Oase AquaMax Eco Classic Series User manual

31164/01-15
Máy bơm AquaMax Eco Classic
2500/3500/5500/8500/11500/14500/17500
31164 GAW_AquaMax_Eco_Classic_A5_end_. 22.01.15 08:30 Seite 2
EN Operating Instructions
VI Hướng dẫn vận hành

--
2
Máy bơm AquaMax Eco Classic 2500
Máy bơm AquaMax Eco Classic 3500/5500/8500/11500/14500/17500

--
3
Máy bơm AquaMax Eco Classic 3500/5500/8500/11500/14500/17500
Tối đa 90 độ

--
4
Máy bơm AquaMax Eco Classic 2500
Máy bơm AquaMax Eco Classic 3500/5500/8500/11500/14500/17500
Tối đa 90 độ
Tối đa 90 độ

-EN -
5
-EN -
Translation of the original Operating Instructions
WARNING
•This unit can be used by children aged 8 and above and by per-
sons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they are supervised or have been
instructed on how to use the unit in a safe way and they understand
the hazards involved.
•Do not allow children to play with the unit.
•Only allow children to carry out cleaning and user maintenance un-
der supervision.
•Ensure that the unit is fused for a rated fault current of max. 30 mA
by means of a fault current protection device.
•Only connect the unit if the electrical data of the unit and the power
supply correspond. The unit data is to be found on the unit type plate,
on the packaging or in this manual.
•Possible death or severe injury from electrocution! Before reaching
into the water, always disconnect all units in the water that have a
voltage of >12 V AC or >30 V DC from the power supply.
•Only operate the unit if no persons are in the water.
•Do not use the unit if electrical cables or housings are damaged.
•A damaged connection cable cannot be replaced. Dispose of the
unit.
Safety information
Correct electrical installation
•Electrical installations must meet the national regulations and may only be carried out by a qualified electrician.
•A person is regarded as a qualified electrician if, due to his/her vocational education, knowledge and experience, he
or she is capable of and authorised to judge and carry out the work commissioned to him/her. This also includes the
recognition of possible hazards and the adherence to the pertinent regional and national standards, rules and regula-
tions.
•For your own safety, please consult a qualified electrician.
•Extension cables and power distributors (e.g. outlet strips) must be suitable for outdoor use (splash-proof).
•Protect the plug connection from moisture.
•Only connect the unit to a correctly fitted socket.

-EN -
6
Safe operation
•The impeller unit in the pump contains a magnet with a strong magnetic field that may affect the operation of pace-
makers or implantable cardioverter defibrillators (ICDs). Always keep magnets at least 0.2 m away from implanted
devices.
•Never carry or pull the unit by the electrical cable.
•Route cables such that they are protected from damage and do not present a tripping hazard.
•Never carry out technical changes to the unit.
•Only carry out work on the unit that is described in this manual. If problems cannot be overcome, please contact an
authorised customer service point or, if in doubt, the manufacturer.
•Only use original spare parts and accessories for the unit.
Information about these operating instructions
Welcome to OASE Living Water. You made a good choice with the purchase of this product AquaMax Eco Classic
2500/3500/5500/8500/11500/14500/17500.
Prior to commissioning the unit, please read the instructions of use carefully and fully familiarise yourself with the unit.
Ensure that all work on and with this unit is only carried out in accordance with these instructions.
Adhere to the safety information for the correct and safe use of the unit.
Keep these instructions in a safe place! Please also hand over the instructions when passing the unit on to a new
owner.
Symbols used in these instructions
Warnings
The warning information is categorised by signal words, which indicate the extent of the hazard.
WARNING
•Indicates a possibly hazardous situation.
•Non-observance may lead to death or serious injuries.
CAUTION
•Indicates a possibly hazardous situation.
•Non-observance may lead to slight or minor injuries.
NOTE
Information for the purpose of clarification or for preventing possible damage to assets or to the environment.
Additional information
A Reference to a figure, e.g. Fig. A.
→Reference to another section.

