Oki T400 User manual

Page 1
Installing the Cutter Kit
ITEM "A"
SCREW
ITEM "B" SCREWS
ITEM "A"
ITEM "B"
STEP PROCEDURE
1. Switch the printer OFF and disconnect the power cord.
2. Raise the top cover and print head assembly.
3. Refer to the illustrations on the following pages.
Remove the front door panel.
4. Raise the tear bar to the upright position.
5. nsert the connector from tem "B" into CN3 on the printer.
6. nstall tem "B" by placing the tabs in and down into the slots on the
printer. Be sure the positioning holes on tem "B" are inserted on the
positioning pins. Secure with (2) tem "B" screws.
7. Lower the tear bar to the operating position.
8. Secure tem "A" to the print head with tem "A" screw. Lever on tem
"A" swings down to unlock and up to lock and pivots forward in the
unlocked position.
9. Lower the print head assembly and replace the front door panel and top
cover.
10. Set the dip switch settings to the cutter mode.
1WSD2WSD3WSDGNITTES
ffOnOffOedoMrettuC

Page 2
Installing the Cutter Kit
REMOVE THE
FRONT DOOR
PANEL
RAISE THE TEAR BAR TO
THE UPRIGHT POSITION
ATTACH CONNECTOR
FROM ITEM "B" TO CN3
SECURE WITH
ITEM "B"
SCREWS
INSERT TABS FROM
ITEM "B" INTO SLOTS
POSITIONING
PINS

Page 3
Installing the Cutter Kit
SECURE ITEM "A" TO
PRINT HEAD WITH
ITEM "A" SCREW
REATTACH
FRONT DOOR
LEVER ON ITEM "A"
SWINGS DOWN TO
UNLOCK AND UP TO
LOCK
ITEM "A" PIVOTS
FORWARD
59408501
