Novatel U620L User manual

MIU620L-AT001
MiFi 4G LTE Global USB Modem
U620L
AT Command Reference Guide
Version 1.0 July 8, 2015

NOVATEL WIRELESS COPYRIGHT STATEMENT
©2015 Novatel Wireless, Inc. All rights reserved. The information contained in this document is subject
to change without notice and should not be construed as a commitment by Novatel Wireless, Inc.
NOVATEL WIRELESS TRADEMARKS AND SERVICE MARKS
Novatel Wireless is a trademark of Novatel Wireless, Inc., and the other trademarks, logos, and service
marks (collectively the “Trademarks”) used in this user manual are the property of Novatel Wireless or
their respective owners. Nothing contained in this user manual should be construed as granting by
implication, estoppel, or otherwise, a license or right of use of Novatel Wireless or any other Trademark
displayed in this user manual without the written permission of Novatel Wireless or its respective
owners.
Novatel Wireless, and the Novatel Wireless logo are all trademarks of Novatel Wireless, Inc.
MiFi® and the MiFi logo are registered trademarks of Novatel Wireless, Inc.

iii
General Disclaimer
TERMS OF USE OF NEW MATERIALS - PLEASE READ CAREFULLY
From time to time, Novatel Wireless, in its sole discretion, may make available for download on its
website (www.novatelwireless.com), or may transmit via mail or email, updates or upgrades to, or new
releases of, the firmware, software, or documentation for its products (collectively, 'New Materials'). Use
of such New Materials is subject to the terms and conditions set forth below, and may be subject to
additional terms and conditions as set forth in Novatel Wireless's Technical Support Policy (posted on its
website) and/or any written agreement between the user and Novatel Wireless.
All New Materials are provided AS IS. Novatel Wireless makes no warranty or representation with
respect to the merchantability, suitability, functionality, accuracy, or completeness of any such New
Materials. The user of such New Materials assumes all risk (known or unknown) of such use. Novatel
Wireless reserves all rights in such New Materials. The user shall have only a revocable and limited
license to use such New Materials in connection with the products for which they are intended.
Distribution or modification of any New Materials without Novatel Wireless's consent is strictly
prohibited.
IN NO EVENT WILL NOVATEL WIRELESS BE RESPONSIBLE FOR ANY INCIDENTAL, INDIRECT,
CONSEQUENTIAL, OR SPECIAL DAMAGES AS A RESULT OF THE USE OF ANY NEW MATERIALS. NOVATEL
WIRELESS'S MAXIMUM LIABILITY FOR ANY CLAIM BASED ON THE NEW MATERIALS SHALL NOT EXCEED
FIFTY U.S. DOLLARS ($50).
Version Verification
To ensure you have the latest version of this document, visit the Novatel Wireless IoT Technical
Documentation site at documentation.nvtl.com.

iv
Contents
Introduction 1
Standard AT Commands 3
NVTL 4
AT$CNTI 5
AT$NWACTIVATION 6
AT$NWATI 7
AT$NWATR 9
AT$NWBAND 10
AT$NWBAND2 12
AT$NWCCMAUTOCONNECT 14
AT$NWCCMCONNECT 15
AT$NWCFT 16
AT$NWCHBAND 17
AT$NWCID 18
AT$NWCSLFILTER 19
AT$NWDATAUSAGE 20
AT$NWDEGC 21
AT$NWDIVCTRL 22
AT$NWDLOAD 24
AT$NWDYNAMICSTATUS 25
AT$NWERR 26
AT$NWFID 28
AT$NWFOTASTATUS 29
AT$NWFWAPIVER 30
AT$NWHWID 31
AT$NWICCID 32
AT$NWIMSREGSTATUS 33
AT$NWLOCK 34
AT$NWLTEBAND 35
AT$NWLTIME 38
AT$NWMCCFILTER 39
AT$NWMDN 40
AT$NWMFG 41
AT$NWMIFIOSSTATUS 42
AT$NWNITZ 43
AT$NWNN 44
AT$NWNPC 45
AT$NWNVITEMINACTIVE 47

