NXP Semiconductors i.MX 6Dual User manual

© 2012-2016 NXP B.V.
NXP Semiconductors
Chip Errata
This document details the silicon errata known at the time of publication for the i.MX 6Dual/6Quad and
i.MX 6DualPlus/6QuadPlus multimedia applications processors.
Table 2 provides a revision history for this document.
Table 3 contains a summary of the silicon errata. Bolded rows are specific to either i.MX 6Dual/6Quad or
i.MX 6DualPlus/6QuadPlus (see the errata description column).
Table 4 lists the ARM errata excluded from detailed description in this document.
To identify the silicon revision, refer to the last letter of the part number. See Table 1 for examples.
For additional information, see either the i.MX 6Dual/6Quad Applications Processor Reference Manual
(IMX6DQRM) or the i.MX 6DualPlus/6QuadPlus Applications Processor Reference Manual
(IMX6DQPRM).
Table 1. Part number/silicon revision examples
Example Part Numbers Silicon Revision
MCIMX6Q6AVT10ACi.MX 6Quad, Revision 1.2
MCIMX6D6AVT10ADi.MX 6Dual, Revision 1.3
MCIMX6QP6AVT1AAi.MX 6QuadPlus, Revision 1.0
MCIMX6DP6AVT1AAi.MX 6DualPlus, Revision 1.0
IMX6DQCE
Rev. 6.1, 06/2016
Chip Errata for
the i.MX 6Dual/6Quad and
i.MX 6DualPlus/6QuadPlus

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
2NXPSemiconductors
NOTE
BSP functionality in some configurations and use cases, or your own/added
software functionality, may be affected by an erratum. We have made our
bestattemptatprovidingsoftwareworkaroundrequirementsandBSPstatus
foreacherratuminthisdocument.Whether a software workaround hasbeen
implemented in the BSP or not, the user should evaluate his specific use
cases and take any (additional) necessary actions to prevent the occurrence
or impact of each erratum. Go through your support channel if you have any
questions or concerns.

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
NXP Semiconductors 3
The following table provides a revision history for this document.
Table 2. Document Revision History
Rev.
Number Date Substantive Changes
Rev. 6.1 06/2016 • Updated ERR004536 in Table 3 and ERR004536 changing from: Silicon revision 1.3 to; No fix
scheduled and removing i.MX 6Dual/6Quad Only.
Rev. 6 02/2016 • Updated the following i.MX 6Dual/6Quad-specific errata:
–ERR004300, ERR004484, ERR004536, ERR005216, ERR005723, ERR005768, ERR005908,
ERR006282, ERR006687, ERR007966, ERR008506,
• Added the following i.MX 6Dual/6Quad-specific errata:
–ERR007926, ERR008587, ERR009219
• Added the following i.MX 6DualPlus/6QuadPlus-specific errata:
–ERR009619, ERR009623, ERR009624
• Added the following i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus-specific errata:
– ERR007555, ERR007556, ERR007557, ERR007573, ERR007575, ERR007577, ERR007881,
ERR008990, ERR009165, ERR009218, ERR009535, ERR009596, ERR009598, ERR009604,
ERR009605, ERR009606, ERR009678, ERR009704, ERR009742, ERR009743, ERR009858
• Updated the following i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus-specific errata:
– ERR004366
• Added Table 4 describing ARM errata not documented in this deliverable.
• Updated the following ARM errata:
• ERR003717, ERR003718, ERR003719, ERR003720, ERR003721, ERR003723, ERR003724,
ERR003725, ERR003726, ERR003727, ERR003728, ERR003729, ERR003730, ERR003731,
ERR003732, ERR003735, ERR003736, ERR003737, ERR003738, ERR003740, ERR003741,
ERR004324, ERR004326, ERR004327, ERR005175, ERR005183, ERR005185, ERR005187,
ERR005199, ERR005200, ERR005382, ERR005383, ERR005385, ERR005386, ERR005387,
ERR007006, ERR007007, ERR007008
• Removed errata:
– ERR005779
Rev. 5 06/2015 • Update to ERR006282
Rev. 4 06/2014 • Added ERR007805
• Added ERR008001
• Added ERR008000
• Added ERR007554
• Added ERR007926
• Added ERR007966
• Removed ERR003742. This item was ARM erratum 732672. Access to this information must come
directly from ARM.
• Removed ERR007005. This item was ARM erratum 791420. Access to this information must come
directly from ARM.
Rev. 3 11/2013 • Added the following: ERR007005, ERR007006, ERR007007, ERR007008, ER007117, ER007220,
ERR007265, ERR007266
• Updated the following: ERR003740, ERR003742, ERR003778, ERR004512

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
4NXPSemiconductors
Rev. 2 5/2013 • Deleted ERR003775—Addressed in rev. 1 of the i.MX 6Dual/6Quad Applications Processor Reference
Manual (IMX6DQRM).
• Added the following errata:
– ERR006282
– ERR006308
– ERR006358
– ERR006687
• Updated the following:
– ERR004353
– ERR004446
– ERR005829
Rev. 1.1 2/2013 Restored pages omitted in Rev. 1.
Rev. 1 1/2013 • Added the following:
–ERR006223
–ERR006259
–ERR006281
• Updated ERR004367
– Deleted ERR005384 (not relevant to this Freescale implementation of the ARM®core)
Rev. 0 10/2012 Initial public release.
Table 2. Document Revision History (continued)
Rev.
Number Date Substantive Changes

