Ocean Digital WR-100F User manual

WR-100F
Internet Radio
Please read this user manual carefully before using the receiver.
User Manual

Contents
Location of Controls .........................................1
Switching the radio on ......................................3
Connecting to your WiFi Network ......................4
Internet Radio ...................................................6
Media Center ....................................................9
FM Radio .........................................................11
Information Center ..........................................12
Aux In .............................................................13
Bluetooth .......................................................13
Configuration .................................................14
Trouble Shooting ............................................22
Technical Specification ...................................26
What is included in the box .............................27

Location of Controls
18 3 24 5 67
9
Dial /S elect
10 11 12 13
AUX-IN
- 01 -

1. Standby button
2. Home button
3. Left/Back button
4. Right button
5. Volume / Dial / Select rotary knob
(Rotate to adjust the volume or browse the menu. Push
down the button to confirm selection)
6. Favourite button
(Press and hold to enter "Add to Favourite", press and
release to recall the favourite list)
7. 1-3 Presets buttons
(Press and hold to store preset, press to recall the
preset stations1-3)
8. Speaker
9. Color screen 2.4"
10. DC IN Jack
11. 3.5 mm Aux-In jack
12. 3.5 mm earphone jack
13. Telescopic antenna
Location of Controls
- 02 -

Switching the radio on
Connect the mains adaptor to the radio unit, one end to
the DC IN on the radio and the other end to the AC mains
wall socket.
Caution: Use only the mains adaptor supplied with the
radio. Connecting a power supply with a
different rating will cause permanent
damage to the radio and may be hazardous.
The radio will power up and display Welcome:
Select the language for the radio menu:
It will ask to set the <Check Network when Power on>, it
is suggested to choose <Yes>. The radio will always
check the available WiFi network automatically.
- 03 -

Connecting to your WiFi Network
Followed by the steps above, it will come to the network
configuration setting. Choose <Yes> to start searching
the available WiFi network. If your router has the WPS
function, you can select <Yes(WPS)> to proceed.
After the search is done, it will display a list of the
available wifi network.
Choose your network from the list, enter the password if
the network is set with encryption code. If your network
does not require any password to access, the wifi will be
connected automatically.
Note: The encryption code would have been set up by
the person who set up and configured your network.
Follow the steps below to enter the password of your wifi
network:
- 04 -

- Rotate the [Dial/Select] knob to browse the character
- Press the [►] button to skip to the next entry
- When it is done, push the [Dial/Select] rotary knob to
confirm.
The radio will start connecting to the network.
When the wifi is connected successfully, it will pop to the
main menu and you are ready to access the worldwide
internet stations.
08:58
Internet Radio
5
Connecting to your WiFi Network
- 05 -

Choose <Internet Radio> from the menu, you can see
several listed options.
To start listening the radio stations worldwide, select
<Radio Station / Music>. You can find your favourite
station by Genre or Location.
My Favorite
This is to show the list of your Favorite stations which
have been added to the list.
To preset a station:
When your favourite station is playing and you want to add
it to favourite list, press and hold the [Preset] button and
<Add to My Favorite> menu will display. The preset
number will be assigned automatically to the next
available number. Push the [Dial/Select] knob to confirm.
The playing station will be added to the preset list.
The presets will be stored in ascending order. You can
store up to 250 presets.
Note: Preset 1 to 5 are reserved for your own choice of
the dedicated radio channels. The preset will be
intended to store from no. 6 onwards, you can scroll to
choose no. 1-5 at your preference.
Internet Radio
Push [Dial/Select] dial to confirm
The symbol on the top row
means station is added to
favourite list
- 06 -

For FM, you can store up to 99 presets
You can edit your favorite list anytime with the options
below:
Delete - To delete the selected station
Shift up - To shift the selected station by one level up on
the ranking
Shift down - To shift the selected station by one level down
on the ranking
Rename - To rename the selected station
Play - press and play the selected station
Navigate to <My Favourite> on the menu or press the [ ]
button, choose the radio station that you want to make the
above changes. Then press the [►] button to enter the
edit menu.
To recall a preset station:
Press the [ ] button briefly and choose your desire
station.
Local Radio
Select this option to access quickly the radio station
located in your country.
Sleep Radio
Use this option to choose the sleeping sound for better
sleep, there are various kinds of sound for your selection.
Internet Radio
- 07 -