v
AT$NWPINR 48
AT$NWPREFMODE 49
AT$NWPRI 50
AT$NWQMICONNECT 51
AT$NWQMIDISCONNECT 52
AT$NWQMISTATUS 53
AT$NWRAT 54
AT$NWSFEUIMID 56
AT$NWSIMCAP 57
AT$NWSMSIMSFORMAT 58
AT$NWSNAPSHOT 59
AT$NWSPPC 60
AT$NWSTATICSTATUS 61
AT$NWSTKRSP 62
AT$NWSVN 63
AT$NWTESTROAM 64
AT$NWTHERM 65
AT$NWTHERMTEMP 66
AT$NWTIMESINCEBOOTUP 67
AT$NWWMCNETWORKTYPE 68
AT+CRST 69
AT+ICCID 70
AT+NWAPNE 71
AT+VZWMRUC 73
AT+VZWMRUE 74
AT+VZWRSRP 76
AT+VZWRSRQ 77
3GPP 78
AT+CCLK 79
AT+CEER 80
AT+CEMODE 81
AT+CEREG 82
AT+CFUN 83
AT+CGACT 84
AT+CGCMOD 85
AT+CGDCONT 86
AT+CGDSCONT 87
AT+CGEQOSRDP 88
AT+CGEREP 89
AT+CGMI 90
AT+CGMM 91
AT+CGMR 92

vi
AT+CGPADDR 93
AT+CGPIAF 94
AT+CGREG 95
AT+CGSMS 96
AT+CGSN 97
AT+CGTFT 98
AT+CGTFTRDP 99
AT+CIMI 100
AT+CIND 101
AT+CLAC 102
AT+CLCK 103
AT+CMEC 106
AT+CMEE 108
AT+CMER 109
AT+CMGD 110
AT+CMGF 111
AT+CMGL 112
AT+CMGR 113
AT+CMGS 114
AT+CMGW 115
AT+CMSS 116
AT+CNUM 117
AT+COPN 118
AT+COPS 119
AT+CPAS 121
AT+CPIN 122
AT+CPMS 123
AT+CPWD 124
AT+CRSM 126
AT+CSCA 127
AT+CSCS 128
AT+CSIM 129
AT+CSMP 130
AT+CSMS 131
AT+CSQ 132
AT+CSS 133
AT+CSTF 135
AT+GCATT 136
AT+WS46 137
VZW 138
AT+VZWAPNE 139
AT+VZWRSRP 140

vii
AT+VZWRSRQ 141

Introduction
This document lists and describes the AT Command Set to be used in conjunction with the Novatel
Wireless MiFi 4G LTE Global USB Modem U620L.
Platform Reference and Use
In this document, the device may be referred to using various terms, such as MS (Mobile Station), TA
(Terminal Adapter), DCE (Data Communication Equipment), or ME (Mobile Equipment).
You can control the device on a DTE (Data Terminal Equipment) platform by issuing the AT commands
through a serial interface.
Command Syntax
The attention or “AT” prefix is required prior to entering any command. All commands require a carriage
return or <CR> following the entry of the command. All command responses are encapsulated by a
carriage return and line feed or <CR><LF>. The ASCII display of these characters is suppressed with
only the modem response being presented.
In addition to terminating AT commands, you can use the carriage return <CR> to abort commands
that are executing.
Most AT commands complete immediately so there is no opportunity to abort them, for instance ATI.
However, some commands like AT+COPS or AT+CFUN can take several seconds to complete. The AT
command interface is said to be in execution mode when a command is running and has not returned a
result code (OK/ERROR). A second <CR> entered while the AT command interface is in execution mode
aborts the command and returns the interface to command mode.
Some AT commands require additional input, for instance AT+CMGS. After terminating the AT+CMGS
command with a <CR> the AT command interface enters line edit mode. While in line edit mode all
characters are accepted except CNTL-Z. CNTL-Z terminates line edit mode and the AT command
interface enters execution mode. Like before, at this point another <CR> aborts the command.
1
1