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
NXP Semiconductors 5
Table 3. Summary of Silicon Errata
Errata Name Solution Page
Analog
ERR005852 Analog: Transition from Deep Sleep Mode to LDO Bypass Mode may cause the slow
response of the VDDARM_CAP output No fix scheduled 15
ARM®
ERR003717 ARM: 740657—Global Timer can send two interrupts for the same event No fix scheduled 16
ERR003718 ARM: 743622—Faulty logic in the Store Buffer may lead to data corruption No fix scheduled 18
ERR003719 ARM/MP: 751469 — Overflow in PMU counters may not be detected No fix scheduled 20
ERR003720 ARM/MP: 751472—An interrupted ICIALLUIS operation may prevent the completion
of a following broadcast operation No fix scheduled 22
ERR003721 ARM: 751473—Under very rare circumstances, Automatic Data prefetcher can lead
to deadlock or data corruption No fix scheduled 24
ERR003723 ARM: 751476—May miss a watchpoint on the second part of an unaligned access
that crosses a page boundary No fix scheduled 25
ERR003724 ARM: 754322—Possible faulty MMU translations following an ASID switch No fix scheduled 26
ERR003725 ARM: 725631—ISB is counted in Performance Monitor events 0x0C and 0x0D No fix scheduled 28
ERR003726 ARM: 729817—MainID register alias addresses are not mapped on Debug APB
interface No fix scheduled 29
ERR003727 ARM: 729818—In debug state, next instruction is stalled when sdabort flag is set,
instead of being discarded No fix scheduled 30
ERR003728 ARM: 740661—Event 0x74 / PMUEVENT[38:37] may be inaccurate No fix scheduled 31
ERR003729 ARM: 740663—Event 0x68 / PMUEVENT[9:8] may be inaccurate No fix scheduled 32
ERR003730 ARM: 743623—Bad interaction between a minimum of seven PLDs and one
Non-Cacheable LDM can lead to a deadlock No fix scheduled 34
ERR003731 ARM: 743626—An imprecise external abort, received while the processor enters
WFI, may cause a processor deadlock No fix scheduled 36
ERR003732 ARM: 751471—DBGPCSR format is incorrect No fix scheduled 37
ERR003733 ARM: 751480—Conditional failed LDREXcc can set the exclusive monitor No fix scheduled 39
ERR003734 ARM: 752519—An imprecise abort may be reported twice on non-cacheable reads No fix scheduled 40
ERR003735 ARM: 754323—Repeated Store in the same cache line may delay the visibility of the
Store No fix scheduled 41
ERR003736 ARM: 756421—Sticky Pipeline Advance bit cannot be cleared from debug APB
accesses No fix scheduled 43
ERR003737 ARM: 757119—Some “Unallocated memory hint” instructions generate an
UNDEFINED exception instead of being treated as NOP No fix scheduled 44
ERR003738 ARM/MP: 751475—Parity error may not be reported on full cache line access
(eviction / coherent data transfer / cp15 clean operations) No fix scheduled 45

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
6NXPSemiconductors
ERR003739 ARM: 751470—Imprecise abort on the last data of a cache linefill may not be
detected No fix scheduled 46
ERR003740 ARM/PL310: 752271—Double linefill feature can cause data corruption [i.MX
6Dual/6Quad only] No fix scheduled 47
ERR003741 ARM/PL310: 729815—The “High Priority for SO and Dev reads” feature can cause
Quality of Service issues to cacheable read transactions No fix scheduled 48
ERR003743 ARM/PL310: 754670—A continuous write flow can stall a read targeting the same
memory area No fix scheduled 49
ERR004324 ARM/MP: 761319—Ordering of read accesses to the same memory location may not
be ensured No fix scheduled 50
ERR004325 ARM/MP: 764369—Data or unified cache line maintenance operation by MVA may
not succeed on an Inner Shareable memory region No fix scheduled 51
ERR004326 ARM/MP: 761321—MRC and MCR are not counted in event 0x68 No fix scheduled 53
ERR004327 ARM/MP: 764319—Read accesses to DBGPRSR and DBGOSLSR may generate
an unexpected UNDEF No fix scheduled 54
ERR005175 ARM/MP: 771221—PLD instructions may allocate data in the DataCache regardless
of the Cache Enable bit value No fix scheduled 55
ERR005183 ARM/MP: 771224—Visibility of Debug Enable accessrightstoenable/disable tracing
is not ensured by an ISB No fix scheduled 56
ERR005185 ARM/MP: 771225—Speculative cacheable reads to aborting memory region clear
the internal exclusive monitor, may lead to livelock No fix scheduled 57
ERR005187 ARM/MP: 771223—Parity errors on BTAC and GHB are reported on
PARITYFAIL[7:6], regardless of the Parity Enable bit value No fix scheduled 59
ERR005198 ARM/PL310: 780370—DATAERR, TAGERR, and Tag parity errors are incorrectly
sampled by the eviction buffer, leading to data corruption No fix scheduled 60
ERR005199 ARM/MP: 769419—No automatic Store Buffer drain, visibility of written data requires
an explicit Cache Sync operation [i.MX 6Dual/6Quad Only] No fix scheduled 63
ERR005200 ARM/MP: 765569—Prefetcher can cross 4 KB boundary if offset is programmed with
value 23 No fix scheduled 64
ERR005382 ARM/MP: 775419—PMU event 0x0A (exception return) might count twice the LDM
PC ^ instructions with base address register write-back No fix scheduled 65
ERR005383 ARM/MP: 775420—A data cache maintenance operation that aborts, followed by an
ISB and without any DSB in-between, might lead to deadlock No fix scheduled 66
ERR005385 ARM/MP: 782772—A speculative execution of a Load-Exclusive or Store-Exclusive
instruction after a write to Strongly Ordered memory might deadlock the processor No fix scheduled 67
ERR005386 ARM/MP: 782773—Updating a translation entry to move a page mapping might
erroneously cause an unexpected translation fault No fix scheduled 69
ERR005387 ARM/MP: 782774—A spurious event 0x63, “STREX passed,” can be reported on an
LDREX that is preceded by a write to Strongly Ordered memory region No fix scheduled 71
Table 3. Summary of Silicon Errata (continued)
Errata Name Solution Page