-EN -
7
Intended use
AquaMax Eco Classic 2500/3500/5500/8500/11500/14500/17500, referred to as "unit", may only be used as specified
in the following:
•For pumping normal pond water for filters, waterfalls and water courses.
•Operate in accordance with instructions.
•Operation under observance of the permissible water quality. (→Water quality)
The following restrictions apply to the unit:
•Do not use in swimming ponds.
•Never use the unit to convey fluids other than water.
•Never run the unit without water.
•Do not use for commercial or industrial purposes.
•Do not use in conjunction with chemicals, foodstuff, easily flammable or explosive substances.
•Do not connect to the domestic water supply.
Installation and connection
A
WARNING
Death or serious injuries from hazardous electrical voltage due to operation of this unit in a swimming pond.
•Never operate this unit in a swimming pond.
WARNING
Possible death or severe injury from hazardous electrical voltage!
•Prior to reaching into the water, isolate (switch off and disconnect) all units/devices used in the water.
•Isolate the device (disconnect from the power supply) before carrying out any work on it.
Aquamax Eco Classic 2500
Installation
Always place the unit below water level.
Place the unit horizontally on the ground ensuring its stable position.
Operating the unit in the pond
B
The pump is in the pond. The return system, e.g. a pond filter, is connected to the pump outlet.
How to proceed:
C
1. Screw the stepped hose adapter to the outlet.
2. Shorten the stepped hose adapter to the diameter of the hose used if necessary.
–This reduces pressure losses.
3. Slip the hose clip over the hose, fit the hose onto the hose connector and secure with the hose clip.
Aquamax Eco Classic 3500/5500/8500/11500/14500/17500
Installation
The unit can be placed submerged or dry.
Always place the unit below water level.
Place the unit horizontally on the ground ensuring its stable position.

-EN -
8
Operating the unit in the pond
B
The pump is in the pond. The return system, e.g. a pond filter, is connected to the pump outlet.
How to proceed:
D
1. Screw the stepped hose adapter including union nut and sealing ring to the outlet.
2. Shorten the stepped hose adapter to the diameter of the hose used if necessary.
–This reduces pressure losses.
–Align the stepped hose adapter prior to tightening the union nut.
3. Slip the hose clip over the hose, fit the hose onto the hose connector and secure with the hose clip.
Install the unit at a dry place
E
Install the unit so that it is not exposed to direct sun radiation (max. 40 ºC).
How to proceed:
F
1. Remove screws.
–The screws are used as transport protection and not required for operation.
2. Actuate the engagement hook and fold up the strainer top casing.
3. Remove pump.
4. Screw the stepped hose adapter including sealing ring onto the inlet.
5. Shorten the stepped hose adapter to the diameter of the hose used if necessary.
– This reduces pressure losses.
6. Slip the hose clip over the hose, fit the hose onto the hose connector and secure with the hose clip.
–Align the stepped hose adapter prior to tightening the union nut.
7. Screw the stepped hose adapter including union nut and sealing ring to the outlet.
8. Shorten the stepped hose adapter to the diameter of the hose used if necessary.
–This reduces pressure losses.
–Align the stepped hose adapter prior to tightening the union nut.
9. Slip the hose clip over the hose, fit the hose onto the hose connector and secure with the hose clip.
Commissioning/start-up
NOTE
Sensitive electrical components. Incorrect connection will destroy the unit.
•Do not connect the unit to a dimmable power supply.
This is how to connect the power supply:
Switching on: Connect the unit to the mains. The unit switches on immediately.
Switching off: Disconnect the unit from the mains.
Aquamax Eco Classic 3500/5500/8500/11500/14500/17500
When started up, the pump automatically performs a pre-programmed self-test of approx. two minutes length (Envi-
ronmental Function Control (EFC)). The pump detects if it is running dry / blocked or submerged. The pump
switches off automatically after approx. 90 seconds if it runs dry (is blocked). In the event of a malfunction, disconnect
the power supply and flood the pump or remove the obstacle. Following this, the unit can be restarted.

