Oki C9800hdn User manual

2Copyright
C9800 Color Guide - 2
C OPYRIGHT
C9800 Color Guide
P/N 59374501, Revision 1.0
May 13, 2005
Every effort has been made to ensure that the information in this document is complete, accurate, and up-to-date. Oki assumes
no responsibility for the results of errors beyond its control. Oki also cannot guarantee that changes in software and equipment
made by other manufacturers and referred to in this guide will not affect the applicability of the information in it. Mention of
software products manufactured by other companies does not necessarily constitute endorsement by Oki.
While all reasonable efforts have been made to make this document as accurate and helpful as possible, we make no warranty
of any kind, expressed or implied, as to the accuracy or completeness of the information contained herein.
The most up-to-date drivers and manuals are available from the Oki web site:
http://www.okidata.com and http://my.okidata.com
Copyright © 2005 Oki Data Americas, Inc.

Contents
C9800 Color Guide - 3
About the Documentation
Introduction
About this manual 11
Key features of ColorWise 12
Chapter 1: Fiery Color Management
Managing color on the Fiery 1-14
Rendering Style 1-18
Pure Black Text/Graphics 1-19
Black Overprint 1-20
Spot Color Matching 1-21
RGB Source Profile 1-22
CMYK Simulation Profile 1-23
CMYK Simulation Method 1-24
RGB Separation 1-25
Output profile 1-26
Combine Separations 1-26
PostScript printer driver for Windows and Mac OS 1-27
Setting color management print options for Windows 1-27
Adobe PostScript printer driver for Mac OS 1-29
Chapter 2: Color Calibration
An overview of calibration 2-34
Understanding calibration 2-35
How calibration works 2-35
Scheduling calibration 2-36
Checking calibration status 2-37
Using Calibrator 2-38

4Contents
C9800 Color Guide - 4
Starting Calibrator 2-38
Expert Mode 2-40
Restoring default calibration measurements 2-41
Using the EFI Spectrometer ES-1000 2-43
Setting up the ES-1000 2-43
Calibrating the Fiery with the ES-1000 2-44
Using the EFI Densitometer ED-100 2-46
Setting up the ED-100 2-46
Calibrating the Fiery with the ED-100 2-47
Calibrating the Fiery with the DTP41 2-50
Calibrating the Fiery with the DTP32 2-53
Chapter 3: ColorWise Pro Tools
Profile Manager 3-56
Setting the default profiles 3-57
Downloading profiles 3-58
Editing profiles 3-59
Managing profiles 3-60
Defining profiles 3-61
Color Editor 3-63
Editing profiles 3-63
Undoing CMYK simulation edits 3-69
Checking edited profiles 3-69
Using Spot-On 3-70
Starting Spot-On 3-70
Using the Spot-On main window 3-72
Working with existing colors 3-73
Creating custom colors 3-75
Downloading custom color groups 3-76
Uploading custom color groups 3-76
Editing color values 3-77
Using a measurement instrument to target colors 3-81
Saving changes and exiting Spot-On 3-82

5Contents
C9800 Color Guide - 5
Color Setup 3-83
Setting default ColorWise options 3-83
Appendix A: Color Measurement Instruments
Using the X-Rite DTP41 spectrophotometer A-84
Setting up the DTP41 A-84
Calibrating the DTP41 A-87
Using the X-Rite DTP32 densitometer A-91
Setting up the DTP32 A-91
Calibrating the DTP32 A-93
Appendix B: Importing Density Measurements
Simple ASCII Import File Format (SAIFF) B-95
Example of 1D Status T density for EFI 34 patch page B-96
Example of 1D Status T density for EFI 21 patch page B-96
Example of 1D Status T density for an arbitrary page B-97
Index 98

6 About the Documentation
C9800 Color Guide - 6
This manual is part of a set of Fiery Network Controller for C9800, herein referred to
as the “Fiery,” documentation that includes the following manuals for users and system
administrators. Most are available as Acrobat PDF (Portable Document Format) files
on the User Documentation CD.
•TheUser Software Installation Guide describes how to install software from the
User Software CD to enable users to print to the Fiery Network Controller for
C9800 with the EFI PostScript driver, and also describes setting up printing
connections to the Fiery.
•TheConfiguration Guide explains basic configuration and administration of
the Fiery for the supported platforms and network environments. It also includes
guidelines for setting up UNIX, Windows NT 4.0/2000/Server 2003, and Novell
NetWare servers to provide printing services to users.
•ThePrinting Guide describes the printing features of the Fiery for users who send
jobs from their computers using the EFI PostScript driver.
•TheColor Guide provides information on managing the color output of the Fiery.
It explains how to calibrate your Fiery and take advantage of the ColorWise®
color management system, as well as features in ColorWise Pro Tools™.
•TheFiery Color Reference addresses concepts and issues associated with managing
color output of the Fiery and outlines key workflow scenarios. In addition, it offers
information on printing color documents from popular Microsoft Windows and
Apple Mac OS applications.
•TheJob Management Guide explains the functions of the job management
utilities, including Command WorkStation™, Command WorkStation LE™, and
DocBuilder Pro™, and how you can use them to monitor and control jobs on the
Fiery. This manual is intended for an operator or administrator, or a user with the
necessary access privileges, who monitors and manages job flow, performs color
calibration, and troubleshoots problems that may arise.
•Release Notes provide last-minute product information and workarounds for some of
the problems you may encounter.
About the
Documentation

