Oki ES3037 User manual

ES 3037/3037e Macintosh • 2
Every effort has been made to ensure that the information in this
document is complete, accurate, and up-to-date. The manufacturer
assumes no responsibility for the results of errors beyond its
control. The manufacturer also cannot guarantee that changes in
software and equipment made by other manufacturers and referred
to in this Guide will not affect the applicability of the information in it.
Mention of software products manufactured by other companies
does not necessarily constitute endorsement by the manufacturer.
While all reasonable efforts have been made to make this document
as accurate and helpful as possible, we make no warranty of any
kind, expressed or implied, as to the accuracy or completeness of
the information contained herein.
Copyright © 2003. All rights reserved.
As an ENERGY STAR®Program Participant, the
manufacturer has determined that this product meets
the ENERGY STAR guidelines for energy efficiency.
ESTAR.eps
This product complies with the requirements of the Council
Directives 89/336/EEC (EMC) and 73/23/EEC (LVD) as amended
where applicable on the approximation of the laws of the member
states relating to electromagnetic compatibility and low voltage.
Oki and Microline are registered trademarks of Oki Electric Industry Company Ltd.
ENERGY STAR is a registered trademark of the United States Environmental
Protection Agency.
Hewlett-Packard, HP, and LaserJet are registered trademarks of Hewlett-Packard
Company.
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft
Corporation.
Apple, Macintosh and Mac OS are registered trademarks of Apple Computers Inc.
Other product names and brand names are registered trademarks or trademarks of
their proprietors.

ES 3037/3037e MacintoshContents • 3
Contents
Notes, Cautions, etc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Model summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
How to use this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Online usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Printing Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Getting started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Unpacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
CD-ROM disk contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Printer location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Printer components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Setting up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Packaging and protective sheet removal . . . . . . . . . . . . . . . . . . . . . .20
Toner cartridge installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Loading paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Manual feed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Power connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Changing the display language . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Printing the MenuMap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Media settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Media recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Envelopes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Paper feed and exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Paper Sizes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Paper weights and media settings . . . . . . . . . . . . . . . . . . . . . . . . .45
Printer settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Confirming current settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
List of menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
List of administrator menu settings . . . . . . . . . . . . . . . . . . . . . . . . . .74
Setting color tuning from the front panel. . . . . . . . . . . . . . . . . . . . . .77
Switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
Mac OS 8.6-9.2.2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83

ES 3037/3037e MacintoshContents • 4
Adjusting Printer Driver Options . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Change PostScript®Printer Description (PPD) File . . . . . . . . . . .83
Installable Options: Available Tray. . . . . . . . . . . . . . . . . . . . . . . .85
Installable Options: Duplex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Installable Options: Hard Disk . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Installable Options: Finisher . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Installable Options: Memory Configuration . . . . . . . . . . . . . . . . .89
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Color Print Matching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Factors that affect the appearance of prints . . . . . . . . . . . . . . . . . .91
Choosing a Color Matching Method . . . . . . . . . . . . . . . . . . . . . . . . .94
RGB or CMYK? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
Matching Photographic Images . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Matching Specific Colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Printing Vivid Colors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Driver Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Color Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Job Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Job Option List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Job Type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
General Printing Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
Multiple Pages on One Sheet. . . . . . . . . . . . . . . . . . . . . . . . . . . .120
Duplex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
Collating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .124
Mac OS 10.1.5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Printer Drivers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Adjusting options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Color Print Matching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
Factors that affect the appearance of prints . . . . . . . . . . . . . . . . .127
Monitor Color Profile Select . . . . . . . . . . . . . . . . . . . . . . . . . . . .128
Color Profile Select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130
Choosing a Color Matching Method . . . . . . . . . . . . . . . . . . . . . . . .132
RGB or CMYK? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132
Matching Photographic Images . . . . . . . . . . . . . . . . . . . . . . . . . .133
Matching Specific Colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .133
Printing Vivid Colors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134
Driver Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135
OKI Printer Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135
General Printing Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .149

ES 3037/3037e MacintoshContents • 5
Multiple Pages on One Sheet. . . . . . . . . . . . . . . . . . . . . . . . . . . .149
Duplex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150
Collating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .151
Mac OS 8.6-9.2.2 Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .154
Storage Device Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .154
Installation Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .156
Storage Device Manager Operation . . . . . . . . . . . . . . . . . . . . . . . . .158
Open SDM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .158
SDM Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .161
SDM Menu Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162
Fonts Downloader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168
Color Swatch Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169
Open Color Swatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169
Create a Custom Swatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170
OkiNet Utility for EtherTalk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .172
Rename Printer/Zone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .172
Change Parse Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174
Print Config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174
Check Print Server Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175
Configure Printer Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .176
Reset/Restore. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .176
Mac OS 10.1.5 Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Adding Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178
Changing the toner cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .180
Changing the image drum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .186
Changing the transfer belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190
Changing the fuser unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .192
Cleaning the LED heads. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195
Transporting the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .196
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
LCD messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .198
Paper jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .201
Parallel transmission mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .209
Problem solving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .210
Paper feed problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .210
Paper jam has been cleared, but printer does not print.. . . . . . . .210
Problems printing from Macintosh. . . . . . . . . . . . . . . . . . . . . . . . . .211
Cannot configure for USB connection. . . . . . . . . . . . . . . . . . . . .211
Cannot print. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .212

