Add a Network Group to Option 81C CP2-4
with FNF
Description
Update the chapter “Add a Network Group to Option 81C with FNF” to “Add
a Network Group to Option 81C CP2-4 with FNF” and include Option 81C
CNI group assignments on a system that originated as a non-FNF system
prior to X11 Release 25.
Correction
Note: Figure, table, procedure, and page numbers (for example, Table 5,
page 10) are subject to change in the next standard release of documentation.
Revision in Upgraded Systems Installation: Upgrade to Options
51C, 61C, 81C, 553-3001-258:
Customer Service Report Number N/A
NTP Number 553-3001-258
Software Release Meridian 25.40

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/022of 26
TM
Add a Network Group to
Option 81C CP2-4 with FNF
Contents
The following are the topics in this section:
Reference list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Preparing for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Verifying removal of 3PE cards from Option 81 Core shelves . . . . 2
Add the new Network modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Add CNI cards if necessary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Pre-routing CNI to 3PE cables . .. . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Pre-route the FIJI cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing cards in the Network modules . . . . . . . . . . . . . . . . . . . . . . . 16
Installing and enable the 3PE cards . . . . . . . . . . . . . . . . . . . . . . . . . 16
Installing and enabling the Peripheral Signaling (Per Sig) cards . .. 18
Disabling and inserting the FIJI cards . . . . . . . . . . . . . . . . . . . . . . . 18
Disabling and inserting the Conf/TDS cards, if necessary . . . . . . . 18
Enabling the CNI cards . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Enabling the FIJI cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Connect the new groups to the Fiber Network . . . . . . . . . . . . . . . . . . . 21
Reference list
The following are the references in this section:
•System Installation Procedures (553-3001-210)

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/023of 26
TM
Preparing for installation
The procedures in this section are for systems that have already been
upgraded to the Fiber Network. Follow the procedures in order.
Verifying removal of 3PE cards from Option 81 Core shelves
In Option 81 systems, the 3PE card must be removed from the Core shelves.
This card should have been removed during the upgrade procedure. If this
card was not removed during the upgrade process, remove it now.
Note: This procedure is for Option 81 systems with Core shelves. This
procedure is NOT necessary for Option 81C systems with Core/Net
shelves.
Procedure 1
Removing the 3PE card from both Cores:
1In Core 1, hardware disable the 3PE card.
2In Core 0, hardware disable the 3PE card.
3Remove the 3PE faceplate cable.
4Remove the 3PE cards from Core 1 and 0.
—————————— End of Procedure ——————————
Add the new Network modules
The new Network modules must be connected to the system. Follow the
instructions in System Installation Procedures (553-3001-210) to correctly
configure the power and System Monitor connections.
Add CNI cards if necessary
CNI-3 cards are added only if additional ports are required. CNI-3 cards can
only be installed in an inactive Core module.
Port assignments
The default port assignments for CNI cards in Option 81 and 81C systems are
shown in Table 1 and Table 2. These assignments can be modified in
Overlay 17 if necessary.

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/024of 26
TM
When a two port CNI card is replaced with a three port CNI-3 card, the
original port assignments for the backplane connections remain the same.
Procedure 2
Installing the CNI-3 cards
1On the inactive Core, software disable the CNI slots where the new
cards will be installed:.
2Faceplate disable the CNI cards to be replaced on the inactive Core.
3Remove the CNI cards to be replaced, if necessary.
4Install the new CNI-3 cards. The CNI-3 cards must be faceplate
disabled before installation.
5Faceplate enable all CNI cards on the inactive Core.
—————————— End of Procedure ——————————
Procedure 3
Adding a CNI group
1Add CNI group(s).
2Software enable the original CNI ports on the inactive Core. Do NOT
activate the CNI ports for the new Network Groups:.
3Switch active Cores:
4Follow steps 1 and 2 to install the CNI cards on the second Core. Be
sure to make the second Core inactive.
LD 135 to load the program.
DIS CNI c s p (core slot port) to disable the card and ports.
LD 17 to load the program
CHG change existing data block
CEQU type of data block
CNI s p g (slot port group) to add a CNI group
LD 135 to load the program.
ENL CNI c s p (core slot port) to enable the card and ports.
SCPU to switch Cores

