NSS WRANGLER 1708CE User manual

OPERATION MANUAL
WRANGLER 1708CE/2008CE
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Failure to observe these instructions can cause
personal injury to machine operator or bystanders.
WARNING: Shock or electrocution hazard.
ALWAYS unplug machine before
performing any maintenance or service.
WARNING: Shock or electrocution hazard.
NEVER connect this machine to an
electrical outlet that is not properly
grounded.
WARNING: Fire or explosion hazard.
NEVER operate this machine in an explosive
atmosphere (grain dust, flammable liquids or
fumes, etc.).
WARNING: Fire or explosion hazard.
NEVER attempt to pick up flammable or
combustible materials or use such materials in
tank.
WARNING: Orange Oil (D-limonene) is not compatible with the plastics used in NSS automatic scrubbers and
the Sidekick Chemical Metering System. Use of D-limonene may result in damage to the machine.
WARNING: This product contains a chemical known to the state of California to cause cancer and birth defects
or other reproductive harm.
INTENDED USE
This machine is intended for commercial use,
scrubbing floors in an indoor environment. NSS
does not recommend using this machine for any
other purpose.
FOR SAFETY:
•ALWAYS read and understand all instructions before
operating or servicing machine.
•ALWAYS use this machine ONLY as described in this
manual.
•NEVER attempt to operate this machine unless you
have been trained in its operation.
•NEVER allow an untrained person to operate this
machine.
•NEVER attempt to operate this machine if it is not
working properly or has been damaged in any manner.
•NEVER disconnect or modify any switches or safety
devices (circuit breaker).
•NEVER leave the machine plugged in to the electrical
outlet when not in use.
•NEVER unplug the machine from an electrical outlet
until after the machine is turned off.
•NEVER operate this machine if the cord and/or plug
has been damaged, broken, cut, abraded or taped.
•NEVER handle the machine, cord or plug with wet
hands.
•ALWAYS replace the entire cord when the cord or plug
is damaged in any way.
•NEVER pull machine by the cord.
•NEVER operate this machine with any air opening
blocked. Keep all air openings free of dust, lint, hair,
etc.
•NEVER drop or insert any object into any machine
opening.
•NEVER pick up anything that is burning or smoking, such as
cigarettes, matches or hot ashes.
•NEVER spray this machine with water or any liquids.
•NEVER allow the vacuum motor to get wet.
•NEVER operate this machine with the side skirt removed.
•NEVER allow this machine to be used as a toy. Close
attention is necessary when used by or near children.
•ALWAYS wear clean tennis shoes or “non-slip” shoes.
Leather sole shoes will be extremely slippery.
•ALWAYS keep face, fingers, hair or any other body part or
loose clothing away from any machine opening or moving
part (revolving brush, pad driver, or vacuum motor).
•ALWAYS unplug the machine when attaching pads or
brushes.
•ALWAYS be sure that the ramp is secured to the vehicle
before attempting to load/unload.
•ALWAYS use extreme caution when operating the machine
on a ramp or loading/unloading this machine into or out of a
truck/trailer. Use extreme caution if the ramp is wet, oily,
or covered with cleaning chemicals.
•NEVER stop or turn the machine on a ramp or incline.
•NEVER attempt to climb a grade or operate this machine
on a ramp or incline of more than 8 degrees.
•NEVER park or store the machine near a dock, on ramps,
near a furnace, boiler, open flame, or other high heat
source.
•NEVER allow this machine to freeze.
•NEVER expose the machine to rain, snow, or extreme
temperatures.
•NEVER store any items on this machine.
•ALWAYS store this machine indoors in a dry, cool area.
ALL REPAIR SERVICE MUST BE PERFORMED BY AN NSS AUTHORIZED DISTRIBUTOR/
SERVICE STATION USING ONLY NSS ORIGINAL EQUIPMENT PARTS.
SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS
GROUNDING OF ELECTRICAL EQUIPMENT
WARNING: Improper connection of the equipment–grounding
conductor can result in a risk of electric shock. Check with a qualified
electrician or service person if you are in doubt as to whether the outlet
is properly grounded. Do not modify the plug provided with the machine
– if it will not fit the outlet, have a proper outlet installed by a qualified
electrician.
Always use a properly grounded 3-wire extension cord which has
male and female plugs. If 25 foot extension cords are used, the
electrical carrying capacity should be no less than 14-3 ST. For 50’
foot extension cords no less than 12-3 ST.
GROUNDING INSTRUCTIONS
This machine shall be grounded while in use to protect the operator from electric shock. The machine is provided
with a three-conductor cord and a three-contact grounding type attachment plug. The plug must be plugged into
an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
The green conductor in the cord is the ground wire. Never connect this wire to anything other than the grounding
pin of the attachment plug.
Check nameplate on the machine to be sure voltage and cycle stated is the same as the electrical outlet. Do not
attempt to plug a 120 volt machine into a 240 volt outlet or a 240 volt machine into a 120 volt outlet. If the
machine is provided with an attachment plug as shown in Figure A below, it is intended for use on a nominal 120
volt circuit. If a properly grounded receptacle as shown in Figure A is not available, an adapter may be installed
as shown in Figure B if the outlet box that houses the receptacle is grounded. Be sure to fasten the grounding tab
(the green colored rigid ear, lug or the like extending from the adapter) with a metal faceplate screw.
If the machine is provided with an attachment plug as shown in Figure C, it is intended for use on a nominal 240
volt circuit. No adapter is available for this plug.
NOTE: In Canada, the use of a temporary adaptor is not permitted by Canadian electrical code.
ALL REPAIR SERVICE MUST BE PERFORMED BY AN NSS AUTHORIZED DISTRIBUTOR/
SERVICE STATION USING ONLY NSS ORIGINAL EQUIPMENT PARTS.
SAVE THESE INSTRUCTIONS

