Oce cm3521 User manual

Welcome
cm3521 x-1
Welcome
Thank you for purchasing the machine.
The machine is equipped with an integrated printer controller that allows you
to print directly from Windows-compatible computers or Macintosh comput-
ers.
This User’s Guide describes the printing functions, operations, usage, and
safety precautions of the printer controller. In order to ensure that this ma-
chine is used efficiently, carefully read this manual before using the machine.
In order to ensure that this machine is used safely, carefully read “Installation
and Operation Precautions” in the User’s Guide [Copy Operations] before
using the machine.
The illustrations used in this User’s Guide may differ from the actual model.