You can concatenate an ATmessage using the semicolon (;) between commands.
The following examples demonstrate the potential usage of AT commands presented:
Type Example Description
Command Format Query AT+GXXX=? Returns the command format and value
ranges.
Command Read AT+GXXX? Returns the current value assigned to the
command.
Command Write AT+GXXX=<value>,<value>, Sets the command to specified value(s).
Command Execution AT+GXXX Executes the specified command.
Command
Concatenation
AT+CRC=1;S0=1 Executes both the CRC and S0 command.
U620L AT Command Reference Guide 2

U620L AT Command Reference Guide 3
Standard AT Commands
The following is the format in which all commands will be presented.
Command Function (Description of the command function)
Query Syntax ATx=?
Query Response ATx: (parameter1 name 1 – 15), (parameter2 name 1-10),…
Write Syntax ATx=<value>,<value>[,<optional value>],…
Write Response OK or ERROR
Read Syntax ATx?
Read Response <value>,<value>,…
Execute Syntax ATx
Execute Response OK, ERROR, or <value>
Unsolicited Response
Parameter Values
<Value 1> ATx: (1-15),(1-10)
<Value 2>
Notes (Additional command notes)
Examples
NOTE: Where applicable, the <value> responses provided for the READ and EXECUTE formats are
modem default values. All efforts will be made by Novatel Wireless. to keep these values current in the
documentation but will not be responsible for any differences that may occur as a result subsequent
software builds and version enhancements.
WARNING! Do not use tab characters in the custom AT command scripts.

NVTL
2
4

AT$CNTI
Command AT$CNTI
Command Function Queries the current network technology.
Query Syntax AT$CNTI=?
Query Response CNTI: (0-2)
Write Syntax
Write Response
Read Syntax AT$CNTI?
Read Response $CNTI: 0, LTE
$CNTI: 1, LTE
$CNTI: 2, GSM, GPRS, EDGE, UMTS, HSDPA, HSUPA, HSPA+, HSPA+DC, LTE,
1xRTT, EVDO, EVDO_REL_0, EVDO_REL_A, EVDO_REL_B
Execute Syntax
Execute Response
Unsolicited Response
Parameter Values 0 - <current network access technology
1 - <supported network access technologies>
2 - <all supported network access technologies by the device>”
where the network access technologies have the following values:
GPRS – GPRS network
EDGE – Edge network
UMTS – UMTS network
HSDPA – HSDPA network
HSUPA – HSUPA network
HSPA+ – HSPA Plus
HSPA+DC – HSPA plus DC
Notes
Examples
U620L AT Command Reference Guide 5

U620L AT Command Reference Guide 6
AT$NWACTIVATION
Command AT$NWACTIVATION
Command Function Queries MDN, MIN.
Query Syntax AT$NWACTIVATION=?
Query Response NWACTIVATION: (ACTIVATION CODE:[xxxxxx] MDN:[XXXXXXXXXX] MIN:
[XXXXXXXXXX])
Write Syntax
Write Response
Read Syntax AT$NWACTIVATION?
Read Response NWACTIVATION: 8584721331, 8584721331
Execute Syntax
Execute Response
Unsolicited Response
Parameter Values
— <Activation Code>
— <MDN>
— <MIN>
Notes
Examples

AT$NWATI
Command AT$NWATI
Command Function Queries the superset of the ATI command and adds some more info to that AT
command.
Query Syntax AT$NWATI=?
Query Response Manufacturer: Novatel Wireless Incorporated
Model: MiFi 6620L
Revision: 2.03+ SVN 0 [Feb 4 2014 13:56:48] (Engineering Build - FW123_)
SVN: 00
+GCAP: +CLTE1, +CIS707-A, +MS, +ES, +DS
VID:PID:RID: 0x1410:0xb00d
MEID:0x99000062989008
ESN:0x80226577
HWREV:0
MSISDN:+
IMSI:311480083505147
OK
Write Syntax
Write Response
Read Syntax
Read Response
Execute Syntax
Execute Response
Unsolicited Response
U620L AT Command Reference Guide 7

U620L AT Command Reference Guide 8
Parameter Values Response:
Manufacturer:
Model:
Revision:
SVN:
+GCAP:
VID:PID:RID:
MEID:
ESN:
HWREV:
FID:
MSISDN:
IMSI:
Notes
Examples