3
NOISE AND VIBRATION
MACHINE INSPECTION
• Now that the machine is unpacked remember to
recycle all packing materials.
• Inspect machine for damage or missing components.
If damage is found, contact the local freight company
and file a freight claim.
MACHINE COMPONENTS
Solution Tank
The solution tank is the lower part of the machine
body. It has a capacity of 8 gallons (30 liters).
•The amount of water in the tank is measured by the
sight hose, (clear plastic tube), at the rear of the
machine.
Recovery Tank
The recovery tank is the upper part of the machine
body. It has a capacity of 10 gallons (38 liters).
•A rectangular, clearview lid assembly closes the
recovery tank.
•The recovery tank has a foam-sensitive float shut-
off assembly. As the water or foam level rises, the
float ball will rise and shut off the air-flow of the
vacuum motor to the squeegee. It does not shut off
the vacuum motor.
Control Panel
•The operator control panel is located at the rear
area of the machine. This panel has components
that control various machine functions.
•Starting from the left side:
•The circuit breaker is for both the brush motor and
the vacuum motor.
•The first switch turns the brush motor on and off.
•The next switch turns the vacuum motor on and off.
•The red switch is the master power switch; it
controls the power to all components
Squeegee Assembly
The squeegee assembly has a wide, flat frame to
help prevent damage, two ( 2) mounting knobs, and
two (2) small wheels to prevent “rollover” in reverse.
Brush Gear Motor
This machine has one (1) 24-volt brush motor located
at the front of the machine. The motor is attached to
a gearbox to turn the pad drivers or brushes.
•This motor has carbon brushes that must be
serviced on a regular basis. The carbon brushes
have an expected life of 2,000 operating hours.
Refer to the maintenance section later in this book.
Vacuum Motor
This machine has a 24-volt vacuum motor.
•The vacuum motor is attached to the underside of
the solution tank behind the rubber flap.
•This motor has carbon brushes that must be
serviced on a regular basis. The carbon brushes
have a maximum expected life of 700 operating
hours. Refer to the maintenance section later in
this book.
NOISE
Sound pressure level at Operator
position
74dB(A)
VIBRATION
Weighted RMS acceleration value
(ISO 5349)
.367 m/s2

