Ocean Digital WR-03 User manual

WR-03
Internet Radio Adaptor with
DAB and Bluetooth
Please read this user manual carefully before using the receiver.
User Manual
(Additional powered speaker/active speaker is required to use this product)

Contents
Location of Controls .......................................1
Remote Control .............................................2
Remote control character list ..........................3
Getting started ..............................................5
Connecting to your WiFi network .....................6
Internet Radio ...............................................7
Spotify Connect .............................................9
Media Center ...............................................10
FM mode .....................................................12
DAB Mode ...................................................13
Information Center .......................................14
DLNA ..........................................................15
Bluetooth ....................................................15
Configuration ..............................................16
Trouble Shooting .........................................24
Technical Specification .................................27

Location of Controls
1. 2.8'' TFT color screen
2. Infrared remote sensor
3. 3.5mm antenna input socket
Two types of antenna are supplied with the radio. One is wire
type and the other is the rod antenna. Apply one of them to get
the best result on the reception of DAB and FM radio
4. 3.5 mm audio out socket
Connect external powered speakers with 3.5 mm plug or RCA
adaptor with 3.5mm plug
5. Optical Out
Digital optical output connection
6. DC IN socket
Connect with the power adaptor supplied in the package
7. Power ON/OFF switch
1 2
3 4 5 6 7
- 01 -

1. : Mute
2. : Standby button
3. 0-9: Favorite station key / input
letters and numbers for WiFi
Encryption code
4. : Preset the current playing station
to Favorite
5. : Recall the favorite list
6. ▲: Cursor up
7. t: Cursor left / back to previous
menu
8. u: Cursor right
9. ▼: Cursor down
10. OK: confirm button
11. : Alarm button
12. : Sleep Timer
13. Vol+: Volume up
14. Vol-: Volume down
15. : Main Menu
16. Mode: Switch between the modes of
radio
17. EQ: Equalizer
18. : Previous station on the list /
previous track on UPnP
19. : Play/pause for internet radio
20. : Next station on the list/next track
on UPnP
21. Local: Access the local station list
(Local area set up in
Configuration)
22. Info: View the detailed info of the
radio channel or the music info
under UPnP.
23. Dimmer: Dim down the backlight of
display
Remote control
- 02 -

Remote control character list
Key“0”―― 0,‘DEL’
Key“1”―― ‘1’->‘@’->‘ ’（space）->‘！’-> “ (double quotes)
->‘#’->‘$’->‘%’->‘&’-> ’（single quotes）->‘（’
->‘）’->‘*’->‘+’->‘，’->‘-’->‘.’->‘/’->‘:’->‘;’->‘<’->‘=’-
>‘>’->‘?’-
>‘[’->‘\’->‘]’->‘^’->‘_’->‘`’->‘{’->‘|’->‘}’->‘~’
Key “2”―― 2,A,B,C,a,b,c
Key“3”―― 3,D,E,F,d,e,f
Key“4”―― 4,G,H,I,g,h,i
Key“5”―― 5,J,K,L,j,k,l
Key“6”―― 6,M,N,O,m,n,o
Key“7”―― 7,P,Q,R,S,p,q,r,s
Key“8”―― 8,T,U,V,t,u,v
Key“9”―― 9,W,X,Y,Z,w,x,y,z
To enter the password, press " ▲ " or " ▼ " button to select the
characters. Press the " ► " button for the next entry, press " ◄ "
button to delete the character or to amend it. When the last
character is entered, press the <OK > button this time.
Do NOT press the " ► " button.
The radio will start connecting to the network.
- 03 -

Please ensure the following is ready:
• You have a broadband internet connection.
• A wireless (Wi-Fi) broadband router is connected to the internet
successfully. The radio supports Wireless B, G and N
connection (Wireless N router can also be used with the setting
on B or G).
• You know the Wired Equivalent Privacy (WEP) or Wi-Fi
Protected Access (WPA) data encryption code/password. You
need to key in the correct code when the radio is connected to
the wireless router for network connection. If you do not know
the code/password, please contact the person /technician who
set up the router/network for you.
• The radio can work via Wireless network connection (Wi-Fi
connection).
Precautions
• The radio should not be used in a high temperature or high
humidity environment over prolonged periods of time as this
may damage the unit.
• Keep the radio away from liquids as it may get damaged. Please
switch off the radio immediately if water or liquids is spilled into
the radio. Consult with the shop you bought this radio for any
question.
• Avoid using or storing the unit in dusty or sandy environment.
• Do not open and repair the radio by yourself.
• Use only the DC adaptor supplied with the radio.
Connecting a power supply with a different rating will cause
permanent damage to the radio and may be hazardous.
• Clean only with dry cloth
Before you start
- 04 -