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
NXP Semiconductors 7
ERR006259 ARM: Debug/trace functions (PMU, PTM and ETB) are disabled with absence of
JTAG_TCK clock after POR No fix scheduled 72
ERR007006 ARM/MP:794072-- Short loop including a DMB instruction might cause a denial of
service No fix scheduled 73
ERR007007 ARM/MP: 794073 -- Speculative instruction fetches with MMU disabled might not
comply with architectural requirements No fix scheduled 75
ERR007008 ARM/MP: 794074 --A write request to Uncacheable Shareable memory region might
be executed twice No fix scheduled 76
ERR009604 ARM (CA9): 845369 — Under very rare timing circumstances, transition into
streaming mode might create a data corruption No fix scheduled 78
ERR009605 ARM (CA9): 761320—Full cache line writes to the same memory region from at least
two processors might deadlock the processor No fix scheduled 80
ERR009742 ARM: 795769 - “Write Context ID" event is updated on read access No fix scheduled 82
ERR009743 ARM: 799770 - DBGPRSR Sticky Reset status bit is set to 1 by the CPUdebug reset
instead of by the CPU non-debug reset No fix scheduled 83
ERR009858 ARM/PL310: 796171 When data banking is implemented, data parity errors can be
incorrectly generated No fix scheduled 84
CAAM
ERR004320 CAAM: Three encryption functions may show up as available, even though they are
not No fix scheduled 85
ERR004347 CAAM: False read access error No fix scheduled 86
ERR004348 CAAM: Internal 16 Kb RAM (CAAM) does not support wrapped accesses No fix scheduled 87
ERR005766 CAAM:CAAMcannothandleinterleavedREAD data“beats”returnedbytwodifferent
slaves in the system, in reply to two different AXI-ID accesses No fix scheduled 88
CCM
ERR006223 CCM: Failure to resume from Wait/Stop mode with power gating No fix scheduled 89
ERR007265 CCM: When improper low-power sequence is used, the SoC enters low power mode
before the ARM core executes WFI No fix scheduled 90
ERR009219 CCM: Asynchronous clock switching can cause unpredictable behavior [i.MX
6Dual/6Quad Only] No fix scheduled 91
eCSPI
ERR009165 eCSPI: TXFIFO empty flag glitch can cause the current FIFO transfer to be sent twice No fix scheduled 93
ERR009535 eCSPI: Burst completion by SS signal in slave mode is not functional No fix scheduled 94
ERR009606 eCSPI: In master mode, burst lengths of 32n+1 will transmit incorrect data No fix scheduled 95
EIM
ERR004446 EIM: AUS mode is nonfunctional for devices larger than 32 MB No fix scheduled 96
Table 3. Summary of Silicon Errata (continued)
Errata Name Solution Page

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
8NXPSemiconductors
ERR009218 EIM: Signals fail to drive as outputs during boundary scan test No fix scheduled 97
ENET
ERR004512 ENET: 1 Gb Ethernet MAC (ENET) system limitation No fix scheduled 98
ERR005783 ENET: ENET Status FIFO may overflow due to consecutive short frames No fix scheduled 99
ERR005895 ENET: ENET 1588 channel 2 event capture mode not functional No fix scheduled 100
ERR006358 ENET: Write to Transmit Descriptor Active Register (ENET_TDAR) is ignored No fix scheduled 101
ERR006687 ENET: Only the ENET wake-up interrupt request can wake the system from Wait
mode [i.MX 6Dual/6Quad Only] No fix scheduled 102
ESAI
ERR008000 ESAI: ESAI may encounter channel swap when overrun/underrun occurs No fix scheduled 103
EXSC
ERR004365 EXSC: Exclusive accesses to certain memories are not supported to full AXI
specification No fix scheduled 104
ERR005828 EXSC: Protecting the EIM memory map region causes unpredictable behavior No fix scheduled 105
FlexCAN
ERR005829 FlexCAN: FlexCAN does not transmit a message that is enabled to be transmitted in
a specific moment during the arbitration process No fix scheduled 106
GPMI
ERR008001 GPMI: GPMI does not support the Set Feature command in Toggle mode No fix scheduled 108
GPU
ERR004341 GPU2D: Accessing GPU2D when it is power-gated will cause a deadlock in the
system No fix scheduled 109
ERR005908 GPU2D: Image quality degradation observed for stretch blits when the stretch factor
is exactly an integer [i.MX 6Dual/6Quad Only] No fix scheduled 110
ERR004300 GPU3D: L1 cache performance drop [i.MX 6Dual/6Quad Only] No fix scheduled 111
ERR004484 GPU3D: L1 cache “Write Address Data” pairing error [i.MX 6Dual/6Quad Only] No fix scheduled 112
ERR005216 GPU3D: Black texels in Android App Singularity 3D [i.MX 6Dual/6Quad Only] No fix scheduled 113
HDMI
ERR003744 HDMI: 9000446457—Audio DMA does not generate an interrupt after software stops
DMA transaction No fix scheduled 114
ERR003745 HDMI: 9000440660—Audio DMA fails to stop after ERROR detection No fix scheduled 115
ERR004308 HDMI:8000504668—The arithmeticunitmayget wrong video timing values although
the FC_* registers hold correct values No fix scheduled 116
Table 3. Summary of Silicon Errata (continued)
Errata Name Solution Page

