OHAUS Navigator NV212 User manual

Navigator®Balances
Instruction Manual
99 Washington Street
Melrose, MA 02176
Phone [phone]
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com

Navigator®EN-1
1. INTRODUCTION
This manualcontains installation, operation and maintenance instructions for the Navigator®Series.
Please read the manual completely before using the balance.
1.1 Safety Precautions
Please follow these safety precautions:
•Verify that the AC Adapter input voltage matches the localAC power supply.
•Only use thebalance in dry locations.
•Do not operate the balance in hostile environments.
•Do not drop loads on the platform.
•Service should be performed only by authorized personnel.
1.2. Controls
Standard (non-approved) models – shownwith LED display.
Button Functions
Zero
Yes
Short Press (when on): Sets display to zero
(when off): Turns balance on
Long Press (when on): Turns the balance off
Short Press (in Menu): Selects/accepts displayed setting
Print
Units
No
Short Press: See Interface Manual for operation description.
Long Press: Toggles through active units
Short Press (in Menu): Toggles through available settings
Function
Mode
Back
Short Press: Selects function setting
Long Press: Selects active Mode
Short Press (in Menu): returns to previous settings
Tare
Menu
Exit
Short Press: Enter / clear a Tare value
Long Press: Enters User Menu
Short Press (in Menu): Quickly exit User Menu
IR Sensor-Left
IR Sensor-Right IR Sensors can be programmed to act as “touchless” buttons. See the User Menu section 4.3 for the available settings.
The IR Sensors can be activated bya hand or other object that is placed about 12mm (½ inch)
above the sensor locations. The sensor activation distance will vary based on the reflective nature
of the object. If unwanted activations occur due to unique situations the sensors can be turned off.

EN-2 Navigator®
F1 F2 F3 F4
Approved models – shown with LCD display.
2. INSTALLATION
2.1 Package Contents
•Balance
•Pan •Power Adapter •Instruction Manual •Warranty Card
2.2 Transportation Lock
The Transportation Lock is located under the balance.Rotate the pointer to theunlocked position.
Note: No shipping lock on Approved models.
2.3 Location
Use the balance on a firm, steady surface. Avoid locations with excessive air current,vibrations, heat
sources, or rapid temperature changes.
Adjust the levelingfeet so the bubble is centered in the circle.

Navigator®EN-3
2.4 Power
The AC Adapter is used to power the balance when battery power is not needed.
Connect the AC Adapter plug to the
input jack. Connect AC Adapter to the proper AC supply.
Battery installation (without optional internal battery):
Remove battery cover and install 4 batteries using the polarity indications as shown in the
compartment.
Optional rechargeable battery (NVL and NVT models only):
Balances with the optional rechargeable battery will need to be charged for 12 hours before the
balance can be operatedon battery power for the firsttime. The battery is protected from
overcharging so the balance can remain connected to the AC power.When the battery is fully
charged the battery indicator on the display will stop blinking.
To remove the rechargeable battery option and installC cell batteries, reference theRecharging
Battery Option instruction manual for step by step instructions as well as disposal instructions.
Caution: Risk of explosion can occur if the rechargeable battery is replaced with the
wrong type or if it is not properly connected.
2.5 Initial Calibration
When the balance is firstinstalled it should be calibrated to ensure accurate results.
Press and hold Menu until [mMeNU] (Menu) is displayed. When the button is released, the display will
display [.C.A.L.]. Press Yes to accept, [SpaN] will then be shown. Press Yes again to begin the span
calibration. [--C--] blinks while zero reading is stored. Next, the displayshows the calibration weight
value. Place the specified calibration mass on the pan. [--C--] blinks while the reading is stored. The
balance returns to the previous application mode and is ready for use.
Required Span Calibration Mass (sold separately)
Capacity Mass*Capacity Mass*Capacity Mass*
210g 200g 1600g - 2100g 1kg / 2lb 6400g - 10kg 5kg / 10lb
310g - 510g 300g 3100g - 4100g 2kg / 5lb 16kg - 20kg 10kg / 20lb
1100g 500g / 1lb 5100g 3kg / 5lb
*Pound masses are usedwhen calibrating in the lb unit.
Input Jack
Battery
Cover

