Oase Profi Clear Premium Compact L US User manual

Profi Clear Premium Compact L US

--
2
A
ProfiClear0239

--
3
B
ProfiClear0243

--
4
C
ProfiClear0279
D
ProfiClear0164

--
5
E
ProfiClear0129
F
ProfiClear0130

--
6
G
ProfiClear0244
H
ProfiClear0245
I
ProfiClear0169

--
7
J
ProfiClear0240
K
ProfiClear0280

--
8
L
EGC0009
M
EGC0003
N
ProfiClear0134

--
9
O
P
PrifiClear0135
Q
ProfiClear0041

--
10
R
ProfiClear0137
S
ProfiClear0138

--
11
T
U
ProfiClear0140
ProfiClear0141
V
ProfiClear0139

-EN -
12
-EN -
Translation of the original Operating Instructions
EN
WARNING
WARNING
►This unit can be used by children aged 8 and above and by persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they
are supervised or have been instructed on how to use the unit in a safe way and they
understand the hazards involved.
►Do not allow children to play with the unit.
►Only allow children to carry out cleaning and user maintenance under supervision.
►Ensure that the unit is fused for a rated fault current of max. 30 mA by means of a
fault current protection device.
►Only connect the unit if the electrical data of the unit and the power supply
correspond. The unit data is to be found on the unit type plate, on the packaging or
in this manual.
►Possible death or severe injury from electrocution! Before reaching into the water,
disconnect all electrical units in the water from the mains.
►A damaged connection cable cannot be replaced. Dispose of the unit.

-EN -
Questions, problems, missing parts?
Before returning to your retailer, call us at 1-866-627-3435, 8 a.m.-6 p.m., EST, Monday-Friday, or email
us at [e-mail]. Or visit our website at www.oase-livingwater.com
13
Table of Contents
1Information about this operating manual...........................................................................................15
1.1 Warnings used in these instructions .........................................................................................15
1.2 Cross-references used in these instructions.............................................................................15
2Safety information .............................................................................................................................16
2.1 Electrical connection .................................................................................................................16
2.2 Danger for persons with pacemakers .......................................................................................16
2.3 Safe operation...........................................................................................................................16
3Product Description...........................................................................................................................17
3.1 Intended use .............................................................................................................................17
3.2 Unit configuration ......................................................................................................................18
3.3 Function description..................................................................................................................19
3.4 Easy Garden Control System (EGC) ........................................................................................19
4Installation and connection................................................................................................................20
4.1 Transporting the container........................................................................................................20
4.2 Fitting the filter container...........................................................................................................21
4.3 Connecting the drum filter.........................................................................................................22
4.3.1 Information regarding pipes..........................................................................................22
4.3.2 Connecting the inlet ......................................................................................................22
4.3.3 Fitting the UVC clarifier.................................................................................................23
4.3.4 Connecting the coarse dirt outlet..................................................................................23
4.3.5 Connecting the dirt outlet..............................................................................................23
4.4 Connecting the control system with EGC box ..........................................................................24
4.4.1 Connecting the control system .....................................................................................24
4.4.2 Connecting the EGC box..............................................................................................24
4.4.3 Connecting an additional EGC compatible unit............................................................24
4.5 Installing the control system with EGC box ..............................................................................25
4.6 Installing the capacitor box .......................................................................................................25
4.7 Connecting the pond aerator ....................................................................................................25
5Commissioning/start-up ....................................................................................................................26
5.1 Order of starting up steps .........................................................................................................27
5.1.1 Setting the level detection device.................................................................................28
6Operation...........................................................................................................................................29
6.1 Control system overview...........................................................................................................29
6.2 Switching ON/OFF ....................................................................................................................29
6.3 Operating modes ......................................................................................................................30
6.4 Manual cleaning ........................................................................................................................30
6.5 Settings in the menus ...............................................................................................................30
6.5.1 CL: Cleaning time "Cleaning" .........................................................................................30
6.5.2 EC: Extended cleaning time "Extra Cleaning"................................................................31
6.5.3 In: Time-dependent cleaning "Interval" .........................................................................31
6.5.4 E7: Pump status detection .............................................................................................32
6.6 Reading out the number of cleaning cycles..............................................................................32
6.6.1 Cleaning cycles in 24 hours..........................................................................................32
6.6.2 Total cleaning cycles ....................................................................................................33
6.7 Loading default settings ............................................................................................................33
6.8 System messages.....................................................................................................................34
7Remedy of faults ...............................................................................................................................36