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
NXP Semiconductors 9
ERR004323 HDMI: The DMA burst read transaction address region is limited to 8 KB No fix scheduled 117
ERR004366 HDMI: 9000482480—ARM core read operation returns incorrect data for certain
HDCP registers No fix scheduled 124
ERR005171 HDMI: HDMI Tx audio may have noise due to audio DMA FIFO overflow No fix scheduled 118
ERR005172 HDMI: Under certain circumstances, the HDCP may transmit incorrect Ainfo value,
causing a failure on the receiver side No fix scheduled 119
ERR005173 HDMI: Clarification on HDMI programming procedure to avoid FIFO overflow No fix scheduled 120
ERR005174 HDMI: HDMI AHB Audio DMA stream misalignment on system initialization No fix scheduled 122
I2C
ERR007805 I2C: When the I2C clock speed is configured for 400 kHz, the SCL low period violates
the I2C specification No fix scheduled 126
I/O
ERR004307 I/O: MIPI_HSI, USB_HSIC, and ENET I/O interfaces should not be configured to
Differential input mode No fix scheduled 126
IPU
ERR009623 IPU: IDMAC burst errors when crossing a 4k boundary using NI/PI 420/422 formats
[i.MX 6DualPlus/6QuadPlus Only] No fix scheduled 127
MIPI
ERR004310 MIPI: Glitch or unknown clock frequency on MIPI input clock may occur in case the
CCM source clock is modified No fix scheduled 128
ERR005190 MIPI: CSI2 Data lanes are activated before the HS clock from the CSI Tx side
(camera) starts No fix scheduled 129
ERR005191 MIPI: Corruption of short command packets with Word Count (WC) greater than
16’hFFEE, during video mode transmission by the MIPI Generic Interface No fix scheduled 130
ERR005192 MIPI: Reverse direction long packets with no payload incorrectly issue a CRC error
for MIPI DSI No fix scheduled 131
ERR005193 MIPI: The bits for setting the MIPI DSI video mode cannot be changed on the fly No fix scheduled 132
ERR005194 MIPI: On MIPI DSI, there is a possible corruption of the video packets caused by
overlapping of the current line over the next line, if the configuration is programmed
incorrectly when using the DPI interface
No fix scheduled 133
ERR005195 MIPI: Incorrect blanking packet may be sent by the MIPI DSI interface No fix scheduled 134
ERR005196 MIPI: Error Interrupt generated by the MIPI CSI interface for certain legal packet
types No fix scheduled 135
ERR005197 MIPI: Null and Blanking data packets activate ‘dvalid’ signal No fix scheduled 136
ERR009704 MIPI: CSI-2: CRC error produced in 4-lane configuration No fix scheduled 137
Table 3. Summary of Silicon Errata (continued)
Errata Name Solution Page