ES 3037/3037e MacintoshContents • 6
Printing is slow. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .212
Printer requests paper size change to continue printing. . . . . . . .212
Problems with poor quality printing. . . . . . . . . . . . . . . . . . . . . . . . .213
Longitudinal white stripes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .213
Longitudinal fading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .213
Faint printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .213
Fading in patches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .213
Longitudinal black stripes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214
Faint shading on unprinted sections. . . . . . . . . . . . . . . . . . . . . . .214
Blurred letter edges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .214
Miscellaneous problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .215
The power is on, but the printer does not go online. . . . . . . . . . .215
Print processing does not start. . . . . . . . . . . . . . . . . . . . . . . . . . .215
Print processing cancels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .215
Printer makes a strange noise. . . . . . . . . . . . . . . . . . . . . . . . . . . .215
An asterisk (*) symbol appears on the display, repeatedly moving
across the first line then the second. . . . . . . . . . . . . . . . . . . . . . .216
It takes a long time to start printing. . . . . . . . . . . . . . . . . . . . . . .216
Toner rubs off the printed surface.. . . . . . . . . . . . . . . . . . . . . . . .217
Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .218
Additional memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .219
Installing additional memory . . . . . . . . . . . . . . . . . . . . . . . . . . . .220
Internal hard disk drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .223
Installing the hard disk drive . . . . . . . . . . . . . . . . . . . . . . . . . . . .223
Duplex unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .226
Additional paper trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .229
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .229
High capacity feeder (HCF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .233
Installing the high capacity feeder. . . . . . . . . . . . . . . . . . . . . . . .233
Finisher. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .237
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238
Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242
Toner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .242
Drums . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .242
Fuser units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .243
Transfer belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .243
OKI®print media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .244
Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246

ES 3037/3037e MacintoshContents • 7
Print menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .246
Media menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .247
Color menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .248
System Config menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .249
PCL Emulation menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .249
PPR Emulation menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .250
FX Emulation menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .251
Parallel menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .251
USB menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .252
Network menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .252
Memory menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .252
System Adjust menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .253
Maintenance menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .254
Usage menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .254
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

ES 3037/3037e Notes, Cautions, etc. • 8
Notes, Cautions, etc.
NOTE
A note appears like this. A note provides additional
information to supplement the main text which helps you to
use and understand the product.
CAUTION!
A caution appears like this. A caution provides additional
information which, if ignored, may result in equipment
malfunction or damage.
WARNING!
A warning appears like this. A warning provides additional
information which, if ignored, may result in a risk of
personal injury.
Important!
An important message appears like this. An important message
provides supplemental information which can prevent potential
problems.

ES 3037/3037e Introduction • 9
Introduction
Congratulations on purchasing this OKI Executive Series color
printer!
In this chapter you will find a summary of the main features of your
printer followed by some advice on how to use this User’s Guide to
get the most from your printer.
MODEL SUMMARY
Model Resolution Print speed
Network
card
Duplex
Unit Memory
Hard
disk
ES 3037 600 x 1200
dpi
Letter:
30 ppm color
37 ppm mono
Tabloid:
16 ppm color
20 ppm mono
Option Option
(Requires
additional
memory
128 Mb Option
ES 3037e 1200 dpi Letter:
30 ppm color
37 ppm mono
Tabloid:
16 ppm color
20 ppm mono
Standard Standard 320 Mb Standard

ES 3037/3037e Introduction • 10
FEATURES
•Single pass digital technology for high quality, speed and
reliability.
•Duplex printing for fast reliable two-sided output (standard
on ES 3037e, optional on ES 3037).
•High capacity 10Gb hard disk drive (standard on ES
3037e, optional on ES 3037).
•Versatile paper handling:
– Standard 550-sheet (20-lb. paper) paper tray
– Standard 100-sheet (20-lb. paper) multi-purpose tray for
paper, card stock, envelopes, labels, etc.
– Optional 550-sheet paper trays: up to two can be added to
expand the paper capacity to 1690 sheets.
– Optional High Capacity Feeder, mounted on casters, with
three 550-sheet trays expanding printer capacity by 1650
sheets (approx.).
•Flexible interfaces with automatic switching:
–USB
– High-speed, bi-directional parallel (IEEE-1284)
– Industry standard network connectivity via internal network
interface card.
•Environmentally friendly: the advanced power save mode
minimizes power consumption and the separate toner and
drum design cuts down on waste.

