Nortel Meridian 1 Option 11C User manual

Meridian 1
Option 11C
2.0 Mb DTI/PRI
Document Number: 553-3011-315
Document Release: Standard 13.00
Date: January 2002
Year Publish FCC TM
Copyright © 1992– 2002 Nortel Networks
All Rights Reserved
PrintedinCanada
Information is subject to change without notice. Nortel Networks reserves the right to make changes in design
or components as progress in engineering and manufacturing may warrant. This equipment has been tested
and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC rules, and the
radio interference regulations of Industry Canada. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at their own expense.
SL-1 and Meridian 1 are trademarks of Nortel Networks.

Page 3 of 126
Option 11C 2.0 Mb DTI/PRI
4
Revision history
January 2002
Standard 13.00. This global document is up-issued for Release 25.40.
December 2000
Standard 12.00. This global document is up-issued to include updates and
changes required for Option 11C IP Expansion field trials with Release 25.3x
software.
April 2000
Standard 11.00. This is a global document and is up-issued for X11 Release
25.0x. Document changes include removal of redundant content, including
references to previous software releases, and references to equipment types
except Option 11C.
March 1999
Release 10.00, Standard , for Generic X11 Release 24.0x
October 1997
Release 9.00, Standard, for Generic X11 Release 23.00
September 1996
Release 8.00, Standard, for Generic X11 Release 22.0x
November 1995
Release 7.00, Standard, for Generic X11 Release 21.1x
July 1995
Release 6.00, Standard, for Generic X11 Release 21.0x
December 1994
Release 5.00, Standard, for Generic X11 Release 20.0x

Page 4 of 126 Revision History
553-3011-315 Standard 13.00 January 2002
July 1994
Issue 4.00, Standard, published for Generic X11 Release 19.0x
February 1994
Issue 3.00, Standard, published for Generic X11 Release 18.0x
January 1993
Issue 2.00, Standard, published for Generic X11 Release 17.0x
April 1992
Issue 1.00, Standard, published for Generic X11 Release 16.0x

Page 5 of 126
Option 11C 2.0 Mb DTI/PRI
6
Contents
About this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
ISDN features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.0 Mb DTI Implementation . . . . . . . . . . . . . . . . . . . 11
2.0 Mb PRI Implementation . . . . . . . . . . . . . . . . . . . 35
DTI Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
PRI Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
ISL Implementation and Maintenance . . . . . . . . . . 111

Page 6 of 126 Contents
553-3011-315 Standard 13.00 January 2002

Page 7 of 126
Option 11C 2.0 Mb DTI/PRI
8
About this guide
This document contains specifc information on how to configure 2.0 Mb
ISDN DTI/PRI on Meridian 1 Option 11C. For general information on ISDN,
and for information on software features, refer to X11 Networking Features
and Services (553-2901-301).
This document is a global document. Contact your system supplier or your
Nortel Networks representative to verify that the hardware and software
described is supported in your area.

Page 8 of 126 About this guide
553-3011-315 Standard 13.00 January 2002

Page 9 of 126
Option 11C 2.0 Mb DTI/PRI
10
ISDN features
For a detailed description and implementation information, see the X11
Networking Features and Services (553-2901-301).
For a detailed description and implementation information for DPNSS1, see
the DPNSS1: Features and Services Guide (553-3921-300).
For a detailed description and implementation information for DASS2, see
the DASS: Features and Services Guide (553-3911-300).

Page 10 of 126 ISDN features
553-3011-315 Standard 13.00 January 2002

Page 11 of 126
Option 11C 2.0 Mb DTI/PRI
34
2.0 Mb DTI Implementation
Contents
This section contains information on the following topics:
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Hardware Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
NTAK10 2.0 Mb DTI card . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Install DTI hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Inspect the NTAK10 circuit card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Set the switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Insert the NTAK10 . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Connect the cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
DTI software programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Task summary list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Overview
This chapter provides the information required to install the 2.0 Mb DTI card
in Meridian 1 Option 11C systems. It includes information for:
• hardware installation
• software programming
With the introduction of Release 25.3x, the 2.0 Mb DTI card is now supported
in Option 11C IP expansion cabinets. This increased capability is possible
with the introduction of IP daughterboards in expansion cabinets and
100BaseTor F connectivity with the Main cabinet.