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
10 NXPSemiconductors
MLB
ERR004312 MLB: Multi frame per sub-buffer mode is not supported No fix scheduled 138
MMDC
ERR005778 MMDC: DDR Controller’smeasureunitmayreturn an incorrectvaluewhen operating
below 100 MHz No fix scheduled 139
ERR009596 MMDC: ARCR_GUARD bits of MMDC Core AXI Re-ordering Control register
(MMDC_MAARCR) doesn't behave as expected No fix scheduled 140
PCIe
ERR003747 PCIe: 9000436491—Reading the Segmented Buffer Depth Port Logic registers
returns all zeros No fix scheduled 141
ERR003748 PCIe: 9000427578—Root ports with address translation drop inbound requests,
without reporting an error No fix scheduled 142
ERR003749 PCIe: 9000426180—MSI Interrupt Controller Status Register bit not cleared after
being written by software No fix scheduled 143
ERR003751 PCIe: 9000413207—PME Requester ID overwritten when two PMEs are received
consecutively No fix scheduled 144
ERR003753 PCIe: 9000405932—AXI/AHB Bridge Slave does not return a response to an
outbound non-posted request No fix scheduled 145
ERR003754 PCIe: 9000403702—AHB/AXI Bridge Master responds with UR status instead of CA
status for inbound MRd requesting greater than CX_REMOTE_RD_REQ_SIZE No fix scheduled 146
ERR003755 PCIe: 9000402443—Uncorrectable Internal Error Severity register bit has incorrect
default value No fix scheduled 147
ERR003756 PCIe: 9000387484—LTSSM: Software-initiated transitions to Disabled, Hot Reset,
Configuration, or Loopback states sometimes take longer than expected No fix scheduled 148
ERR003757 PCIe: 9000448152—Internal Address Translation Unit (iATU): Inbound Vendor
Defined Message (VDM) ‘ID Match Mode’ is not functional No fix scheduled 149
ERR003758 PCIe: 9000441819—Upstream Port does not transition to Recovery after receiving
TS OSs during “ENTER_L2 negotiation” No fix scheduled 150
ERR003759 PCIe: 9000439510—Internal Address Translation Unit (iATU) can sometimes
overwrite Outbound (Tx) Vendor Messages and MSIs No fix scheduled 151
ERR003760 PCIe: 9000439175—Poisoned Atomic Op requests targeting RTRGT0 receive UR
response instead of CA response No fix scheduled 152
ERR004297 PCIe: 9000336356—Link configuration sometimes proceeds when incorrect TS
Ordered Sets are received No fix scheduled 153
ERR004298 PCIe: 9000471173—Bad DLLP error status checking is too strict No fix scheduled 154
ERR004299 PCIe: 9000493959—L1 ASPM incorrectly entered after link down event during L1
ASPM entry negotiation No fix scheduled 155
ERR004321 PCIe: 9000470913—Power Management Control: Core might enter L0s/L1 before
Retry buffer is empty No fix scheduled 156
Table 3. Summary of Silicon Errata (continued)
Errata Name Solution Page

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
NXP Semiconductors 11
ERR004374 PCIe: 9000487440—TLP sometimes unnecessarily replayed No fix scheduled 158
ERR004489 PCIe: 9000505660—PCIe2 receiver equalizer settings No fix scheduled 159
ERR004490 PCIe: 9000514662—LTSSM delay when moving from L0 to recovery upon receipt of
insufficient TS1 Ordered Sets No fix scheduled 160
ERR004491 PCIe: 9000507633—TLP might be replayed an extra time before core enters
recovery No fix scheduled 162
ERR005184 PCIe: Clock pointers can lose sync during clock rate changes No fix scheduled 163
ERR005186 PCIe: The PCIe Controller Core Does Not Send Enough TS2 Ordered Sets During
Link Retrain And Speed Change No fix scheduled 165
ERR005188 PCIe: The PCIe Controller cannot exit successfully L1 state of LTSSM when the Core
Clock is removed No fix scheduled 166
ERR005189 PCIe: PCIe Gen2/Gen3 Hardware Autonomous Speed Disable Bit In Configuration
Register is not sticky No fix scheduled 167
ERR005723 PCIe: PCIe does not support L2 power down [i.MX 6Dual/6Quad Only] No fix scheduled 168
ERR007554 PCIe: MSI Mask Register Reserved Bits not read-only No fix scheduled. 169
ERR007555 PCIe: iATU - Optional programmable CFG Shift feature for ECAM is not correctly
updating address (9000642041) No fix scheduled 170
ERR007556 PCIe: Core Delays Transition From L0 To Recovery After Receiving Two TS OS And
Erroneous Data (9000597455) No fix scheduled 171
ERR007557 PCIe: Extra FTS sent when Extended Synch bit is set (9000588281) No fix scheduled 172
ERR007559 PCIe: Core sends TS1 with non-PAD lane number too early in
Configuration.Linkwidth.Accept State (9000574708) No fix scheduled 173
ERR007573 PCIe: Link and lane number-match not checked in recovery (9000569433) No fix scheduled 174
ERR007575 PCIe: LTSSM delay when moving from L0 to recovery uponreceipt of insufficient TS1
Ordered Sets (9000514662) No fix scheduled 175
ERR007577 PCIe: DLLP/TLP can be missed on RX path when immediately followed by EIOS
(9000487440) No fix scheduled 176
ERR008587 PCIe: Random link down after warm reset [i.MX 6Dual/6Quad Only] No fix scheduled 177
PRE
ERR009619 PRE: GPU3D, GPU2D and VPU cannot be power-gated if the PRE is in use [i.MX
6DualPlus/6QuadPlus Only] No fix scheduled 178
ERR009624 PRE: ENABLE bit cannot be set in a special case, when the EN_REPEAT bit is set
[i.MX 6DualPlus/6QuadPlus Only] No fix scheduled 179
ROM
ERR007117 ROM: When booting from NAND flash, enfc_clk_root clock is not gated off when
doing the clock source switch [i.MX 6Dual/6Quad Only] Fixed in silicon revision 1.3. 180
ERR007220 ROM: NAND boot may fail due to incorrect Hamming Checking implementation in the
ROM code [i.MX 6Dual/6Quad Only] Fixed in silicon revision 1.3 181
Table 3. Summary of Silicon Errata (continued)
Errata Name Solution Page