7Copyright
C9800 Color Guide - 7
Copyright © 2005 Electronics for Imaging, Inc. and OKI Data Corporation. All rights reserved.
This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose
without express prior written consent from Electronics for Imaging, Inc. Information in this document is subject to change without notice and does not represent a
commitment on the part of Electronics for Imaging, Inc.
This publication is provided in conjunction with an OKI Printing Solutionsproduct (the “Product”) which contains EFI software (the “Software”). The Software is
furnished under license and may only be used or copied in accordance with the terms of the Software license set forth below.
This product may be covered by one or more of the following U.S. Patents:þ 4,716,978, 4,828,056, 4,917,488, 4,941,038, 5,109,241, 5,170,182, 5,212,546, 5,260,878,
5,276,490, 5,278,599, 5,335,040, 5,343,311, 5,398,107, 5,424,754, 5,442,429, 5,459,560, 5,467,446, 5,506,946, 5,517,334, 5,537,516, 5,543,940, 5,553,200,
5,563,689, 5,565,960, 5,583,623, 5,596,416, 5,615,314, 5,619,624, 5,625,712, 5,640,228, 5,666,436, 5,745,657, 5,760,913, 5,799,232, 5,818,645, 5,835,788,
5,859,711, 5,867,179, 5,940,186, 5,959,867, 5,970,174, 5,982,937, 5,995,724, 6,002,795, 6,025,922, 6,035,103, 6,041,200, 6,065,041, 6,112,665, 6,116,707,
6,122,407, 6,134,018, 6,141,120, 6,166,821, 6,173,286, 6,185,335, 6,201,614, 6,215,562, 6,219,155, 6,219,659, 6,222,641, 6,224,048, 6,225,974, 6,226,419,
6,238,105, 6,239,895, 6,256,108, 6,269,190, 6,271,937, 6,278,901, 6,279,009, 6,289,122, 6,292,270, 6,299,063, 6,310,697, 6,321,133, 6,327,047, 6,327,050,
6,327,052, 6,330,071, 6,330,363, 6,331,899, 6,340,975, 6,341,017, 6,341,018, 6,341,307, 6,347,256, 6,348,978, 6,356,359, 6,366,918, 6,369,895, 6,381,036,
6,400,443, 6,429,949, 6,449,393, 6,476,927, 6,490,696, 6,501,565, 6,519,053, 6,539,323, 6,543,871, 6,546,364, 6,549,294, 6,549,300, 6,550,991, 6,552,815,
6,559,958, 6,572,293, 6,590,676, 6,606,165, 6,633,396, 6,636,326, 6,643,317, 6,647,149, 6,657,741, 6,662,199, 6,678,068, RE33,973, RE36,947, D341,131,
D406,117, D416,550, D417,864, D419,185, D426,206, D439,851, D444,793.
Trademarks
Auto-Count, ColorCal, ColorWise, Command WorkStation, EDOX, EFI, Fiery, the Fiery logo, MicroPress, Printcafe, PrinterSite, Prograph, Proteus, and Spot-On are
registered trademarks of Electronics for Imaging, Inc., in the U.S. Patent and Trademark Office and/or certain other foreign jurisdictions. Bestcolor is a registered
trademark of Best GmbH in the U.S. Patent and Trademark Office.
AutoCal, Digital StoreFront, DocStream, Fiery Link, FreeForm, Hagen, Intelligent Device Management, Logic, OneFlow, PrintFlow, PrintMe, PrintSmith Site,
PrintSmith, PSI Flexo, PSI, SendMe, Splash, VisualCal, the EFI logo, Essential to Print are trademarks of Electronics for Imaging, Inc. Best, the Best logo, Colorproof,
PhotoXposure, Remoteproof, and Screenproof are trademarks of Best GmbH.
All other terms and product names may be trademarks or registered trademarks of their respective owners, and are hereby acknowledged.
Legal Notices
APPLE COMPUTER, INC. (“APPLE”) MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THE APPLE SOFTWARE.
APPLE DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE
USE OF THE APPLE SOFTWARE IN TERMS OF ITS CORRECTNESS, ACCURACY, RELIABILITY, CURRENTNESS, OR OTHERWISE. THE
ENTIRE RISK AS TO THE RESULTS AND PERFORMANCE OF THE APPLE SOFTWARE IS ASSUMED BY YOU. THE EXCLUSION OF
IMPLIED WARRANTIES IS NOT PERMITTED BY SOME STATES. THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.
IN NO EVENT WILL APPLE, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE TO YOU FOR ANY CONSEQUENTIAL,
INCIDENTAL OR INDIRECT DAMAGES (INCLUDING DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF
BUSINESS INFORMATION, AND THE LIKE) ARISING OUT OF THE USE OR INABILITY TO USE THE APPLE SOFTWARE EVEN IF APPLE HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY
FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU. Apple’s liability to you for actual damages
from any cause whatsoever, and regardless of the form of the action (whether in contract, tort [including negligence], product liability or otherwise), will be limited to $50.
PANTONE® Colors displayed in the software application or in the user documentation may not match PANTONE-identified standards.þ Consult current PANTONE
Color Publications for accurate color. PANTONE® and other Pantone, Inc. trademarks are the property of Pantone, Inc.þ © Pantone, Inc., 2001.
Pantone, Inc. is the copyright owner of color data and/or software which are licensed to Electronics for Imaging, Inc.,þto distribute for use only in combination with the
products, or software of Electronics for Imaging, Inc. þPANTONE Color Data and/or Software shall not be copied onto another disk or into memory except as part of
the delivery of the Electronics for Imaging, Inc., products or software.
This product includes software developed by the Apache Software Foundation (http://www.apache.org/).
FCC Information
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s
authority to operate this equipment.