4
PREPARING THE MACHINE
•Preparing the Solution and Recovery Tanks:
•Never use water over 140°F (60°C) degrees.
•Excessively hot water may damage components
such as the tanks.
•Put 1 to 2 gallons of clean water into the solution
tank first to help dilute the chemicals and prevent
excess sudsing. Dilute the cleaning chemicals
according to the manufacturer’s instructions.
•Fill the tank by pouring the water and cleaning
chemicals through the mesh filter that covers the
opening at the front of the solution tank.
•Make sure the recovery tank drain hose is tight on
the plug.
•Always use a defoamer to protect the vac motor.
•Consult your local distributor for complete chemical
advice.
Install a Pad Driver and Pad:
•There is a wide range of pads or brushes available
for the many cleaning applications. Consult your
NSS authorized distributor for recommendations.
•Turn off all switches and empty all liquids from the
recovery and solution tank.
•Raise the brush motor into the “up” position. The
foot pedal is at the rear left of the machine. Step on
the pedal and slide it to the right into the notch.
•Step on the foot pedal latch at the front of the
machine chassis.
•Lift the machine body by the opening for the
solution tank. Tilt the machine body backward until
the handles rest on the floor.
•Remove pad driver assembly from drive casting on
end of brush motor shaft by turning the driver
counter-clockwise.
•Turn the pad drivers upside down on the floor and
remove the pad holding cup.
•Remove the center cutout of the 17” (43cm) or 20”
(51cm) pad if present and place pad on the face of
the pad driver.
•The pad must be centered on the driver to prevent
wobbling or bouncing.
•Install and secure the pad holding cup to the pad
driver. Turn the pad driver over so that the pad
faces the floor.
•Align the notches of the pad driver with the lugs of
the drive casting.
•Turn the pad driver clockwise to lock onto the drive
casting.
•Turn the pad driver counter-clockwise to remove.
Install a Brush:
•Align the notches of the brush with the lugs of the
drive casting.
•Turn the brush clockwise to lock onto the drive
casting.
•Turn the brush counter-clockwise to remove.
•Install the Squeegee Assembly:
•Place the squeegee lift arm in the storage (up)
position.
•The squeegee assembly mounts to a metal bracket
at the bottom center of the machine, using two (2)
mounting knobs. Loosen the mounting knobs and
slide the squeegee assembly onto the mounting
plate.
•The squeegee assembly has two (2) small wheels
to prevent “rollover” while in reverse. The roller
wheels must face the operator. Hand tighten the
mounting knobs. Do not use pliers to tighten
knobs, as this will defeat the “break-away” design.
•Do not add any weights or other pressure to the
squeegee mechanism. This will not improve the
performance and will shorten the life of the blades.
Operating the Machine
The Wrangler 1708/2008 is very maneuverable and
is designed for light to medium scrubbing as you
operate the machine from behind. Follow these
steps to prepare the machine for daily operation.
•Sweep and dust mop the floor to remove dirt and
debris before scrubbing. Accumulations of dirt or
debris on the floor will reduce cleaning
performance.
•You may also need to preclean some types of
spills or stains before scrubbing.
•Plan your work so that you make long, straight
paths with the fewest amounts of turns as possible,
overlapping each cleaning path about 2 in. (5cm) to
prevent streaking and dirty areas.
•Remove as many obstacles as possible from the
area to be scrubbed.
•Do not put strip solution in solution tank. Apply
with mop and bucket and rinse with clean water in
solution tank.

5
MACHINE MAINTENANCE
Routine maintenance is critical to ensure proper
machine operation and cleaning performance.
Perform all maintenance procedures as follows.
Always turn OFF all machine switches before
performing any maintenance.
Adjusting the Squeegee Assembly:
As the machine is used, the squeegee blades will
wear or need to be replaced due to damage. Some
adjustment may be needed.
•Squeegee blades should lie over slightly (like a
window squeegee) when the machine is moving
forward or in reverse.
•Adjust the blade angle by turning the wing nut on
the pivot arm clockwise/counterclockwise.
Daily Maintenance
Solution and Recovery Tanks
•Drain the solution tank through the solution valve or
the sight hose at the rear of the machine.
•The recovery tank is emptied through the black
hose at the rear of the machine. Remove the plug
and drain the liquids according to your local EPA
regulations.
•Every time you empty the recovery tank, we
recommend that you add at least 4 to 6 ounces of
defoamer chemical into the recovery tank before
resuming work. Vacuum the defoamer into the
empty recovery tank through the squeegee vac
hose.
•At the end of the day empty all liquids from both
solution and recovery tanks. Rinse both tanks with
clean water to prevent chemical residue build-up,
allow to air - dry to prevent odors.
•Leave lid off recovery tank to prevent moisture from
building up.
•Remove any residue from screen and float ball to
ensure proper operation. Replace float assembly
in recovery tank.
•Check clear lid for airtight seal.
•Check the drain hose for damage and / or
restriction, to access the hose, remove the clean
out cap from inside the Recovery tank, replace the
cap before using the machine.
Pad Drivers or Brushes
•Remove either pad drivers or brushes from
machine after use.
•Rinse with clean water to prevent chemical residue
build-up.
•Allow to air-dry, on a peg or upside down on a
shelf.
•Inspect for wear or damage. Repair or replace as
needed.
Squeegee Assembly
•Remove squeegee assembly from machine.
•Rinse with clean water to prevent chemical residue
build-up.
•Allow to air dry, it can be stored on top of the
machine for drying.
•Inspect the squeegee assembly, linkage, and
vacuum hose, for wear, damage or obstruction.
Repair or replace as needed.
•Remove debris from squeegee hose and entrance
to recovery tank.
Weekly Maintenance (25 Hours)
•Verify all daily maintenance has been performed.
Check solution flow to pad drivers / brushes. Flush
clean solution tank and hoses with a mixture of 8
oz. (250ml.) white vinegar to one-gallon (4 liter)
warm water.
•Repair or replace any worn or damaged
components as needed.
Monthly Maintenance (100 Hours)
•Verify all daily and weekly maintenance has been
performed.
•Lubricate the axle bearings of the two large 8”
(20cm) wheels. Use high-grade water-resistant
grease.
•Lubricate the caster with moisture resistant
foaming-type spray.
MANDATORY Periodic Maintenance
It is important for you to maintain a record of the
amount of machine operating hours in order to
perform this machine maintenance.
It is mandatory that the following maintenance
procedure be performed at the described interval.
Failure to perform this procedure may result in poor
machine performance, machine component damage
and failure. This procedure should be performed by
an authorized NSS distributor or service center.
Repairs performed by an unauthorized company will
void the machine warranty. If you require assistance
finding an authorized service center, please contact
NSS Enterprises, Inc.
After every 450-500 hours of operation you must
inspect vacuum motor carbon brushes for wear.
Replace the vacuum motor carbon brushes when
they are 7/16in. (11mm) in length.
After every 650-700 hours of operation you must
inspect brush motor carbon brushes for wear.
Replace the brush motor carbon brushes when they
are 1/2in. (13mm) in length

