Nucraft Performance Credenza Console Guide

Disassembly and Service Part Guide
Performance Credenza
Product Line
Performance Credenza Console
Tools Required
Phillips Head Screwdriver
Disassembly Time
Approximately 10 Minutes
5151 West River Drive
Comstock Park, MI 49321
p 616.784.6016
f 616.784.4402
nucraft.com
877.NUCRAFT
BIFMA e3-2011
Credit 5.9.1, 5.9.2, 5.9.3
DSG-Perf Cred-Console
1
3
4
5
6
2
Item
1
2
3
4
5
6
Component
Top
Side Panel
Drawer Box (Not Shown)
Drawer Front
Glide (Not Shown)
Brackets (Not Shown)
Hardware (Screws, Slides and Lock)
Material
MDF with Veneer
Particle Board with Veneer
Plywood
Particle Board with Veneer
Plastic with Threaded Steel Insert
Steel
Various Metals

5151 West River Drive
Comstock Park, MI 49321
p 616.784.6016
f 616.784.4402
nucraft.com
877.NUCRAFT
BIFMA e3-2011
Credit 5.9.1, 5.9.2, 5.9.3
DSG-Perf Cred-Trash/
Recycling Center
2
6
4
5
7
3
8
9
4
1
Item
1
2
3
4
5
6
7
8
9
Component
Top and Back (Not Shown)
Doors
Side Panels and Bottom
Pull
Shelves and Center Supports (Not shown)
Recycling Case
Trash/Recycling Container (Not Shown)
Caster (Not Shown)
Glide
Hardware (Screws, Hinges, Shelf Pins, Slides, Brackets and Locks)
Material
MDF with Veneer
PB with Veneer
PB with Veneer
Aluminum
PB with Veneer
MDF (Painted)
Plastic and Steel
Plastic with Threaded Steel Insert
Various Metals
Plastic - LDPE (#4)
Disassembly and Service Part Guide
Performance Credenza
Product Line
Performance Credenza Trash/Recycling Center
Tools Required
Phillips Head Screwdriver
Disassembly Time
Approximately 20 Minutes

Disassembly and Service Part Guide
Performance Credenza
Product Line
Food Service Performance Credenza
Tools Required
Phillips Head Screwdriver
Disassembly Time
Approximately 45 Minutes
5151 West River Drive
Comstock Park, MI 49321
p 616.784.6016
f 616.784.4402
nucraft.com
877.NUCRAFT
BIFMA e3-2011
Credit 5.9.1, 5.9.2, 5.9.3
DSG-Perf Credenza-Food Service
5
4
6
7
9
3
3
12
8
11
2
1
10
Item
1
2
3
4
5
6
7
8
9
10
11
12
Component
Top
Sub-Top
Side Panels, Bottom and Back
Door
Drawer Front
Drawer Box
Shelves and Center Supports (Not Shown)
Pull Out Shelves
Pulls
Flip Up Shelves
Pneumatic Cylinder
Damper Assembly and Cover
Hardware (Screws, Hinges, Shelf Pins, Slides and Locks)
Material
Particle Board w/Veneer & Inset Laminate
Particle Board with Laminate
Particle Board with Veneer
Particle Board with Veneer
Particle Board with Veneer
MDF (Painted)
Particle Board with Veneer
Particle Board with Laminate
Aluminum
Steel
Steel
Steel
Various Metals

Disassembly and Service Part Guide
Performance Credenza
Product Line
Utility Performance Credenza
Tools Required
Phillips Head Screwdriver
Disassembly Time
Approximately 15 Minutes
5151 West River Drive
Comstock Park, MI 49321
p 616.784.6016
f 616.784.4402
nucraft.com
877.NUCRAFT
BIFMA e3-2011
Credit 5.9.1, 5.9.2, 5.9.3
DSG-Perf Credenza-Utility
6
3
4
5
2
7
1
Item
1
2
3
4
5
6
7
Component
Top and Back (Not Shown)
Side Panels and Bottom
Doors
Shelves
Rack (Not Shown)
Pull
Glide (Not Shown)
Hardware (Screws, Hinges, Shelf Pins and Locks)
Material
MDF with Veneer
Particle Board with Veneer
Particle Board with Veneer
Particle Board with Veneer
Steel
Aluminum
Plastic with Threaded Steel Insert
Various Metals
