GB Instructions for use
IEC countries
TG-3

1
Warning
In case this appliance contains hydrocarbon refrigerant please refer to guidelines listed below.
As the appliance contains a flammable refrigerant, it is essential to ensure that the refrigerant
pipes are not damaged.
Standard EN378 specifies that the room in which you install your appliance must have a
volume of 1m³ per 8 g of hydrocarbon refrigerant used in the appliances. This is to avoid the
formation of flammable gas/air mixtures in the room where the appliance is located in the
event of a leak in the refrigerant circuit. The quantity of the refrigerant used in your appliance
is indicated on the rating plate.
Warning:
Keep ventilation openings in the appliance’s cabinet or in the built-in structure clear of
obstruction
Do not use other mechanical devices or other means to accelerate the defrosting process
than those recommended by the manufacturer
Do not damage the refrigerant system
Do not use electrical appliances inside the refrigerated storage compartment, unless they
are of a type recommended by the manufacturer
Do not expose the appliance to rain
This appliance is not intended for use by young children or infirm persons unless they have
been adequately supervised by a responsible person to ensure that they can use the
appliance safely. Young children should be supervised to ensure that they do not play with
the appliance
Always keep the keys in a separate place and out of reach of children
Do not try to repair the faulty unit.
Do not storage flammable or explosive materials in the refrigerators.
If you don’t want to use the unit for a while pull out the plug from the mains socket.
Do not cover the ventilation openings of the back of the fan, on the upper part of the
refrigerator and the gap below the door.
Before servicing or cleaning the appliance, unplug the appliance from the mains or
disconnect the electrical power supply
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or
similarly qualified persons in order to avoid a hazard
Relevant for Australia: Supply cord fitted with a plug complies with AS/NZS 3112.
Frost formation on the interior evaporator wall and upper parts is a natural phenomenon.
Therefore, the appliance should be defrosted during normal cleaning or maintenance.
Please note that changes to the appliance construction will cancel all warranty and product
liability.
GB

2
Contents
Warning.............................................................................................................................1
Technical date................... ...............................................................................................2
Before using the appliance................................................................................................3
Electrical connection .........................................................................................................3
Temperature control .........................................................................................................4
Control and cleaning .........................................................................................................4
Warranty, spare parts and service.....................................................................................5
Disposal..................................................................................................................................6
The technical specifications may change without notice.
Technical date
Net capacity (litres)
39 l
Refrigerant
R 134a/110g
Gross capacity (litres)
44,5 l
External dimensions ( W * D * H )
700 * 675 * 515
Temperature range °C
-20 2 °C
Internal dimensions ( W * D * H )
538* 360 * 165
Climatic class
III. (25°C)
Branding surface
0,35m2
Cooling
Silent
Net weight
34 kg
Voltage
230 V/50 Hz
Gross weight
37 kg
Energy consumption
2.9 kWh/24 h
GB

3
Before using the appliance
Please read these instructions carefully. They will give you important information on the
installation, operation and maintenance of the appliance.
Damaged appliances must not be connected to the mains. If in doubt, ask your supplier.
Placing
It is best to place the appliance in a dry room with good air circulation. The room temperature
should be as low as possible (energy-saving), but not lower than +5°C.
The unit belongs to climate category 3 and may be operated only rooms with a temperature
range from +16°C and +25°C.
In placing the appliance, it must not be exposed to direct sunlight or placed up against a heat
source
The appliance must be placed on an even, horizontal and stable surface.
If the furnishing of the room allows positioning only close to the heat source, the following
minimum clearance of 4 cm must be kept: If the clearance from a gas or electric oven is 25
cm (or less), a 0.5-1.0 cm thick insulating sheet must be inserted between the two units.
Min. 120 cm from oil or coal fired ovens. Not for built in, only free standing.
Minimum free space above appliance 500mm
Starting:
Before using the appliance, it is advisable to wash down the inside wit lukewarm water and a
mild detergent, and then to dry it thoroughly.
Operate the unit empty for circa 2 or 3 hours after turning on.
The refrigerator filled up with pre- cooled product.
The runtime in the appliance will depend on the temperature of the room.
It may therefore be necessary to change the thermostat setting from time to time.
Electrical connection
Important: Wiring and connections in power supply systems must have all applicable (local
and national) electrical codes. Consult these codes lengths and sizes prior to cabinet installa-
tion.
This appliance meets the provisions of the following directives: 89/336/EEC (electromagnet-
ic compatibility), 73/23/EEC (electrical equipment designed for use within certain voltage lim-
its) as amended.
The rating plate provides various technical information as well as type and serial number.
Do not under any circumstances cut or remove the round grounding prong from the appli-
ance plug.
Do not under any circumstances use extension cords.
PRODUCT FOR INDOOR USE ONLY
GB