-EN -
14
8Maintenance and cleaning ............................................................................................................... 38
8.1 Cleaning the device ................................................................................................................. 38
8.2 Regular tasks ........................................................................................................................... 38
8.3 Cleaning the entire filter system............................................................................................... 38
8.4 Cleaning the rinsing device...................................................................................................... 39
8.5Cleaning the screen elements ................................................................................................. 39
8.5.1 Removing/fitting a screen element .............................................................................. 39
8.5.2 Decalcifying the screen elements ................................................................................ 39
8.6 Removing/fitting the filter drum ................................................................................................ 40
8.7 Cleaning the rinsing pump ....................................................................................................... 40
8.8 Replacing the rinsing pump ..................................................................................................... 40
8.9 Replace the aerator rod ........................................................................................................... 41
9Storage/overwintering ...................................................................................................................... 41
10 Wear parts........................................................................................................................................ 41
11 Disposal............................................................................................................................................ 41
12 Technical data .................................................................................................................................. 42
13 Symbols on the unit.......................................................................................................................... 43

-EN -
Questions, problems, missing parts?
Before returning to your retailer, call us at 1-866-627-3435, 8 a.m.-6 p.m., EST, Monday-Friday, or email
us at [e-mail]. Or visit our website at www.oase-livingwater.com
15
REMINDER
CALL 1-866-627-3435
BEFORE RETURNING TO STORE.
Questi on s, pr oblem s, m issi ng parts ?
Befor e re tur ning t o yo ur re tail er, c all us at 1-866-6 27-34 35, 8 a.m .-6 p.m. , ES T, M onday -Fri day , or emai l
us at custom er car e@ oas e-liv ing wat er.c om. Or vis it o ur we bsit e at www .oas e-liv ing w ater .com
1 Information about this operating manual
You made a good choice with the purchase of this product ProfiClear Premium Compact-L EGC USA.
Prior to commissioning the unit, please read the instructions of use carefully and fully familiarise yourself
with the unit. Ensure that all work on and with this unit is only carried out in accordance with these
instructions.
Adhere to the safety information for the correct and safe use of the unit.
Keep these instructions in a safe place! Please also hand over the instructions when passing the unit on
to a new owner.
1.1 Warnings used in these instructions
The warning information is categorised by signal words, which indicate the extent of the hazard.
WARNING
Indicates a possibly dangerous situation, which could lead to death or severe injuries, if not avoided.
CAUTION
Indicates a possibly dangerous situation, which could lead to medium or minor injuries, if not avoided.
NOTE
Indicates a possibly dangerous situation, which could lead to damage to property or the environment, if
not avoided.
TIP
Useful tip.
1.2 Cross-references used in these instructions
A reference to a figure, e.g. figure A.
→Reference to another section.

-EN -
16
2 Safety information
2.1 Electrical connection
►Electrical installations must meet the national regulations and may only be carried out by a qualified
electrician.
►A person is regarded as a qualified electrician if, due to his/her vocational education, knowledge and
experience, he or she is capable of and authorised to judge and carry out the work commissioned to
him/her. This also includes the recognition of possible hazards and the adherence to the pertinent
regional and national standards, rules and regulations.
►For your own safety, please consult a qualified electrician.
►Switch off all units in the aquarium or disconnect the power plugs of all units before reaching into the
water.
►Only connect the unit to a correctly fitted socket.
►Extension cables and power distributors (e.g. outlet strips) must be suitable for outdoor use (splash-
proof).
►Protect the plug connection from moisture.
2.2 Danger for persons with pacemakers
►The impeller unit in the pump contains a magnet with a strong magnetic field that may affect the
operation of pacemakers or implantable cardioverter defibrillators (ICDs). Maintain a distance of at
least 8 in (0.2 m) between the implanted device and the magnet.
2.3 Safe operation
►Never operate the unit if the housing is defective!
►Never operate the unit if an electrical cable is defective!
►Never carry or pull the unit by the electrical cable.
►Route cables such that they are protected from damage and do not present a tripping hazard.
►Never carry out technical changes to the unit.
►Only carry out work on the unit that is described in this manual. If problems cannot be overcome,
please contact an authorised customer service point or, if in doubt, the manufacturer.
►Only use original spare parts and accessories for the unit.
►Disconnect the unit from the power supply during thunderstorms.
►Overvoltage in the mains could lead to operating malfunctions of the unit. For information, please refer
to chapter "Remedy of faults".
►Do not breath in the spray from the rinsing device. The spray may contain harmful bacteria. When the
container cover is lifted up, the rinsing device continues operating.

