Novatel Ovation U727 User manual

Installing your Sprint Mobile Broadband Device
on your Mac Computer:
If you purchased a U727, insert the CD that
came with your device and run the Mac package file
If you do not have that CD, or purchased a U720,
EX720 or S720, visit www.sprint.com/downloads,
select Mac OS as the operating system, and
download and install the “NovatelMacIntegration.zip”
package available under “Instructions for EVDO
Rev A Devices S720,U720,EX720,and U727”
Warning! When inserting or removing your device,
always grip it by its sides. Gripping the device by its
antenna may damage the device.
Quick Start Guide for Sprint
Mobile Broadband Devices
on Mac OS X Leopard
>>|
OvationTM U727 by Novatel Wireless
MerlinTM EX720 by Novatel Wireless
Ovation U720 by Novatel Wireless
Merlin S720 by Novatel Wireless
Mac Computer Requirements:
You will need one of the following computers running
Mac OS X Leopard version 10.4.10 or higher:
A PowerBook G4 computer with PC Card
(PCMCIA) slot or USB port, depending on the
Mobile Broadband Device you purchased
A MacBook computer with USB port or a
MacBook Pro computer with a PC Express slot or
USB port, depending on the Mobile Broadband
Device you purchased
An iMac computer with USB port
To check your OS version, from the Apple menu ( )
choose About This Mac. If your version is earlier,
visit: www.apple.com/support/downloads for upgrad-
ing instructions, or, in FinderTM, choose GO >
Applications > System Preferences
If your device is not activated:
You will need to contact Sprint Customer Service to
get your device set up on an account. Follow these
steps:
Ensure you have the items listed on the screen
and call the phone number listed
Follow the instructions of the Sprint Customer
Service specialist to activate your device. Write
down the following information provided to you:
My Sprint Device Phone Number (MDN):
My MSID:
Master Subsidy Lock (MSL):
Follow the on-screen installation instructions.
You will be required to sign in as administrator to
install, and asked to restart your computer upon
completion
Click Continue Installation and follow the on
screen prompts until “Install Successful” appears
Activating your Sprint Mobile Broadband
Device on the Sprint Network:
Once your computer has restarted, open your
Applications folder in the hard drive and launch
the Sprint Activation Utility application
Disconnect any other connections to the internet
available - turn off your AirPort connection and
unplug any ethernet connections
Follow the instructions on screen to insert your
device
This document describes how to use the Mac OS®X
Network support of the Sprint Mobile Broadband
Connectivity Devices with PowerBook®G4
computers, MacBook®computers and iMac®desktop
computers running Mac OS X Leopard.
Page 1 of 3

Follow the on screen prompts to complete the
activation process
If you are using a U720, EX720 or S720, you will
be prompted at this time to enter the information
from page 1: MSL, MDN, and MSID
NOTE: You will need to hit the tab or enter key
after typing in the MSID to initiate the activate
button
Once you’ve activated your device you can close
the Sprint Activation Utility by selecting Quit
Setting up your Mac Network Connection for
the S720 and U727:
NOTE: The EX720 and U720 have been integrated
into Apple’s WWAN 1.0 updater which is included in
Leopard. Move to Page 3 for those devices
Launch System Preferences from the Apple
menu and select the Network icon
If you are using a U727, the device will be
auto-programmed. Just follow the on screen
prompts
When you enter Network Preferences you may
see the Novatel CDMA option appear in the
device listing. If so, select that device.
If not, click the “+” below the list and select
“Novatel Wireless CDMA” from the pull down
and Click the OK button
Once available in the list, select the device and
click the Advanced button
Under the WWAN tab, select “Novatel” as the
Vendor in the pull down menu provided
Click the OK button and then click the Advanced
button again (NOTE: This step is necessary due
to a glitch in Leopard that does not refresh the
Model options upon Vendor selection)
Confirm that CDMA is selected for Model or select
“CDMA” from the pull down menu and click OK
Once back on the Network screen, click Apply to
save changes. Then click Connect
Once connected, duration and send/receive
status will appear on screen. Return to the
Network screen to disconnect and connect
again in the future
It is recommended that you utilize the same USB
port for future U727 connectivity
Due to changes in Leopard, the S720 and U727
will not be accessible using the “show modem
status in menu bar” at the top of your screen
Page 2 of 3

Using Sprint Location & Search Utility:
Make sure you have established a Mobile
Broadband connection
Open your Applications folder in the hard drive
and launch the Sprint Location & Search
application
Review the Privacy Consent screen. If you’d
prefer not to see this screen each time you
launch the application, uncheck the box “Always
Show Privacy Consent Agreement”
The software will search for your location. Once
found, you can enter a search or select one of
six pre-set search options
Page 3 of 3
Setting up your Mac Network Connection for
the U720 and EX720:
Insert the device. A pop-up should appear
recognizing the device
Look at the top menu bar for grayed out bars
Click on the grayed out bars to get a menu and
select Connect to connect to the Sprint Mobile
Broadband network
The bars will turn black once connected. To
disconnect, click on the black bars and select
Disconnect from the menu
Click on Open Network Preferences in the pull
down menu to view connection details
Your search results will appear in Google maps.
You can utilize the zoom capabilities to narrow
your search results or enter a new search
location
There are multiple ways to access Sprint
Location & Search for future use:
Find the application in the Applications
folder of your hard drive
With the application launched, click and
hold your mouse cursor on the application
icon in your doc. When the menu appears,
select Keep in Dock
To uninstall the Mobile Broadband Device
drivers and applications:
If you would like to remove this driver and its
associated files from your machine in the future,
delete the following files (requires Administrator
permissions):
/Applications/Sprint Activation Utility
/Applications/Sprint Location & Search
/System/Library/Extensions/NovatelWireless3G.kext
/System/Library/Extensions/NovatelWirelessFilter.kext
/Library/Modem Scripts/EVDO Support
/Library/Modem Scripts/HSDPA Support
