Ocean Digital DK-821B User manual

DK-821B
Desktop DAB+/DAB/FM
Radio Receiver
User Manual
Please read this user manual carefully before using the receiver

- 3 -
Contents
1. Introduction to the DK-821B Desktop DAB+/DAB
/FM Radio Receiver ......................................4
2. Location of Controls ......................................6
3. Overview of Radio modes and functions ..........8
4. DAB Radio mode ...........................................9
5. Main Menu-Options and Settings ..................10
6. FM Mode ....................................................14
7. Station Preset and Recall .............................15
8. Bluetooth mode ...........................................16
9. Micro SD/TF Playback mode ........................17
10. Reboot Radio ..............................................18
11. Q & A ..........................................................19
12. Technical Specifications ..............................20
13. In the box ...................................................21

- 4 -
The DK-821B Radio is a compact, multi-purpose and
attractive clock radio with 5V/1.2A power supply for long
hours of audio entertainment and a gateway into the world
of digital DAB and FM audio.
There are four different operating modes:
1) DAB - Digital Audio Broadcast Radio
• CD quality audio received by the attached pigtail
antenna
2) FM – Frequency Modulated Radio
• Listen to local FM Radio stations received by the
attached pigtail antenna
3) BT – Bluetooth Powered Speaker
• Play audio transmitted from a Bluetooth source e.g.
smart phone, laptop
4) SD – Micro SD/TF
• Play CD quality audio entertainment from MP3 files
stored on Micro SD/TF memory card
Introduction to the DK-821B Desktop
DAB+/DAB/ FM Radio Receiver
DAB
DAB
FM
FM
BT

- 5 -
Precautions
ØConnect the power adaptor to the wall and the radio rear
DC jack for power supply – do not apply any other power
source or permanent damage to the radio may occur
and be hazardous.
ØTo clean use only a damp cloth and dry with a clean
towel - keep away from all liquids.
ØTo avoid loss of warranty do not attempt to repair or
remove the cover for any reason.
Introduction to the DK-821B Desktop
DAB+/DAB/ FM Radio Receiver
SD

- 6 -
1
2
3
7
6
5
4
8
9
10
11
12
13 14
15
16
Location of Controls
Top
Front
Back
Bottom
17

- 7 -
Location of Controls
1. On/Standby ( ) – Press to power on the radio and
press again for standby
2. Info/Menu – Press to display radio station information
or Press and Hold for main menu
3. Mode/Scan – Press to switch between radio operating
modes i.e. DAB, FM, BT, and Micro SD/TF, or Hold for
full scan in DAB and FM modes.
4. Preset – Press and hold to add to preset list or press
and release to display the list
5. Sleep – Press to enter sleep setup mode
6. Alarm – Press to enter the alarm setup mode.
7. Tune/Select – Rotate the tune knob to highlight
different options, press to confirm selection.
8. Volume +/- – Rotate the volume knob to increase or
decrease volume level
9. Snooze/Dimmer – Press to dim the LCD backlight or
when alarm is sounding , press to active the snooze.
10. Large Display – 3x8cm monochrome LCD
11. Loud Speaker – high fidelity, 2 Watt output power
12. DC IN Connector – use the power adaptor provided
13. Headphone Connector – Stereo 3.5mm
14. Micro SD/TF – Card slot for audio file playback
15. Antenna – attached pigtail antenna for DAB and FM
modes
16. USB port – Provides USB power source (i.e. 5 Volts)
to charge battery of other USB devices e.g. smart
phone.
17. Battery Compartment – AAAx2 battery backup for
clock power when DC IN not connected

- 8 -
Overview of Radio modes and functions
When the radio is turned on for the first time it will go to
DAB mode and scan for all available stations to create a
list.
To go to a different mode, press the Mode button
repeatedly to navigate through the modes to find and
select any of these functions:
1) DAB – After a full scan to create a list of available
stations; highlight and select a preferred station to start
playing.
2) FM – After a full scan to create a list of available local
stations; highlight and select a preferred station to start
playing.
3) BT (Bluetooth) – Switch your Bluetooth device to a
paring mode and look up the device named “DK-821B ”
from the list, select it to start pairing. When “Paired”
(connected) to another Bluetooth device, use the Radio
as a powered speaker. Maximum range of the Bluetooth
wireless signal is 10 meters but this may be reduced by
the presence of walls or other obstructions.
4) SD (Micro SD/TF) – Play audio files stored in MP3
format on Micro SD/TF memory card.
>>>-- 0
DAB

- 9 -
DAB Radio mode
With the attached pig tail antenna fully extended, turn on
the radio and position antenna for strongest signal
reception.
If this is the initial/first time the radio is turned on, it will go
directly to DAB mode, automatically start a full station
scan, create a list of all the DAB stations found and when
finished, it is start playing the first station on the list.
If message “No DAB” is displayed, please press and hold
the Mode/Scan button to start a full scan.
To play a different station, rotate the Tune/Select knob to
display the station list; navigate the list to highlight the
next station to play, press the knob to select the station
and start playing.
>>>-- 0
DAB