8Copyright
C9800 Color Guide - 8
Class B Declaration of Conformity
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with non-approved equipment or unshielded cables
is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of
manufacturer could void the user’s authority to operate this equipment.
Industry Canada Class B Notice
This Class B digital apparatus complies with Canadian ICES-003.
Avis de Conformation Classe B de l’Industrie Canada
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.
RFI Compliance Notice
This equipment has been tested concerning compliance with the relevant RFI protection requirements both individually and on system level (to simulate normal
operation conditions). However, it is possible that these RFI Requirements are not met under certain unfavorable conditions in other installations. It is the user who is
responsible for compliance of his particular installation.
Dieses Gerät wurde sowohl einzeln als auch in einer Anlage, die einen normalen Anwendungsfall nachbildet, auf die Einhaltung der Funkentstörbestimmungen geprüft.
Es ist jedoch möglich, dass die Funkentstörbestimmungen unter ungünstigen Umständen bei anderen Gerätekombinationen nicht eingehalten werden. Für die
Einhaltung der Funkentstörbestimmungen einer gesamten Anlage, in der dieses Gerät betrieben wird, ist der Betreiber verantwortlich.
Compliance with applicable regulations depends on the use of shielded cables. It is the user who is responsible for procuring the appropriate cables.
Die Einhaltung zutreffender Bestimmungen hängt davon ab, dass geschirmte Ausführungen benützt werden. Für die Beschaffung richtiger Ausführungen ist der Betreiber
verantwortlich.
Software License Agreement
YOU SHOULD CAREFULLY READ THE FOLLOWING TERMS AND CONDITIONS BEFORE USING THIS SOFTWARE. IF YOU DO NOT AGREE TO
THE TERMS AND CONDITIONS OF THIS AGREEMENT, DO NOT USE THE SOFTWARE. INSTALLING OR USING THE SOFTWARE INDICATES
THAT YOU AGREE TO AND ACCEPT THE TERMS OF THIS AGREEMENT. IF YOU DO NOT AGREE TO ACCEPT THE TERMS OF THIS
AGREEMENT YOU MAY RETURN THE UNUSED SOFTWARE FOR A FULL REFUND TO THE PLACE OF PURCHASE.
License
EFI grants you a non-exclusive license to use the Software and accompanying documentation (“Documentation”) included with the Product. The Software is licensed,
not sold. You may use the Software solely for your own customary business or personal purposes. You may not rent, lease, sublicense or lend the Software or use the
Software in any time sharing, service bureau, or similar arrangement.
You may not make or have made, or permit to be made, any copies of the Software or portions thereof, except one (1) copy for backup or archive purposes in support of
your use of the Software as permitted hereunder. You may not copy the Documentation. You may not attempt to localize, translate, disassemble, decompile, decrypt,
reverse engineer, discover the source code of, modify, create derivative works of, or in any way change any part of the Software.
The terms, conditions, and restrictions in the License Agreement apply to all bug fixes, patches, releases, release notes, updates, and upgrades related to the Software.
Proprietary Rights
You acknowledge and agree that all rights, title and interest, including all intellectual property rights, in and relating to the Software, Documentation and all modifications
and derivative works thereof are solely owned by and shall remain with EFI and its suppliers. Except for the express limited license granted above to use the Software, no

