Oceanled X Series User manual

LIGHT. YEARS AHEAD. WWW.OCEANLED.COM
OceanLED MANUAL / X-Series/ REVISION 1
INSTALLATION & OPERATION MANUAL
X-SERIES
X4 / X8 / X16

X-SERIES X4 / X8 / X16.
INSTALL & OPERATION MANUAL
1
Preface
READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL
CAUTION
(Risk Group 2): Possibly hazardous optical radiation emitted from this product. Do not stare at the operating
lamp. Maybe harmful to the eye.
WARNINGS
Before installing your OceanLED Light, read and follow all warning notices and instructions which are
included. Failure to follow safety warnings and instructions can result in property damage, severe injury or
even death.
Before installing your OceanLED Light, check local laws for restrictions regarding the use of coloured lights
in your area.
Salt is an inherently corrosive material. Metal parts and certain natural and man-made surfaces are
particularly susceptible to corrosion and deterioration when used in and around saltwater. Some OceanLED
lights contain combinations of plastic and polymer products which are impervious to saltwater corrosion,
however, screws and fasteners used for the installation must be of a marine grade type stainless steel or
equivalent and monitored annually to ensure the lights remain in service for years to come.
Never connect/disconnect lights with power applied as irreversible damage may occur. Ensure polarity of
power connections is correct. Failure to do this may invalidate the warranty.
X Series light is for mounting directly to a flat surface, with the cable passing through a ½” (12.5mm) hole.
Do not submerse your cable ends in water; cable and connections exposed to underwater submersion will
not be covered by warranty.
Mounting the light in any other configuration, other than those described in this guide, will invalidate its
warranty.
Never Use Solvents! Cleaners, fuel, and other products that may contain strong solvents, such as acetone,
that attack many plastics greatly reducing their strength and irreversibly damaging the special lens coatings
and cable sheathings.
If bottom painting your lights, ensure lens is free of any paint / residue.
Not suitable for use as on docks, piers or pilings. See our Dock Light products.
OUT OF WATER LOCATION
X Series light output differs in performance from the previous Xtreme XT range of lights when viewed out of
water. Do not mount X Series lights alongside previous Xtreme variations to maintain a consistent light
display.
DANGER
RISK OF ELECTRIC SHOCK OR ELECTROCUTION
This underwater light must be installed by a licensed or certified electrician in accordance with all applicable
local codes and ordinances. Improper installation will create an electrical hazard which could result in death
or serious injury to swimmers, installers, or others due to electrical shock, and may also cause damage to
property. Always disconnect the power to the light at the circuit breaker before servicing the light.

X-SERIESX4 / X8 / X16.
INSTALL & OPERATION MANUAL
2
Contents
1 Installation Checklist.......................................................................................................................................................3
2 Overview.........................................................................................................................................................................4
3 Preparing the Hull...........................................................................................................................................................5
4 Installation.......................................................................................................................................................................7
4.1 Installing The Light Fixture......................................................................................................................................7
4.2 Electrical Installation (12/24V DC).........................................................................................................................10
4.3 Control System Installation....................................................................................................................................14
4.4 Finalising The Installation......................................................................................................................................15
4.5 Test YourInstallation..............................................................................................................................................15
5 Operation / Maintenance..............................................................................................................................................16
5.1 Operation...............................................................................................................................................................16
5.2 Maintenance..........................................................................................................................................................17
5.3 Replacement Parts................................................................................................................................................17
6 Troubleshooting............................................................................................................................................................18
6.1 Troubleshooting Problems And Their Solutions ...................................................................................................18
7 Appendix.......................................................................................................................................................................21
7.1 Overall Dimensions ...............................................................................................................................................21
7.2 Light Setup.............................................................................................................................................................22
7.3 Cable Gauge Chart 12V........................................................................................................................................24
7.4 Cable Gauge Chart 24V........................................................................................................................................25
8 Warranty.......................................................................................................................................................................27
PRE-TEST
Always test the lights prior to installation. Failure to do this may result in additional installation time and could invalidate
the warranty.
IMPORTANT NOTICE
Attention Installer: This manual contains important information about the installation, operation and safe use of this
product. This information should be given to the owner and/ or operator of this equipment.
WARRANTY COVERAGE
Please refer to www.oceanled.com/warranty for full warranty statement.