- 10 -
Main Menu – Options and Settings
To display the Main Menu, press and hold the Info/Menu
button until an option list is displayed. The Main menu is
not available if no radio station available on DAB mode.
To exit sub-menu, press Info/Menu button again to go
back to the previous menu.
Navigate the list to highlight an option; select by pressing
the Tune/Select button.
If there is no activity within 30 seconds the radio will return
to its previous function.
• Full Scan – Carry out a full scan to create or update list of
all DAB stations available
• Manual (Manual tune) – Manually select a station by its
transmission frequency and signal strength from the list
provided.
• DRC (Dynamic Range Control) – This function improves
the audio clarity when the DAB signal is poor or noisy by
selecting one of three options:
1) OFF (DRC Off) – No signal compression
FUL L SCA N
MANUAL
DRC
PRUNE
SYS TEM
1 2 DAB

- 11 -
2) HIGH (DRC High) – Maximum signal compression to
boost the low volume sounds while keeping the loud
sounds at the received level.
3) LOW (DRC Low) – Medium Compression
• Prune – Edit station list option to remove unwanted
stations or stations that can no longer be received.
Navigate to and highlight station to be removed; select
“YES” to delete from list.
• System - The DAB main menu contains other options to
customize the radio:
◦ Sleep – The radio has a built-in Sleep Timer with
multiple delay options to enable listening while falling
asleep. To turn off the timer select off in the time
delay list.
◦ Alarm - There are two separate wake up alarms that
are set up independently i.e. act as two completely
separate alarms.
Rotate Tune/Select knob to highlight Alarm mode;
press knob to select Alarm mode and display a list of
options.
To setup or change option selections navigate and
highlight option by rotating the Tune/Select knob;
press knob to confirm selection:
1) Select Alarm 1 or Alarm 2 for setup
2) Select ON to enable the Alarm function for the
Alarm selected
3) Set the time when the Alarm will sound
Main Menu – Options and Settings

- 12 -
4) Select Alarm sound duration option i.e. 15, 30,
45, 60 or 90 minutes
5) Select the source for the Alarm sound i.e. Buzzer
or DAB and FM radio station in My Favorite list
6) Select option for the Alarm to automatically
repeat i.e. daily, weekdays, weekends or once
7) Set Alarm sound volume; rotate Tune/Select
knob to adjust volume level; press knob to
confirm level
8) When Alarm setup is complete the display will
show SAVED to confirm setup
Snooze - When the alarm sounds, press the Snooze
button to mute the alarm for 9 minutes before the
Alarms sounds again. The Snooze feature can be
repeated multiple times.
To turn off the “Snooze” function, press the Power( )
button.
◦ Time - Select option from list to setup time standard
to use along with preferred display format for the time
and date:
1) Set Time/Date – manual setup of current time and
date
2) Auto Update – For manual time and date setup
select “No Update” option or select automatic
updates from either DAB or FM radio signal
Main Menu – Options and Settings
14:53
SNZ 1

- 13 -
3) Set 12/24 – option to select time display in 12 or
24 hour format
4) Set Date Format – Select DD/MM/YYYY or
MM/DD/YYYY display format
Note: FM time updates are not always available in
some areas.
◦ Backlight – options for setting functionality and
brightness level for the color LCD.
Timeout – options for how long the backlight remains
on with no user activity e.g. making selections,
changing volume level etc. There are 9 options; ON to
keep the backlight on until the radio is turned off or 8
delay times from 10 – 180 seconds.
◦ Language – Select one of five different languages
used for displays: ENGLISH, DEUTSCH, ITALIANO,
FRANCAIS, NEDERLANDS and NORSK.
◦ Reset – This is a factory reset to set all options and
settings to the exit factory condition, delete all other
user input (e.g. Presets); reboot the radio and go to
DAB mode.
◦ SW VER – System information display e.g. Firmware
/ Software version.
Main Menu – Options and Settings

- 14 -
FM Mode
With the pig tail antenna fully extended, position for
strongest signal reception and select FM mode
(Mode>FM).
To setup FM mode options press and hold Info/Menu
button until the option list is displayed. The list contains all
the same options as in the DAB main menu with two
specific FM options added.
1) Scan setting – An option to scan for all stations or list
only stations with good reception such that stations with
low signal and noisy reception are not included in the FM
station list.
If there is no FM station list or the list needs to be
refreshed / updated press and hold the Mode/Scan button
for a full station scan; add all the stations found in the
Preset station list (maximum of 20 stations) and
automatically start playing the first station on the list.
To select a different station press Preset button to display
the station list, navigate the list using the Tune/Select
knob to highlight the next station to play; press knob to
start playing the station.
To fine tune the reception frequency (i.e. tune in) rotate
the Tune/Select knob to change the frequency up or down
in 0.05 MHz (50 KHz) steps.
93.90 01
1 2 FM

