O2 Xda Atom Exec User manual

1
Contents
Chapter 1 Before using your O2Xda Atom Exec 8
1.1 What’s in the box? 8
1.2 Familiarizing yourself with your Xda Atom Exec 9
1.3 Features 11
1.4 Key functions 12
1.5 Display information 13
Chapter 2 Getting started 26
2.1 Inserting the battery & SIM card 26
2.2 SIM card 27
2.3 Battery 27
2.4 Switching the device on or off 29
2.5 Screen tapping & calibration 29
2.6 Screen Orientation 30
2.7 Entering information 30
2.8 Recording a message 34
2.9 Data backup 35

2
2.10 Memory expansion 35
2.11 Resetting your Xda Atom Exec 35
2.12 Power management 36
Chapter 3 Synchronization 38
3.1 About synchronization 38
3.2 Installing ActiveSync 39
3.3 Choosing your connection 40
3.4 Synchronizing information 41
3.5 ActiveSync Errors 44
Chapter 4 Getting connected 46
4.1 Making a connection 46
4.2 Connecting to the Internet 60
Chapter 5 Basic phone functions 62
5.1 Making a call 65
5.2 Ending a call 68
5.3 Receiving/Ignoring a call 68
5.4 International calls 68

3
5.5 Emergency calls 69
5.6 In-call options 69
5.7 Contact information 71
5.8 Device security 74
Chapter 6 Messaging 78
6.1 Text 79
6.2 Multimedia messages (MMS) 84
6.3 Voicemail 92
6.4 E-mail 93
6.5 Pocket MSN 103
Chapter 7 Camera 106
7.1 Capture mode 107
7.2 Setup menu 110
7.3 Photo Album 113
7.4 View mode 115
7.5 Edit mode 118

4
Chapter 8 O2MediaPlus & Equalizer 126
8.1 My Radio 128
8.2 My Music 130
8.3 My Pictures 132
8.4 My Videos 133
8.5 My Settings 134
8.6 Equalizer 138
Chapter 9 Windows mobile applications 142
9.1 Outlook 142
9.2 Word Mobile 149
9.3 Excel Mobile 150
9.4 PowerPoint Mobile 151
9.5 Pictures & Videos 153
9.6 Calculator 154
9.7 Games 154
9.8 File Explorer 155
9.9 Searching for Files 155

5
Chapter 10 Applications 158
10.1 O2Connect 158
10.2 O2SMS Plus 160
10.3 ClearVue PDF 162
10.4 JAVA Midlet 163
Chapter 11 Settings 166
11.1 Personal settings 167
11.2 System settings 176
11.3 Connection settings 178
Chapter 12 Managing your Xda Atom Exec 180
12.1 Self Diagnostics 180
12.2 Auto-Configurator 180
12.3 Setup Wizard 181
12.4 Download Agent 182
12.5 Installing my own applications 182
12.6 AutoInstaller 184

6
Chapter 13 Don’t panic 186
13.1 In plain English 186
13.2 Troubleshooting 187
13.3 Vital statistics 188
Chapter 14 The important safety bit at the back 190
14.1 Safety information 190
14.2 Phone care 190
14.3 Driving safety 192
14.4 Electronic devices 192
14.5 Other safety guidelines 193
14.6 Cautions 194
14.7 About this guide 194
Index 195

Chapter 1
Before using your O2Xda Atom Exec
1.1 What’s in the box?
1.2 Familiarizing yourself with your Xda Atom Exec
1.3 Features
1.4 Key functions
1.5 Display information

8
1
Before using your O2Xda Atom Exec
1. Before using your O2Xda Atom Exec
1.1 What’s in the box?
Thank you for selecting the O2Xda Atom Exec. Please check if your package comes with the
following items. If any of them is missing, please contact your retailer.
• Xda Atom Exec – your
Windows Mobile-based
Pocket PC phone
• Universal AC adapter with
four plugs for different
countries
• Companion CD
• Warranty Card
,)-)4%$7!22!.49 34!4%-%.4
ڶૻঅᢞᜢࣔ஼
0%2.9!4!!.*!-).!.4%2"!4!3
BAÛO HAØNH COÙ GIÔÙI HAÏN
ΩϭΪ˰˰˰˰˰˰˰˰˰Τ˰˰˰ϣ ϥΎ˰Ϥ˰˰˰˰˰˰˰ο
• Quick Start Guide
• User Manual
• Additional Stylus
• USB cable
• High quality stereo
wired headset
• Battery

9
1
Before using your O2Xda Atom Exec
1.2 Familiarizing yourself with your Xda Atom Exec












No. Item Description
1 Volume Press up/down to increase/decrease the volume.
2 Talk/Send Press to make or receive a call.
3 Windows Start menu Press to bring up the Start menu.
4 Stereo speakers Instead of using earphones, you can play sounds or music through
the built-in stereo speakers.
5 Notification LEDs Indicates charging, GSM/GPRS status, Bluetooth, WiFi and
notification for other phone events (e.g. message arrival).
6 Touch screen Use the stylus or other pointed objects to select items on the
screen.
7 Navigation pad
Press to move up/down and right/left through any of the drop-down
menus or program instructions; confirm your selection by pressing
the center key (See 1.4 Keypad functions).
8 End Press to end a call.
9 Messaging Quick access key to Messaging service to send SMS, MMS and Email.
10 Infrared port Enables you to exchange files or data with other devices without
cables or wires.
11 Record Press and hold to record a voice note. Press and release
immediately to access Notes.
12 Camera Press the button to launch Camera.