-EN -
Questions, problems, missing parts?
Before returning to your retailer, call us at 1-866-627-3435, 8 a.m.-6 p.m., EST, Monday-Friday, or email
us at [e-mail]. Or visit our website at www.oase-livingwater.com
17
3 Product Description
A
The filter system must be installed above the water level of the pond. A filter pump pumps the dirty pond
water out of the pond into the filter system. The clean water is returned to the pond through a pipe via
gravity.
Advantages of the pump fed system:
►Minimal installation work required
►System can be easily extended
►Simple upstream connection of UVC clarifiers.
►Perfectly tailored to the AquaMax Eco Premium filter pump from OASE
3.1 Intended use
Only use the product described in this manual as follows:
►For cleaning garden ponds.
►Operate in accordance with instructions. (→ Technical data)
►Use for private purposes only.
The following restrictions apply to the unit:
►Only operate with water at a water temperature of 39 … 95 °F (+4 … +35 °C).
►Never use the unit with fluids other than water.
►Not suitable for salt water.
►Never run the unit without water.
►Do not use in conjunction with chemicals, foodstuff, easily flammable or explosive substances.

-EN -
18
3.2 Unit configuration
C
Description
1
Container cover
2
Signal box with level detection device (3) and temperature probe (7)
•The signal box is connected to the control system (30, 32)
3
Level detection device
•Signals the water level in the filter system
4
Rollers for guiding the filter drum
6
Filter drum with 8 screen elements
•Screen elements for coarse dirt down to 60 µm in size, 30 + 150 µm also available as an option
7
Temperature probe
•monitors the water temperature
8
Air hose ∅⅜in (∅9 mm)
9
Hel-X 13 biomedia in Moving Bed filter chamber
10
2 × outlet ∅4 in (DN 110)
11
Aerator rod
12
Meshed tube
•Prevents the Hel-X- biomedia from being flushed out
13
Rinsing pump for supplying the rinsing device (24)
14
1 × dirt outlet with slide valve ∅3 in (DN 75)
15
2 × adapter, 2 × 30° inlet bend with union nut
For connection of UVC clarifier Bitron to ∅1½ in (∅38 mm) connections (18)
16
Connection set for filter pumps
•1 × hose connector ∅2 in (∅50 mm), 1 × union nut for hose connector, 1 × hose clip ∅1.6 … 2.3 in
(∅40 … 60 mm), 1 × flat gasket 2.2 × 1.7 × 0.1 in (56 × 43 × 3 mm)
17
1 × inlet ∅2 in (∅50 mm)
•For connecting a filter pump
18
2 × inlet ∅1½ in (∅38 mm), closed with sealing plugs
•For connecting an optional UVC clarifier Bitron
20
1 × optional inlet ∅2 in (∅50 mm)
•Must be cut out, if required (connection not included in the scope of delivery)
21
1 × coarse dirt outlet ∅4 in (DN 110)
22
Drum motor for filter drum
•The motor is connected to the control system (30, 31)
23
Dirt channel
•Collects the coarse dirt and rinsing water from the screen elements (6)
24
Rinsing device
•Sprays water at high pressure onto the screen elements (6) to rinse off the coarse dirt
25
Grease for the drum seal
27
Transition piece ∅⅜in to ∅⅛in (∅9 mm to ∅4 mm)
28
Y piece
29
2 × cable binder for fastening the air hoses to the Y piece
30
Control system with EGC box
•Allows integration with cables into an EGC network.
31
Plug for connecting the drum motor
32
Socket for connecting the signal box
33
Mains connection cable
34
Connector for rinsing pump
35
Fuse holder
•Fuse protection of the control system with safety fuse 5 × 20 mm, T16 A, 250 V
36
2 x cap, cap nut for fastening the EGC box
•Required for mounting the EGC box on the container wall
37
Capacitor box for the rinsing pump
38
Plug for connecting the control system (34)
39
Plug for connecting the rinsing pump