- 15 -
Station Preset and Recall
Preset
Up to 20 DAB and 20 FM stations (i.e. 20 for DAB and 20
for FM) can be stored in the Preset memory for easy and
fast access of favorite stations.
To set a Preset play the station to be stored in the preset
memory; press and hold the Preset button to display
current preset list.
Navigate the list by rotating the Tune/Select knob to
highlight one of the 20 locations to store the station; press
the knob to store the station in the location shown on the
display and return to playing the station with the display
updated to show the preset number / location.
The station assigned to a Preset button can be changed
at any time by following the same procedure。
Recall
To recall any preset DAB or FM station press and release
the Preset button to display the current list of Presets.
Navigate the list by rotating the Tune/Select knob to
highlight a station; press the knob to start playing the
station.
02 EMPTY
1 2 FM

- 16 -
Bluetooth mode
Press Mode button repeatly to show “BT” on the display.
The radio’s Bluetooth wireless receiver can receive and
play audio data files but does not support Bluetooth
headphones.
Before the radio can be used as a powered speaker to
play audio files received from a Bluetooth source device it
must be connected (i.e. paired) to the device.
The Bluetooth source device controls the pairing process;
find DK-821B in the list of available devices on the
Bluetooth source device and pair the two devices. The
“BT” icon will stop flickering when the two devices are
paired.
Once paired the radio and source device will recognize
each other, automatically connect and start playing the
received audio files.
After pairing the radio and Bluetooth device will
automatically recognize each other whenever the radio is
in Bluetooth mode and in range i.e. less than 10 meters.
The audio files are played as they are received by the
radio with playback volume controlled by the Volume+/-
knob.
To go to the main menu while in Bluetooth mode; press
and hold the Info/Menu button; press and release to
return to Bluetooth mode.

- 17 -
Micro SD/TF Playback mode
Insert a Micro SD/TF card with audio files stored in MP3
format, into the slot on the rear of the radio; press the
Mode button repeatedly to navigate to Micro SD/TF mode
to automatically start playing the first track.
Playback/Select song
While playing, rotate the Tune/Select knob to skip to
different tracks; press the knob to pause and resume
playing.
Volume control
Increase or decrease playback volume by rotating the
V+/V- knob.
While in Micro SD/TF mode, press and hold the Info/Mode
button to go to the main menu; and press again to return to
Micro SD/TF mode.

- 18 -
Reboot Radio
In the unlikely event that the radio becomes unresponsive
or a mode stops functioning correctly, disconnect the
power adaptor, wait a few seconds and then plug it in
again. The radio will reset and turn itself off without
changing any of the options or setting previously made.
Use Factory Reset option (in the DAB Main Menu) to reset
all options and setting previously made back to exit
factory condition.

- 19 -
Q & A
Radio does not turn on
• Connect the power adaptor to the radio and plug it into
the A/C wall socket.
No DAB or poor reception
• Make sure the pig tail antenna is fully extended and
positioned (i.e. angle and direction) to improve
reception.
• Move radio closer to a window for a stronger DAB signal
reception.
• Move the radio away from other electrical equipment.
• Confirm that DAB is available in the area.
• Go to DAB Main Menu and select Factory Reset to reset
the software. Note that this will reset all options and
setting previously made.
No sound in DAB or FM mode
• Volume level is too low for the weak reception of the
radio signal.
No or very low sound in Bluetooth mode
• The volume level on the Bluetooth source device or the
radio is too low.
• Distance from Bluetooth source device is too far;
maximum distance must be less than 10 meters with no
obstructions (e.g. wall, furniture) or less distance if there
are obstructions.
• Check the pairing status on Bluetooth source device and
radio i.e. check that the Radio Bluetooth code is in the
“paired” device list and playing or connected is displayed
on the radio.
• Delete the radio from the paired devices list on the
Bluetooth source device, edit the Radio Bluetooth code
in the available device list to remove the radio name (i.e.
use only Bluetooth code) and pair the radio with the
device.

- 20 -
Technical Specifications
Specifications subject to change without notice
Model
5 Volts 1.2 Amp
(Power adaptor included)
DC Power Input
Radio Reception
Frequency Range
DAB+/DAB Band III, 5A – 13F
FM 87.5 – 108 MHz
DK-821B
Bluetooth Version
Frequency
Range
BT Transmit Power
SD Storage
Audio Output
Analogue Output
Dimension
Weight
V4.2 BR, EDR Compliant
2.4 GHz
≤10 meters (Line of sight)
0 dBm Receive only
(not for earphones)
Micro SD/TF card (maximum 32 GB)
MP3 format
2 Watts
3.5 mm Stereo Headphone
L 120 x W 120 x H 120 mm
415g
Battery back up AAA x 2pcs (for clock)
USB power output 5 Volts 1Amp (Maximum)