EN-4 Navigator®
3. OPERATION
All modes except forweighing mustbe activated in the User Menubefore they areavailable,see
Section 4.
3.1 Weigh Mode
1. Press and hold Mode until [wJeIGH] (Weigh) is displayed.
2. If required, place an emptycontainer on the pan and press Tare.
3. Add material to the container. The display shows the weight of the material.
3.2 Parts Counting Mode
This mode counts large numbers ofitems based on the weightof a reference count.
1. Place an empty container on the panand press Tare.
2. Press and hold Mode until [Count] (Count) is displayed. [CLr.APU] (Clear Average Piece
Weight) will then display.
3. Press No to use the stored APW.Proceed to step 6.
4. Press Yes to establish an APW. The balance will then display the stored sample size, i.e. [Put
10]. Press No or Back to toggle the choices (5, 10, 20, 50 or 100).
5. Put the indicated number of pieces on thepan then press Yes to calculate the APW. The
display shows the piece count.Note: Press Function to view the current APW.
6. Add additionalpieces untilthe desired countis reached.
7. To clear the stored APW press and hold Mode until [Count] is displayed. Press Yes when
[Clr.APU] is displayed.
3.3 Percent Mode
This mode measures the weight of a sample as a percentage of a reference weight.
1. Place an empty container on the panand press Tare.
2. Press and hold Mode until [Percnt] is displayed. [Clr.ref](clear reference) will then display.
3. Press No to use the stored referenceweight and proceed to step 6.
4. Press Yes to establish a new reference. Balance will now display [Put.ref].
5. Add the desired reference material to the container.Press Yes to store the reference weight.
The display shows100%.
Note: Press Function to view the current reference weight.
6. Replace the reference material with the samplematerial.The display shows the percentage of
the samplecompared to referenceweight.
7. To clear the stored reference pressand hold Mode until [Percnt] is displayed. Press Yes
when [Clr.ref] is displayed.

Navigator®EN-5
3.4 Display Hold Mode
This mode holds the highest stable weightvalue for easy reference.
1. Press and hold Mode until [Hold] is displayed.
2. Place samples to be weighed on the pan. When the balance detects thehighest stableweight
the “Hold Indicator” will blink and the displayed weight will not change.
3. Press Function to release the held weight value.
3.5 Accumulation Mode
This mode allows the user to store the total of a series of weight measurements.With an Interface
Option thecomponentweights and the total weight can be transmitted.
1. Press and hold Mode until [ACCUmM] (Accumulate) is displayed. [Clr.Acc] (clear accumulate)
will then display.
2. Press Yes to clear the stored value or No to continue adding to the stored total.
3. If required, place an emptycontainer on the pan and press Tare.
4. Add first item, its weight is displayed. Press Function to store the weight, the “Accum” indicator
will flash and the display will show the total weight.
5. Remove the first item and add the next item. The balance will display its weight. Press
Function to store its weight. The “Accum” indicator will flash and the new total weight will be
displayed.
6. Repeat step 5 for all of the items to be added. Note: While thedisplay indicates zero,press
Function to view the current total number of samples and the total weight.
7. To clear the stored total press and hold Mode until [ACCUmM] is displayed. Press Yes when
[Clr.Acc] is displayed.
3.6 Checkweigh Mode
This mode sets low and high weight limits for portion control processes.
1. Press and hold Mode until [CHeCk] (Check) is displayed. [CLr.ref] (clear references) will then
display.
2. Press No to use the stored reference weight limits and proceed to step 5.
Note: Press Function to view the low and high reference weight limits.
3. Press Yes to establish new reference values. The balancewill then display [Set. Lo]. Press
Yes to view the “Low” limit value. Press Yes to accept or No to edit the“Low” limit value. The
stored value then displayswith the first digit highlighted [000.000 kg]. Repeatedly press No
until the desired number appears. Press Yes to acceptand highlight the next digit. Repeat until
all the digits are correct. Press Yes to accept the“low” limit value, [Set. Hi] will be displayed.
4. Repeat the same procedure to accept or edit the “high” value.
5. Place sample material on the Pan. The “Accept” indicator will now show that the sample weight
is within the acceptable range.
6. To clear the stored reference values press and hold Mode until [CHeCk] is displayed. Press Yes
when [Clr.ref] is displayed.