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/025of 26
TM
5Verify the status of the CNI cards:
—————————— End of Procedure ——————————
Pre-routing CNI to 3PE cables
The CNI backplane ports are connected to the 3PE cards with two NTND14
CNI to 3PE cables per port. The third port connects from the CNI-3 faceplate
to the 3PE card with two NT9D89 cables.
When a CNI card is upgraded to a CNI-3 card, the original NTND14
backplane cables are left in place; only the NT9D89 CNI-3 to 3PE faceplate
cables must be added.
Procedure 4
Pre-routing CNI to 3PE cables
1Label the cables with Network Group, CNI port and connection
information.
2Route the new CNI to 3PE cables according to the port assignments in
Tables 1, Table 2 and Table 3. Do NOT attach the cables.
—————————— End of Procedure ——————————
STAT CNI to check the status of the cards and ports.

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/026of 26
TM
.
Table 1
Option 81 CNI group assignments
Group CNI connection 3PE faceplate
connection Cable
58A (Core backplane) J3 NTND14
58C (Core backplane) J4 NTND14
08D (Core backplane) J3 NTND14
08F (Core backplane) J4 NTND14
19A (Core backplane) J3 NTND14
19C (Core backplane) J4 NTND14
29D (Core backplane) J3 NTND14
29F (Core backplane) J4 NTND14
310A (Core backplane) J3 NTND14
310C (Core backplane) J4 NTND14
410D (Core backplane) J3 NTND14
410F (Core backplane) J4 NTND14
69 J1 (CNI-3 faceplate) J3 NT9D89
69 J2 (CNI-3 faceplate) J4 NT9D89
710 J1 (CNI-3 faceplate) J3 NT9D89
710 J2 (CNI-3 faceplate) J4 NT9D89
Note: The default assignments in this table can be reconfigured with Overlay 17 (LD 17) if necessary.

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/027of 26
TM
Table 2
Option 81C CNI group default assignments (introduced with X11 25.xx)
Group CNI slot connections 3PE faceplate
connection Cable
112D (Core/Net backplane) J3 NTND14
112F (Core/Net backplane) J4 NTND14
212 J1 (CNI-3 faceplate) J3 NT9D89
212 J2 (CNI-3 faceplate) J4 NT9D89
313A (Core/Net backplane) J3 NTND14
313C (Core/Net backplane) J4 NTND14
413D (Core/Net backplane) J3 NTND14
413F (Core/Net backplane) J4 NTND14
513 J1 (CNI-3 faceplate) J3 NT9D89
513 J2 (CNI-3 faceplate) J4 NT9D89
614A (Core/Net backplane) J3 NTND14
614C (Core/Net backplane) J4 NTND14
714D (Core/Net backplane) J3 NTND14
714F (Core/Net backplane) J4 NTND14
Note 1: Group 0 is hard-wired through the Core/Net module backplane; no cable is required.
Note 2: The default assignments in this table can be reconfigured with Overlay 17 (LD 17) if necessary.
Note 3: Table shown is using CNI-3 hardware in slots 12 and 13.

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/028of 26
TM
Table 3
Option 81C CNI group assignments on a system that originated as a non-FNF system prior
to X11 Release 25
Group CNI slot connections 3PE faceplate
connection Cable
012A (Core/Net backplane) J3 NTND14
012C (Core/Net backplane) J4 NTND14
112D (Core/Net backplane) J3 NTND14
112F (Core/Net backplane) J4 NTND14
213A (Core/Net backplane) J3 NTND14
213C (Core/Net backplane) J4 NTND14
313D (Core/Net backplane) J3 NTND14
313F (Core/Net backplane) J4 NTND14
414A (Core/Net backplane) J3 NTND14
414C (Core/Net backplane) J4 NTND14
514D (Core/Net backplane) J3 NTND14
514F (Core/Net backplane) J4 NTND14
613G (CNI-3 faceplate) J3 NT9D89
613H (CNI-3 faceplate) J4 NT9D89
714G (CNI-3 faceplate) J3 NT9D89
714H (CNI-3 faceplate) J4 NT9D89
Note 1: The default assignments in this table can be reconfigured with Overlay 17 (LD17) if necessary.
Note 2: This table represents the typical assignments that would follow a system originating from a pre
25.10 system. The CNI cards in slot 13 and 14 have been replaced with CNI-3 cards allowing the expansion
to a 8 group system