ES 3037/3037e Introduction • 11
•Automatic color balance adjustment: in order to ensure
consistent output at all times, the machine automatically
performs a color check when the machine is switched on,
when the top cover is opened and then closed, and adjusts
the color balance automatically. It can even be set to adjust
the color balance during long print runs.
•Auto media detect: detects the weight of the media being
fed through the printer then automatically adjusts the fusing
temperature, speed (if necessary) and transfer voltage to
ensure correct fusing and print quality.

ES 3037/3037e Introduction • 12
HOW TO USE THIS MANUAL
This manual will lead you logically through the unpacking, setup and
operation of your printer to help you to make the best use of its
many advanced features.
It also includes:
•troubleshooting information
•maintenance guidelines
•instructions for adding optional accessories as your needs
evolve
Online usage
This manual is intended to be read on screen using Adobe Acrobat
Reader. Use the navigation and viewing tools provided in Acrobat.
You can access specific information in two ways:
•In the list of bookmarks down the left hand side of your
screen, click the topic of interest to jump to the required
topic. (If the bookmarks are not available, use the Table of
Contents.)
•In the list of bookmarks click Index to jump to the Index. (If
the bookmarks are not available, use the Table of
Contents.) Find the term of interest in the alphabetically
arranged index and click the associated page number to
jump to the page containing the subject.
NOTES
This User’s Guide has been written using one printer as a
model, and the illustrations/screenshots reflect this.
The information in this manual is supplemented by the
extensive online help facility associated with the printer
driver software.

ES 3037/3037e Introduction • 13
Printing Pages
The whole book, Individual pages, or sections may be printed. The
procedure for printing from Acrobat Reader is:
1. From the toolbar, select File, then Print (or press the
Ctrl + P keys).
2. Choose which pages you wish to print:
a. All pages for the entire manual.
b. Current page for the page at which you are looking.
c. Pages from and to for the range of pages you specify by
entering their page numbers.
3. Click OK.

ES 3037/3037e Getting started • 14
Getting started
UNPACKING
After unpacking the printer and choosing a suitable place to put it,
check that all the necessary parts are available to continue:
zprinter and toners.eps
1. The printer.
2. 4 toner cartridges (cyan, magenta, yellow and black).
3. Power cable
4. CD-ROM disks.
5. LED lens cleaner (not illustrated).
6. Light-proof plastic bags (not illustrated).
7. Documentation (not illustrated): Setup Guide, Software
Installation Guide, Warranty booklet.
Retain all packing materials to facilitate transport.
WARNING!
The printer weighs 160 lbs. ( 72 kg) without the duplex
unit; 172 lbs. (78 kg) with the duplex unit installed (dxn
models).
Three (3) people are required to lift the printer safely.

ES 3037/3037e Getting started • 15
CD-ROM DISK CONTENTS
The CD-ROM disks supplied with your printer contain the following
software:
•CD1 - Drivers, Software Utilities
•CD2 - Manuals

ES 3037/3037e Getting started • 16
PRINTER LOCATION
Place the printer on a flat surface large enough and strong enough
to accept the size and weight of the printer. There must be sufficient
space around the printer to allow for access and printer
maintenance.
c93printerloca.EPS
39.4inches
100cm
23.6inches
60cm 7.9inches
20cm
23.6inches
60cm
27.6inches
70cm 160lbs(72kg)
or 172lbs(78kg)
with duplexer
installed

ES 3037/3037e Getting started • 17
PRINTER COMPONENTS
zprinter components 1a.eps
1. Top cover
2. Control panel
3. Top cover release catch
4. Multi-purpose (MP) tray (manual feed)
5. Paper support extensionPaper guides
6. Right side cover
7. Paper tray
8. Paper level indicator
9. Power switch
10. LED heads (4)

ES 3037/3037e Getting started • 18
PRINTER COMPONENTS (CONTINUED)
11. Discharge roller
12. Fuser unit
13. Image drum (cyan)
14. Image drum (magenta)
15. Image drum (yellow)
16. Image drum (black)
17. Power connector

ES 3037/3037e Getting started • 19
PRINTER COMPONENTS (CONTINUED)
18. Straight-through exit paper tray
19. Interfaces and card slot
20. USB interface connector
21. Parallel interface connector
22. Network interface card

ES 3037/3037e Setting up • 20
Setting up
Before connecting this printer to a computer and power supply, the
toner cartridges must be installed and paper must be inserted in the
paper tray.
PACKAGING AND PROTECTIVE SHEET REMOVAL
1. Remove any adhesive tape and packaging from the printer.
2. Using the release handle, open the top cover.
zmopen top cover.eps