EN-6 Navigator®
4. SETTINGS
The User Menu allows the customizing of balance settings.
Note: Additional Sub-Menus maybe available ifInterface Options are installed.See InterfaceUser
Manual for the additional setting information.
4.1 Menu Navigation
User Menu:
Sub-Menus: .C.a.l. .S.e.t.u.p. .M.o.d.e. .U.n.i.t. .E.n.d.
Menu Items:
Span
Lin
End
A-off
Disply
Bright
IR.LEFT
IR.RGHT
End
Count
Percnt
Hold
Accum
Check
End
ct, g, kg, grn,
lb, oz, lb:oz,
ozt, N, dwt,
thk, tsg, ttw,
tola, tical
End
Press and hold Menu until [mMeNU] (Menu) isdisplayed. When released the first sub-menu [.C.a.l.]
(Cal) will be shown.
Press Yes to enter the displayed sub-menu or press No to advance to the next.
Selecting a sub-menu will display the first menu item. Press Yes to view the menu item setting or
press No to move to the next menu item. When viewing the setting, press Yes to accept the setting, or
press No to change the setting. When [End] is displayed, press Yes to return to the sub-menu
selections or No to return to the first item in the current menu.
4.2 Cal Sub-Menu
•Span [SpaN] (yes, no) - Initiates a span calibration procedure (zero and span). A span
calibration is important when initially setting up the balance.
•Lin [Lin] (yes, no) - Initiates a linearity calibration procedure (zero, mid-point and span).
4.3 Setup Sub-Menu
The backlit LCD and (red) LED displays will have different menu items or settings based on the
functionality.
•Auto Off [A-Off] (on, off) - When Auto Off is set to “on” the balance will turn off automatically
after 5 minutes of inactivity. Auto off is used to save battery power.
•Display [disply] (on, auto, dim (LED), off (LCD)) - This setting controls the LCD backlight or
the LED digits; constant on, automatic turn off after 5 seconds of balance inactivity, dimming of
the LED after 60 seconds of balance inactivity or LCD backlight always off.
•Bright [Bright] (hi, mid, low) - This setting controls the brightness of the LED display. LCD
models will not see this menu item.
•IR Sensor Left [Ir.LEFt] / Right [Ir.rght] (Off, Tare, Function, Print, Zero, Display) - These
settings determine the role of the IR Sensors. “Zero”, “Print”, “Function” or “Tare” allows the IR
sensor to actthe same as the relatedbutton. “Display” activates the display if Display-Auto is
set. “O
•ff” disables the sensor.