9Copyright
C9800 Color Guide - 9
right or license of any kind is granted. You receive no rights or license under any patents, copyrights, trade secrets, or trademarks (whether registered or unregistered).
You agree not to adopt, register, or attempt to register any EFI trademark or trade name (“EFI Mark”) or any confusingly similar mark, URL, internet domain name, or
symbol as your own name or the name of your affiliates or products, and not to take any other action which impairs or reduces the trademark rights of EFI or its suppliers.
Confidentiality
The Software is confidential, proprietary information of EFI and you may not distribute or disclose the Software. You may, however, permanently transfer all of your
rights under this Agreement to another person or legal entity provided that: (1) such a transfer is authorized under all applicable export laws and regulations, including
the U.S. Export Administration Regulations, (2) you transfer to the person or entity all of the Software and Documentation (including all copies, updates, upgrades,
prior versions, component parts, the media and printed materials, and this Agreement); (3) you retain no copies of the Software and Documentation, including copies
stored on a computer; and (4) the recipient agrees to the terms and conditions of this Agreement.
Remedies and Termination
Unauthorized use, copying, or disclosure of the Software, or any breach of this Agreement will result in automatic termination of this license and will make available to
EFI other legal remedies. In the event of termination, you must destroy all copies of the Software, Documentation, and all component parts thereof. All provisions of
this Agreement relating to disclaimers of warranties, limitation of liability, remedies, damages, governing law, jurisdiction, venue, and EFI’s proprietary rights shall survive
termination.
Limited Warranty and Disclaimer
EFI warrants to the original purchaser (“Customer”) for thirty (30) days from the date of original purchase from EFI or its authorized retailer that the Software will
perform in substantial conformance to the Documentation when the Product is used as authorized by EFI’s specifications. EFI warrants the media containing the Software
against failure during the above warranty period. EFI makes no warranty or representation that the Software will meet your specific requirements, that the operation of
the Software will be uninterrupted, secure, fault-tolerant, or error free, or that all defects in the Software will be corrected. EFI makes no warranty, implied or otherwise,
regarding the performance or reliability of any third party products (software or hardware. THE INSTALLATION OF ANY THIRD PARTY PRODUCTS OTHER
THAN AS AUTHORIZED BY EFI WILL VOID THIS WARRANTY. IN ADDITION, USE, MODIFICATION, AND/OR REPAIR OF THE PRODUCT
OTHER THAN AS AUTHORIZED BY EFI WILL VOID THIS WARRANTY.
EXCEPT FOR THE ABOVE EXPRESS LIMITED WARRANTY AND TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, EFI MAKES AND
YOU RECEIVE NO WARRANTIES OR CONDITIONS ON THE SOFTWARE, EXPRESS, IMPLIED, STATUTORY, OR IN ANY OTHER PROVISION OF
THIS AGREEMENT OR COMMUNICATION WITH YOU, AND EFI SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTY OR CONDITION OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF THIRD PARTY RIGHTS.
Limitation of Liability
TO THE MAXIMUM EXTENT PERMITTED BY LAW, EFI AND ITS SUPPLIERS SHALL NOT BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF
DATA, LOST PROFITS, COST OF COVER OR OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING FROM THE
SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE OR FAILURE OF THE SOFTWARE, HOWEVER CAUSED AND ON ANY THEORY OF
LIABILITY. THIS LIMITATION WILL APPLY EVEN IF EFI HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. YOU ACKNOWLEDGE
THAT THE PRICE OF THE PRODUCT REFLECTS THIS ALLOCATION OF RISK. BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY
TO YOU.
You are hereby notified that Adobe Systems Incorporated, a Delaware corporation located at 345 Park Avenue, San Jose, CA 95110-2704 (“Adobe”) is a third-party
beneficiary to this agreement to the extent that this agreement contains provisions which relate to your use of any software, font programs, typefaces, and/or trademarks
licensed or supplied by Adobe. Such provisions are made expressly for the benefit of Adobe and are enforceable by Adobe in addition to EFI. ADOBE WILL HAVE NO
LIABILITY WHATSOEVER TO YOU FOR ANY ADOBE SOFTWARE OR TECHNOLOGY LICENSED HEREUNDER.
Export Controls
EFI’s Products are subject to U.S. export laws and regulations, including the U.S. Export Administration Regulations, as well as foreign export laws and regulations. You
agree that you will not use, distribute, transfer, export, or re-export any portion of the Product or the Software in any form in violation of any applicable laws or regulations
of the United States or the country in which you obtained them.

