User Instructions
Intended Use
The Wheeled Commode range is designed to be
used, either as a commode, or over the toilet. It may
be used for short transfers on even floor surfaces to
move the client over the toilet subject to a suitable
risk assessment. It is suitable for less mobile clients.
The products feature; removable arms to allow side
transfers, detachable swing away footrests and four
brake castors. Model M66119 is also height
adjustable.
Limitations of use
Do not use as an alternative to a wheelchair.
Do not use in the shower/ as a shower chair.
Do not use to transfer clients over raised thresholds.
The commode should only be used indoors.
If you have any doubts about the restrictions on use,
please contact NRS (details on reverse).
General Safety Warning
Please ensure these instructions are fully read and
understood before installation/ use. Retain these
instructions in a safe place for future reference.
Unpacking
Remove all items from the packaging, check all the
items listed below are present (dependant on model
type). Check each component for any visible damage.
If you see any damage, or suspect a fault, do not
assemble the product; but contact your supplier
immediately
Contents:
L22056
M99448 M66119
Qty.
Main Chassis (c/w Castors) P 1
Main Chassis P 1
Seat Cover P P 1
Detachable arms P P 2
Detachable back P P 1
Potty P P 1
Footrest P P 2
Adjustable Height Castors P 4
Hand wheel P P 2
E - Clip P 4
Model:
M66119
Assembly Instructions:
1 –M66119 Only
Fit the Adjustable height castors to the main
chassis, slide the tube to the desired height, and
check that all legs are equal in height. Secure
with the E-clips provided, making sure each clip is
fully connected.
Please note; the height should be set so the client
feels comfortable, but ensure there is adequate
clearance if being used over a toilet
2 –All models
Place the chassis on a level floor.
3–At the rear of the commode there are two
black threaded hand wheels. Undo the hand
wheels so that the screw thread is clear from the
inside of the vertical tubes. Place the tubes of the
detachable back into the chassis tubes and
secure by turning the hand wheels until you feel
the resistance and the screw thread is biting
against the leg of the backrest.
Caution: DO NOT over tighten the hand
wheels. Do not use tools as it is only
necessary for the back to be secured finger
tight.
4 - Place the two detachable arms into the
locating holes on either side of the seat moulding,
ensuring they are fully inserted and secure.
L22056
M99448
NRS Wheeled Commode Fixed Height
NRS Wheeled Commode Wide/Fixed Height
30st
190kg
Max.
User
Weight
M66119 NRS Wheeled Commode Height Adjustable
25st
160kg

www.nrs
-
uk.co.uk
UI/L22056/M66119/01/14/Iss4
Assembly continued:
5 - Position potty on supports brackets (if
required) and place grey vinyl seat pad over the
moulded seat.
6 - Clip the two footrests into position, by fitting
them from the side, over the two studs on either
side of the front of the commode frame and
rotating them towards the front of the frame until
they click into place. Check the “swing away”
and “tilt up”operation of the footrests.
7 - Check the operation of the braked castors
and that the commode runs smoothly on a level
surface.
Caution: If you suspect a fault for any reason
with your commode, do not use and contact your
supplier immediately.
8 - The commode is now ready for use.
Safety precautions:
·Do not exceed Maximum User Weight.
·Always ensure the product is suitable for
your requirements; if in doubt, check with a
health professional.
·Always ensure all castors have the brake
applied and are in a forward aspect (not
trailing) and the footrests are up when sitting
onto or rising from the commode to reduce
the risk of tipping. Note: Footrests should
only be used to support the feet and should
not be used to stand on when entering or
leaving the commode.
·Check that no parts of the body are outside
the commode if passing through doorways.
·Take particular care when using the product
on damp surfaces.
·Before every operation inspect the product to
ensure it is fit for purpose; see Maintenance.
·Damaged, worn or missing components must
be replaced before further use by an
approved repairer.
Commode Bucket Cleaning
Note: protective gloves are recommended when
emptying the commode potty.
To remove the commode bucket, simply slide
the bucket out from the chrome runners at the
rear of the commode. Cover the top of the
bucket to avoid splashing. Carefully dispose of
the contents into a proper sluice or toilet.
Caution: Never empty contents into an open
drain, sink or basin. This could cause a
serious health risk.
Clean out the residue with a suitable disinfectant
and refit to the commode.
It is recommended that the seat is also wiped
with a disinfectant wipe or mild solution after
each use. Also wipe down the frame if any
spillages are apparent using a mild disinfectant
solution/wipe.
Note: NRS Healthcare offers a range of
protective
gloves and cleaning solutions to assist in the
effective decontamination of the potty and
commode.
For further information contact customer
services on: 0845 120 4522
Commode cleaning
Simply hose down/wash down or pressure wash with
a mild detergent solution, ensuring all detergents are
washed off thoroughly.
Wipe the commode thoroughly dry, paying particular
attention to all joints and abutments. Do not use an
abrasive cloth for drying
Caution: you must not use abrasive cleaners or
cleaners that attack chromium plating as this will
affect the integrity of the chromium plated
surface.
It is recommended that all joints, abutments and
castors are then sprayed with a water dispersing
agent such as WD40; this will give your commode
greater longevity and avoid premature rusting.
Maintenance
Check all components while in service on a regular
basis, once a week is recommended (and, following
decontamination, prior to reissue).
Ensure that all components are secure.
This includes:
The tightness of nuts and hand wheels.
The tightness, condition and operation of castors
including brake function.
Check all E-clips are securely engaged.
Check the condition and operation of footrests.
Check upholstery and moulding for splits.
Tighten and/or replace as necessary before re-use.
If in any doubt, please do not use or issue, but
contact your supplier for service support.
Manufactured for
NRS Healthcare
Sherwood House, Cartwright Way,
Forest Business Park, Bardon Hill,
Coalville, Leicestershire.
LE67 1UB, UK
Tel. Main Office: 0330 100 00 98
Tel. Customer Services: 0845 120 4522
Email: [email protected]
This product is from a range of over 3000 daily
living aids available from NRS Healthcare.
To view the full range visit: www.nrs-uk.co.uk
or request a catalogue from the above number.