Page 12 of 126 2.0 Mb DTI Implementation
553-3011-315 Standard 13.00 January 2002
Hardware Requirements
Hardware requirements for 2.0 Mb DTI are as follows:
• 2.0 Mb DTI Circuit card - NTAK10
(a Clock Controller is incorporated into the circuit card)
• CEPT Cable – NTBK05DA (120 ¾ twisted pair – 6.15 m length)
or
CEPT Cable – NTBK05CA (75 ¾ coaxial – 6.15 m length)
Figure 1
2.0 Mb DTI Cabling
NTBKO5DA
120ΩTwisted Pair (6.15 m)
NTBKO5CA
75ΩCoax Pair (6.15 m)
To 2.048
Mpbs Carrier
Cross Connect
553-8316.EPS
PRI2
or
DTI2
OPTION 11

2.0 Mb DTI Implementation Page 13 of 126
Option 11C 2.0 Mb DTI/PRI
NTAK10 2.0 Mb DTI card
The 2.0 Mb Digital Trunk Interface card provides the physical interface for
the digital E-1 carrier on the Option 11C system. The card includes an
on-board clock controller and is installed in slots 1 through 9 in the main
cabinet. On IP Expansion cabinets, it may be placed in slots 11-19, 21-29,
31-39, 41-49 of the first, second, third, and fourth expansion cabinets,
respectively.
The NTAK10 2.0 Mb DTI card is also used for ISL shared mode applications.
For information on the NTAK10 faceplate LEDs, refer to DTI Maintenance
in this guide.
Install DTI hardware
The NTAK10 circuit card can be installed in any available card slot 1-9 in the
main cabinet. On IP Expansion cabinets, it may be placed in slots 11-19,
21-29, 31-39, 41-49 of the first, second, third, and fourth expansion cabinets,
respectively
Inspect the NTAK10 circuit card
Inspect the circuit card before installing it in the main cabinet:
• Locate the NTAK10 2.0 Mb circuit card and carefully remove it from its
packaging.
• Inspect the circuit card for any visible damage which may have occurred
during shipping.
Set the switches
The NTAK10 incorporates four surface mounted dip switches. The following
tables provided information on the various settings and related functions of
these switches.
Note: The ON position for all the switches is towards the bottom of the
card. This is indicated by a white dot printed on the board adjacent to the
bottom left corner of each individual switch.
Set the switches found on the circuit card as per the requirements of your
specific installation.

Page 14 of 126 2.0 Mb DTI Implementation
553-3011-315 Standard 13.00 January 2002
Switch S1—Clock Controller Configuration
This switch enables/disables the on-board Clock Controller.
Switch S2—Carrier Impedance Configuration
This switch sets the carrier impedance to either 120¾ or 75¾. Twisted pair
cable is usually associated with 120¾. Coaxial cable is usually associated
with the 75¾ setting.
Switch S3—Mode of Operation
This switch selects the mode in which the NTAK10 operates. The NTAK10
supports firmware that allows it to operate in the standard CEPT format
mode, or the modified CEPT format used in France.
Table 1
Switch S1
Switch Off (Up) On (Down)
S1-1 Spare Spare
S1-2 Clock Controller
Enabled
Clock Controller
Disabled
Table 2
Switch S2
Switch Off (Up) On (Down)
S2-1 120¾75¾
S2-2 75¾120¾
Table 3
Switch S3
Switch Off (Up) On (Down)
S3-1 Non-French Firmware French Firmware
S3-2 Spare Spare