10 Copyright
C9800 Color Guide - 10
U.S. Government Restricted Rights:
Use, duplication, or disclosure of the Software by the United States Government is subject to restrictions as set forth in FAR 12.212 or DFARS 227.7202-3 -227.7202-
4 and, to the extent required under U.S. federal law, the minimum restricted rights as set out in FAR 52.227-14, Restricted Rights Notice (June 1987) Alternate
III(g)(3)(June 1987) or FAR 52.227-19 (June 1987). To the extent any technical data is provided pursuant to the Agreement, such data is protected per FAR 12.211 and
DFARS 227.7102-2 and to the extent explicitly required by the U.S. Government, is subject to limited rights as set out in DFARS 252.227.7015 (November 1995) and
DFARS 252.227-7037 (September 1999). In the event that any of the above referenced agency regulations are modified or superceded, the subsequent or equivalent
regulation shall apply. The name of the Contractor is Electronics for Imaging.
General
The rights and obligations of the parties related to this Agreement will be governed in all respects by the laws of the State of California exclusively, as such laws apply to
contracts between California residents performed entirely within California. The United Nations Convention on Contracts for the International Sale of Goods and any
other similar convention does not apply to this Agreement. For all disputes related to this Agreement, you consent to the personal and exclusive jurisdiction and venue
of the state courts in San Mateo County, California and the federal court for the Northern District of California. This Agreement is the entire agreement held between
us and supersedes any other communications or advertising with respect to the Software. If any provision of this Agreement is held invalid, such provision shall be deemed
modified to the extent necessary to be enforceable and the other provisions in this Agreement shall continue in full force and effect.
If you have any questions, please see EFI’s web site at www.efi.com.
Electronics for Imaging
303 Velocity Way
Foster City, CA 94404

11 About this manual
C9800 Color Guide - 11
This manual explains how to manage color output on the Fiery, and provides
information on calibration and color profiles.
This manual is part of a set of documentation that includes manuals for users and
system administrators. The other manuals are available at your site—refer to them for
a complete description of your Fiery.
NOTE:The term “Fiery” is used in this manual to refer to the Fiery Network Controller
for C9800. The name “Aero” is used in illustrations to represent the Fiery. The term
“Windows” is used to refer to Windows 98, Windows Me, Windows NT 4.0,
Windows 2000, Windows XP, and Windows Server 2003, wherever appropriate.
Illustrations of Windows software may not necessarily reflect the version of Windows
that you use.
About this manual
This manual is organized to supply you with key information about managing the
color output of your Fiery.
•Chapter 1 describes the Fiery print options and how to get the best color results.
•Chapter 2 covers various methods of calibrating the Fiery.
•Chapter 3 discusses the features of ColorWise Pro Tools. ColorWise Pro Tools
include Profile Manager, used to manage color profiles on the Fiery, and Color
Editor, which allows you to customize simulation and output profiles. This chapter
also describes Spot-On®, which allows you to define CMYK equivalents for spot
colors. Spot-On®is a utility supplied with C9800 GA only. It is not available for
standard models.
•Appendix A provides information about setting up and calibrating color
measurement instruments.
•Appendix B describes the Simple ASCII File Format (SAIFF), which can be used to
import toner density measurements from measurement devices.
Introduction

12 Introduction
C9800 Color Guide - 12
•TheFiery Color Reference Glossary defines words in bold—for example, output
profile—that appear throughout this manual. Color terms and concepts, such as
“color space,” “spot color,” “gamut,” and “source profile,” are used throughout this
manual. If you are new to desktop color, or if any terms are unfamiliar, check the
Glossary.
Key features of ColorWise
ColorWise is the color management system (CMS) built into the Fiery and designed to
provide both casual and expert users with the best color output for a variety of
purposes. The ColorWise default settings provide high-quality out-of-box color from
many Windows and Mac OS applications. This allows casual users to achieve quality
output without knowing about or changing any color settings on the Fiery.
For consistent color, calibrate the Fiery on a regular basis. ColorWise Pro Tools include
an easy-to-use calibrator, which allows you to calibrate using a spectrophotometer or
densitometer (see Chapter 2).
ColorWise features allow you to modify printing results. Depending on your particular
needs, you can:
• Set the behavior of CMYK printing to emulate DIC, Euroscale, and SWOP offset
press standards.
• Match PANTONE and other spot colors for the best match when printed using
four-color press conditions or when printed using presses with extra, custom plates.
• Select a color rendering dictionary (CRD), also called a rendering style, for RGB
printing. CRDs allow for rich, saturated printing of presentation graphics; smooth,
accurate printing of photographs; and relative or absolute colorimetric rendering for
specialized needs.