X-SERIES X4 / X8 / X16.
INSTALL & OPERATION MANUAL
3
1 Installation Checklist
1. Decide on light spacing –OceanLED recommendations available.
2. Ensure correct cable gauge is used (refer to relevant cable gauge chart).
3. Control system chosen (switch control, OceanLED DMX RC control kit, 3rd party DMX control)
Max 32 lights per DMX chain (as per recommended by the DMX standard).
4. Preparing the hull.
6. Correct marine sealant applied evenly around the cable and around the perimeter of the light unit.
7. Correct hardware used for fixing of light fixture onto hull. Never leave vessel unchecked for a few
days after install. Always check routinely for a few days after installation to ensure the install is
correct and fully sealed.
8. Test installation BEFORE entering water. Never connect/ disconnect lights whilst powered ON.
9. Troubleshooting if required - most issues can be resolved by following the guidelines.

X-SERIESX4 / X8 / X16.
INSTALL & OPERATION MANUAL
4
2 Overview
Product Kit Includes:
Power Source
Most installations will utilize on-board 12/24V DC power supply from a marine battery. However, if AC to DC power
supply is being used, allow at least 15% reserve for voltage fluctuations due to variables beyond your control such as
ambient temperature and supply voltage fluctuations to ensure your lights are always receiving the proper voltage and
to ensure the power supply is not “overworked” causing premature failure. Use the chart below to determine the power
supply requirements.
Power Consumption and Recommended Fuse Values
Model
Current @ 12V
DC
Current @ 24V
DC
Max Nominal
Power
consumption
Minimum PSU Power
(15% reserve)
Recommended
fuse
12V/24V DC
X4
0.8A
0.4A
10W
12W
1.25A
X8
1.65A
0.75A
20W
23W
2A
X16
3.2A
1.5A
37W
43W
4A
Identifying your model
X16
X8
X4
4x Mounting Screws
Fuse Kit
X Light Unit with Bezel
(Bezel choice: White, Black, Stainless Steel)

X-SERIES X4 / X8 / X16.
INSTALL & OPERATION MANUAL
5
3 Preparing the Hull
OceanLED recommends using a qualified installer / technician when making modifications to your vessel.
Please also consult the manufacturer for more detail on modifications and installation.
OceanLED recommends use of provided screws: No.6 (3.5mm) x 1 inch (25mm) Pozi Self Tapping Pan Head
Screws - Stainless Steel. If alternative screws are used, do not use counter sunk or non-flat shoulder screws
to secure your lights to the hull (failure to do so will invalidate your warranty).
OceanLED does not recommend using the stainless steel bezel on conductive hulls (e.g., carbon fibre,
aluminium/steel).
If the lights (with plastic bezel) are to be fitted to a conductive hull or any other metal surface/ outboard jet
bracket, Isolating Mounting Kit must be used. Please contact OceanLED for additional details.
Isolating Mounting Kit
4x M3.5 x 35mm Nylon Bolt
4x Nylon Washer
4x M3.5 Nylon Nut
(1x spare of each component)
Part Number:
019913 - D3 and X-Series Isolating Mounting Kit
Depth/Spacing
Ideally mount your lights at similar depth levels to ensure matching colour consistency through the water. Deeper lights
will look duller and possibly differ in colour compared to shallower mounted units.
Spacing / Install Depth
X4 / X8 / X16
Recommended Spacing
0.5-1m (2-3’)
Recommended Installation depth (From the light waterline)
100-200mm (4-8”)
Hole Cut Out
Hole Cut out size: 12.5mm (1/2”)
Overall Dimensions
See overall dimension schematic –See Appendix (Section 7.1)

X-SERIESX4 / X8 / X16.
INSTALL & OPERATION MANUAL
6
Mounting location considerations:
•If positioning lights on a transom, more small lights look better than few bigger lights. E.g., 4x X8’s look better than
2x X16’s.
•When lights are pointing downwards, the light can reflect off a sandy seabed giving a mirrored effect, and light will
bounce back creating even more illumination.
•If positioning lights on a transom, take into consideration swim platforms and obstacles that may block the initial
portion of the light, it may be necessary to use the next model size up.

