OHAUS CHAMP II BASE User manual

Ohaus Corporation
29 Hanover Road, P.O. Box 900
Florham Park, NJ 07932-0900
Phone: [phone]
Fax: [phone]
CHAMP II SCALE with CD11
Operating and Installation Instructions
All manuals and user guides at all-guides.com
all-guides.com

2
Ohaus Corporation, 2 Hanover Road, Florham Park, New Jersey, 07 32, USA
Declaration of Conformity e, Ohaus Corporation, declare under our sole responsibility that the instrument models listed below
marked with CE - are in conformity with the directives and standards mentioned.
Konformitätserkärung ir, die Ohaus Corporation, erklären in alleiniger Verantwortung, dass die untenstehenden aagentypen,
instrument mit CE - mit den genannten Richtlinien und Normen übereinstimmen.
Déclaration de conformité Nous, Ohaus Corporation, déclarons sous notre seule responsabilité, que les types de instrument ci-
dessous cité - munis de la mention «CE» - sont conformes aux directives et aux normes mentionnées ci-après.
Declaración de Conformidad Nosotros, Ohaus Corporation, declaramos bajo responsabilidad exclusiva que los modelos de
instrumento indicados a continuación - con el distintivo ,CE - están conformes con las directivas y normas citadas.
Dichiarazione di conformità Noi, Ohaus Corporation, U.S.A, dichiariamo sotto nostra unica responsabilità, che i tipi di strumento
specificati di seguito - contrassegnati con la marcatura CE - sono conformi alle direttive e norme citate.
Instrument Type/ aagentyp/Type de instrument/Modelo de instrumento/Tipo di strumento CHAMP II SCALE
Marked with:
Gekennzeichnet mit:
Munis de la mention:
Con el distintivo:
Contrassegnati con la
Marcatura:
Directive
Richtlinie
Directive
Directiva
Direttiva
Standard
Norm
Norme
Norma
Norma
EU 73/23 Low Voltage
EU 73/23
Niederspannung
EU 73/23 Basse tension
EU 73/23 Baja tensión
EU 73/23 Bassa
tensione
EU 89/336, 92/31, 93/68
Electromagnetic
compatibility
EU 89/336, 92/31, 93/68
Elektromagnetische
Verträglichkeit
EU 89/336, 92/31, 93/68
Compatibilité
électromagnétique
EU 89/336, 92/31, 93/68
Compatibilidad
electromagnética
EU 89/336, 92/31, 93/68
Compatibilità
elettromagnetica
EC1010-1 & EN60950:1992 Safety Regulations
IEC1010-1 & EN60950:1992 Sicherheitsbestimmungen
IEC1010-1 & EN60950:1992 Consignes de sécurité
IEC1010-1 & EN60950:1992 Disposiciones sobre seguridad
IEC1010-1 & EN60950:1992 Prescrizioni . di sicurezza
EN55022:1987 Emissions
EN50082-1:1992 Immunity
NOTE: The displayed value may be adversely affected under
extreme electromagnetic influences, eg. when using a radio unit
in the immediate vicinity of the device. Once the interference
has been rectified, the product can once again be used for its
intended purpose.
EN55022:1987 Funkstörungen
EN50082-1:1992 Immunität
Hinweis: Unter extremen elektromagnetischen Einflüssen z.B.
bei Betreiben eines Funkgerätes in unmittelbarer Nähe des
Gerätes kann eine Beeinflussung des Anzeigewertes verusacht
werden. Nach Ende des Störeinflusses ist das Produkt wieder
bestimmungsgemäss benutzbar.
EN55022:Emissions parasites
EN50082-1:1992 Immunité
Remarque: Dans des conditions d'influences électromagnètiques
extrêmes, par exemple en cas d'exploitation d'un appareil radio
à proximité immédiate de l'appareil la valeur d'affichage risque
d'être influencée. Une fois que l'influence parasite est terminée,
le produit peut être de nouveau utilisé de manière conforme aux
prescriptions.
EN55022:1987 Radiointerferencias
EN50082-1:1992 Inmunidad
Nota: Bajo influencias electromagnèticas extremas, p.ej. cuando
funciona una radio en las inmediaciones del aparato, se pueden
alterar los valores del display. Cuando concluye el efecto
perturbador, el producto puede ser utilizado de nuevo, de
acuerdo con lo estipulado.
EN55022:1987 Radiointerferenze
EN50082-1:1992 Immunità
Nota: ll valore visualizzato può essere influenzato negativamente
dalla presenza di forti interferenze elettromagnetiche, per
esempio quando viene usata una radio in prossimità della
bilancia. Eliminata la fonte dell'interferenza, il prodotto può
essere nuovamente utilizzato per le funzioni cui è preposto.
All manuals and user guides at all-guides.com