13 Key features of ColorWise
C9800 Color Guide - 13
• Define the source of incoming RGB color data for better screen matching and
provide for better color conversion of RGB data with no source information.
• Define whether RGB data is converted into the full gamut of the printer or whether
it is first converted into the gamut of another device, such as a press standard. This
feature is helpful for making one device behave like another. It is also useful for
evaluating the appearance of the RGB file under different printing conditions
without having to reprocess the RGB data each time.
ColorWise color management (ColorWise) offers an open color architecture, allowing
users to customize the Fiery to meet new printing needs as they arise. ColorWise
supports ICC profiles, which are industry standard color profiles that describe the
color behavior of a device. Downloading ICC profiles to the Fiery enables the Fiery to
simulate a custom press (or another printer), as well as accurately print colors from a
particular monitor or a scanner. In addition, you can create customized ICC profiles
for the printer.
ColorWise also allows you to use any Status T densitometer by importing data in a
standard file format (see Appendix B). In this case, it is important to note that the
quality of the instrument used will determine the quality of the calibration.

1
1-14 Managing color on the Fiery
C9800 Color Guide - 14
The following sections describe the options available from the ColorWise color
management system and explain how to customize the color settings for your
particular needs. They provide descriptions of the preset ColorWise default settings
and cover additional options for users who need to customize ColorWise.
For information on PostScript Level 2 or 3 printer drivers, see page 1-27. The section
also contains information on the capabilities of printer drivers and instructions for
setting color options with the PostScript drivers for Windows and Mac OS computers.
Managing color on the Fiery
To modify printing behavior, do any of the following:
• Select ColorWise options for an individual print job using menus that appear in the
printer driver.
• Select most ColorWise options as server defaults from the “Color Setup” application
in ColorWise Pro Tools (see page 3-83). Defaults can also be set from Fiery Setup, as
described in the Configuration Guide Chapter 4. These defaults will apply to all
subsequent print jobs unless you override them.
• Select some ColorWise options, particularly default ICC profile settings and
calibration options, from ColorWise Pro Tools. These options include default
Simulation Profile (see page 1-23), CMYK Simulation Method (see page 1-24),
Appear in Driver as (see page 3-61), default Source Profile (see page 1-22), RGB
Separation (see page 1-25), and associated calibration set (see page 2-36).
Applications can generate color data for the Fiery in many different color spaces. The
most common type of color data produced from office applications is RGB, while
prepress applications generally produce CMYK data. Desktop applications can also
generate spot colors, such as PANTONE colors. To complicate matters, a single page
may contain a mix of RGB, CMYK, and spot colors. The Fiery allows users to control
the printing of these mixed-color documents with features that apply specifically to
RGB, CMYK, or spot color data. Fiery color management generates CMYK data to be
sent to the printer.
Chapter 1:
Fiery Color
Management

1
1-15 Managing color on the Fiery
C9800 Color Guide - 15
The following diagram illustrates the print options in the Fiery color management
process that affect color data conversions. You can access these print options when you
send a print job to the Fiery. Most of these options and settings are described in
subsequent sections of this chapter.
RGB Source Profile is the only color option that applies strictly to RGB color data.
The other options that affect RGB color also affect the more rarely used Lab, XYZ, and
other calibrated color spaces.
NOTE:For users who are familiar with PostScript 3 color, RGB Source Profile affects all
CIEBasedABC color spaces (if the source space is RGB). If you send CMYK data to
the Fiery in CIEBasedDEFG format, for example, by choosing PostScript Color
Management in Adobe Photoshop, the Fiery Rendering Style selection—which
normally affects only RGB data—will also affect this CMYK data.
RGB Source Profile
Gamma
Phosphors
White Point
Rendering Style (CRD)
Black Overprint
Brightness
Pure Black Text/Graphics
RGB Separation
Output profile color data sent
to printer
Fiery
color processor
RGB data
CMYK data
Spot color data Spot Color Matching
CMYK Simulation Profile
CMYK Simulation Method
Black Overprint
Brightness
Pure Black Text/Graphics
Combine Separations
Output profile