Getting started
Connect the mains adaptor to the radio unit, one end to the DC IN
on the radio and the other end to the mains wall outlet.
Caution: Use only the mains adaptor supplied with the radio.
Connecting a power supply with a different rating will cause
permanent damage to the radio and may be hazardous.
The radio is an adaptor and does not have internal speaker.
Prepare a powered speaker which has the 3.5mm pin in plug in to
the 3.5mm line out jack on the radio.
The radio supports also the optical connection. If you have a
system comes with optical input, connect to the optical out on the
radio to listen.
Switch the radio on using the Power on/off switch at the rear side
of the radio. The display on the front of the radio will light up and
show:
Then you can select your prefer language on the radio.
It will ask you if you want to Enable the <Check Network when
Power on>, it is suggested to choose <Yes>. Then the radio will
always check the available WiFi network automatically.
- 05 -
• English
Deutsch
Español
Français
1/17
01:44
Welcome

Connecting to your WiFi network
The following screen will appear. You can choose <Yes> to
proceed to search for the available WiFi network. If your router
has the WPS function, you can select <Yes(WPS)> to proceed.
It will then start scanning the network. After the search is done, it
will display a list of the available Wifi networks.
Choose your network from the list, enter the WEP(Wired
Equivalent Privacy) or WPA(Wi-Fi Protected Access) code. If
your network is not enabled with security code, the unit will
connect to the network automatically.
Note: The encryption code would have been set up by the
person who set up and configured your network.
Please refer to the “Remote Control character list” for you to
enter the passwords. Press the “►” button to go to the next entry,
press “◄” button to make correction, press OK when the last
character is entered.
The radio will start connecting to the network.
After the wifi network is connected successfully, it will display the
main menu as follow:
You can now start enjoying the internet radio.
08:58
Internet Radio
5
- 06 -
01:44
Linksys
Homeaudio
Demo
01:01
Would you like to
configure Network now?
Yes(WPS) NOYes
Ent er
Password
1/1
16:23
Input: Ç È Å Move Æ OK

Internet Radio
Choose <Internet Radio> from the menu, you can see different
functions as below:
To start listening the radio stations worldwide, select <Radio
Station/Music>.
My Favorite
This is to show the list of your Favorite stations which have been
assigned to the presets.
To preset a station:
While you are playing the favorite station, simply hold and
press the key until the follow screen appear. Press OK to
confirm. The playing station will be added to the preset list
automatically.
The presets will be stored in ascending order. You can store
up to 250 presets.
Note: Preset 1 to 5 are reserved for your own choice of the
dedicated radio channels. Scroll to choose the desired
number to save your favourite channel. To save more
channels after the first five presets are occupied, press
and hold the preset button and it will assign to preset no.
6 onwards.
You can edit your favorite list anytime. Go to Internet radio>
My Favourite or press the on the remote, When it
displays the list of favorite stations then press the ► button.
The following options will display:
Delete – To delete the selected station
Shift up- To shift the selected station by one level up on the
ranking
Press OK to confirm The symbol means the station has
already been added to the favourite lis
- 07 -
Delete
Shift Up
Shift Down
Rename
1/5
iRadio

Internet Radio
Shift down – To shift the selected station by one level down on
the ranking Rename – To rename the selected station
Play – press and play the selected station
Choose the radio station that you want to make with the above
changes. Then press the Right key, it will enter into the list
with the options listed above. Then choose your desire action.
To recall a preset station:
Press the on the remote briefly and choose your desire
station.
Radio Station / Music
Select this option, then you can select your desired radio station
by Category, Genre or Location., etc.
Local Radio
If you want to access quickly the radio station located in your
area, select this function and it will display the list of the stations
available in your area.
History
The radio will memorize the last listened 10 stations.
Service
Search Stations
You can find your desire radio station by entering the name of
the radio.
Add New Radio Station
If you cannot find your desire station from the Radio station
list and you have the URL address, you can input the link here
and add to your favorite list.
Note: The URL has to be an audio streaming URL in order
to play on the radio.
When the radio station is playing, the display will show a color
image transmitted from the radio station.
iRadio
.977 The 80s Channel
977
Music
Internet Radio
- 08 -