X-SERIES X4 / X8 / X16.
INSTALL & OPERATION MANUAL
7
4 Installation
4.1 INSTALLING THE LIGHT FIXTURE
Additional items required not supplied by OceanLED:
•Marine sealant - 3M 4200 or equivalent
•Cable ties
•Waterproof cable connectors / Butt splices glue lined heat shrink / Junction Box* (optional)
•Philips Screwdriver or Pozidrive #2 Screwdriver Bit
•12.5mm (1/2”) Hole Saw Cutter
•Drill Bit for Screws pilot hole
*Optional 4-Way Junction box available from OceanLED. Please contact OceanLED or your representative for further information.
Ensure mounting location is flat and check internally for ease of access or if there is a rib, strut, stringer
or other hull irregularity that may interfere with the installation.
OceanLED recommends dry fitting all products. Before applying sealant, please ensure the surface is clean
of any dust, dirt or grease. When installing, be sure that the light fits the area and secures to the hull using
the appropriate hardware before applying any sealant.
When applying sealant tothe light fixture, use OceanLED packaging material such as the light cardboard box
when placing the light on the ground face down to prevent lens damage.
Never use power tools to secure your lights; hand tighten only.
X Series (X4 / X8 / X16)
Kit Includes
X Light
4x Mounting Screws

X-SERIESX4 / X8 / X16.
INSTALL & OPERATION MANUAL
8
Installation Overview:
Exploded view of the standard assembly.
Exploded view of the assembly with Isolating Mounting Kit.

X-SERIES X4 / X8 / X16.
INSTALL & OPERATION MANUAL
9
Installation (Once hull preparation is complete)
1. Testlight(s) before fitting.
2. Fit the bezel over the light unit.
3. Applygenerousamountsofthesealantto theback perimeterofthelightbody①andaroundcablewhereitmeets
the back of the light ②. There should be an unbroken bead of sealant around the perimeterofthelight unit ①.
It is critical to cover the entire body and circle the mounting screw holes so that there is a continuous
and unbroken bead of sealant.
4. To guarantee correct light orientation ensure the OceanLED logo ③on the front is facing upwards. Insert the
light on to the hull, feeding the cable through first and seat into place. Press the light hard into the hull and twist
slightly to spread the sealant around behind the light to ensure good adhesion.
5. Cover the screws ④threads with the sealant and screw into the pre-drilled pilot holes.
6. Tighten the screws with a hand tool ONLY! DO NOT over-tighten the screws, as you could damage the light
enclosure, and will void your warranty.
7. Once you are satisfied that the unit is fully tightened, you will notice that sealant has squeezed out from
around the perimeter of the light. Using a thinner or cleaner, apply to cloth and wipe off excess sealant to
leave a clean seal. AVOID CONTACT WITH LENS. If you do not see sealant squeeze out from the body,
you have not used enough sealant or tightened the unit enough to the hull. Carefully examine the
installation to make sure the sealant you have installed on the unit is fully watertight. Ifin doubt, remove
light, re-apply sealant and re-install.
①
②
③
④

X-SERIESX4 / X8 / X16.
INSTALL & OPERATION MANUAL
10
4.2 ELECTRICAL INSTALLATION (12/24V DC)
Additional items required not supplied by OceanLED:
•Waterproof cable connectors / Butt splices glue lined heat shrink / Junction Box* (optional)
•Sufficient cable to connect to DC Power Source
*Optional 4-Way Junction box available from OceanLED. Please contact OceanLED or your representative for further information.
Always consult a qualified electrician when connecting OceanLED light fixtures.
When connecting light units, please note that all OceanLED lights will operate within a specific voltage range.
Please check the electrical information to ensure cable gauge, fuse and breakers size follow the
recommendations.
For complete instructions on DC connections, please refer to ABYC codes of practice and other applicable
codes and ordinates for DC connections.
Where multiple lights are fitted, and especially on 12V systems, it is advised to use a relay system to supply
the switched power to the lights, to reduce load on the switch and voltage drops caused by long cable runs
to the switch location.
Connecting the light fixture
X-Series DMX Colours
The X4, X8 & X16 Colour change models can either be used in DMX mode (using the OceanDMX RC controller kit) or
simple DC switch mode, where a simple toggle of the power switch can be used to change colour modes. To use in
DC switched mode; connect DC power +Ve to the RED wire, and DC power -Ve to the BLACK, BROWN & YELLOW
wires:
For connecting X Series Lights with the OceanDMX RC Controller Kit, please refer to the OceanDMX RC Installation
Manual. Note that when using with the DMX controller, the cable from the light to the junction box cannot be extended.
X-Series Single Colour
For the X-Series single colour connect DC power +Ve to the RED wire, and DC power -Ve to the BLACK wire.
+
-
+
-