2.0 Mb DTI Implementation Page 15 of 126
Option 11C 2.0 Mb DTI/PRI
Switch S4—Carrier Shield Grounding
This switch allows for the selective shield grounding of the Tx and/or Rx
pairs of the carrier cable. Closing the switch (down position) applies Frame
Ground (FGND) to the coaxial carrier cable shield, creating a 75¾
unbalanced configuration. The Tx and Rx pairs are referenced with respect to
the 2.0 Mb DTI card (i.e. Rx is carrier received from the far end device).
Note: The usual method is to ground the outer conductor of the receive
coax signal.
Insert the NTAK10
Slide the circuit card into any unused slot 1 through 9 in the main cabinet, or
in slots 11-19, 21-29, 31-39, 41-49 of the first, second, third, and fourth IP
xpansion cabinets, respectively. Secure the circuit card in the cabinet by
locking the lock latch assemblies.
Connect the cables
• In the cabling area, located directly below the card cage, remove the
retaining bar used to secure the MDF cables. Connect the
NTBK05DA/CA interface cable to the 50-pin Amphenol connector
below the card slot holding the NTAK10 2.0 Mb DTI circuit card.
Re-install the retaining bar to secure the cable(s) in place.
• Terminate the NTBK05DA/CA carrier cable as required.
Table 4
Switch S4
Switch Off (Up) On (Down)
S4-1 Receive Shield
Unconnected
Frame Ground on
Receive Shield
S4-2 Transmit Shield
Unconnected
Frame Ground on
Transmit Shield

Page 16 of 126 2.0 Mb DTI Implementation
553-3011-315 Standard 13.00 January 2002
NTBK05DA pinouts
The pinouts for the NTBK05DA cable are as follows:
NTBK05CA pinouts
The pinouts for the NTBK05CA cable are as follows:
Table 5
NTBK05DA pinouts
From:
50 pin MDF
connector
To:
9 pin
connector Colour Signal
pin 23 pin 6 Black R0
pin 48 pin 7 White T0
pin 50 pin 9 Bare R0/T0 FGND
pin 24 pin 2 Black R1
pin 49 pin 3 Red T1
pin 25 pin 5 Bare R1/T1 FGND
Table 6
NTBK05CA pinouts
From:
50 pin MDF
connector
To:
Transmit coax
connector
To:
Receive coax
connector
To:
50 pin MDF
connector
pin 23 Inner conductor ——
pin 48 outer conductor ——
pin 24 —Inner conductor —
pin 49 —outer conductor —
pin 21 ——pin 49
pin 46 ——pin 48

2.0 Mb DTI Implementation Page 17 of 126
Option 11C 2.0 Mb DTI/PRI
DTI software programming
The following procedure describes the process required to program basic
2.0 Mb DTI on the Meridian 1 Option 11C main and IP expansion cabinets.
Task summary list
The following is a summary of the tasks in this section:
1LD 17 – Add a 2.0 Mb DTI card.
2LD 73 – Define the 2.0 Mb DTI ABCD signaling bit tables.
3LD 73 – Define the 2.0 Mb DTI pad tables.
4LD 73 – Define the 2.0 Mb DTI timers.
5LD 73 – Define the 2.0 Mb DTI system timers.
6LD 16 – Configure the service routes.
7LD 14 – Define the associated list of service trunks.
LD 17 – Add a 2.0 Mb DTI card.
LD 73 – Define the 2.0 Mb DTI ABCD signaling bit tables.
Prompt Response Description
REQ: CHG
TYPE: CEQU Change common equipment
...
DTI2 xx Enter a card slot number for 2.0 Mb DTI.
xx = 1-9 in main cabinet.
xx = 11-19, 21-29, 31-39, 41-49 in IP expansion cabinets 1-4,
respectively.
Prompt Response Description
REQ NEW
CHG
Add or change Digital Trunk Interface data block
TYPE DTI2 2.0 Mb/s DTI data block

Page 18 of 126 2.0 Mb DTI Implementation
553-3011-315 Standard 13.00 January 2002
FEAT ABCD ABCD bit signaling category.
SICA 2-16 Signaling category
...
DFLT (1)-16 Default signaling category to be used for default values
JDMI defaults to 16 with <CR>3.
Incoming/Outgoing Calls:
IDLE(S) abcd (Send) idle signal bits
IDLE(R) abcd (Receive) idle signal bits
FALT(S) abcd (Send) bits. 2.0 Mb DTI out-of-service
N If FALT (send) signal not required
FALT(R) abcd (Receive) bits. 2.0 Mb DTI out-of-service
N If FALT (receive) signal not required
Incoming Calls:
SEZ(R) abcd Seize signal (send or receive) for voice or data calls from or to
a non-SL-1.
SEZD(R) abcd Seize signal (send or receive) for data calls between SL-1s.
NIf SEZD(R) signal not required
SEZV(R) abcd Seize signal (send or receive) for voice calls.
NIf SEZV(R) signals not required
P CALL(R) abcd (Receive) signal sent during seize by an incoming CO trunk.
TIME ON OFF Length of pulse time on, and time off.
(default 2 seconds on, 8 seconds off)
SEZA(S) abcd Seize signal acknowledgment (send).
NIf SEZA(S) signal not required
P WNKS(S) abcd Wink start (corresponds to a pulsed seize
acknowledgment).Prompted when SEZA(S) not required.
NIf WNKS(S) signal not required
TIME 10-(220)-630 Time for WNKS(S) signal in milliseconds
P DIGT(R) abcd (Receive) decadic pulses
NIf DIGT(R) not required
NRCV(S) abcd Number received signal (send).
Prompt Response Description

