Oki C9200 User manual

Phase 1: Install the Duplex Unit
!If you will be using the duplex unit to print complicated
files with graphics, you need to purchase and install 64
MB additional printer memory (OKI # 70037401).
1Unpack the duplex unit and remove any shipping
materials.
2Turn the printer off, then pull out Tray 1.
3Push up on the latches at either end of the front cover and
remove it from the printer.
!Do not throw the front cover away: you will need it if
you ever remove the duplex unit from the printer.
4Place the duplex unit on top of Tray 1 and align it so that
it is flush with the tray.
5Open the small cover on the duplex unit and pull the blue
handle gently until the duplex unit and Tray 1 are locked
together.
6Gently slide the tray/duplex unit back into the printer.
7Turn the printer back on.
(continued on back)
Installing
the Duplex Unit OKI®P/N 70037101

Oki Data Americas, Inc., 2000 Bishops Gate Blvd., Mt. Laurel, NJ 08054-4620
Tel: [phone] FAX: [phone] http://www.okidata.com 58347501
Phase 2: Activate the Duplex Unit in
the Driver
Windows®PCL Driver
1Click Start ® Settings ® Printers.
The Printers dialog box opens.
2Right click the OKI C9200 or C9400 PCL printer icon,
then click Printing Preferences (Windows 2000),
Properties (Windows Me, 98, 95) or Document Defaults
(Windows NT 4.0).
3In the Paper tab, click Device options.
4Click Duplex option unit to select it, then click OK.
5Click OK, then close the Printers dialog box.
Windows PostScript®Driver
1Click Start ® Settings ® Printers.
The Printers dialog box opens.
2Right click the OKI C9200 or C9400 PostScript printer
icon, then click Properties.
3Change the setting:
Windows 2000 and NT 4.0:
aClick the Device Settings tab.
bScroll down to Installable Options and click
Duplex.
cUnder Change ‘Duplex’ Setting, click Installed.
Windows Me, 98 and 95:
aClick the Device Options tab.
bClick Duplex.
cUnder Change setting for: Duplex, click Installed.
4Click OK, then close the Printers dialog box.
Macintosh®Driver
1Activate Chooser from the Apple menu.
2Select LaserWriter 8.
3Click Printer ® Setup.
4Click Configure.
5Change the Duplex setting to Installed.
6Click OK twice.
7Close Chooser.
Oki Data Service Center Information
UNITED STATES CANADA MEXICO BRAZIL
Oki Data Americas, Inc. Oki Data Americas, Inc. Oki Data de Mexico, S.A. de C.V. Oki Data do Brasil, Ltda.
2020 Bishops Gate Blvd. 2735 Matheson Blvd. East, Unit 1 Mariano Escobedo No. 748 - 8 Piso Rua Alexandre Dumas, 2220 - 8 andar
Mt. Laurel, NJ 08054 Mississauga, Ontario Col Anzures, e.p. 11590 Chácara Sto Antonio
Canada L4W 4MB Mexico, DF São Paulo 04717-004, Brasil
Tel: [phone] Tel: [phone] Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone]
Limited Warranty: U.S.
Oki Data Americas, Inc. (Oki Data) warrants this OPTION to be free
from defect in material and workmanship and will remedy any such
defect according to the terms of this Limited Warranty.
Oki Data will repair (or at its option, replace) at no charge, any
defective part(s) of the OPTION for one (1) year from the date of
purchase. This Limited Warranty extends to the original purchaser only.
To make request or claim for service under this Limited Warranty the
original purchaser must return the Oki Data product, shipping prepaid,
in the original shipping container or equivalent, to Oki Data or an
authorized Oki Data service center and assume the risk of loss or
damage in transit. Awritten receipt for the product, showing the date of
purchase, dealer’s name, and item purchased must accompany any
request or claim for work to be performed under this Limited Warranty.
This Limited Warranty shall not apply if the product has been damaged
due to abuse, misuse, misapplication, accident, or as a result of service
or modification by any other than an authorized Oki Data service
center.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE
ON THE FACE HEREOF AND DESCRIBEDABOVE. NO
WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, SHALL EXTEND BEYOND THE RESPECTIVE
WARRANTY PERIOD DESCRIBED ABOVE OF ONE (1) YEAR.
Some states do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you.
OKI DATA SHALL NOT BE RESPONSIBLE OR LIABLE FOR
ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
OR LOSS ARISING FROM THE USE OF THIS PRODUCT. Some
states do not allow the exclusion or limitation of incidental or
consequential damages, so the above exclusion may not apply to you.
Additional information on obtaining service under this Limited
Warranty is available by contacting the Oki Data dealer from whom the
product was purchased, by contacting Oki Data directly at 1-800-
OKI-DATA (U.S. and Canada), or by contacting one of the service
depots listed below.
This Limited Warranty applies to this Oki Data Option. However, the
procedure for obtaining service may vary outside the continental
United States. Contact your Oki Data dealer for such warranty service
information.
This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
For the most comprehensive, up-to-date listing of Oki Data authorized
Service Centers, go to http://www.okidata.com and click on Dealer
Locator or call 1-800-OKI-DATA(1-800-654-3282).
