NSK Viva Ace User guide

VIVA ace Quick Operation Guide
1. Installing the Holder Bar and Arm ...........................2
2. Connecting the Motor, the Scaler, and the Syringe ...3
3. Installing the Vacuum ............................................4
4. Installing the Water Bottle ......................................5
5. Connecting the Foot Control ..................................6
6. Connecting the AC Power Cord..............................6
7. Check before treatment .........................................7
8. Control Panel ........................................................8
9. Liquid Crystal Display of the Control Panel ............10
10. Motor .................................................................12
11. Motor <Endodontic treatment> ...........................13
12. Ultrasonic Scaler................................................. 14
13. Light Probe ......................................................... 15
14. Vacuum..............................................................16
15. Sync Mode
(Synchro Mode)
...................................16
16. 3way Syringe...................................................... 17
17. When the Water bottle is empty or
the Vacuum bottle is filled with liquid during use .....17
18. Storage Procedure.............................................. 18
19. Troubleshooting ..................................................22
Contents
1

1. Installing the Holder Bar and Arm
1Pull down the Holder Bar Lock and stretch the Holder Bar
upward. The position can be set at four points.
2Press the Holder Arm Lock and turn the holder forward.
The position can be set at four points.
2
Holder Bar Lock Holder Arm Lock

2. Connecting the Motor, the Scaler, and the Syringe
6&$/(5 02725
Place the Motor, the Scaler and
the Syringe on the Holder.
Connect each connector with
▲mark upside. 3
MotorScaler Syringe
Insert the syringe nozzle into
the syringe.

3. Installing the Vacuum
1After checking that the Vacuum Bottle lid is tightly closed,
place the Vacuum Bottle in the Control Unit. Insert the
Vacuum Junction Hose and the Vacuum Hose to the Vacuum
Bottle Lid until they meet the end.
2Insert the Vacuum Valve to the Vacuum Hose, then insert
the Suction Tube to the Vacuum Valve.
4
Vacuum Junction Hose
Suction Tube
Vacuum Valve
Vacuum Hose
Vacuum Hose

4. Installing the Water Bottle
1Fill with drinking water until it reaches
below the maximum line (350 ml). Then
tightly close the Water Bottle lid.
2Insert the Water Plug to the lid until hearing a clicking sound.
5
Maximum line
Tighten
Water Plug (OUT)
[Blue Tube]
Water Plug (IN)
[Clear Tube]

5. Connecting the Foot Control 6. Connecting the AC Power Cord
After turning the Power Switch OFF (to O side),
insert the AC Power Cord into the inlet until it
meets the end. Then insert it to the commercial
power outlet.
Insert the FC-76S Foot Control Plug (Black) into the Connector on the right.
Insert the FC-70S Foot Control Plug (White) into the Connector on the left.
Insert each plug until it meets the end.
Plug (White) Plug (Black)
FC-70S FC-76S
▲mark
Insert each plug
with ▲mark upside.
6

Perform the following checks before using the product on a patient to confirm that there are no abnormalities. If abnormal
vibration, noise, or overheating is detected when using or checking, stop using the product and contact your Authorized NSK
Dealer.
□There is no abnormal deformation or damage in the appearance.
□Drinking water is supplied into the Water Bottle.
□All the accessories are properly connected.
□Turn the Power Switch ON (l side ), and confirm that the product is in
the state of stand-by as defined below.
• The compressor is activated and stops after a few seconds.
• The liquid crystal display of the control panel lights and notification
sound rings.
□Start the Vacuum and confirm that it vacuums.
□Activate the Syringe for about 5 seconds by pressing both the air
button and the water button.
□Activate the motor for about 10 seconds while applying water.
Also, confirm the points below.
• Check if there is any abnormal vibration, noise or overheating.
• Check that the handpiece supplies water properly.
• Check that the light on the motor is on.
□Activate the scaler for about 10 seconds while applying water.
Also, confirm the points below.
• Check that the tip is vibrating properly.
• Check if there is any abnormal looseness, vibration, noise, or
overheating with the tip.
• Check that the tip supplies water properly.
• Check that the light on the handpiece is on.
7. Check before treatment
7

8. Control Panel
8

Selecting the suitable mode and the gear ratio (1:1,1:5)for
general cutting and tooth surface cleaning.
Selecting the suitable mode for root canal treatment.
Selecting Light Probe Mode.
Selecting Ultrasonic Scaler.
At the same time, selecting the Treatment Mode (P, E , G ).
(P :PERIO Mode, E :ENDO Mode, G :GENERAL Mode)
Switching ON/OFF of Motor and Scaler Operation.
It stores five setting programs (speed, torque, and auto reverse
setting ) during ENDO Mode.
Setting and cancellation of auto reverse function during the
ENDO Mode.
Selecting the direction of rotation during MOTOR, ENDO Mode.
Selecting ON/OFF of lighting during MOTOR and ENDO, Light
Probe Mode.
Selecting ON/OFF of Water Pouring functions during MOTOR,
ENDO, and SCALER Mode.
Selecting the Vacuum suction power in three levels.
Selecting Linking/Unlinking of the Vacuum with Motor and
Scaler.
ON/OFF of the Vacuum function.
During the ENDO Mode Torque Setting (0.3 - 3.0 N · cm)
During the SCALER Mode Power Setting (1-10)
When selecting the Light
Probe Mode
Sound Volume Setting
(High/ Low/Silent)
During the MOTOR/ENDO Mode Speed Setting
When selecting the Light
Probe Mode Light Quantity Setting
9