History
The radio will memorize the last 10 listened stations.
Service
Search Stations
You can find your desire radio station by inputting the
name of the radio or just a few characters to filter the list.
Add New Radio Station
If you want to add the station and you have the audio
stream URL, it is suggested to add it through the
MediaYou website as follow, or you can contact MediaYou
if the station cannot be located.
http://www.mediayou.net/
Please refer to the “Manage My mediaU” under
Configuration section below for more details.
When a radio station is playing, press the [►] button and it
will display the station logo (if any). Continue to press the
[►] button to view the radio information.
APP
Scan the QR code to visit the mediaU website to sign up
an account.
Internet Radio
Station
<Station Logo>
- 08 -

Media Center
UPnP (Universal Plug and Play)
The device supports UPnP and is DLNA-compatible.
This provides the opportunity to stream music from your
other network devices. However, this requires you to have
a compatible device in your network that can function as a
server. This can be e.g., a network hard drive or a
conventional PC with e.g., Windows 8 via which access to
the shared folder or media sharing is permitted. The
folders can then be browsed and played on the Tuner.
Please make sure your computer laptop is on the
same Wi-Fi network as the Radio before you start
using this function.
DLNA
The Internet radio can play music stream from DLNA
compatible device, provided that the Internet radio and
other DLNA devices are under the same Wi-Fi network.
The radio will be discovered as “AirMusic” when you try to
search it on other devices. If you want to change other
name from AirMusic, go to Configuration and DLNA setup
to make the change.
Music streaming
1. Once the UPnP/DLNA compatible server is configure to
share media files with your radio, you can start music
streaming.
2. On the main menu, select [Media Centre] and choose
[UPnP].
3. It may take a few seconds for the radio to complete the
scan for available UPnP servers. If no UPnP servers are
found, it will show [Empty List].
- 09 -

4. After a successful scan is done, select your UPnP
server.
5. The radio will show the media categories available from
the UPnP server, e.g. ‘Music’, ‘Playlists’ etc.
6. Choose the media files that you wish to play.
You can set the mode of playback under
Configuration>Playback setup.
My Playlist
You can make your own playlist from the UPnP music files.
Choose and highlight the song you want to add to playlist,
press and hold the [Dial/Select] knob, unit the sign
appears. The song will be added to My playlist.
Clear My Playlist
Remove all songs in My playlist to allow a new playlist to
be prepared.
Note - If you have DLNA compatible servers available,
follow the steps described above to browse the audio files
from DLNA compatible device on the radio to play.
Media Center
- 10 -

To receive the ordinary FM stations(No internet
connection is required), place the radio close to the
window and extend the antenna as far as it can go to get
the best reception. You may need to adjust the direction of
the antenna to improve reception.
On the main menu, scroll to FM radio.
Auto Scan
Press and release the [Dial/Select] knob, it will ask if you
want to "Auto Scan", choose yes to confirm and it will start
auto scanning the local FM radio stations that can be
received and stored as presets automatically. To change
listening a preset, press and release the [ ] button,
rotate the [Dial/Select] knob to select the preset and
press [Dial/Select] knob to recall the desired station.
Manual Scan
To seek a FM station manually, press and hold the [◄] or
[►] button, the radio will seek the previous or next
available station. If you want to fine tune the frequency,
press the [◄] or [►] to tune by 0.05Mhz.
Note: You may need to move the telescopic antenna
into different direction or adjust the length to find the
best reception level.
FM Radio
- 11 -

On the main menu, navigate to <Information Center>
and select to enter. You will find the options as follow:
Weather Information
The radio supports weather display in standby mode.
Navigate to Information Center> Weather Information,
choose the region you want it to display the weather
information. After region is selected, continue pressing
OK (push the [Dial/Select] rotary knob) unit it shows
<Add to Standby Display>, push the [Dial/Select] rotary
knob to confirm.
The date/time and weather info will appear alternatively
every 10 seconds under the standby mode.
When the weather screen is shown, press [►] button to
see the current weather information.
Press the [►] button again will show the forecast for the
next 4 days.
Continue to press the [►] button will display the detailed
weather information for each of the next 4 days. To view
more details for a particular day, rotate the [Dial/Select]
rotary knob to scroll down for more information.
Note: Weather information may vary and not sync to
the actual weather depends on the network situation.
System Information
You can view the information of the radio such as the
software version / Wireless Mac / IP address..etc.
Information Center
- 12 -

You can enjoy the music from other audio devices by
connecting the audio cable to the AUX IN connector at the
rear of the unit, such as smart phone, MP3 player, etc.
Bluetooth
1. The radio can receive and play music streamed by other
Bluetooth device.
Choose Bluetooth mode on the radio, it will be
discoverable on other Bluetooth devices.
2. Turn on Bluetooth on your device and look up the device
named “WR-100F” from the list.Select it to start pairing.
3. If the connection is successful, it will show “Connected”
on your Bluetooth device list.
4. You can start playing music from your Bluetooth device
now.
Aux In
Aux In/Bluetooth
- 13 -