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
12 NXPSemiconductors
ERR007926 ROM: 32 kHz internal oscillator timing inaccuracy may affect SD/MMC, NAND, and
OneNAND boot [i.MX 6Dual/6Quad Only] No fix scheduled 182
ERR005645 ROM: Normal SD clock speed (SDR12) not selectable in SD/SDXC boot mode No fix scheduled 184
ERR005768 ROM: In rare cases, secondary image boot flow may not work due to mis-sampling
of the WDOG reset [i.MX 6Dual/6Quad Only] No fix scheduled 185
ERR006282 ROM: ROM code uses nonreset PFDs to generate clocks, which may lead to random
boot failures [i.MX 6Dual/6Quad Only] Fixed in silicon revision 1.3 186
ERR007266 ROM: EIM NOR boot may fail if plug-in is used No fix scheduled 190
ERR008506 ROM: Incorrect NAND BAD Block Management [i.MX 6Dual/6Quad Only] No fix scheduled 191
ERR009678 ROM: SD/EMMC/NAND prematurely times out during boot [i.MX 6Dual/6Quad Only] No fix scheduled 192
SATA
ERR003761 SATA: 9000433864—COMRESET and COMWAKE do not always contain six bursts No fix scheduled 193
ERR003762 SATA: 9000450053—In SDB FIS with N-bit set, non-matching PMP field is not
discarded No fix scheduled 194
ERR003763 SATA: 9000448817—Soft Reset command does not SYNC-escape incoming data
FIS No fix scheduled 195
ERR003764 SATA: 9000447882—ERR_I bit set when PhyRdy goes low during non-data FIS
reception No fix scheduled 196
ERR003765 SATA: 9000447627—Global reset does not clear IS.IPS register bits when P#IS is
non-zero No fix scheduled 197
ERR003766 SATA: 9000446485—phy_partial, phy_slumber incorrectly asserted for a power
mode No fix scheduled 198
ERR003767 SATA: 9000446482—hCccComplete cleared, incorrectly incremented No fix scheduled 199
ERR003769 SATA: 9000445811—Erroneous PRD interrupt assertion No fix scheduled 200
ERR003770 SATA: 9000451535—Hang due to FIFO count change, when FIFO is cleared No fix scheduled 201
ERR003771 SATA: 9000451305—Hang after incoming FIS and soft reset No fix scheduled 202
ERR003772 SATA: 9000451274—Power mode request collision causes assertion of phy_partial,
phy_slumber No fix scheduled 203
ERR003773 SATA: 9000451526—Hang after Soft Reset and PM Request from the Device No fix scheduled 204
ERR007966 SATA:SATA speed negotiation fails after suspend and resume —[i.MX 6Dual/6Quad
Only] No fix scheduled 205
ERR009598 SATA: PRD not flushed from PRD FIFO at command list underflow No fix scheduled 207
SNVS
ERR004367 SNVS: SNVS_LP resets to the power OFF state No fix scheduled 208
SSI
ERR003778 SSI: In AC97, 16-bit mode, received data is shifted by 4-bit locations No fix scheduled 209
Table 3. Summary of Silicon Errata (continued)
Errata Name Solution Page

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
NXP Semiconductors 13
ERR005764 SSI: AC97 receive data may be wrong when clock ratio between external clock to ipg
is higher than 1:8 No fix scheduled 210
ERR008990 SSI: Channel swap in single FIFO mode when an underrun or overrun occurs No fix scheduled 211
USB
ERR004534 USB: Wrong HS disconnection may be generated after resume No fix scheduled 212
ERR006281 USB: Incorrect DP/DN state when only VBUS is applied No fix scheduled 213
ERR006308 USB: Host non-doubleword –aligned buffer address can cause host to hang on OUT
Retry No fix scheduled 214
ERR004535 USB: USB suspend and resume flow clarifications No fix scheduled 215
ERR007881 USB: Timeout error in Device mode No fix scheduled 216
uSDHC
ERR004364 uSDHC: Limitations on uSDHC3 and uSDHC4 clock-gating No fix scheduled 217
ERR004536 uSDHC: ADMA Length Mismatch Error may occur for longer read latencies No fix scheduled 218
VPU
ERR004345 VPU: Wrong interrupt is generated sometimes when context switching to H.264
encoder, during multi-instance No fix scheduled 219
ERR004349 VPU: Cannot decode Sorenson Spark Version 0 bitstream No fix scheduled 220
ERR004361 VPU: VPU does not work in case of smaller chunk size in SSP (streaming pump
processing) No fix scheduled 221
ERR004363 VPU: Causes a macro-block of P-picture decoding error No fix scheduled 222
WDOG
ERR004346 WDOG: WDOG SRS bit requires to be written twice No fix scheduled 223
XTAL
ERR005777 XTAL: In some cases, the 24 MHz oscillator start-up is slow or may fail to start No fix scheduled 224
Table 3. Summary of Silicon Errata (continued)
Errata Name Solution Page

Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
14 NXPSemiconductors
Table 4. Excluded ARM Errata
ARM Errata Reference Title Reason why excluded from this errata
document
743625 A coherent ACP request might interfere with a
non-cacheableSWP/SWPBfromtheprocessor,
Potentially causing deadlock
i.MX6 does not support the ACP (Accelerator
Coherency Port) hence errata not applicable.
754319 A sequence of cancelled Advanced-SIMD or
VFP stores might deadlock Errata was fixed in the Floating Point Unit (FPU) Revision 0x4 which is used across i.MX6, hence
not applicable.
754320 A cancelled Advanced-SIMD or VFP load
multiple of more than 8 beats might deadlock Errata was fixed in the Floating Point Unit (FPU) Revision 0x4 which is used across i.MX6, hence
not applicable.
745320 A Floating Point write following a failed
conditional read might write corrupted data Errata was fixed in the Floating Point Unit (FPU) Revision 0x4 which is used across i.MX6, hence
not applicable.
751469 Overflow in PMU counters may not be detected i.MX6 does not support PMU (Performance
Monitoring Unit) hence this ARM errata is not
applicable.
751475 Parity error may not be reported on full cache
line access (eviction / coherent data transfer /
cp15 clean operations)
i.MX6 does not implement parity hence errata not
applicable.Theparityfeature isdisabledby default
and should not be enabled.
761321 MRC and MCR are not counted in event 0x68 i.MX6 does not support PMU (Performance
Monitoring Unit) hence this ARM errata is not
applicable.
764269 Under very rare circumstances, a sequence of
at least three writes merging in the same 64-bit
address range might cause data corruption
ARM has not managed to reproduce the failure in
actual Silicon and no software workaround
available for this erratum.
791420 Possible denial of service for coherent requests
on a cache line which is continuously written by
a processor
Freescale cannot disclose this errata per ARM
requirements, however software workaround has
been implemented in the Freescale Linux BSP for
this erratum. OS vendors/users must approach
ARM if further information is required.
756420 Instruction Cache parity error reporting on
PARITYFAIL[5:4]outputisonecycleearlierthan
the other PARITY FAIL bits
i.MX6 does not implement parity hence errata not
applicable.Theparityfeature isdisabledby default
and should not be enabled.
732672 An abort on the second part of a double linefill
can cause data corruption on the first part Freescale cannot disclose this errata per ARM requirements, however software workaround has
been implemented in the Freescale Linux BSP for
impacted devices. OS vendors/users must
approach ARM if further information is required.

ERR005852
Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
NXP Semiconductors 15
Description:
Normally, the VDDARM_CAP supply takes only approximately 40 μs to raise to the correct
voltage when exiting from Deep Sleep (DSM) mode, if the LDO is enabled. If the LDO bypass
mode is selected, the VDDARM_CAP supply voltage will drop to approximately 0 V when
entering and when exiting from DSM, even though the VDDARM_IN supply is already stable, the
VDDARM_CAP supply will take about 2 ms to rise to the correct voltage.
Projected Impact:
ARM core might fail to resume.
Workarounds:
The software workaround to prevent this issue it to switch to analog bypass mode (0x1E), prior to
entering DSM, and then, revert to the normal bypass mode, when exiting from DSM.
Proposed Solution:
No fix scheduled
Linux BSP Status:
Software workaround integrated in Linux BSP codebase starting in release imx_3.0.35_4.1.0.
ERR005852 Analog: Transition from Deep Sleep Mode to LDO Bypass Mode may
cause the slow response of the VDDARM_CAP output

ERR003717
Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
16 NXPSemiconductors
Description:
The Global Timer can be programmed to generate an interrupt request to the processor when it
reaches a given programmed value. Due to the erratum, when the Global Timer is programmed not
to use the auto-increment feature, it might generate two interrupt requests instead of one.
Conditions:
The Global Timer Control register is programmed with the following settings:
• Bit[3] = 1’b0 – Global Timer is programmed in “single-shot” mode
• Bit[2] = 1’b1 – Global Timer IRQ generation is enabled
• Bit[1] = 1’b1 – Global Timer value comparison with Comparator registers is enabled
• Bit[0] = 1’b1 – Global Timer count is enabled
With these settings, an IRQ is generated to the processor when the Global Timer value reaches the
value programmed in the Comparator registers.
The Interrupt Handler then performs the following sequence:
1. Read the ICCIAR (Interrupt Acknowledge) register
2. Clear the Global Timer flag
3. Modify the comparator value to set it to a higher value
4. Write the ICCEOIR (End of Interrupt) register
Under these conditions, due to the erratum, the Global Timer might generate a second (spurious)
interrupt request to the processor at the end of this Interrupt Handler sequence.
Projected Impact:
The erratum creates spurious interrupt requests in the system.
Workarounds:
Because the erratum only happens when the Global Timer is programmed in “single-shot” mode,
that is, when it does not use the auto-increment feature, a first possible workaround could be to
program the Global Timer to use the auto-increment feature.
If this solution does not work, a second workaround could be to modify the Interrupt Handler to
avoid the offending sequence. This is achieved by clearing the Global Timer flag after having
incremented the Comparator register value.
Then, the correct code sequence for the Interrupt Handler should look as below:
1. Read the ICCIAR (Interrupt Acknowledge) register
2. Modify the comparator value to set it to a higher value
3. Clear the Global Timer flag
4. Clear the Pending Status information for Interrupt 27 (Global Timer interrupt) in the
Distributor of the Interrupt Controller.
ERR003717 ARM: 740657—Global Timer can send two interrupts for the same
event

ERR003717
Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
NXP Semiconductors 17
5. Write the ICCEOIR (End of Interrupt) register
Proposed Solution:
No fix scheduled
Linux BSP Status:
Software workaround not needed in the BSP. Functionality or mode of operation in which the
erratum may manifest itself is not used. The BSP does not use ARM global timer. The
configuration and logic of the kernel does not make use of the Global Timer. If the Global timer is
used, the workaround documented by ARM should be followed. Due to limitations of this timer
specifically in low power mode operation we do not recommend the use of this ARM Global timer.

