NRS Healthcare WHEELED COMMODE Series User manual

1
USER INSTRUCTIONS
NRS WHEELED COMMODE
L22056 Wheeled Commode Fixed Height M66119 Wheeled Commode Height Adjustable
N54411 Economy Wheeled Commode Fixed Height S30063 Wheeled Commode Powder Coated
General Safety Warning
Please make sure that you read and follow
these instructions carefully. Keep these
instructions in a safe place for future reference.
Maximum User Weight
30st
190kg
1. INTENDED USE
The Wheeled Commode range has been designed for use as a traditional commode or for use over a
standard toilet. Subject to completion of a suitable risk assessment, the wheeled commode can be used for
short transfers to move the user over the toilet. It features removable arms to enable side transfers.
2. SAFETY
Warning: Do not exceed the maximum user weight
specied for each product.
Always perform a risk assessment prior to use,
including safe moving distance.
Do not use as an alternative to a wheelchair.
Do not use in a shower or as a shower chair.
Do not use the product outdoors.
Only use indoors on level surfaces and take care
over door thresholds.
Always engage the brakes and swing away or lift o󰀨
the footrests when the user is transferring onto or o󰀨
the commode.
Take care to ensure all body parts are inside the
perimeter of the commode when passing through
doorways.
3. UNPACKING
Remove the packaging and check all parts carefully.
Contact your supplier immediately if parts are
missing or damaged and do not try and assemble.
3.1 Contents:
Part L22056
N54411
M66119
S30063 Qty
Main Chassis & Castors P1
Main Chassis P1
Seat Cover P P 1
Detachable Arms P P 2
Detachable Back P P 1
Potty P P 1
Footrest P P 2
Adjustable-Height Castors P4
Hand Wheel P P 2
E-Clip P4
4. ASSEMBLY
4.1 Fitting the Castors (M66119 and S30063):
Slide the castors into the main chassis, set to the
desired height, then secure with the e-clips.
Note: Make sure that all castor legs have been set
to the same height.

2
Note: The height should be set for user comfort but
must allow for adequate clearance if being used
over a toilet.
4.2 Fitting the Armrests:
Note: The armrests are left and right-handed,
please check the labels on the armrest. The padded
overhang should face the outside of the chair.
Attach the arms by slotting the tube inside the main
chassis frame on either side of the seat moulding.
Push and hold the button-clip, then push the armrest
down until the button-clip clicks into place.
Repeat the steps for the armrest on the opposite
side.
Note: Make sure the button-clip has fully engaged
the hole and that the armrest is fully secure.
4.3 Fitting the Backrest:
2. Slot the backrest into the main chassis frame,
then turn the hand-wheels clockwise to secure.
Note: Make sure the backrest is fully secure before
moving to the next step.
4.4 Fitting the Footrests:
Slot the footrests onto the studs on the main chassis
frame.
Rotate the footrest into the working position and
secure with the locking clip.
Note: Make sure the locking clip has clicked into
place and has fully secured the footrests.
Unfold the footrests into the working position.

3
4.5 Fitting the Commode Pan:
Slide the commode pan onto the metal runners at
the rear of the commode.
Note: Make sure that the commode pan is fully
secure before use.
4.6 Fitting the Padded Seat Cover
Fit the padded seat cover over the moulded seat.
5. IN USE
5.1 Adjusting the leg height (M66119 and
S30063):
Remove the e-clip and slide the castor leg to the
desired position, then replace the e-clip to secure.
Repeat for the other castor legs.
Note: Make sure that all castor legs have been set
to the same height.
5.2 Removing the Footrests:
Push the fastener clip to release the footrest.
Twist the footrest outwards and lift o󰀨 from the main
chassis frame studs.
5.3 Adjusting the Footrest Height.
Use the spanner provided to loosen the locking nut
on the end of the tube.
Slide the inner tube to the desired height.
Use the spanner to re-tighten the nut and secure the
position.
5.4 Operating the Brakes
Push the lever down to lock the brakes.

4
Flip the lever up to unlock the brakes.
6. CLEANING INSTRUCTIONS
6.1 Cleaning the Commode Pan:
Remove the commode pan by carefully sliding it
along the metal runners at the rear of the commode.
Place the lid over the commode pan to prevent
spillages and splashing.
Dispose of the contents into a proper sluice or toilet.
Warning: Never empty the contents into an open
drain, sink or basin as this could cause a severe
health risk.
Wash out any residue with a disinfectant solution
and rinse thoroughly with fresh water.
Ret the commode pan to the commode, refer to
Section 4.5.
6.2 Cleaning the Commode Chair & Frame:
Thoroughly wash the commode after each use using
a general purpose neutral detergent and warm water.
To disinfect, in particular the seat, wipe with a dilute
bleach solution and rinse thoroughly with fresh water.
Please check the suitability of the cleaning product
before use. Do not use abrasive cleaners or cloths
as this will permanently damage the surface and
invalidate any warranty.
7. MAINTENANCE
Inspect the product regularly for signs of wear or
damage. Pay particular attention to the upholstery.
Any suspected faults or damage should immediately
be reported to the supplier and the product taken out
of use.
Periodically spray a water dispersing agent (e.g.
WD40) onto all joints and castors.
Check that all components are correctly tted and
secure. If necessary tighten the nuts, screws and
hand wheels.
Check the castors are free to rotate, remove any
build-up of dirt/debris.
Frequently check the brakes are operational and
there are no signs of wear.
Store the commode on a at surface, with the brakes
locked, out of reach of children.
8. PRODUCT DISPOSAL
This product must be thoroughly cleaned/sterilised
prior to disposal.
This product is manufactured from metal, plastic and
PVC and can be disposed of through Local Authority
Household Waste and Recycling Centres or through
Local Trade Waste Collectors.
9. PRODUCT GUARANTEE
NRS Healthcare guarantee this product for a period
of 12 months, from the date of purchase, against
faulty materials and workmanship.
This guarantee does not cover; abuse, misuse,
interference or tampering with any part of the
product.
Any guarantee issued by NRS Healthcare does not
a󰀨ect your statutory rights.
L22056-UI-12 21-02-2023
NRS HEALTHCARE Sherwood House, Cartwright Way, Forest Business Park
Bardon Hill, Coalville, Leicestershire, LE67 1UB, UK.
Tel: Customer Services: 0345 121 8111 Email: [email protected]