A better way to listen at home. Listen on the WR-03 using the
Spotify app as a remote. Enjoy the music together.
Use your phone, tablet or computer as a remote control for
Spotify.Go to spotify.com/connect to learn how.
The Spotify Software is subject to third party licenses found
here:www.spotify.com/connect/third-party-licenses
Please make sure your device is on the same Wi-Fi
network as the Radio before you start using this function
- 09 -

UPnP (Universal Plug and Play)
The device supports UPnP and is DLNA-compatible.
This provides the opportunity to stream music from your other
network devices. However, this requires you to have a
compatible device in your network that can function as a server.
This can be e.g., a network hard drive or a conventional PC with
e.g., Windows 8 via which access to the shared folder or media
sharing is permitted. The folders can then be browsed and played
on the Tuner.
Please make sure your computer laptop is on the same
Wi-Fi network as the Radio before you start using this
function.
DLNA
The Internet radio can play music stream from DLNA compatible
device, provided that the Internet radio and other DLNA devices
are under the same Wi-Fi network.
The radio will be discovered as “AirMusic” when you try to search
it on other devices. If you want to change other name from
AirMusic, go to Configuration and DLNA setup to make the
change.
Music streaming
1. Once the UPnP/DLNA compatible server is configure to share
media files with your radio, you can start music streaming.
2. On the main menu, select [Media Centre] and choose [UPnP].
3. It may take a few seconds for the radio to complete the scan for
available UPnP servers. If no UPnP servers are found, it will
show [Empty List].
4. After a successful scan is done, select your UPnP server.
5. The radio will show the media categories available from the
UPnP server, e.g. ‘Music’, ‘Playlists’ etc.
6. Choose the media files that you wish to play.
You can set the mode of playback under Configuration >
Playback setup.
Media Center
- 10 -

My Playlist
You can make your own playlist from the UPnP music files.
Choose and highlight the song you want to add to playlist, press
and hold the [Dial/Select] knob, unit the sign appears. The song
will be added to My playlist.
Clear My Playlist
Remove all songs in My playlist to allow a new playlist to be
prepared.
Note - If you have DLNA compatible servers available, follow the
steps described above to browse the audio files from DLNA
compatible device on the radio to play.
Media Center
- 11 -

FM Mode
You can listen to the ordinary FM radios without wifi connection.
Take out the wire antenna supplied in the package, plug it into the
antenna socket on the rear side of the adaptor, extend it
perpendicular to the radio unit or in other direction / length of the
antenna may be required to optimize the reception level.
Choose FM from the main menu or use the <Mode> button to
switch to FM radio.
Auto preset scan
There is an option to auto preset the FM stations. Press and
release OK button, it will prompt you for Auto Scan. Choose Yes
to start. It will start auto scanning the local FM radio stations that
can be received and stores the channels as presets
automatically. To play a particular channel from the presets:
1. Press and release the button to recall the Preset list.
2. Press ▲ / ▼ to choose your desired channel.
3. When you reach the desired station, press OK to listen to the
channel.
It can store up to 99 presets.
Manual Scan
To seek a FM station manually, press and hold ◄/► button then
the radio will seek the previous or next available station. If you
want to fine tune the frequency, press ▲ /▼ to tune 0.05Mhz,
- 12 -

DAB Mode
You can listen to ordinary DAB channels without wifi connection.
Take out the wire antenna supplied in the package, plug it into the
antenna socket on the rear side of the adaptor, extend it
perpendicular to the radio unit or in other direction / length of the
antenna may be required to optimize the reception level.
Choose the DAB from the main menu or press <Mode> button to
switch to DAB. If this is the first time you use the DAB mode, it will
scan the DAB radio station automatically. It will display the DAB
station list when the scan is done.
Choose the station you want to listen, and press OK to confirm
for playing. Press ◄ to return to station list. If you press ◄
again, it will display as follow. It allows for a re-scan of the DAB
stations:
Choose <NO> to keep the existing station list and scan for any
new stations.
Choose <YES> to delete the existing station list and perform a
full scan again.
Choose <ESC> to exit the current operation.
It can store up to 99 presets.
- 13 -