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/029of 26
TM
Pre-route the FIJI cables
To minimize system downtime during the upgrade, all FIJI cables must be in
place before the new Network Groups are added.
Route FIJI to FIJI cables
Route a NTRC47AA cable between the FIJI cards in shelf 0 and shelf 1 of
each new Network Group.
Figure 1
Route FIJI to FIJI cables (Option 81C example)
J3
J4
J3
J4
J3
J4
J3
J4
J3
J4
J3
J4
J3
J4
Tx (J1)
Rx (J2)
Group 0, shelf 0
Group 0, shelf 1
Tx (J1)
Rx (J2)
Group 2, shelf 0
Tx (J1)
Rx (J2)
Group 2, shelf 1
Tx (J1)
Rx (J2)
Group 4, shelf 1
Tx (J1)
Rx (J2)
Group 4, shelf 0
Group 3, shelf 0
Tx (J1)
Rx (J2)
Group 3, shelf 1 Group 1, shelf 0
Tx (J1)
Rx (J2)
Group 1, shelf 1
Tx (J1)
Rx (J2)
IPE IPE
IPE
IPE
IPE
553-9556
J3
J4
J3
J4
Tx (J1)
Rx (J2)
J3
J4
Tx (J1)
Rx (J2)
IGM
(not used with
Fiber Network)
NTRC47AA FIJI to FIJI cables

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/0210of26
TM
Labelling and routing the shelf 0 fiber optic cables (ascending)
Route the NTRC48 cables between the FIJI cards in each new Network shelf
0 in ascending order. See Figure 2 on page 11.
Procedure 5
Labelling and routing the shelf 0 fiber optic cables (ascending)
1Start with shelf 0 in the current highest Network Group.
2Label each cable on both sides with the appropriate connection
information from Table 4.
3Route a NTRC48 FIJI Fiber Ring cable of the appropriate length from
the FIJI card in shelf 0 of the current highest Network Group, to the FIJI
card in shelf 0 of the new Network Group.
4If more than one Network Group is to be added, route a second
NTRC48 cable of the appropriate length to shelf 0 of the second new
group.
5Continue to route NTRC48 cable of the appropriate length in
ascending order between shelf 0 of each new Network Group.
6To complete the Ring, route a final cable from the highest number
group back to Group 0, shelf 0.
CAUTION
Damage to Equipment
Do not excessively bend or cinch the Fiber Ring cables.
These cables are easily damaged. Use the Optical Cable
Management Card (OCMC) to manage and protect the
Fiber Ring cables.

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/0211of26
TM
Figure 2
Shelf 0 ascending fiber optic Ring (example)
NTRC48xx fiber optic cable
Tx (J1)
Rx (J2)
Group 0, shelf 0
Group 0, shelf 1
Tx (J1)
Rx (J2)
Group 2, shelf 0
Tx (J1)
Rx (J2)
Group 2, shelf 1
Tx (J1)
Rx (J2)
Group 4, shelf 1
Tx (J1)
Rx (J2)
Group 4, shelf 0
Tx (J1)
Rx (J2)
Group 3, shelf 0
Tx (J1)
Rx (J2)
Group 3, shelf 1
Tx (J1)
Rx (J2)
Group 1, shelf 0
Tx (J1)
Rx (J2)
Group 1, shelf 1
Tx (J1)
Rx (J2)
IPE IPE
IPE
IPE
IPE
IGM
(not used with
Fiber Network)
553-9553

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/0212of26
TM
Table 4
FIJI Ring 0 connections
Groups X - 0 are cabled in ascending order
Group/shelf NTRC48 fiber cable
connector FIJI card connector
0/0 P1 Tx - J1
1/0 P2 Rx - J2
1/0 P1 Tx - J1
2/0 P2 Rx - J2
2/0 P1 Tx - J1
3/0 P2 Rx - J2
3/0 P1 Tx - J1
4/0 P2 Rx - J2
4/0 P1 Tx - J1
5/0 P2 Rx - J2
5/0 P1 Tx - J1
6/0 P2 Rx - J2
6/0 P1 Tx - J1
7/0 P2 Rx - J2
7/0 P1 Tx - J1
0/0 P2 Rx - J2