X-SERIES X4 / X8 / X16.
INSTALL & OPERATION MANUAL
11
Electrical Installation
1. Depending on the model and number of lights installed, you will need to pull the correct sized power cable
from the DC power source (breaker/fuse panel) to the light locations to supply constant power to the light
units. It is imperative that the correct sized tinned marine grade cable is usedto avoid voltage drop issues.
See Chapter 7: Appendix for recommended cable gauges.
2. Using waterproof butt splices or IP66 waterproof junction boxes, make the connections at either end of the
system to attach the lights to the DC system. Make sure any heatshrink used completely encapsulates the
outer wire sheath (the use of glue-lined heat shrink is highly recommended to ensure water tightness).
Never leave the bare cables unprotected. Take care to not leave the bare wire ends in bilge water before
making the waterproof connections. Water deposits in the connectors and cables will cause corrosion. Over
time water can also work its way into the unit along the inside of the cable due to capillary action causing the
light to fail. This will NOT be covered under warranty.
3. It is imperative that either the OceanLED supplied fuse on eachpowerlineto eachlight or a suitable protection
device is used to protect the cable/light unit. Failure to do so will void the warranty. See table in Chapter 2:
Power Consumption and Recommended Fuse values. Make sure any heatshrink used completely
encapsulates the outer wire sheath (the use of glue-lined heat shrink is highly recommended to ensure water
tightness).
4. Securecablesensuringwhere the cableexits the lightit is not under undue stress.Finishand test the light units
BEFORE the vessel goes into the water.
+
-
+
-

X-SERIESX4 / X8 / X16.
INSTALL & OPERATION MANUAL
12
Fuse Kit wiring/assembly diagram.
Example of the DC Installation –X-Series with the OceanLED Junction Box

X-SERIES X4 / X8 / X16.
INSTALL & OPERATION MANUAL
13
Example of the DC Installation –X-Series DMX Colours with the OceanDMX RC Controller
The DMX standard recommends a maximum of 32 devices to be connected in one chain. If installation
requires more lights than this, please contact OceanLED for advice.
For the X-Series installation do not extend the 3m cable length to the DMX junction box,for longerconnection
use of additional DMX junction boxes will be required.
Do not submerse your cable ends in water; cable and connections exposed to underwater submersion will not be covered by warranty.

X-SERIESX4 / X8 / X16.
INSTALL & OPERATION MANUAL
14
4.3 CONTROL SYSTEM INSTALLATION
Switch Control
Additional items required not supplied by OceanLED:
•Power switch
•Push switch (Normally closed, momentary type) –optional for DMX Colours
The X-Series Single Colour and X-Series DMX Colours (used in the DC switch mode) installations will utilize simple
power switch to control the lights. For the X-Series DMX Colours used in the DC switch mode additional in line push
switch maybe installed to simplify the changing mode operation.
Ensure power is disconnected before attempting to connect or solder any wire.
OceanLED DMX Control (X-Series DMX Colours only)
To use OceanLED DMX Control, OceanDMX RC Controller Kit must be purchased from OceanLED. Please
consult the X Series Light Choice Diagram for details (see Chapter 7.2).
To enable the DMX Control of all lights, OceanLED DMX Junction Box must be used. One junction box can
be used to power and control maximum of four X-Series Colour DMX lights. If the installation consist of more
than four lights additional DMX Junction Box/es will be required. The DMX Junction boxes can be linked in
chain.
Please consult the manual for the purchased OceanDMX RC Controller for more information on installation and
operation.
DMX Addressing (X-Series DMX Colours only)
•OceanLED X-Series Colour DMX lights use 4 Channels DMX-512 standard for communication.
•The default addresses of the colour lights are:
Channel 1, DMX address: 1
Red
Channel 2, DMX address: 2
Green
Channel 3, DMX address: 3
Blue
Channel 4, DMX address: 4
White
The DMX standard recommends a maximum of 32 devices to be connected in one chain, and a maximum
network length of 300m. If installation requires more lights than this, or a longer network length then please
contact OceanLED for advice.