3
NOTE:
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY ITH
THE LIMITS. FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15
OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE
PROTECTION AGAINST HARMFUL INTERFERENCE HEN THE
EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS
EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO
FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE ITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY
TO CAUSE HARMFUL INTERFERENCE IN HICH CASE THE USER
ILL BE REQUIRED TO CORRECT THE INTERFERENCE AT HIS O N
EXPENSE.
THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS A LIMITS
FOR RADIO NOISE EMISSIONS FROM DIGITAL APPARATUS AS SET
OUT IN THE INTERFERENCE-CAUSING EQUIPMENT STANDARD
ENTITLED DIGITAL APPARATUS, ICES-003 OF THE DEPARTMENT OF
COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS
RADIOELECTRIQUES APPLICABLES AUX APPAREILS NUMERIQUES
DE CLASSE A PRESCRITES DANS LA NORME SUR LE MATERIEL
BROUILLEUR : APPAREILS NUMERIQUES, NMB-003 EDICTEE PAR LE
MINISTRE DES COMMUNICATIONS.
Unauthorized changes or modifications to this equipment are not
permitted.
Before plugging in the Indicator, make sure that the voltage of the power
adapter and plug match.
All manuals and user guides at all-guides.com

4
CHAMP II BENCH SCALE
1. Overview
CHAMP II is a single load cell bench scale connected
to CD-11 Industrial Indicator.
2. Physical Descriptions
Construction
Platform - Fabricated stainless steel
Scale Base - Formed and welded mild steel, painted
black.
Overloading
Corner Loading - 100% of Full Capacity
Safe Overload - 150% of Full Capacity
Ultimate Overload - 300% of Full Capacity
Operation Environment
Champ II is designed to meet NTEP 3000d
requirements to operate in a temperature range from
-10!C to 40!C, 0 to 95% relative humidity.
Models Available/Factory Set-up
MODEL PLATFORM CAPACITY
CH15R 305 X 355 / 12" x 14" 15 KG x 0.002
CH30R 305 X 355 / 12" x 14" 30KG x 0.005
CH60R 305 X 355 / 12" x 14" 60KG x 0.01
CH60L 400 X 500 / 16" x 20" 60KG x 0.01
CH100R 400 X 500 / 16" x 20" 100KG x 0.02
CH150R 420 X 550 / 17" x 22" 150KG x 0.02
CH300R 420 X 500 / 17" x 22" 300KG x 0.05
All manuals and user guides at all-guides.com

5
3. Installation Procedures
Assembly and Installation
Examine the shipping box for any signs of damage. If
DAMAGE is found, make a claim with the carrier
immediately.
Open the box and remove the scale assembly. Place
the scale assembly on a stable flat surface.
Follow the Champ II Scale Assembly Instructions.
Level the scale, apply power and weigh.
Good rong
Level Indicator
BEFORE CALIBRATION OR USE, REMOVE THE
RED PLASTIC SHIPPING TABS IN THE CORNERS
OF THE SCALE BASE.
Troubleshooting
If operational difficulties are encountered, first obtain
as much information as possible regarding the
problem. Failures and malfunctions often may be
traced to simple causes such as loose connections to
the indicator, low battery power, improper setup, etc.
If simple causes cannot be found, additional
troubleshooting is best performed by substitution. A
PCB or LOAD CELL believed to be defective may be
checked by replacing the suspect part with known
good part and then observing whether the problem is
corrected.
All manuals and user guides at all-guides.com

