Unpack the Board
• Unpacktheboard.Verifypackage
contentsaccordingtothekitwebsite:
freescale.com/sensortoolbox.
• Assemblethehardwarebyconnecting
adevelopmentboardtotheinterface
board.Thisboardisintendedforuse
withsensortoolboxdevelopment
boards,purchasedseparately.
Moreinformationcanbefoundat
freescale.com/sensortoolbox.
Download Latest Software
• Downloadthelatestversionat
freescale.com/sensortoolbox.
• Allsensortoolboxkitsusethesame
softwareanddriver,sotheinstallonly
needstobedoneonce.Followthe
on-screeninstructionstoinstallthe
communicationdriverforthetool.
Checkbackoccasionallyforsoftware
updates.
Power Up
• PlugintheUSBandturntheboard
onusingthepowerswitch.
• Runthesensortoolboxlinkon
yourdesktop.
• Exploreothersensorkitsat
freescale.com/sensortoolbox.
Sensor Toolbox Xtrinsic MMA865xFC Accelerometers
LFSTBEB865xQuickStartGuide
Freescale’sMMA8652FC(12-bit)andMMA8653FC(10-bit)low-power,low-noise
accelerometershaveuniqueperformanceforsmartphones,smartmobiledevices,
tabletsandmediaplayerapplications.
1
3
Xtrinsic
2
Downloaded from Arrow.com.

Learn more at freescale.com/sensortoolbox
Freescale and the Freescale logo are trademarks of Freescale
Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. Xtrinisic is a trademark of
Freescale Semiconductor, Inc. All other product or service names are the
property of their respective owners. © 2012 Freescale Semiconductor, Inc.
Doc Number: LFSTBEB865xQSG / REV 0
Agile Number: 926-78586 REV A
Quick Start Guide for i.MX50
Sensor Toolbox Xtrinsic MMA865xFC Accelerometers
Application
Button
Freescale
MC9S08QE8CWL
Accelerometer
Socket
Bottom
Top
MMA8652FC
12-bit
Accelerometer
MMA8653FC
10-bit
Accelerometer
