accessory.
If any device is not working properly,
take it to the nearest authorised
service facility for service.