6
TROUBLE-SHOOTING
PROBLEM CAUSE SOLUTION
No Solution Flow. Solution tank is empty. Fill the tank.
Clogged filter. Clean filter.
The solution valve is closed. Open the solution valve.
Obstruction in the solution hose. Remove the obstruction.
Solution valve or linkage damaged. Repair / replace the valve linkage.
Solution hose kinked. Check for kinks and remove.
Solution Flow Does Not
Stop. The solution valve is open. Close the solution valve.
Solution valve or linkage damage. Repair / replace the valve linkage.
The solution valve is dirty. Clean the solution valve.
Damaged seat and washer in valve. Replace valve.
The valve stem is dirty. Clean and lubricate valve stem.
Hose disconnected or damaged between
solution tank and valve. Reinstall or replace hose.
Will Not Pick Up Any
Water From Floor. Squeegee is up. Squeegee hose is off or plugged. Lower squeegee. Reinstall hose. Remove cap inside the
Recovery tank to clean hose restriction.
Vac motor switch is off. Turn vac motor switch “on”.
Recovery tank is full. Empty tank.
Vacuum shut-off float is stuck. Open float valve/remove obstruction.
Obstruction / damage in the squeegee,
squeegee hose or standpipe. Remove obstruction / repair damage.
Leaking over gasket. Remove old gasket / replace.
Vac motor is not running. Have an authorized serviceman repair.
Recovery drain hose not plugged
properly. Install drain hose plug properly.
Will Not Pick Up All Of The
Water From The Floor. Debris on squeegee blades. Squeegee blade is worn / damaged. Clean squeegee. Reverse / replace squeegee blade.
Obstruction / damage in the squeegee,
squeegee hose, or standpipe. Remove obstruction / repair damage.
Squeegee angle needs adjustment. Adjust angle.
Vacuum motor worn out. Repair / replace vac motor.
Recovery tank drain hose damaged. Repair / replace recovery drain hose.
Cleaning Is Not Even. Brush / pad is worn. Replace brush / pads.
Damage to brush assembly; casters or
solution valve. Have an authorized serviceman repair.
Machine does not run. Circuit breaker tripped. Reset circuit breaker.
NOTE: If any problems remain after taking the above steps, contact your local authorized
distributor / service station for further evaluation and repair.

7
NOTES:

NSS®Enterprises, Inc.
3115 Frenchmens Road, Toledo, Ohio 43607
PHONE [phone] FAX [phone]
NSS ® Enterprises, Inc. European Distribution Centre
Unit II, Pinfold Trading Estate * 55 Nottingham Road
STAPLEFORD, NOTTINGHAM NG9 8AD ENGLAND U.K.
PHONE: [phone] * FAX: [phone]
WRANGLER 1708CE/2008CE Orig. 06/02 Rev B 12-09 9091717
