Oki MC860 MFP Service manual

Handy Reference
Guide de référence pratique
Referencia Rápida
Guia de referência rápida
MC860 MFP
59398701 my.okidata.com

2
Walk-up Operation . . . . . . . . . . 4
General Information . . . . . . . . . .4
Access Control . . . . . . . . . . . .4
Power Save Mode . . . . . . . . . .5
Loading Documents for Scanning .6
Copying . . . . . . . . . . . . . . . . . .8
Scanning. . . . . . . . . . . . . . . . .10
Faxing . . . . . . . . . . . . . . . . . .14
Exit Trays. . . . . . . . . . . . . . . . . 17
Print Media Settings . . . . . . . . 18
The Help System . . . . . . . . . . . 19
Maintenance . . . . . . . . . . . . . . 20
Ordering Replacement Supplies .
27
Service & Support . . . . . . . . . . 28
Fonctionnement en mode
autonome . . . . . . . . . . . . . . . . 29
Généralités. . . . . . . . . . . . . . . 29
Contrôle de l'accès . . . . . . . . 29
Mode Économie d'énergie . . . 30
Chargement de documents pour
numérisation . . . . . . . . . . . . . 31
Copie . . . . . . . . . . . . . . . . . . . 33
Numérisation . . . . . . . . . . . . . 35
Télécopie . . . . . . . . . . . . . . . . 39
Bacs de sortie . . . . . . . . . . . . . 42
Paramètres de support
d’impression. . . . . . . . . . . . . . 43
Système d'aide . . . . . . . . . . . . 44
Entretien . . . . . . . . . . . . . . . . . 45
Commande de fournitures. . . . 52
Service et soutien . . . . . . . . . . 53
Contents Table des matières
59398701

3
Funcionamiento Walk-up. . . . . 54
Información general . . . . . . . . .54
Acceso controlado . . . . . . . . .54
Modo de ahorro de energía. . .55
Cómo colocar documentos para
escanear . . . . . . . . . . . . . . . .56
Copiado . . . . . . . . . . . . . . . . .58
Escaneado. . . . . . . . . . . . . . . .60
Faxes . . . . . . . . . . . . . . . . . . .64
Bandejas de salida. . . . . . . . . . 67
Configuración de los medios de
impresión . . . . . . . . . . . . . . . . 68
El sistema de Ayuda . . . . . . . . 69
Mantenimiento. . . . . . . . . . . . . 70
Cómo colocar sus pedidos de
suministros . . . . . . . . . . . . . . 77
Servicio & Soporte. . . . . . . . . . 78
Operação direta. . . . . . . . . . . . 79
Informações gerais . . . . . . . . . 79
Controle de acesso . . . . . . . . 79
Modo de economia de energia 80
Colocação de documentos para
escanear. . . . . . . . . . . . . . . . 81
Copiar . . . . . . . . . . . . . . . . . . 83
Uso do scanner . . . . . . . . . . . . 85
Modo de fax . . . . . . . . . . . . . . 89
Escaninhos de saída . . . . . . . . 92
Configurações da mídia de
impressão. . . . . . . . . . . . . . . . 93
O sistema de ajuda . . . . . . . . . 94
Manutenção . . . . . . . . . . . . . . . 95
Pedidos de suprimentos de
reposição . . . . . . . . . . . . . . . 102
Assistência técnica e suporte 103
Contenido Sumário

4 • English
English
Walk-up Operation
General Information
These instructions assume that
all necessary configurable
parameters and profiles have
been set up and, where
applicable, password-protected
by your System Administrator. If
you have any questions, consult
your System Administrator.
1. If you do not have a System
Administrator, see the SetUp
Guide supplied with your
system or consult the on-line
User’s Guide provided on the
CD supplied with the system
for more information.
Available Walk-up
Options
• Copy (see page 8)
•Fax (see page 14)
•Scan (see page 10)
Access Control
If your Administrator has enabled
access control on your machine,
it will automatically start up in
access control mode.
If the PIN screen is
displayed
1. Press PIN No. and use the
numeric keys to enter your
PIN.
2. Press
Enter .
3. Press
Log in .
If the User/Password
screen is displayed
1. Press User Name and use the
touch screen keyboard to enter
your user name.
1. Press
Enter to confirm.
1. Press
Password and use the
touch screen keyboard to enter
your password.
1. Press
Enter to confirm.
1. Press
Log in .
Logging Out
When you have finished using the
unit, select
Others > Logout to
return to the access control
screen.