Configuration
Time Display
You can choose the time display as analog or digital form.
Manage my mediaU
You can personalize your own favorite station list through
MediaYou website.
Set <Enable> on this option. It will prompt you to sign up
on www.mediayou.net before the function can be used.
On the main menu, you will find the <My mediaU> icon
appears after Enable is set.
Follow the steps below to sign up MediaYou:
1) Visit http://www.mediayou.net/
2) Then you have to find out the Mac Address of the radio
for registration.
To locate the MAC address, please follow the path
below:
2a) Go to Main Menu and select <Information Center>
2b) Go to <System Information>
2c) Choose <Wireless Info> and you will find your Mac
address.
3) Log-in Media You, click Radio, then input the Radio
name and Serial number (i.e. MAC Address) and save it.
- 14 -

You can then organize your own favorite stations or add
any new station which is not found on the station list.
Once the changes are done, your radio will synchronize
the changes immediately and you will find your favorite list
under <My MediaU> on the radio menu.
Note: If you are going to add URL which is not on
MediaU database, ensure the URL is an audio
streaming URL or contact MediaU to add it for you.
Network
Wireless Network Configuration
Press <Enter> to scan for wireless network list.
Wireless Network (WPS PBC)
The WPS allows to connect the radio with your router by
pressing one key on the radio and a WPS key on your
router for wifi connection, provided that your router has
the WPS function.
Manual Configuration
You can set the DHCP on or off, and enter the SSID name,
or delete the connected SSID.
Check network when power on
This is set to enable or disable <Check network when
power on>.
Date & Time
The time is set automatically to your local area.
You can choose to manual set the time if you want.
Configuration
- 15 -

Time Format setting
Time format setting: 12hours / 24hours
Date Format setting
Date format: YYYY/MM/DD, DD/MM/YYYY and
MM/DD/YYYY
If manual setup is selected, you will see an added item
Daylight Saving Time (DST) setting appeared on the list.
Alarm
Dual alarm clock
There are 2 alarm clocks available and settings as follow:
Schedule the alarm: You can schedule the alarm repeated
for every day, particular day in the week or just once.
Alarm sound: Wake to Radio (the radio must be one of the
favourite stations), Wake to Melody or Wake to Beeping
sound.
Alarm Volume: adjust your desire volume level.
NAP Alarm
If you would like to take a nap or need an alarm to due in
short time, you can use this function.
You can select the time from 5 minutes up to 120 minutes.
No Snooze function available for the NAP alarm.
Remark: The NAP Alarm will only release beeping
sound.
Snooze
When the Alarm sounds, press any keys on the radio unit
(except Power) will activate the <Snooze>. The alarm will
come on again 5 minutes later. You can always press
[Power] button to cancel the alarm.
Configuration
- 16 -

Remark: In case there is network issue renders the
wake to radio not working, it will automatically issue
melody sound after 1 minute.
Timer
Press [◄] or [►] button to set the timer, then press
[Dial/Select] knob to confirm. When the time is due, it will
release some beeping sound. Press the [Dial/Select] to
cancel. Press and hold the [Dial/Select] can cancel the
timer setting.
Language
There are 17 Languages available, such as English,
German, French, Norwegian, Italiano, Svenska, Dansk
and more.
Dimmer
You can adjust the backlight of the LCD with below
settings:
Power Saving
You can set the backlight to dim down when there is no
operation in a certain time of period.
Turn on
You can adjust the backlight level for the operation mode,
i.e. when you are operating the radio or checking on the
menu.
Display
You can choose the display in color or monochrome style.
Configuration
- 17 -

Power Management
This function is to allow the radio to go Standby if there is
no internet signal received in certain time to save power.
The default setting is 15 minutes. When the radio does not
receive any internet signal, the radio will go into Standby
after 15 minutes. Other time frame in 5 minutes and 30
minutes are available.
Sleep Timer
You can set the timer to turn the radio in standby after
certain time elapsed, from 15 minutes to 180 minutes in
the step of every 15 minute.
Internet Radio
You can set the Buffer and sound quality under this
setting.
- Buffer
Sometimes you may experience uneven playback of the
internet radio. This can happen if the internet connection
is slow or network congestion occurs. To help improving
the situation, you can choose longer buffer time to get a
few seconds of radio stream before beginning to play. The
default value is 2 seconds. You can choose 4 or 8 seconds
if you prefer to have a longer buffering time.
- Sound Quality
You can choose high or Low, the default setting is High.
Weather
The radio will display weather information in standby by
default. You can select the regions and temperature unit.
You can turn it off by selecting “Show on Standby > Off”.
Configuration
- 18 -