X-SERIES X4 / X8 / X16.
INSTALL & OPERATION MANUAL
15
4.4 FINALISING THE INSTALLATION
The X Series body is constructed from chemically resistant optical polymer and doesnot require further protection. The
lens is pre-coated with a specialized Tritonium® coating which makes the surface of the lens a non-stick layer.
OceanLED does not recommend that bottom paint or any type of anti-fouling agent is applied to the light body
apart from the front bezel, as damage may occur due to chemical incompatibility.
4.5 TEST YOURINSTALLATION
Always test the lights BEFORE the vessel goes back into the water. At this final stage make sure all of the system is
operational. If you have any issues, please contact your local OceanLED representative.
Never install a new light fixture then leave the vessel in the water unchecked for several days.
When the vessel is placed in the water, immediately check for leaks. Note that very small leaks may not be
readily observed. It is best not to leavethe vessel in the waterfor more than 3 hours before checking it again.
If there is a small leak, there may be considerable bilge water accumulation after 24 hours. If a leak is
observed, youmust TAKE ACTION IMMEDIATELY to prevent damage.

X-SERIESX4 / X8 / X16.
INSTALL & OPERATION MANUAL
16
5 Operation / Maintenance
5.1 OPERATION
X-Series lights have active thermal protection. This means that while underwater, they run at full power due to water
cooling. Moderate dimming may be noticeable with above water installations when high ambient temperatures are
reached to avoid damage.
Single Colour Strobe
To enter strobe mode, toggle the power on and off quickly twice (on →off →on →off →on). They should now strobe
in a pseudo-random pattern. To reset from strobe mode, turn off then back on again.
DMX Colour Change
Please refer to the purchased DMX Controller for details about how to use it.
Colours control with DC switch operation:
The colour change has three modes of operation, single colour mode, cycle / programming mode, and strobe mode:
1. Single colour mode –this mode is entered when the light is first turned on. The light will be a single colour,
either a default blue, or a previously selected colour.
2. Strobe mode –to enter this mode, turn off the light for less than 1 second, then back on again. The light will
flash in a pseudo-random pattern - the colour will be the same as that in single colour mode.
3. Cycle / Program mode, to enter this toggle the power to the unit off twice for less than 1 second each time
(on→off →on →off →on). Thelightwill then slowly cycle and fade through the colour spectrum(see diagram
below for cycle order). It can be left in cycling if required, or alternatively, once the light shows the desired
colour this can be stored by switching the light off for more than 2 seconds. When the light is switched back on
it will be back in single colour mode, displaying the previously selected colour. Single colour mode –this mode
is entered when the light is first turned on.The light will be a single colour, either a default blue, or a previously
selected colour.
Blue → Red → Green → Blue → White → Blue/White → Red/White → Green/White
NOTE: If during the aboveoperations, one or more lightsconnected go out of sync,simply switch off the lights formore
than 2 seconds, then re-enter cycle mode to re-select the colour.
Colour Change Fade Cycle Order