Navigator®EN-7
4.4 Mode Menu
This sub-menu activates modes so they will be available for use with the Mode button. Weigh mode is
always active.
•Parts Count [Count] (on, off) - Set on for the mode to be active.
•Percent [Percnt] (on, off) - Set on for the mode to be active.
•Hold [Hold] (on, off) - Set on for the mode to be active.
•Accumulate [ACCUmM] (on, off) - Set on for the mode to be active.
•Check Weigh [CHECk] (on, off) - Set on for the mode to be active.
4.5 Units Menu
This sub-menu activates units so they will be accessible with the Units button. The units in the menu
must be turned“on” to be active.The ounce (oz)and pound:ounce (lb:oz) units include the optionof
decimal [dec] or fractional [frac] readouts. Due to different agency requirements the grain unit has
two icon display options, gr or grn.
Note: Available units and modes vary by model and local regulations.
4.6 Sealing access to balance settings
The Menu Lock switch limits changes to the Cal, Setup, Mode and Unit menus. The switch in type
approved models may set some balance settings as required by the approval agency. The switch may
be secured using paper seals, wire seals or plastic ties.
Locked Unlocked
5. MAINTENANCE
5.1 Troubleshooting
The following table listscommon problems and possible causes and remedies.
If the problem persists, contact OHAUS or your authorized dealer.
Symptom Possible Cause Remedy
Cannot turn on No power to balance Verify connections and voltage
Poor accuracy Improper calibration
Unstable environment Perform calibration Move balance to suitable location
Cannot calibrate Unstable environment
Incorrect calibration weight Move the balance to suitable location Use correct calibration weight
Cannot access mode Mode not enabled Enter menu and enable mode
Cannot access unit Unit not enabled Enter menu and enable unit
Lo ref Reference weight is too low Increase reference weight.
ref err Parts counting– sample weight <1d. Shows error - exits mode or goes to [Clr.ApU].
Err 3.0 Cal Incorrect calibration weight See section 2.5 for correct weights
Err 4.4 full RS232 buffer is full Set Handshake on, see Interface User Manual.

EN-8 Navigator®
Err 8.1 ¯Load¯Power on zero range exceeded Clear pan, check Shipping Lock setting
Err 8.2 _Load_ Power on zero under range Install pan, check Shipping Lock setting
Err 8.3 ¯Load¯Overload (>cap+9e) Load exceeds balance maximum capacity
Err 8.4 _Load_ Under load Reading below min. range - Re-install pan.
Err 8.6 999999 Displayed value >999999 Result exceeds display capability.
Err 9 Data Internal data error. Contact an authorized service agent
Err 13 mMEmM Fail to write EEPROM. Contact an authorized service agent
Err 53 CSumM Invalid checksum data Contact an authorized service agent
5.2 Service Information
If the troubleshooting section does notresolve or describe your problem, contact your authorized
OHAUS service agent. For service assistance or technical support in the UnitedStates calltoll-free 1-
800-526-0659 between 8:00 AM and 5:00 PM EST. An OHAUS product service specialist will be
available to provide assistance. Outside the USA, please visitour web site, www.ohaus.com to locate
the OHAUS office nearest you.
5.3 Accessories
Rechargeable Battery Kit 83032106 (NVL, NVT)
RS232 Interface Kit 83032107 (NV, NVL, NVT)
USB Interface Kit 83032108 (NV, NVL, NVT)
Ethernet Interface Kit 83032109 (NV, NVL, NVT)
In-Use Cover Kit 83032223 (NV) 83032222 (NVL) 83032221 (NVT)
Carrying Case Kit 83032226 (NV) 83032225 (NVL) 83032224 (NVT)
Printers and Cables Contact OHAUS
6. TECHNICAL DATA
The technical data is valid under the following ambient conditions:
Ambient temperature: 10°C to 40°C,Approved models (M) 0°C to 40°C
Relative humidity: 20% to 85% relative humidity, non-condensing
Height above sea level: Up to 4000m
Operability: assured at ambient temperatures between 0°C and 40°C
Power: AC Adapter – 12VDC 420mA output, 4 batteries or rechargeable battery
Protection: dust and water
Pollution degree: 2
Installation category: Class III
EMC: See Declaration of Conformity