10
1
Before using your O2Xda Atom Exec




  
 
 
No. Item Description
13 Camera lens The CMOS camera supports 2-Megapixel color.
14 Self-portrait mirror The preview mirror for self-portrait.
15 Flash light White LED strobe flash.
16 Battery cover Push and slide out the battery cover to replace the Li-ion battery.
17 Stylus & stylus holder The stylus slot holds your stylus when not in use.
18 Power Press to turn your Xda Atom Exec on/off.
19 Mini SD card slot Insert Mini SD card here. This is an optional accessory. For more
information, please see 2.10 Memory Expansion.
20 Strap hole For tying on a strap.
21 Soft reset
Press here with the stylus to soft reset your Xda Atom Exec. For
information about hard reset, please see 2.11 Resetting your Xda
Atom Exec.
22 Mini-USB connector Use this connector to synchronize information with your desktop
PC, transmit data or recharge the battery.
23 Earphone plug Plug in the stereo headset and listen to audio files or use the
phone’s handsfree kit.

11
1
Before using your O2Xda Atom Exec
1.3 Features
Like a standard cell phone, your Xda Atom Exec supports basic dialing features. However,
it also integrates Personal Digital Assistant (PDA) capability. The following section provides
more information about the phone’s features:
• Touchscreen: 2.7” TFT LCD display with 65536 colors effective. (Hardware support 262K
colors).
• 5-way navigation key.
• Windows Start menu key and O2MediaPlus key.
• Stereo speaker (with receiver) & Omnidirectional mono microphone.
• Mini-USB connector for connection and battery charging.
• Camera: 2 Megapixels.
• Connections: IrDA, Bluetooth, and Wireless LAN.
• Microsoft Windows Mobile 5.0: Pocket MSN, Pocket Outlook, Pocket Explorer, and Office
tools (Word, Excel, and PowerPoint). Also features Windows Media Player 10, Terminal
Service Client, Pictures & Videos, calculator, games, ActiveSync, and File Explorer.
• O2programs: O2connect, O2SMS Plus, O2Plus, O2Phone Plus, O2AutoInstaller and O2
MediaPlus.
• Other programs: FM Radio, Java, Equalizer DirectShow plug-in, AutoConfigurator, Setup
Wizard, Self Diagnostics, GPRS Monitor, and ClearVue PDF viewer.

12
1
Before using your O2Xda Atom Exec
1.4 Key functions
Key Description
Scroll up or move the cursor up the screen.
Scroll down or move the cursor down the screen.
Move the cursor to the right.
Move the cursor to the left.
Select highlighted icon.
Pick up calls and make new calls.
Hang up calls or press and immediately release to return to the Today screen.
Bring up the program list.
Access Messaging Service.

13
1
Before using your O2Xda Atom Exec
1.5 Display information
The screen displays the following information:
Start menu Status & icon area
Main
Display
Command
bar
Pop-up
menu
Windows Start menu
Tap on the Windows Start menu on the top left of
the screen to bring up a menu. To return to the
Today screen at any time, Tap Start > Today.
Status & icon area
This area shows your current mode, such as
Phone mode or MSN Sign In mode. The rest of
the area displays notification icons such as time,
signal strength, message arrival, etc.
Main Display
Depending on the current mode or program, this
area shows the major features of the mode. On
the Today screen, this area contains shortcuts to
certain programs. To change the Today screen
settings, tap Start > Settings > Today.
Command bar
Depending on the mode, this area contains
different features such as input panel and
commands to create or edit a file.
Pop-up menu
This feature allows you to quickly access an
item. To access a pop-up menu, simply tap the
icon on the screen and tap again to perform
an action. To cancel it, tap other places on the
screen.

14
1
Before using your O2Xda Atom Exec
Start menu area
Tap Start to bring up a list of menu options.
No. Description
1 Quick access to a program.
2 Recently accessed programs.
3Access program folder. Please refer to the following Programs table for a detailed
program list.
4 Device settings. Please refer to the following Settings table for a detailed setting list.
5 Help information.