5 • English
Walk-up Operation
General Information
Power Save Mode
Power Save sets how long the
printer waits before going into
standby mode. This saves energy,
but the printer requires time to
warm up when it receives a print
job.
The system comes from the
factory set for a 30-minute delay
before entering the Power Save
Mode.
When the system is in Power
Save mode, the Power Save
button is lit. To disengage the
Power Save mode, press the
Power Save button.
Changing the Power Save
Settings
1. Press the S ETUP button on the
control panel.
2. On the
Setup screen, press
Admin Setup .
3. Type in your password (the
default password is aaaaaa),
then press
Enter .
4. Press
Management .
5. Press
䊳 , then press Power
Save
.
6. To switch Power Save on of off:
a. Press
Power Save Enable .
b. Press
OFF or ON .
c. Press
Enter .
7. To change the time setting:
a. Press
Power Save Time .
b. Press the desired time (
5,
15, 30, 60 , or 240
minutes)
c. Press
Enter .
8. Press Close .
9. Press the C
OPY button.

6 • English
Walk-up Operation
Loading Documents for Scanning
Automatic Document
Feeder (ADF)
Adjust the guides for paper size
and load documents face up, with
the top edge entering the
scanner.
• Takes up to 50 sheets 20-lb.
(75 g/m
2
) paper
• No staples, clips, ragged
edges, wrinkles, punch holes,
sticky notes, etc.
• Min. 5" x 5.8"
(128 x 148 mm)
• Max. 11.7" x 18"(297 x 457
mm), plus banners up to
35.4 inches (900 mm) long,
hand fed
• Weight Range:
– Single sheets: 16 to 32 lb.
US Bond (60 to 128 g/m
2
)
– Multiple Sheets: 16 to 28 lb.
US Bond (60 to 105 g/n
2
)
– Banners: 16 to 24 lb. US
Bond (60 to 90 g/m
2
)

7 • English
Walk-up Operation
Loading Documents for Scanning
Manual Feed: The
Scanner Glass
1. Open the scanner lid.
2. Load the document face down,
with the top edge to the left.
3. Close the scanner lid.
• Maximum document size
11.7" x 16.5" (297 x 420
mm)
•Maximumthickness
approximately 0.75" (20
mm)

8 • English
Walk-up Operation
Copying
For more information, check with
your System Administrator or see
the on-line User’s Guide provided
with your system.
Important
The system default is the Copy
mode and the C OPY button is
illuminated. If it is not, press the
C
OPY button.
Using the Default
Settings
1. Load the document (see page
6).
2. Use the numeric keypad to set
the number of copies (up to
99).
3. Press the M
ONO button or the
C
OLOR button.
Using Special Settings
1. Load the document (see page
6).
2. Use the numeric keypad to set
the number of copies (up to
99).
3. Press the appropriate selection
on the left of the Copy screen
to change the settings.
Note
See the next page for a
summary of the setting tree in
the menu. For more
information, consult the on-line
Users Guide.
4. Press the M
ONO button or the
C
OLOR button.

9 • English
Walk-up Operation
Copyin (cont)
*Copy Settings Tree
The default setting is in bold italic .
1 Others
EraseCenter
DuplexCopy
Mixed Size
Scan Size
Cont. Scan
Contrast
Hue
Saturation
RGB
Logout
2 Doc. Type
Doc Type
Removal for Background and Show-Through (sTHR)
3 Density
-3, -2, -1, 0 , +1, +2, +3
4 Tray
Auto , MPT, Tray 1
5 Zoom
Auto , 100%, Fit
Enlarge
Reduce
6 Sort
OFF, ON
1
2
3
4
5
6

10 • English
Walk-up Operation
Scanning
Scanning Options
• Scan to E-mail
• Scan to USB memory
• Scan to Local PC
• Scan to Network PC
• Scan to Remote PC
• Continuous Scan
Note
These instructions assume that
all needed basic data (e.g.,
e-mail addresses) is already
programmed in the system.
Scanning Overview
1. Load the document.
or
2. Press the S CAN button.
3. Select the scan destination:
•
Email (requires connection
to PSTN)
•
USB (requires USB plug-in
device attached to the USB
port on the front of the unit)
•
Local PC (requires USB
connection to local PC)
•
Network PC (requires
Ethernet connection)
•
Remote PC (“pull scan”
controlled from the PC.
requires a USB connection
and a scanning/organizing
software package such as
PaperPort
®
which is supplied
with your system)
4. Set your scanning options.
5. Press the M
ONO button for
black and white scanning, or
the C
OLOR button for color
scanning.