Navigator®EN-9
6.1 Specifications
Typical specifications:
Stabilization Time ≤1 seconds
Tare range To capacity by subtraction
Application Modes1weigh, percent, parts count, checkweigh, accumulate, hold
Weighing Units Non-Approved: ct, g, kg, grn, lb, oz, lb:oz, ozt, N, dwt, tael (3), tola, tical
M models: g, kg, ct N models: g, kg, ct, lb, oz, ozt, dwt, grn
AC Power AC Adapter (supplied)- 12 VDC or 12VAC, 420 mA
Battery Power NV: 4 AA (LR6) batteries (not supplied)
NVL, NVT: 4 C (LR14)batteries (notsupplied) or rechargeable battery option
Calibration Digital with external weight
LCD Display 6-digit 7-segment LCD with white LED backlight
LED Display 6-digit 7-segment LED
Display Size 20 mm / 0.78” digits
Keypad 4-button overlay plus two programmable IR sensors
Ingress Protection IP43 (NVT andNVL models)
Pan Size (W x D) NV: 190 mm x 138 mm NV212: Ø120mm
NVL: 194 mm x 203 mm NVT: 230 mm x 174 mm
Net Weight2NV: 0.9 kg / 2.2 lb NVL: 1.5 kg / 3.3 lb NVT: 1.5 kg /3.3 lb
Shipping Weight2NV: 1.4 kg / 3.1 lb NVL: 2.3 kg / 5.1 lb NVT: 2.3 kg /5.1 lb
Note 1: Some application modes are restricted in Approved models.
Note 2: /1 and /3 models add 0.5kg / 1lb
Non-Approved Models:
Model1Capacity Readability (d)
Repeatability Linearity Span Cal. Wt. Lin. Cal. Wts.
NV212 210g 0.01g 1d ±2d 200g 100g,200g
NV511 510g 0.1g 1d ±2d 300g 300g, 500g
NV1101 1100g 0.1g 1d ±2d 500g 500g,1000g
NV2101 2100g 0.1g 1d ±2d 1kg 1kg,2kg
NV4101 4100g 0.2g 1d ±2d 2kg 2kg,4kg
NV5101 5100g 0.5g 1d ±2d 3kg 3kg,5kg
NVL511 510g 0.1g 1d ±2d 300g 300g, 500g
NVL1101 1100g 0.1g 1d ±2d 500g 500g,1000g
NVL2101 2100g 0.1g 1d ±2d 1kg 1kg, 2kg
NVL5101 5100g 0.5g 1d ±2d 3kg 3kg, 5kg
NVL10000 10000g 1g 1d ±2d 5kg 5kg, 10kg
NVL20000 20000g 1g 1d ±2d 10kg 10kg, 20kg
NVT1601 1600g 0.1g 1d ±2d 1kg 1kg,1.5kg
NVT3201 3200g 0.2g 1d ±2d 2kg 2kg, 3kg
NVT6401 6400g 0.5g 1d ±2d 5kg 3kg, 6kg
NVT10001 10000g 0.5g 1d ±2d 5kg 5kg, 10kg
NVT16000 16000g 1g 1d ±2d 10kg 10kg, 15kg

EN-10 Navigator®
Note 1: /1 = Factory installed rechargeable battery option
/2 = LED display
/3 = LED display with factory installed rechargeable battery option
Approved Models:
Model1,2 Max= e= Approval Class
Span Cal. Wt. Lin. Cal. Wts.
NV311 310g 0.1g III 200g 200g, 300g
NV3100 3100g 1g III 2kg 2kg,3kg
NVT1601 1600g 0.5g III 1kg 1kg,1.5kg
NVT3200 3200g 1g III 2kg 2kg,3kg
NVT6400 6400g 2g III 5kg 3kg,6kg
NVT16000 16000g 5g III 10kg 10kg, 15kg
Note 1: M = EC Type approved
N = NTEP and Measurement Canada approved
Note 2: /1 = Factory installed rechargeable battery option
/2 = LED display
/3 = LED display with factory installed rechargeable battery option
Example: NVT3200M/3
6.2 Drawings
A B C
NV 204 mm / 8 in. 212 mm / 8.4 in. 58 mm / 2.3 in.
NVL 204 mm / 8 in. 282 mm / 11.1 in. 74 mm / 2.9 in.
NVT 240 mm / 9.5 in. 250 mm / 9.8 in. 74 mm / 2.9 in.
A
B
C

