Ocean Digital WR-280S User manual

WR-280S
Stereo Wooden Internet
Radio with DAB
User Manual
Please read this user manual carefully before using the receiver

Contents
Location of Controls ...................................................................1
Remote Control .........................................................................2
Getting started ..........................................................................4
Connecting to your WiFi network .................................................5
Internet Radio ...........................................................................6
Bluetooth .........................................................................8
Media Center ............................................................................8
FM mode ..................................................................................9
DAB Mode ...............................................................................10
Information Center ...................................................................12
Aux In .....................................................................................12
DLNA .....................................................................................12
Configuration ..........................................................................13
Trouble Shooting .....................................................................19
Technical Specification ............................................................21

1. Standby button
2. Volume/Home
Rotate to adjust the volume level/Press the knob to return Home (main menu).
3. Preset
Long press to enter the "Add to favourite" list. Press it briefly to recall the preset
list.
4. Infrared remote sensor
5. 3.5 mm earphone jack
6. Left
Left cursor/Press to return to previous menu.
7. Dial/Select
Rotate to browse the menu/Press to confirm a selection or stop the playback.
8. Right
Right cursor/View radio info
9. 2.8'' color display
10. Speaker
11. DC IN Socket
12. Aux-In Jack
13. Line out Jack
14. Telescopic antenna
Location of Controls
- 01 -
1 5 2 6 7 3 8 4 9 10
11 12 13 14

SELECT
Alarm Sleep
Vol- Vol+
►
►
►
►
1. : Standby button
2. : Mute
3. ▲ : Cursor up
4. ▼ : Cursor down
5. ◄ : Cursor left / back to previous menu
6. ► : Cursor right
7. SELECT: confirm button
8. : Favorite button, press to recall the favorite
stations, hold to enter the "Add to
favourite" list
9. : Main menu
10. Alarm: Alarm button, press to set the alarm
11. Sleep: Sleep Timer, press to set the sleep time
12. Vol+: Volume up
13. Vol-: Volume down
14. : Previous radio channel on the list /
previous song on UPnP
15. : Play/pause (for UPnP)
16. : Next radio channel on the list / next song
on UPnP
Remote Control
- 02 -

- 03 -
Please ensure the following is ready:
• You have a broadband internet connection.
• A wireless (Wi-Fi) broadband router is connected to the internet successfully. The
radio supports Wireless B, G and N connection (Wireless N router can also be
used with the setting on B or G).
• You know the Wired Equivalent Privacy (WEP) or Wi-Fi Protected Access (WPA)
data encryption code/password. You need to key in the correct code when the
radio is connected to the wireless router for network connection. If you do not
know the code/password, please contact the person /technician who set up the
router/network for you.
• The radio can work via Wireless network connection (Wi-Fi connection).
Precautions
• The radio should not be used in a high temperature or high humidity environment
over prolonged periods of time as this may damage the unit.
• Keep the radio away from liquids as it may get damaged. Please switch off the
radio immediately if water or liquids is spilled into the radio. Consult with the shop
you bought this radio for any question.
• Avoid using or storing the unit in dusty or sandy environment.
• Do not open and repair the radio by yourself.
• Use only the DC adaptor supplied with the radio.
Connecting a power supply with a different rating will cause permanent damage to
the radio and may be hazardous.
• Clean only with dry cloth
Before you start

Connect the mains adaptor to the radio unit, one end to the DC IN on the radio and
the other end to the mains wall outlet.
Caution: Use only the mains adaptor supplied with the radio. Connecting a
power supply with a different rating will cause permanent damage to the radio
and may be hazardous.
The display on the front of the radio will light up and show:
Then you can select your prefer language on the radio.
It will ask you if you want to Enable the <Check Network when Power on>, it is
suggested to choose <Yes>. Then the radio will always check the available WiFi
network automatically.
Getting started
- 04 -
• English
Deutsch
Español
Français
1/17
01:44
Welcome

The screen below will appear. You can choose <Yes> to proceed to search for the
available WiFi network. If your router has the WPS function, you can select
<Yes(WPS)> to proceed.
It will then start scanning the network. After the search is done, it will display a list of
the available router.
Choose your router from the list, enter the WEP(Wired Equivalent Privacy) or
WPA(Wi-Fi Protected Access) code. If your network is not enabled with security
code, the unit will connect to the router automatically.
Note: The encryption code would have been set up by the person who set up
and configured your network.
Please follow the steps below to enter the encryption code of your router using the
buttons on the radio:
- Rotate the <Dial/Select> knob to browse the character
- Press the right button to skip to the next entry
- After you finish with the entries, press the <Dial/Select> knob to confirm. Do NOT
press the right button again.
To use the remote control entering the password: Press "▲" or "▼" button to select
the characters. Press the " ► " button for the next entry, press " ◄ " button to delete
the character or to amend it. When the last character is entered, press the
<SELECT> button this time.
Do NOT press the “►” button.
The radio will start connecting to the network.
After the router is connected successfully, it will display the main menu as follow:
You can now start enjoying the internet radio.
08:58
Internet Radio
5
Connecting to your WiFi network
- 05 -
01:44
Linksys
Homeaudio
Demo
01:01
Would you like to
configure Network now?
Yes(WPS) NOYes
Enter
Password
1/1
16:23
Input: Ç È Å Move Æ OK

Choose <Internet Radio> from the menu, you can see several listed options.
To start listening the radio stations worldwide, select <Radio Station/Music>.
My Favorite
This is to show the list of your Favorite stations which have been assigned to the
presets.
To preset a station:
While you are playing the favorite station, long pressing the <Preset> button
( on the remote) and the <Add to My Favorite> menu will display. Press
the rotary knob to confirm. The playing station will be added to the preset list
automatically.
The presets will be stored in ascending order. You can store up to 250
presets.
Note: Preset 1 to 5 are reserved for your own choice of the dedicated
radio channels. Scroll to choose the desired number to save your
favourite channel. To save more channels after the first five presets are
occupied, press and hold the preset button and it will assign to preset
no. 6 onwards.
You can edit your favorite list anytime. Go to Internet radio> My Favourite
or press the <Preset> button ( on the remote), When it displays the list of
favorite stations then press the right button. The following options will
display:
Delete – To delete the selected station
Shift up- To shift the selected station by one level up on the ranking
Shift down – To shift the selected station by one level down on the ranking
Rename – To rename the selected station
Play – press and play the selected station
Choose the radio station that you want to make with the above changes.
Then press the Right key, it will enter into the list with the options listed
above. Then choose your desire action.
Press [Dial/Select] knob to confirm
The symbol means the station has
already been added to the favourite list
Internet Radio
- 06 -
Delete
Shift Up
Shift Down
Rename
1/5
iRadio

Internet Radio
To recall a preset station:
Press the <Preset> button ( on the remote) briefly and choose your desire
station.
Radio Station / Music
Select this option, then you can select your desired radio station by Category,
Genre or Location., etc.
Local Radio
If you want to access quickly the radio station located in your area via internet, ,
select this function and it will display the list of the stations available.
History
The radio will memorize the last listened 10 stations.
Service
Search Stations
You can find your desire radio station by entering the name of the radio.
Add New Radio Station
If you cannot find your desire station from the Radio station list and you have
the URL address, you can input the link here and add to your favorite list.
Note: The URL has to be an audio streaming URL in order to play on the
radio.
When the radio station is playing, the display will show a color image transmitted
from the radio station.
iRadio
.977 The 80s Channel
977
Music
Internet Radio
- 07 -