AT$NWATR
Command AT$NWATR
Command Function Reads the ATR (answer-to-reset) string from the SIM. Used for the AT+CSIM to
determine the capabilities of the SIM (used by the application layer).
Query Syntax AT$NWATR=?
Query Response $NWATR: <length>, <atr_string>
Write Syntax
Write Response
Read Syntax AT$NWATR?
Read Response $NWATR: 23,3b9f97c00a1fc78031e073fe211b65d0011009228100f2
Execute Syntax
Execute Response
Unsolicited Response
Parameter Values
— <length>
— <atr_string>
Notes
Examples
U620L AT Command Reference Guide 9

U620L AT Command Reference Guide 10
AT$NWBAND
Command AT$NWBAND
Command Function Reads the band preference. The band preference returned is read from NV
item’s NV_BAND_PREF_I and NV_BAND_PREF_16_31_I
Query Syntax AT$NWBAND=?
Query Response <band> bit definitions
Write Syntax =<band_pref>
Write Response
Read Syntax AT$NWBAND?
Read Response 4e80187
Execute Syntax
Execute Response
Unsolicited Response
Parameter Values
— <band_pref> This is a 32-bit hexadecimal value that has the bits set for each band that needs to
be enabled. Refer to the query operation for the meaning of each bit.

— <band> 00 CDMA2000 Band Class 0, A-System
01 CDMA2000 Band Class 0, B-System
02 CDMA2000 Band Class 1, all blocks
03 CDMA2000 Band Class 2 place holder
04 CDMA2000 Band Class 3, A-System
05 CDMA2000 Band Class 4, all blocks
06 CDMA2000 Band Class 5, all blocks
07 GSM DCS band
08 GSM Extended GSM (E-GSM) band
09 GSM Primary GSM (P-GSM) band
10 CDMA2000 Band Class 6
11 CDMA2000 Band Class 7
12 CDMA2000 Band Class 8
13 CDMA2000 Band Class 9
14 CDMA2000 Band Class 10
15 CDMA2000 Band Class 11
16 GSM 450 band
17 GSM 480 band
18 GSM 750 band
19 GSM 850 band
20 GSM Band
21 GSM PCS band
22 WCDMA I IMT 2000 band
23 WCDMA II PCS band
24 WCDMA III 1700 band
25 WCDMA IV 1700 band
26 WCDMA V US850 band
27 WCDMA VI JAPAN 800 band
28 Reserved for BC12/BC14
29 Reserved for BC12/BC14
30 Reserved
31 Reserved
Notes
Examples
U620L AT Command Reference Guide 11

U620L AT Command Reference Guide 12
AT$NWBAND2
Command AT$NWBAND2
Command Function Reads the band preference <band-pref>. The band preference returned is read
from NV item NV_BAND_PREF_32_63_I. Queries the possible bands <band>.
Query Syntax AT$NWBAND2=?
Query Response $NWBAND2: <band> bit definitions
Write Syntax
Write Response
Read Syntax AT$NWBAND2?
Read Response 20000
Execute Syntax
Execute Response
Unsolicited Response
Parameter Values
— <band_pref>

— <band> 00 WLAN US 2400 band
01 WLAN ETSI 2400 band
02 WLAN FRANCE 2400 band
03 WLAN SPAIN 2400 band
04 WLAN JAPAN 2400 band
05 WLAN US 2400 band
06 WLAN EUROPE 5000 band
07 WLAN FRANCE 5000 band
08 WLAN SPAIN 5000 band
09 WLAN JAPAN 5000 band
10 Reserved
11 Reserved
12 Reserved
13 Reserved
14 Reserved
15 Reserved
16 WCDMA EUROPE 2600 band
17 WCDMA EUROPE & JAPAN 900 band
18 WCDMA JAPAN 1700 band
19 Reserved for WLAN
20 Reserved for WLAN
21 Reserved for WLAN
22 Reserved for WLAN
23 Reserved for WLAN
24 Band Class 16
25 Reserved
26 Reserved
27 Reserved
28 Reserved
29 Reserved
30 Persistent value from NV
31 Reserved
Notes
Examples
U620L AT Command Reference Guide 13