-EN -
Questions, problems, missing parts?
Before returning to your retailer, call us at 1-866-627-3435, 8 a.m.-6 p.m., EST, Monday-Friday, or email
us at [e-mail]. Or visit our website at www.oase-livingwater.com
19
3.3 Function description
ProfiClear Premium Compact combines the removal of coarse dirt particles and biological filtration in one
unit. Screens separate all types of dirt particles before the water reaches the biological filtration. By
separating the suspended solids, the filter removes most of the nutrient matter from the water. Following
this mechanical filtration, the Hel-X biomedia in the moving bed system carry out the biological filtration of
the pond water.
The control system with an integrated micro-controller system automatically controls and monitors the
filtration process. The automatic self-cleaning function can be individually adjusted to meet the user's
requirements.
Hel-X bio-elements ensure the effective break-down of nutrients and contaminants in the water. Over the
course of time, the surface of the bio-elements is colonised by bacteria responsible for nitrification and
denitrification. They clean the water before it leaves the container. The fluidized bed process (action of
the water flow and oxygen supply) and the bypass technology ensure optimum movement of the Hel-X
bio-elements even at high flow rates. The biological system is self-cleaning and does not need additional
maintenance.
15.85 gal (60 l) of Hel-X biomedia are able to break down the nutrients of approx. 14.4 oz (408 g) of
fish food per day, given optimum conditions. If required, this can be increased to 21.0 gal (80 l) or
22.5 gal (85 l), i.e. 19.2 oz/day (544 g/day) or 20.4 oz/day (578 g/day).
The development of the micro-organisms in the filter takes several days. It can be accelerated by adding
biological starter bacteria.
BioKick contains millions of active micro-organisms. They start cleaning the water immediately. The
biology in the filter is fully developed within only a few weeks.
Nitrification is the process by which ammonia/ammonium and nitrite are removed from the water by
special bacteria. These substances can build up in the water, for example as a result of fish food and fish
excrement. Ammonia is particularly toxic for fish.
Nitrification takes place in two steps. In the first step, the bacteria convert the ammonia/ammonium into
nitrite. In the second step, other bacteria convert this nitrite into nitrate, which although non-toxic, promotes
the growth of algae. Both steps use oxygen that is taken from the water.
Denitrification is the process by which nitrate is broken down to gaseous nitrogen. In the event of a low
oxygen content, the bacteria use the nitrate nitrogen as a source of oxygen and convert it into atmospheric
nitrogen. Atmospheric nitrogen cannot be used by algae and aquatic plants.
3.4 Easy Garden Control System (EGC)
This product can communicate with the Easy Garden Control-System (EGC). EGC allows convenient
control in the garden and pond via smartphone or tablet, and ensures maximum convenience and
reliability. Information about EGC and the possibilities it offers can be found at www.oase-
livingwater.com/na/egc.

-EN -
20
4 Installation and connection
WARNING
Electrical current may cause death or severe injuries.
►Ensure that the unit is installed in a flood protected position at a distance of at least 6.6 ft (2 m) from
the water.
CAUTION
Risk of injury due to sharp-edged components.
►Proceed with caution during any work on the filter container to prevent injuries caused by sharp-edged
components.
NOTE
If the planned installation deviates significantly from the recommendations contained in this manual:
►Have your specialist retailer check whether all technical specifications were adhered to. This is crucial
for a problem-free operation.
4.1 Transporting the container
WARNING
Due to the high weight of the unit, spinal injuries or crushing of limbs is possible when carrying the unit.
The unit weighs more than 55 lb (25 kg). (→ Technical data)
►Have a minimum of 4 persons carry the container on the handles to avoid spinal injuries.
►Protect limbs from crushing.
►Do not transport the unit when it is filled.
D
The filter container has four handles for carrying. Do not use any other carrying or transport aids (e.g.
transport by crane).