6
Load Cell Replacement
Remove the scale platform and disconnect the
indicator battery and AC power source.
IMPORTANT NOTE
ait 30 seconds after removing power to the indicator before unplugging the load
cell cable.
Remove the top load cell mounting bolts that secure the top frame to the load cell.
Set the top frame and load cell spacer aside.Remove the bottom load cell
mounting bolts. The load cell assembly can be removed from the lower base.
hen reinstalling a load cell, reverse the preceding steps. Lubricate the threads
and under the head of the hex bolts before reinstalling. Using a torque wrench,
tighten the hex bolts to the following torque specifications:
Model Torque
CH15R 20 N.m (15 Ft/Ib)
CH30R 20 N.m (15 Ft/Ib)
CH60R 20 N.m (15 Ft/Ib)
CH60L 20 N.m (15 Ft/Ib)
CH100R 30 N.m (22 Ft/Ib)
CH150R 40 N.m (30 Ft/Ib)
CH300R 50 N.m (37 Ft/Ib)
Overload Stop Adjustments
The overload stop gaps must be checked and reset if the top or
bottom frame, or load cell is replaced. To set the gaps, remove
the platform, loosen the jam nuts (refer to Figure 1-1), then use
the proper size feeder gauge in the gap, turn the set screws
until a slight drag on the feeder is felt. Tighten the jam nut and
recheck the gap. Re-adjust if necessary, cover the platform
and check for full capacity. Refer to Figure 1-2 for the location
of the overload stops and Table A for the gap settings per
Order Number.
All manuals and user guides at all-guides.com
all-guides.com

7
Figure 1-1 Figure 1-2
Position CH15R
CH30R
CH60R CH60L
CH100R
CH150R CH300R
A2mm
(0.078)
2mm
(0.078)
4mm
(0.157)
4mm
(0.157)
4 mm
(0.157)
B0.5mm
(0.02)
0.5mm
(0.02)
0.75mm
(0.03)
0.75mm
(0.03)
1mm
(0.04)
Table No. 1 Overload Gap Settings
Shift Test
A shift test verifies that all sections of the scale platform weigh
within tolerance. If the scale does not pass the shift test, verify
the overload stop gaps before replacing the load cell. No
adjustment for the shift is possible. If the shift test cannot be
passed, the load cell must be replaced.
Place test weights equal to one third scale capacity
sequentially at each of the positions A, B, C, D, as shown in
Figure 1-3. Note the indicator reading at each position.
AC
DB
Figure 1-3 Shift Test
AA
AA
BB
Overloa d Sto
p
Jam NutSet Screw
Gap
All manuals and user guides at all-guides.com

8
Positions A, B, C, and D are centered at the each
quarter of the scale platform. The following table
shows the tolerance in d (division) for the shift test.
Scale
Capacity
Test
eight
Acceptable
Tolerance
(New Scale)
Maintenance
Tolerance
(In Service)
3,000d 1,000d "1.0d "2.0d
Table No. 2 Tolerance Table for Shift Test
Factory Setup
hen Champ II bench scales are connected to
indicators in the factory, a full span calibration is
conducted during the configuration. Because of
transportation, local environment and variation in the
earth's gravitation field, the original factory settings
must be verified and checked in the field before use.
Parts list
OHAUS PART NO. DESCRIPTION
71129642 Indicator Bracket Assembly
71125105 Stainless Steel Column, 350 mm high
71125103 Stainless Steel Column, 680 mm high
71129064 Column Bracket
71123975 Load Cell, MT1241-50kg CH15R
71123976 Load Cell, MT1241-100kg CH30R, CH60R, CH60L
71123979 Load Cell, MT1241-250kg CH100R
71124310 Load Cell, MT1260-500kg CH150R, CH300R
71102504 Load Cell Mounting Bolts, M6 x 25
71102512 Load Cell Mounting Bolts, M8 x 230
71129104 Stainless Steel Platform, 305 x 355
71129105 Stainless Steel Platform, 400 x 500
71129106 Stainless Steel Platform, 420 x 550
71125079 Platter Rubber Supporter
71125924 Corner Rubber Supporter, 305 x 355
71125006 Corner Rubber Supporter, 400 x 500 & 420 x 550
71127181 Cover for M6 Screw
71128342 Cover for M8 Screw
71125009 Adjustable Foot (All)
All manuals and user guides at all-guides.com