15
1
Before using your O2Xda Atom Exec
Programs
Your Xda Atom Exec contains a list of programs, allowing you to get the most out of your
phone.
Icons Programs Description
Games Provides games such as Bubblebreaker and Solitaire.
ActiveSync Synchronizes information between your Xda Atom Exec and
a PC.
Auto Configurator Configures your network operator setting.
Calculator Performs mathematical calculations.
Camera Takes photos and shoot video clips.
ClearVue PDF Supports viewing of PDF files.
CodeWallet Pro 5 Holds your secret financial numbers/passwords (Option to
install in O2AutoInstaller).
Download Agent Manages your downloaded content for installation.
Equalizer Edits your sound profile to play back songs.
Excel Mobile Creates, views and edits Excel files.
File Explorer Views all the files on your Xda Atom Exec.
FM Radio Enables you to listen to the radio.
GPRS Monitor Keeps track of your GPRS daily traffic.
Java Installs and run your Java applications.

16
1
Before using your O2Xda Atom Exec
Icons Programs Description
Jeyo SMS Backup Backs up and restores SMS messages (Option to install in O2
AutoInstaller).
Modem Link Links your Xda Atom Exec to a modem.
Notes Creates notes, drawings, and recordings manually or by typing.
O2AutoInstaller User can choose to install O2selected programs.
O2Connect Connect to the O2website and downloads the latest software
updates.
O2MediaPlus
Integrates Windows MediaPlayer with Radio and Pictures &
Photos programs. An outstanding integrated interface for quick
access.
O2Phone Plus Features smart dialing and a block list (Option to install in O2
AutoInstaller).
O2SMS Plus Besides SMS messaging services, also provides chat and
vCard sending features.
Photo Album Views your photos and videos on your Xda Atom Exec.
Photo Editor Edits your photos on your Xda Atom Exec.
Pictures & Videos Views your images and videos.
Pocket MSN Access for MSN services.
PowerPoint
Mobile Views PowerPoint files on your Xda Atom Exec.
Search Searches for a program or file on your Xda Atom Exec.
Self Diagnostics Runs diagnostics to test your system.

17
1
Before using your O2Xda Atom Exec
Icons Programs Description
Setup Wizard Sets up your personal information.
SIM Contacts Copies Contacts on your SIM card to your Xda Atom Exec.
Tasks Keeps track of your appointments and creates meeting
requests.
Terminal Service Allows you to connect to a defined terminal server.
Voice Speed Dial Records a voice speed dial.
Word Mobile Creates, views and edits Word files.
WorldMate
Contains handy traveling information such as time zones, area
codes, currency conversions and clothing sizes (Option to
install in O2AutoInstaller).

18
1
Before using your O2Xda Atom Exec
Settings menu
The Settings menu lists a range of different applications.
Personal
Icons Settings Description
Buttons Assigns an application program to a hardware button.
Input Sets up the input method option of your Xda Atom Exec.
Lock Restricts access to your Xda Atom Exec and prevents
unauthorized use.
Menus Customizes the Start menu list.
MSN Options Provides complete MSN settings such as passwords, Hotmail
account, and Messenger.
Owner Information Displays and sets your personal information.
Phone Configures your Xda Atom Exec settings.
Sounds &
Notifications Customizes the notification type, event and volume.
Today Arranges the appearance and items displayed on the Today
screen.
Voice Speed Dial Manages voice tags for contacts or applications.

19
1
Before using your O2Xda Atom Exec
System
Icons Settings Description
About Shows important information relating to your Xda Atom Exec.
Backlight Configures the backlight settings and adjusts the brightness
level to save power.
Certificates Information about the certificate issuer and expiration date.
Clock & Alarms Sets the time and alarm.
Error Reporting Reports your system errors to the Microsoft help center.
GPS Configures GPS settings.
Memory Displays the memory allocation status and the programs
currently running.
Power Displays battery status and settings.
Regional Settings Customizes formats and settings for the region you use.
Remove Programs Removes programs from your Xda Atom Exec.
Screen Sets orientation of your screen and recalibrates for
alignment.
System Info Displays your system information.

20
1
Before using your O2Xda Atom Exec
Connections
Icons Settings Description
Band Switch
Selects a different frequency band.
The changing of band selection from Automatic to any other
value may affect the ability of your handset to operate at
its optimal level and incorrect band selection may result in
reception failure.
Beam Sets your Xda Atom Exec to receive or disables IrDA signals.
Bluetooth Sets up Bluetooth connection.
Cell Broadcast
Setting
Receives broadcast channel information and news from your
service provider (please check with your service provider for
this service).
Connections Configures connection settings.
CSD Line Type Sets up CSD line type and connection element.
GPRS Setting Selects the GPRS authentication method.
Network Cards Configures the network adapters.
Wi-Fi Utility Connects with other devices via Wireless LAN.
Wireless Manager Activates phone, GPRS, Bluetooth and Wireless
LAN.