Information Center
Weather
The radio provides weather information and can display in
Standby mode. To enable this feature, follow the steps below:
Go to main menu, choose Information Center> Weather
Information, choose the region you want it to display the
weather information. After region is selected, press OK, it will
display the weather info of the selected region. Then press the
same button again and it shows <Add to Standby Display>,
select to confirm. The weather info is enabled now to display in
standby.
The date/time and weather info will appear alternatively every 10
seconds.
In standby with the analogue clock display, press to see the real
time weather information.
Press the same button repeatedly to see the forecast for the next
4 days. To view more details for a particular day individually,
press ▲ / ▼for more information.
To refresh the weather information, press OK to confirm.
Remark: The weather is just for reference only. It may have
deviation to the actual weather.
System Information
You can view the information of the radio such as the Version of
the software / Wlan Mac / IP address..etc.
- 14 -

The Internet radio can play music stream from DLNA compatible
device, provided that the Internet radio and other DLNA devices
are under the same Wi-Fi network.
The radio will be discovered as “AirMusic” when you try to search
it on other devices. If you want to change other name from
AirMusic, go to Configuration and DLNA setup to make the
change.
DLNA
DLNA/Bluetooth
The radio receives and plays music streamed by other Bluetooth
device.
Choose Bluetooth from the main menu or use the <Mode> button
on remote to switch to Bluetooth.
Once it enters into Bluetooth mode, it will be discoverable from
other Bluetooth devices.
1. Turn on Bluetooth on the Bluetooth device and look up the
device named “WR-03” from the list. Select it to start pairing.
2. If the connection is successful, it will show “Connected” on
your Bluetooth device list.
3. You can start playing music from your Bluetooth device now.
Bluetooth
- 15 -

Configuration
Time Display
You can choose the time display at Analog or Digital.
Manage my mediaU
You can tailor made your own favorite station list using your
computer.
1) Go to and sign up to become a http://www.mediayou.net/
member.
2) Then you have to find out the Mac Address to register on the
Media U website. To locate the MAC address, please follow
the path below:
2a) Go to Main Menu and select <Information Center>
2b) Go to <System Information>
2c) Choose <Wireless Info> and you will find your Mac
address.
3) Log-in Media U on your computer, click My Media U > Radio,
then input the Radio name and Serial number (i.e. MAC
Address) and save it.
You can then organize your own favorite stations or add any new
station which is currently not found on the station list. Once the
changes are done, your radio will synchronize the changes
immediately and you will find your favorite list under <My
MediaU> on the radio menu.
- 16 -

Configuration
Note: If you are going to add URL which is not on Media U
database, ensure the URL is an audio streaming URL or contact
Media U to add it for you.
- 17 -

It allows maximum 5 users to register with the same radio and
you can switch to listen the favorite list under one user at a time.
To find your added station / custom favorite list on the radio, go to
Configuration > Manage my mediaU > Enable.
Then go to main menu and choose <My Media U>.
You will find listed options with your favorite list.
Important: Whenever any update is done on your <My Media U>
account, you have to disable the My Media U and enable it again
to refresh and get the latest updated list. (Configuration>
Manage my mediaU > Disable>Enable)
Network
Wireless Network Configuration
Press to choose enable scanning the available wireless
network.
Wireless Network (WPS PBC)
The WPS allows to connect the radio with your router by
pressing one key on the radio and
a WPS key on your router for wifi connection, provided that
your router has the WPS function.
Manual Configuration
You can set the DHCP on or off, and enter the SSID name, or
delete the connected SSID.
Check network when power on
This is set to enable or disable <Check network when power
on>.
Date & Time
The time is set automatically to your local area. You can choose
to manual set the time if you want.
Time Format setting
Time format setting: 12hours / 24hours
Configuration
- 18 -