X-SERIES X4 / X8 / X16.
INSTALL & OPERATION MANUAL
17
Diagnostic LEDs
The X-Series is fitted with an advanced diagnostic indicator system. The X-Series X4 Colours have one small orange
diagnostic LED, while the rest of the X-Series lights havetwo small indicator LEDs (one red and one orange) within the
unit, visible through the front lens.
X-Series X4 Colours (One Diagnostic LED):
When the X-Series X4 Colours unit is first turned on, the single orange diagnostic LED will flash briefly. This is normal
operation and is part of the start-up procedure, to show that the LED is functioning. During normal operation the
diagnostic LED should not be illuminated. Please see the table in chapter 6.1 for more details.
X-Series lights excluding X4 Colours (Two Diagnostic LEDs):
When the unit is first turned on, both red and orange indicator LED's will flash briefly. This is normal operation and is
part of the start-up procedure, to show that the LEDs are functioning. During normal operation, the indicator LEDs
should not be illuminated. Please see the table in chapter 6.1 for more details.
5.2 MAINTENANCE
Marine growth can build up quickly on the light and can reduce the light’s performance injust a few weeks.
To help prevent this, all OceanLED lights have been coated with a specialized Tritonium® coating which helps to
prevent marine growth from adhering to the glass. Lightsshould be cleaned with a boat brush or similar bi-weekly,or as
needed tokeep the lens of the lightclean.
Growth varies greatly around the world and maintenance is imperative to the proper operation and longevity of the
product. If heavy fouling occurs, growth can be removed from the lens using a plastic scraper and moderate pressure
underwater.If cleaning the lens while the boat is out of the water, wet the lens before scraping. Never scrape or try to
removebarnacles from a dry lens.
Harsh cleaning solvents will damage the light and Tritonium coating.
Never use high pressurejet wash to clean the lens / bezel as this will damage the seals and void the warranty.
Corrosion of wire, and/or water ingress into the light unit via cable is NOT covered under warranty.
5.3 REPLACEMENT PARTS
The light source of this luminaire is not replaceable; when the light source reached itsend of the life the whole luminaire
shall be replaced.
If the external flexible cable from the back of the light is damaged, contact your local OceanLED representative to
arrange for replacement (cable must only be replaced by OceanLED, service agent or a similar qualified person).
Lost, broken and worn parts can be replaced on request and can be obtained through your local OceanLED
representative.

X-SERIESX4 / X8 / X16.
INSTALL & OPERATION MANUAL
18
6 Troubleshooting
6.1 TROUBLESHOOTING PROBLEMS AND THEIR SOLUTIONS
The X-Series is fitted with an advanced diagnostic indicator system. The X-Series X4 Colours have one small orange
diagnostic LED, while the rest of the X-Series lights havetwo small indicator LEDs (one red and one orange) within the
unit, visible through the front lens.
X-Series X4 Colours (One Diagnostic LED):
When the X-Series X4 Colours unit is first turned on, the single orange diagnostic LED will flash briefly. This is normal
operation and is part of the start-up procedure, to show that the LED is functioning. During normal operation the
diagnostic LED should not be illuminated.
The table below summarizes the detected fault modes:
X-Series - X4 Colours
Orange LED
Main LEDs
CHECK
On
Off
Input voltage is too low –less than ~9V. Check voltage of power source and cabling for bad
connections and rectify.
Flashing
Off
Input voltage is too high –above ~32V. Check voltage of the power source and rectify.
Quick Flash
Off
Unit has detected a fault with the wiring, or the power source is not capable of supplying the
required current. The input voltage is dropping below the minimum allowed during start-up.
After five start-up attempts the unit will shut down and both indicator LEDs will flash
continuously. This could be due to a poor power source (e.g., discharged battery) or voltage
drops caused by poor connections or incorrect wire gauge.
On
On
Internal fault detected with temperature sensor –if this issue persists contact your dealer.

X-SERIES X4 / X8 / X16.
INSTALL & OPERATION MANUAL
19
X-Series excluding X4 Colours (Two Diagnostic LEDs):
When the unit is first turned on, both red and orange indicator LED's will flash briefly. This is normal operation and is
part of the start-up procedure, to show that the LEDs are functioning. During normal operation, the indicator LEDs
should not be illuminated.
The table below summarizes the detected fault modes:
X-Series (excluding X4 Colours)
Red LED
Orange LED
CHECK
Flashing
Off
The unit has been shut down if the temperature is too high.
Off
On
Input voltage is too low –less than ~9V. Check voltage of power source and cabling for bad
connections and rectify.
Off
Flashing
Input voltage is too high –above ~32V. Check voltage of the power source and rectify.
Flashing
Flashing
Unit has detected a fault with the wiring, or the power source is not capable of supplying the
required current. The input voltage is dropping below the minimum allowed during start-up.
After five start-up attempts the unit will shut down and both indicator LEDs will flash
continuously. This could be due to a poor power source (e.g., discharged battery) or voltage
drops caused by poor connections or incorrect wire gauge.
Flashing
On
Internal fault detected with temperature sensor –if this issue persists contact your dealer.
If the light doesn’t recognize the fault but the fault is still present, please check the table on the following page.