1
1-16 Fiery Color Management
C9800 Color Guide - 16
You can specify settings for the following options by selecting print options when you
send a job to the Fiery. Some can also be set as defaults by the administrator during
Fiery Setup or using ColorWise Pro Tools. Settings specified using print options over-
ride the defaults. Some options are only available with Spot-On, which is supplied
with C9800 GA only.
Fiery color print option What it does
Brightness
85% Lightest to 115% Darkest
Performs a color adjustment on all color channels to make the printed output
lighter or darker.
CMYK Simulation Method
Quick/Full (Source GCR)/Full (Output
GCR)
(Default set at Setup or with ColorWise Pro
Tools)
Quick simulation applies one-dimensional transfer curves that adjust output
density only. The Full simulations apply colorimetric transformations that
adjust hue as well as output density (see page 1-24).
CMYK Simulation Profile
SWOP-Coated (EFI)/DIC (EFI)/
Euroscale (EFI)/None
(Default set at Setup or in ColorWise Pro
Tools)
Adjusts CMYK color data to simulate an offset press standard or a custom
color gamut defined at your site. Choosing None bypasses simulation (see
page 1-23).
Color Mode (Mac OS)
CMYK/Grayscale
or
Print Mode (Windows)
Standard Color/Expert Color/Grayscale
Specifies the output color space of the job. Select CMYK, Standard Color, or
Expert Color for a full-color document.
(Other) Gamma
1.0/1.2/1.4/1.6/1.8/2.0/2.2/2.4/2.6/2.8/3.0
(Default set with ColorWise Pro Tools)
Applies the specified gamma value to the RGB source space definition (see
page 1-22). To use this print option, you must choose Other as the RGB
Source Profile setting.
(Other) White Point
5000 K (D50)/5500 K/6500 K (D65)/
7500 K/9300 K
(Default set with ColorWise Pro Tools)
Applies the specified white point value to the RGB source color space
definition (see page 1-22). To use this print option, you must choose Other as
the RGB Source Profile setting.
(Other) Phosphors
Hitachi EBU/Hitachi-Ikegami/NTSC/
Radius Pivot/SMPTE/Trinitron
(Default set with ColorWise Pro Tools)
Applies the specified phosphor (monitor type) information to the RGB source
space definition (see page 1-22). To use this print option, you must choose
Other as the RGB Source Profile setting.

1
1-17 Managing color on the Fiery
C9800 Color Guide - 17
Detailed explanations of how these and other settings affect your print jobs are
provided in subsequent sections of this chapter.
Output Profile
Output1-10
(Default set at Setup or with ColorWise Pro
Tools)
The output profile is applied to all data in the print job (see page 1-26). User-
defined output profiles can be downloaded to the Fiery using ColorWise Pro
Tools. For more information about using ColorWise Pro Tools, see Chapter 3.
Pure Black Text/Graphics
On/Off
(Default set at Setup or with ColorWise Pro
Tools)
The On setting optimizes the quality of black text and line art output (see
page 1-19).
Rendering Style
Photographic/Presentation/Relative
Colorimetric/Absolute Colorimetric
(Default set at Setup or with ColorWise Pro
Tools)
Applies a Fiery color rendering dictionary (CRD) to RGB data (see page 1-18),
or to any incoming data with a PostScript source color space definition,
including CMYK.
RGB Separation
Output/Simulation
(Default set at Setup or with ColorWise Pro
Tools)
Determines which CMYK color space your original RGB data will be
separated into—CMYK for the printer (Output) or CMYK for a specified
simulation (Simulation). For more information, see page 1-25.
NOTE:When RGB Separation is set to Simulation, RGB colors are affected by
CMYK Simulation Profile and CMYK Simulation Method.
RGB Source Profile
EFIRGB/sRGB (PC)
/Apple Standard/Other/
None
(Default set at Setup or with ColorWise Pro
Tools)
Applies an RGB source space definition to RGB data (see page 1-22). If you
choose the Other setting, you must also specify particular settings for Gamma,
Phosphors, and White Point. See the corresponding options in this table. This
option, along with Gamma, Phosphors, and White Point, only affects
DeviceRGB or calibrated RGB color spaces.
Spot Color Matching
On/Off
(Default set at Setup or with ColorWise Pro
Tools)
The On setting enables Fiery-defined matching of spot colors to their best
CMYK equivalents. With Spot-On, you can manage and edit these spot color
matches (see page 3-70). Off instructs the Fiery to match color output to a
CMYK combination specified by the source application for the document (see
page 1-21).
Fiery color print option What it does