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/0213of26
TM
Label and route the shelf 1 fiber optic cables (descending)
Route the NTRC48 cables between the FIJI cards in each Network shelf 1 in
descending order. See Figure 3.
Figure 3
Shelf 1 descending fiber optic ring (example)
CAUTION
Damage to Equipment
Do not excessively bend or cinch the Fiber Ring cables.
These cables are easily damaged. Use the Optical Cable
Management Card (OCMC) to manage and protect the
Fiber Ring cables.
NTRC48xx fiber optic cable
Group 0, shelf 0
Group 0, shelf 1
Tx (J1)
Rx (J2)
Group 2, shelf 0
Group 2, shelf 1
Tx (J1)
Rx (J2)
Group 4, shelf 1
Tx (J1)
Rx (J2)
Group 4, shelf 0
Group 3, shelf 0
Group 3, shelf 1
Tx (J1)
Rx (J2)
Group 1, shelf 0
Group 1, shelf 1
Tx (J1)
Rx (J2)
IPE IPE
IPE
IPE
IPE
553-9557
IGM
(not used with
Fiber Network)

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/0214of26
TM
Note: Each end of the NTRC48 cable is labeled “Tx” or Rx” in the
factory.
Procedure 6
Labelling and routing the shelf 1 fiber optic cables (descending)
1Start with Group 0, shelf 1.
2Label each cable on both sides with the appropriate connection
information from Table 5.
3Route a NTRC48 FIJI Fiber Ring cable of the appropriate length from
shelf 1 of the FIJI card in Group 0, to the FIJI card in the new highest
Network Group, shelf 1.
4Route a NTRC48 cable from the FIJI card in the new highest Network
Group, shelf 1 to the FIJI card in the second highest Network Group,
shelf 1.
5Continue to route NTRC48 FIJI Fiber Ring cables of the appropriate
lengths between shelf 1 of each new Network Group. Route these
cables in descending order of Network Groups.
6Route a final cable to the current highest Network Group, shelf 1.
—————————— End of Procedure ——————————

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/0215of26
TM
Table 5
FIJI Ring 1 connections
Groups 0 - X are cabled in descending order
Group/shelf NTRC48 fiber cable
connector FIJI card connector
0/1 P1 Tx - J1
7/1 P2 Rx - J2
7/1 P1 Tx - J1
6/1 P2 Rx - J2
6/1 P1 Tx - J1
5/1 P2 Rx - J2
5/1 P1 Tx - J1
4/1 P2 Rx - J2
4/1 P1 Tx - J1
3/1 P2 Rx - J2
3/1 P1 Tx - J1
2/1 P2 Rx - J2
2/1 P1 Tx - J1
1/1 P2 Rx - J2
1/1 P1 Tx - J1
0/1 P2 Rx - J2

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/0216of26
TM
Figure 4
Shelf 1 descending fiber optic Ring (example)
NTRC48xx fiber optic cable
Group 0, shelf 0
Group 0, shelf 1
Tx (J1)
Rx (J2)
Group 2, shelf 0
Group 2, shelf 1
Tx (J1)
Rx (J2)
Group 4, shelf 1
Tx (J1)
Rx (J2)
Group 4, shelf 0
Group 3, shelf 0
Group 3, shelf 1
Tx (J1)
Rx (J2)
Group 1, shelf 0
Group 1, shelf 1
Tx (J1)
Rx (J2)
IPE IPE
IPE
IPE
IPE
553-9557
IGM
(not used with
Fiber Network)