Ⓓ
Ⓔ
Ⓕ
ⒼⒽ
Ⓞ
Ⓝ
ⒿⒾⓀⓁⓂ
Ⓒ
Ⓑ
Ⓐ
9. Liquid Crystal Display of the Control Panel
10

Displays the ENDO Mode.
Displays the gear ratio.
Displays the MOTOR Mode.
Displays the LIGHT PROBE Mode.
Displays during the SCALER operation.
Displays the SCALER Mode.
Displays the memory number.
Displays the current AUTO REVERSE Mode.
Displays the Sound Volume Settings (High/Low/Silent ).
Displays the direction of rotation.
Displays ON/OFF of lighting.
Displays ON/OFF of Water Pouring.
Displays the Vacuum suction power in three levels.
Displays Linking/Unlinking of the Vacuum with Motor and
Scaler.
Displays the set upper limit torque value during the ENDO
Mode.
Displays the selected mode and power setting during the
SCALER Mode.
Displays the actual speed when the motor is running. When
the motor is not running, it displays the maximum set speed.
11

10. Motor
Select the gear ratio
Light ON/OFF Motor Water Adjustment
The water amount can be adjusted
by turning the Water Adjuster.
Water ON/OFF
Set the speed
Gear Ratio Speed(min-1 )
Select the direction of rotation
Forward Rotation
Reverse Rotation
Activate/Stop the Motor
5,000 - 200,000
1,000 - 40,0001 : 1
1 : 5
Two ways to activate/stop
the Motor are shown below :
①FC-76S Foot Control
②Manual Operation ON/OFF
Press more than 2 seconds
* Long press works only for ON
12

11. Motor <Endodontic treatment>
The water amount can be adjusted
by turning the Water Adjuster.
Select the direction of rotation
Forward Rotation
Reverse Rotation
Change to ENDO Mode Speed Setting
100 - 5,000 min-1
0.3 - 3.0 N
・
cm
Torque Setting
Water ON/OFF
Light ON/OFF
Motor Water Adjustment
Select the program
Activate/Stop the Motor
Select Auto
Reverse function
Two ways to activate/stop
the Motor are shown below :
①FC-76S Foot Control
②Manual Operation ON/OFF
Press more than 2 seconds
* Long press works only for ON
13

12. Ultrasonic Scaler
Select the treatment mode
P: PERIO Mode
E: ENDO Mode
G: GENERAL Mode
Activate/Stop the Scaler
Two ways to activate/stop
the Scaler are shown below :
①FC-76S Foot Control
②Manual Operation ON/OFF
1 to 10
Set it below the maximum
power of the tip.
Press more than 2 seconds
* Long press works only for ON
Water ON/OFF Scaler Water Adjustment
The water amount can be adjusted
by turning the Water Adjuster.
Power Setting
14

13. Light Probe
Adjustments can be made
in increments and is directly
reflected in the light quantity
of the MOTOR Mode.
Connect the Light Probe Light Quantity Setting
Select the Light Probe Mode
Light ON/OFF
15

14. Vacuum 15. Sync Mode (Synchro Mode)
Select the suction force
Activate/Stop the Vacuum
Vacuum ON/OFF During treatment
Two ways to activate/stop
the Vacuum are shown below :
①FC-70S Foot Control
②Manual Operation ON/OFF
Suctioning stops by closing the
Vacuum Valve Lever.
CLOSE
OPEN
The Vacuum can be synchronized with the Motor and the
Scaler (except during Light Probe Mode). It can be set
individually at each Mode (MOTOR, ENDO, and SCALER),
however the suction force value will remain the same.
Long press the VACUUM Key (More than 1 second )
Linked
Not Linked
16

16. 3way Syringe
1
2
1
2
3
17. When the Water Bottle is empty or the Vacuum
Bottle is filled with liquid during use
Water Button
Water comes out
when pressed.
Air Button
Air comes out
when pressed.
Pressing the both buttons at the same time provides spray water.
Syringe Water Adjustment
(The water amount can be adjusted by turning
the Water Adjuster.)
Turn off the Power Switch (○side).
Dispose of the sucked liquid (saliva, blood, etc.)
in the Vacuum Bottle.
Remove the Water Bottle and fill it with water.
Syringe ON/OFF
17

18. Storage Procedure
12
After closing the Vacuum Valve Lever,
remove the Handpiece, the Syringe
Nozzle, and the Suction Tube and
place them in the holder.
Store the Vacuum Bottle after disposing of the sucked liquid (saliva, blood,
etc.). When storing without disposing of the sucked liquid, put caps on the
Vacuum Bottle and the Vacuum Hose.
CLOSE
Vacuum
Cap B Vacuum
Cap A
Hose
Cap
18

Storage of cords and hoses
is introduced in a video.
Check the URLor the QR code
below.
URL
http://www.nsk-dental.com/
support/videos/
3After dropping the root part of the cords and hoses into the storage part of the Control Unit,
wind the rest of the cords and hoses clockwise.
Drop the bundled cords
and hoses along the right wall.
Point 1 Wind the rest of the cords
and hoses clockwise.
Point 2
19