Navigator®EN-11
6.3 Compliance
Compliance to the following standards is indicated by the corresponding mark on the product.
Mark Standard
This product conforms to the EMC directive 2004/108/EC, the Low Voltage Directive
2006/95/EC and the Non-automatic Weighing Instrument Directive 2009/23/EC. The
Declaration of Conformity is available online at www.OHAUS.com.
AS/NZS4251.1 Emission; AS/NZS4252.1 Immunity
Important notice for verified weighing instruments
Weighing Instrumentsverified at theplace of manufacture bear one of the preceding
marks on the packing label and thegreen ‘M’ (metrology) sticker on the descriptive
data plate. They may be put into service immediately.
Weighing Instruments to be verifiedin two stages haveno green ‘M’ (metrology) on
the descriptive data plate andbear one of the preceding identification marks on the
packing label. The second stage of the initial verification must be carried out by an
authorized and certified service organization established within the European
Community or by the National Notified Body.
The first stage of the initial verification has been carried out at the manufacturers work. It comprises
all tests according to the adopted European standard EN 45501:1992, paragraph 8.2.2.
If national regulations limit the validity period of the verification, the user of the weighing instrument
must strictly observe the re-verification period and inform the respective weights and measures
authorities.
Disposal
In conformance with the European Directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE) this device may not be disposed of in domestic waste.
This also applies to countries outside theEU, per theirspecific requirements.
The Batteries Directive 2006/66/EC introduces new requirements from September
2008 on removability of batteries from waste equipment in EU Member States. To
comply with this Directive, this device has been designed for safe removal of the
batteries at end-of-life by a waste treatment facility.
Please dispose of this product in accordance with local regulations at the collecting pointspecified
for electrical and electronic equipment. If you have any questions, please contact the responsible
authority or the distributor from which you purchased this device.
Should this device be passed on to other parties (for private or professional use), thecontent of this
regulation must also be related.
Disposal instructions in Europe are available online at www.ohaus.com. Choose your country,
then search for “WEEE.”
Thank you for your contribution to environmental protection.

EN-12 Navigator®
FCC Note
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interferencewhen the equipment is operated in a commercial environment.This
equipmentgenerates, uses,and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation ofthis equipment in a residentialarea is likely to cause harmful interference inwhich case
the user will be required to correct the interference at his own expense.
Industry Canada Note
This Class B digital apparatus complies with Canadian ICES-003.
ISO 9001 Registration
In 1994, OHAUS Corporation, USA,was awarded a certificate ofregistration to ISO 9001by Bureau
Veritus Quality International (BVQI), confirming that the OHAUS quality management system is
compliantwith the ISO 9001 standard’s requirements. On May 15, 2003, OHAUSCorporation,USA,
was re-registered to the ISO 9001:2000 standard.
Limited Warranty
OHAUS products are warranted against defects in materials and workmanship from the date of
delivery through the duration of the warranty period. During the warranty period OHAUS will repair, or,
at its option, replace any component(s) thatproves to be defective at no charge, provided that the
product is returned, freight prepaid, to OHAUS. This warranty does not apply if the product has been
damaged by accident ormisuse, exposed to radioactive or corrosive materials, has foreign material
penetrating to the inside of the product, or asa result of serviceor modification by other than OHAUS.
In lieu of a properly returned warranty registration card, the warranty period shall begin on the date of
shipment to the authorized dealer.No other expressor implied warranty is given by OHAUS
Corporation. OHAUS Corporation shall not be liable for any consequential damages.
As warranty legislation differs from state to state and country tocountry, please contactOHAUS or
your local OHAUS dealer for further details.
Product Registration
Protect your investment. Register your product withyour local OHAUS dealer.
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com