1
1-18 Fiery Color Management
C9800 Color Guide - 18
Rendering Style
The Rendering Style option specifies a CRD for color conversions. To control the
appearance of images, such as prints from office applications or RGB photographs
from Photoshop, select the appropriate Rendering Style. The Fiery allows you to select
from the four rendering styles currently found in industry standard ICC profiles.
Fiery rendering style Best used for Equivalent ICC
rendering style
Photographic—Typically results
in less saturated output than
presentation rendering when
printing out-of-gamut colors. It
preserves tonal relationships in
images.
Photographs, including scans
and images from stock
photography CDs and digital
camera images.
Image, Contrast, and
Perceptual
Presentation—Creates
saturated colors but does not
match printed colors precisely
to displayed colors. In-gamut
colors such as flesh tones are
rendered well; similar to the
Photographic rendering style.
Artwork and graphs in
presentations. In many cases, it
can be used for mixed pages
that contain both presentation
graphics and photographs.
Saturation, Graphics
Relative Colorimetric—Provides
white-point transformation
between the source and
destination white points. For
example, the bluish gray color
of a monitor will map to neutral
gray. You may prefer this style
to avoid visible borders when
not printing full-bleed.
Advanced use when color
matching is important, but you
prefer white colors in the
document to print as paper
white. It may also be used with
PostScript color management to
affect CMYK data for
simulation purposes.
Relative Colorimetric
Absolute Colorimetric—
Provides no white point
transformation between the
source and destination white
points. For example, the bluish
gray of a monitor will map to a
bluish gray.
Situations when exact colors are
needed and visible borders are
not distracting. It may also be
used with PostScript color
management to affect CMYK
data for simulation purposes.
Absolute Colorimetric

1
1-19 Managing color on the Fiery
C9800 Color Guide - 19
Pure Black Text/Graphics
The Pure Black Text/Graphics option affects the printout for black text and vector
graphics on a page. Under most circumstances, leave this option set to On. When Pure
Black Text/Graphics is on, black colors generated by applications (for example, RGB =
0, 0, 0; CMYK = 0%, 0%, 0%, 100%; or K = 100%) are printed using the maximum
amount of black toner allowed by the calibration curve. This means the black text and
line art will not exhibit halftone artifacts (as long as the printer is calibrated correctly)
and will not be misregistered, since there is only one toner used. In addition, this
setting eliminates blasting.
For some jobs, it is preferable to clear this option, for example, if the page includes
gradient fills that use black. The following table describes the behavior of the Pure
Black Text/Graphics option with black data defined in different color spaces.
NOTE:Use the Pure Black Text/Graphics option only when printing composites, not
when printing separations.
NOTE:PostScript applications (such as QuarkXPress) may convert elements defined as
RGB = 0, 0, 0 to four-color CMYK black before sending the job to the Fiery. These
elements are not affected by the Pure Black Text/Graphics option. For details, see the
application notes. Also, black text and line art defined as RGB = 0, 0, 0 in office
applications (such as Microsoft Word) are converted to single-color black (CMYK =
0%, 0%, 0%, 100%) by the Microsoft PostScript Level 3 driver for Windows
2000/XP. To print this single-color black at the maximum toner density of the printer,
set the Pure Black Text/Graphics option to On.
Input
black color
Pure Black Text/Graphics
On Off
RGB Prints 100% black With the default profile, prints a rich black using
all toners.
CMYK Prints only with black toner, because CMYK
simulations preserve the black channel. The actual
amount of toner used depends on the current
simulation and the calibration state of the printer.
Spot Prints only with black toner, because spot color
simulations preserve the black channel. The actual
amount of toner used depends on the current
simulation and the calibration state of the printer.

1
1-20 Fiery Color Management
C9800 Color Guide - 20
Black Overprint
The Black Overprint option allows you to specify whether or not black text or
text/graphics—defined as RGB = 0, 0, 0, or as CMYK = 0%, 0%, 0%, 100%—
overprints colored backgrounds.
•Text—Black text overprints colored backgrounds, eliminating white gaps and
reducing halo effects or misregistration of colors.
•Text & Graphics—Black text and graphics overprint colored backgrounds,
eliminating white gaps and reducing halo effects or misregistration of colors.
•Off—Black text or text/graphics knocks out colored backgrounds.
NOTE:PostScript applications may perform their own black overprint conversions
before sending the print job to the Fiery.
One example of how you might use this setting is with a page that contains black text
on a light blue background. The background blue color is CMYK = 40%, 30%, 0%,
0% and the black text is CMYK = 0%, 0%, 0%, 100%.
• With Black Overprint set to Text or Text & Graphics, the final text or text/graphic
portions of the page are overprinted, or combined with the underlying colors. Black
colors generated by applications (for example, RGB = 0%, 0%, 0%; CMYK = 0%,
0%, 0%, 100%) are printed using the maximum amount of black toner allowed by
the calibration curve. This means that black text and line art will not exhibit
halftone artifacts (as long as the printer is calibrated correctly). There is no transition
in the cyan and magenta toners, and the quality of the output is improved since it
will not show artifacts near the edges of the text or text/graphics. The option also
works with text defined in the RGB color space, that is RGB = 0, 0, 0.
• With Black Overprint Off, the border of the text or text/graphics is on an edge that
has cyan and magenta toners on one side (outside the text) and black toner on the
other side (inside the text). This transition may cause visible artifacts because of the
practical limitations of the printer.