ERR003718
Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
18 NXPSemiconductors
Description:
Under very rare conditions, a faulty optimization in the Cortex®-A9 store buffer might lead to data
corruption.
Conditions:
The code sequence which exhibits the failure requires at least five cacheable writes in 64-bit data
chunk:
• Three of the writes must be in the same cache line
• Another write must be in a different cache line
• All of the above four writes hit in the L1 data cache
• A fifth write is required in any of the above two cache lines that fully writes a 64-bit data chunk
With the above code sequence, under very rare circumstances, this fifth write might get corrupted,
with the written data either being lost, or being written in another cache line.
The conditions under which the erratum can occur are extremely rare, and require the coincidence
of multiple events and states in the Cortex-A9 micro-architecture.
As an example: let’s assume A, A’, A”, and A’’’ are all in the same cache line—B and B’ are in
another cache line. The following code sequence might trigger the erratum:
STR A
STR A’
STR A’’
STR B
STR A’’’ (or STR B’)
At the time where the first four STR are in the Cortex-A9 store buffer, and the fifth STR arrives at
a very precise cycle in the Store Buffer input stage, then the fifth STR might not see its cache line
dependency on the previous STR instructions. Because of this, in cases when the cache line A or
Bgetsinvalidated due to a coherentrequestfromanotherCPU,thefifth STR might write in a faulty
cache line, causing data corruption.
An alternative version of the erratum might happen even without a coherent request — In the case
when the fifth STR is a 64-bit write in the same location as one of A, A’, A’’, then the erratum might
also be exhibited. Note that this is a quite uncommon scenario because it requires a first write to a
memory location that is immediately and fully overwritten.
Projected Impact:
When it occurs, this erratum creates a data corruption.
Workarounds:
A software workaround is available for this erratum that requires setting bit[6] in the
undocumented Diagnostic Control register, placed in CP15 c15 0 c0 1.
The bit can be written in Secure state only, with the following Read/Modify/Write code sequence:
ERR003718 ARM: 743622—Faulty logic in the Store Buffer may lead to data
corruption

ERR003718
Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
NXP Semiconductors 19
MRC p15,0,rt,c15,c0,1
ORR rt,rt,#0x40
MCR p15,0,rt,c15,c0,1
When this bit is set, the “fast lookup” optimization in the Store Buffer is disabled, which will
prevent the failure to happen.
Setting this bit has no visible impact on the overall performance or power consumption of the
processor.
Proposed Solution:
No fix scheduled
Linux BSP Status:
Software workaround implemented in Linux BSP codebase (UBOOT) starting in release
imx_3.0.35_4.1.0.

ERR003719
Chip Errata for the i.MX 6Dual/6Quad and i.MX 6DualPlus/6QuadPlus, Rev. 6.1, 06/2016
20 NXPSemiconductors
Description:
Overflow detection logic in the Performance Monitor Counters is faulty, and under certain timing
conditions, the overflow may remain undetected. In this case, the Overflow Flag Status register
(PMOVSR) is not updated as it should, and no interrupt is reported on the corresponding PMUIRQ
line.
It is important to notice that the Cycle counter is not affected by this erratum.
Projected Impact:
PMU overflow detection is not reliable.
Workarounds:
The main workaround for this erratum is to poll the performance counter. The maximum increment
in a single cycle for a given event is 2. Therefore, polling can be infrequent as no counter can
increment by more than 2^32 in fewer than 2 billion cycles.
If the main usage model for performance counters is collecting values over a long period, then
polling can be used to collect values (and reset the counter) rather than waiting for an overflow to
occur. Polling can be done infrequently and overflow avoided.
If the main usage model for performance counters relies on presetting the counter to some value
and waiting for an overflow to occur, then polling can be used to detect when an overflow event
has been missed. An overflow can be determined to have been missed if the unsigned value in the
counter is less than the value preset into the counter. Again, polling can be done infrequently
because of the number of cycles it would need for this check to fail. In the case that the erratum
was triggered and an overflow event was missed, that counter sample can be thrown away or the
true value can be reconstructed.
An alternative workaround is to configure two counters to be triggered by the same event,
staggering their initial count values by 1. This will result in the rollover being triggered by at least
counter.
This alternative workaround works for all Cortex-A9 events but the three following ones, due to
the fact these three events can increment by 2 in a single cycle:
- 0x68 – Instructions coming out of the core renaming stage
- 0x73 – Floating-point instructions
- 0x74 – NEON instructions
For these 3 events, only the first workaround is applicable to fix the defect.
Proposed Solution:
No fix scheduled
Linux BSP Status:
Software workaround is not needed because this erratum will not be encountered in normal device
operation.TheFreescaleLinuxBSPdoes not support this optional profilingfeature.Usersmay add
ERR003719 ARM/MP: 751469 — Overflow in PMU counters may not be detected