2.0 Mb DTI Implementation Page 19 of 126
Option 11C 2.0 Mb DTI/PRI
NIf NRCV(S) signal not required
P EOSF(S) abcd End of selection free (send)
NIf EOSF(S) not required
TIME (100)-150 Time for EOSF(S) in milliseconds
P EOSB(S) abcd End of selection busy (send)
NIf EOSB(S) not required
TIME (100)-150 Time for EOSB(S) in milliseconds
P OPCA(R) abcd Operator calling time (receive) signal
NIf OPCA(R) not required
TIME 64-(128)-192 Time of OPCA(R) pulse in milliseconds
REPT (1)-5 Number of OPCA(R) pulses.
CONN(S) abcd Connect send
CONN(R) abcd Connect receive
P RRC(S) abcd Register recall (send) signal. Activated by Malicious Call
Tr a c e.
NIf RRC(S) not required
TIME 10-(100)-150 Time of RRC(S) signal in milliseconds
P BURS(S) abcd Bring up receiver (send). Uses switch-hook flash timer for
timer.
NIf BURS(S) not required
P BURS(R) abcd Bring up receiver (receive). Uses switch-hook flash timer for
timer.
NIf BURS(R) not required
TIME 64-(128)-192 Length of BURS(R) pulse in milliseconds
P CAS(S) abcd CAS Flash. Same timing as analogue trunks.
Note: Prompted for JDMI only. Operational only if CASM
package equipped.
NIf CAS(S) not required
CLRB(S) abcd Clearback (send) signal.
NIf CLRB(S) not required (IDLE signal is used).
P RCTL(S) abcd Release control (send) signal.
Prompt Response Description

Page 20 of 126 2.0 Mb DTI Implementation
553-3011-315 Standard 13.00 January 2002
NIf RCTL(S) not required
Note: Prompted only when CLRB is unused or is defined the
same as IDLE.
TIME 100-(150)-300 Time value is stored in multiples of 10 milliseconds.
R RCOD(S) abcd Release Control Originating party Disconnect. This signal is
another pulsed SL-1 signal sent on incoming trunks when the
originating party disconnects first.
NIf RCOD(S) not required
TIME 150 Timer value in milliseconds is fixed
P OPRS(R) abcd Operator (receive) manual recall signal
NIf OPRS(R) not required
TIME xxx yyy Minimum and maximum time range for OPRS(R) in
milliseconds.
xxx = 8-(48)-2040
yyy = xxx-(128)-2040
P NXFR(S) abcd Network transfer signal (send) pulse. Pulse time not variable.
NIf NXFR(S) not required
P ESNW(S) abcd ESN wink signal (send) pulse. Pulse time not variable.
NIf ESNW(S) not required
P CAS(S) abcd Centralized Attendant signal (send) pulse. Pulse time not
variable.
Note: Prompted for 2.0 Mb DTI only.
NIf CAS(S) not required
CLRF(R) abcd Clear forward (receive)
N If CLRF(R) not required
SOSI abcd
(N)
Special operator signal defined
Undefined. Prompted when OPRC = N
Outgoing Calls:
SEZ(S) abcd Seize voice or data from or to a non SL-1 switch
SEZD(S) abcd Seize data (send) signal. Only for SL-1 to SL-1 applications
NIf SEZD(S) not required
SEZV(S) abcd Seize voice (send) signal. Only recommended for SL-1 to
SL-1 applications
Prompt Response Description