4
Temperature control
The digital refrigeration controller on the right side controls the temperature.
The inside temperature can be adjusted by the digital controller.
The steps of the setting of the requested temperature:
1. Keep pressed the SET key for minimum 2 sec
2. The value of present SET point appears on the display and the °C or °F
LED starts to flash
3. To change the value press the [UP] or [DOWN] key in 10 sec
4. To save the modified value press the SET key again and wait for 10 sec
The temperature of the cold chamber can be read from the display of digital controller.
The displayed temperature equal with the temperature of the product placed on the load level
±2°C. This marginally can be bigger in different climate classes. In this case adjust colder or
warmer value in the digital controller.
By the setting of temperature note the offered temperature for the store of frozen product.
Control and cleaning
Before beginning cleaning, switch off main power at the wall socket.
Clean the appliance with a mild soap liquid.
Use a wrung-out cloth or sponge.
Always dry off with a clean, dry cloth.
It is recommended to remove dust and debris collected on the condenser under the
refrigerator once or twice every 3 month. Gently lift the refrigerator.
Remove dust and other contamination collected below the refrigerator.
Remove dust collected on the condenser with a brush.
Attention: always keep the ventilation openings clean.
Warning: Never use cleaning agents containing abrasive substances
Switching off the unit when not in use
Pull out the plug from the socket.
Wipe and dry the inner part and open the lid a bit to remove unpleasant odors.
GB

5
Warranty, spare parts and service
Warranty disclaimer
Faults and damage caused directly or indirectly by incorrect operation, misuse, insufficient
maintenance, incorrect building, installation or mains connection. Fire, accident, lightening,
voltage variation or other electrical interference, including defective fuses or faults in mains
installations are not covered by the warranty.
Repairs performed by others than approved service centers and any other faults and
damage that the manufacturer can substantiate are caused by reasons other than
manufacturing or material faults are not covered by the warranty.
Please note that changes to the construction of the appliance or changes to the component
equipment of the appliance will invalidate warranty and product liability, and the appliance
cannot be used lawfully. The approval stated on rating plate will also be invalidated.
Transport damage discovered by the buyer is primarily a matter to be settled between the
buyer and the distributor, i.e. the distributor must ensure that such complaints are resolved to
the buyer’s satisfaction.
Before calling for technical assistance, please check whether you are able to rectify the fault
yourself. If your request for assistance is unwarranted, e.g. if the appliance has failed as a
result of a blown fuse or incorrect operation, you will be charged the costs incurred by your
call for technical assistance.
Spare parts
When ordering spare parts, state the type, serial and production numbers of your appliance.
This information is given on the rating plate. The rating plate contains various technical
information, type and serial numbers.
GB

6
Disposal
Information for Users on Collection and Disposal of Old Equipment and used Batteries.
These symbols on the products, packaging, and/or accompanying documents
mean that used electrical and electronic products and batteries should not be
mixed with general household waste. For proper treatment, recovery and
recycling of old products and used batteries, please take them to applicable
collection points, in accordance with your national legislation and the Directives
2002/96/EC and 2006/66/EC.
By disposing of these products and batteries correctly, you will help to save
valuable resources and prevent any potential negative effects on human health
and the environment which could otherwise arise from inappropriate waste
handling.
For more information about collection and recycling of old products and
batteries, please contact your local municipality, your waste disposal service or
the point of sale where you purchased the items.
Penalties may be applicable for incorrect disposal of this waste, in accordance
with national legislation.
For business users in the European Union.
If you wish to discard electrical and electronic equipment, please contact your
dealer or supplier for further information.
[Information on Disposal in other Countries outside the European Union]
These symbols are only valid in the European Union. If you wish to discard this
product, please contact your local authorities or dealer and ask for the correct
method of disposal.
Note for the battery symbol (bottom two symbol examples):
This symbol might be used in combination with a chemical symbol. In this case it
complies with the requirement set by the directive for the chemical involved.
Reserves the right to alter specifications without prior notice