-EN -
9
Remedy of faults
Malfunction
Cause
Remedy
Pump does not start
No mains voltage
−Check mains voltage
−Check supply lines
Pump does not deliver
Filter housing clogged
−Clean strainer casings
Excessively soiled water
−Clean pump. The pump automatically
switches on again once the motor has
cooled down.
Impeller unit blocked
−Disconnect the power supply and remove
obstacle. Then switch the pump on again.
Insufficient delivered quantity
Filter housing clogged
−Clean strainer casings
Excessive loss in the supply lines
−Select larger hose diameter
−Adapt stepped hose adapter to hose diam-
eter
−Reduce hose length to reduce frictional
loss
−Avoid unnecessary connection elements
Pump switches off after a short running period
Excessively soiled water
−Clean pump. The pump automatically
switches on again once the motor has
cooled down.
Water temperature too high
−Note maximum water temperature of +
35°C. The pump automatically switches on
again once the motor has cooled down.
Impeller unit blocked
−Disconnect the power supply and remove
obstacle. Then switch the pump on again.
Pump has run dry
−Flood pump. Fully submerge the unit when
operated in the pond.
Maintenance and cleaning
WARNING
Possible death or severe injury from hazardous electrical voltage!
•Prior to reaching into the water, isolate (switch off and disconnect) all units/devices used in the water.
•Isolate the device (disconnect from the power supply) before carrying out any work on it.
Cleaning the unit
NOTE
Recommendation regarding cleaning:
•Clean the unit as required but at least twice a year.
•Do not use aggressive cleaning agents or chemical solutions as they could attack the housing or impair the function
of the unit.
•Recommended cleaning agent for removing stubborn limescale deposits:
– Pump cleaning agent PumpClean from OASE.
– Vinegar- and chlorine-free household cleaning agent.
•After cleaning, thoroughly rinse all parts in clean water.
Aquamax Eco Classic 2500
•In the event of the filter housing capacity reducing, clean the unit under running water using a brush.
Clean pump
How to proceed:
G
1. Screw off the stepped hose adapter.
2. Remove screws.
– The screws are used as transport protection and not required for operation.
3. Actuate the engagement hook and fold up the strainer top casing.
4. Remove pump.
5. Unscrew the pump housing and pull out the impeller unit.
– Clean all components under running water using a soft brush, replace damage parts.
6. Reassemble the unit in the reverse order.
– Place the pump cable into the cable opening of the bottom strainer casing such that the cable will not be crushed
when closing the filter housing.

-EN -
10
Aquamax Eco Classic 3500/5500/8500/11500/14500/17500
•In the event of the filter housing capacity reducing, clean the unit under running water using a brush.
Clean pump
How to proceed:
H
1. Screw off the stepped hose adapter.
2. Remove screws.
–The screws are used as transport protection and not required for operation.
3. Actuate the engagement hook and fold up the strainer top casing.
4. Remove pump.
5. Remove screws.
6. Remove the pump housing including its holding ring, sealing and impeller unit.
–Clean all components under running water using a soft brush, replace damage parts.
7. Reassemble the unit in the reverse order.
–Place the pump cable into the cable opening of the bottom strainer casing such that the cable will not be crushed
when closing the filter housing.
Wear parts
•Impeller unit
Spare parts
The use of original parts from OASE ensures continued
safe and reliable operation of the unit.
Please visit our website for spare parts drawings and spare
parts.
www.oase-livingwater.com/spareparts
Storage/overwintering
The unit is not frost-proof and has to be removed and put into storage if minus temperatures are expected.
How to correctly store the unit:
•Thoroughly clean the unit, check it for damage and replace any damaged parts.
•Store the pump submerged and in a frost-free environment.
•Protect open plug connections from moisture and dirt.
Repair
A damaged unit cannot be repaired and must be put out of operation. Dispose of the unit in accordance with the regu-
lations.
Disposal
NOTE
Do not dispose of this unit with domestic waste.
•Render the unit unusable beforehand by cutting the cables and dispose of the unit via the return system
provided for this purpose.