9
All manuals and user guides at all-guides.com

10
CHAMP II BENCH SCALE
Specifications
Model CH15R11 CH30R11 CH60R11 CH60L11 CH100R11 CH150R11 CH300R11
Capacity x Readibility
(kg)* 15 x 0.002 30 x 0.005 60 x 0.01 60 x 0.01 100 x 0.02 150 x 0.02 300 x 0.05
(lb) 30 x 0.005 60 x 0.01 120 x
0.02 120 x 0.02 200 x 0.05 300 x 0.05 600 x 0.1
Factory Set Resolution 1 : 7500 1 : 6000 1 : 6000 1 : 6000 1 : 5000 1 : 7500 1 : 6000
Max. Resolution 1 : 15000 1 : 15000 1 : 12000 1 : 12000 1 : 10000 1 : 15000 1 : 15000
NTEP Resolution 1 : 3000 1: 3000 1 : 3000 1 : 3000 1 : 2500 1 : 3000 1 : 3000
Load Cell - rated IP 65 50 kg 100 kg 250 kg 500 kg
Base size (in/cm) 12 x 14 / 30.5 x 35.5 16 x 20 / 40 x 50 17 x 22 / 42 x 55
Platter Construction Stainless steel 304
Base Structure Black polyurethane painted steel
Column height (in/cm)
Stainless Steel 14 / 35 28 / 70
Scale eight (lb/kg) 24 / 11 49 / 22 55 / 25
Shipping eight 30 / 14 57 / 26 70 / 31
Display (
(in/cm) LCD 1/ 2.54 cm
Keyboard 4 function membrane switches
Power 9 VDC / 150 mA AC adapter or six alkaline C - type batteries
Typical battery life 250 hours / 100 hours continues use
eighing units g, kg, lb
Modes eighing & parts counting
Zeroing Range 2%, 18% or 100% capacity
Span Calibration 10% to 100 %
Repeatability +/- 0.0 1% of the rated load
Linearity +/ - 0.02 % of the rated load
Safe Overload 150 %
Relative Humidity 10% - 95%
Operating Temperature - 10! C to 40! C
Storage Temperature - 20! C to 60! C
Item Ordering Number CH15R11 CH30R11 CH60R11 CH60L11 CH100R11 CH150R11 CH300R11
* Factory set resolution.
** Model CH100R11 is factory calibrated for 100kg. Max. capacity is 150 kg .
User selectable calibration is 150kg x 0.002
M
Me ee et ts s R Re eq qu ui ir re em me en nt ts s o of f A Ap pp pr ro ov va al l A Ag ge en nc ci ie es s: : U UL L, , F FC CC C, , C CE E S Sa af fe et ty y E EN N 0 09 95 50 0, , E Em mi is ss si io on ns s E EN N5 55 50 02 22 2, , I Im mm mu un ni it ty y E EN N5 50 00 08 82 2- -1 1
I
IP P R Ra at ti in ng g: : E Eq qu ui iv va al le en nt t t to o I IP P 5 54 4. .
NTEP CERTIFIED : CD-11 INDICATOR NTEP NO. 99-100, CHAMP II BASE NTEP NO. 99-203
All manuals and user guides at all-guides.com

11
WARRANTY
Ohaus products are warranted against defects in materials and workmanship from the date
of delivery through the duration of the warranty period. During the warranty period Ohaus will
repair, or, at its option, replace any component(s) that proves to be defective at no charge,
provided that the product is returned, freight prepaid, to Ohaus.
This warranty does not apply if the product has been damaged by accident or misuse,
exposed to radioactive or corrosive materials, has foreign material penetrating to the inside
of the product, or as a result of service or modification by other than Ohaus. In lieu of a
properly returned warranty registration card, the warranty period shall begin on the date of
shipment to the authorized dealer. No other express or implied warranty is given by Ohaus
Corporation. Ohaus Corporation shall not be liable for any consequential damages.
As warranty legislation differs from state to state and country to country, please contact
Ohaus or your local Ohaus dealer for further details.
Ohaus Corporation
29 Hanover Road,
Florham Park, NJ 07932, USA
Tel: [phone],
Fax: [phone]
ith offices worldwide.
P/N 80250675-REV 1, Ohaus Corporation 1999, all rights reserved.
All manuals and user guides at all-guides.com
all-guides.com