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/0217of26
TM
Installing cards in the Network modules
Network cards must be installed in the new Network modules as described
below. Each card must be installed and enabled or disabled as indicated.
Procedure 7
Installing cards in network modules
1Complete “Installing and enable the 3PE cards” on page 17.
2Complete “Installing and enabling the Peripheral Signaling (Per Sig)
cards” on page 19.
3Complete “Disabling and inserting the FIJI cards” on page 19.
4Complete “Disabling and inserting the Conf/TDS cards, if necessary”
on page 19.
—————————— End of Procedure ——————————
Installing and enable the 3PE cards
Three steps are required to install the 3PE cards:
Procedure 8
Installing and enabling 3PE cards
1Verify the 3PE card settings.
The group and shelf number of each Network module is determined by
the switch settings on the 3PE card. Use the information in Table 6 on
page 18 to verify that the 3PE cards in the new Network modules have
the correct switch and jumper settings.
This group and shelf setting is displayed on the FIJI card display.
2Install a 3PE card in slot 1 of each new Network module. Push the
latches forward to lock the card in place.
3Attach the cables to the inactive 3PE faceplates.
4Faceplate enable each 3PE card.
—————————— End of Procedure ——————————

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/0218of26
TM
Table 6
3PE card settings
Jumper Settings
Set Jumper RN27 at E35 to “A”.
Switch Settings
D20 switch position: 1 2 3 4
81, 81C (Note) off on on on
Shelf Group D20 switch position: 5678
0
(3PE cards
connected to the a
CNI in Core or
Core/Net 0)
0on on on on
1on on off on
2on off on on
3on off off on
4off on on on
5off on off on
6off off on on
7off off off on
1
(3PE cards
connected to the a
CNI in Core or
Core/Net 1)
0on on on off
1on on off off
2on off on off
3on off off off
4off on on off
5off on off off
6off off on off
7off off off off
Note: For option 81C systems, QPC441 vintage F or later must be used in all modules.

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/0219of26
TM
Installing and enabling the Peripheral Signaling (Per Sig)
cards
Procedure 9
Installing and enabling Peripheral Signaling cards
1Install a Per Sig card into slot 4 of each new Network module. Push the
latches forward to lock the card in place.
2Faceplate enable the cards.
—————————— End of Procedure ——————————
Disabling and inserting the FIJI cards
Procedure 10
Disabling and inserting FIJI cards
1Faceplate disable the FIJI cards.
2Insert the FIJI cards into slots 2 and 3 of each new Network module.
Do not plug the card into the backplane.
—————————— End of Procedure ——————————
Disabling and inserting the Conf/TDS cards, if necessary
If Conf/TDS cards are used in the system, follow the procedures below.
Procedure 11
Disabling and inserting Conf/TDS cards
1Faceplate disable the Conf/TDS cards.
2Insert a Conf/TDS card into each new Network module.
Do not plug the card into the backplane.
—————————— End of Procedure ——————————

Documentation Release Note Number: MER-1002-003
Nortel Networks11/4/0220of26
TM
Enabling the CNI cards
If new CNI-3 cards are required, they must be installed before the cards are
enabled. See “Add CNI cards if necessary” on page 3 to install the cards.
Note 1: If you are adding more than one Network Group, it is
recommended that you add one group at a time in software. Follow all
the remaining procedures in this chapter to complete the addition of one
group before starting to add another group.
Note 2: CNI cards can be enabled and connected on the inactive Core
only.
Follow Procedure 12 to connect and activate the new CNI ports.
Procedure 12
Connecting and activating CNI ports
1Verify that the cables are correctly routed, labeled, and connected to
the 3PE cards. See “Pre-routing CNI to 3PE cables” on page 5.
2Attach the cables to the inactive CNI cards.
See Table 1, “Option 81 CNI group assignments,” on page 6, Table 2,
“Option 81C CNI group default assignments (introduced with X11
25.xx),” on page 7 and Table 3, “Option 81C CNI group assignments
on a system that originated as a non-FNF system prior to X11 Release
25,” on page 8 for connection information.
3Software enable the new CNI ports on the inactive Core.
CAUTION
Damage to Equipment
The backplane connector pins are easily bent. Install
backplane cables with extreme caution to ensure that
these pins are not damaged. Carefully line up the cable
and press it into place. Never force a cable into the slot.
If the cable gets stuck, remove it and try again. Damage
to the backplane connector pins can make installation of
CNI cables impossible.
LD 135 to load the program
ENL CNI c s p (core slot port) to enable the card and ports
