Olivetti Nettun A7000 Open User manual

OLIVETTI S.P.A. VIA JERVIS, 77 10015 IVREA (TO) ITALY www.olivetti.com
QUICK GUIDE - GUIDE RAPIDE
KURZANLEITUNG - GUÍA RÁPIDA
OLIVETTI S.P.A. VIA JERVIS, 77 10015 IVREA (TO) ITALY www.olivetti.com
open
Code: 585411
CASH REGISTER

CASH REGISTER
ISTRUZIONI PER L'USO
Printed in Italy
open
QUICK GUIDE
GUIDE RAPIDE
KURZANLEITUNG
GUÍA RÁPIDA
Printed in Italy
FRANÇAIS
FRANÇAIS ENGLISH
FRANÇAIS
DEUTSCHESPAÑOL

CASH REGISTER
ISTRUZIONI PER L'USO
Printed in Italy
open
QUICK GUIDE
Printed in Italy
ENGLISH

Publication issued by:
Olivetti S.p.A.
Telecom Italia Group
Via Jervis, 77 - 10015 Ivrea (TO)
Copyright © 2015, by Olivetti
All rights reserved
For more detailed information on how to use the cash register functions, the User
Manual can be downloaded from the Olivetti site (www.olivetti.com) that contains
detailed information.
The manufacturer reserves the right to carry out modifications to the product
described in this manual at any time without any notice.
The quality requirements of this product are attested
through display of CE marking on the product.
Your attention is drawn to the following actions which could compromise the
conformity attested to above and also product characteristics:
•incorrect power supply;
•incorrect installation, incorrect or improper use or use not in compliance with
the warnings provided in the User’s Manual furnished with the product;
•replacement of original components or accessories with others of a type not
approved by the manufacturer, or performed by unauthorised personnel
User Safety
Connect the machine to a nearby and readily accessible current outlet.
Access the print unit area only to replace accessories. Do not use the machine
above or close to sources of heat (e.g. radiators) or very close to water (e.g.
swimming-pools or showers).
To effectively disconnect the appliance, remove the plug of the power cord from the
current outlet. To clean the machine, disconnect it from the current outlet, use a
damp cloth. Do NOT not use corrosive liquids.
This manual describes the cash register sold with the name NETTUN@7000open.
Warning:
This is a Class A appliance.
In a residential environment, it may cause radio interference in which
case the user may be required to take adequate measures.

iii
ENGLISH
TABLE OF CONTENTS
INTRODUCTION ................................................................................ 1
INSTALLATION ................................................................................. 2
PACKAGE CONTENTS ............................................................................. 2
INSTALLATION PREREQUISITES ........................................................... 3
CONNECTING THE CASH REGISTER TO THE POWER SUPPLY ......... 4
POWERING ON THE CASH REGISTER ................................................... 6
INSERTING PAPER ................................................................................... 7
SAFETY PRECAUTIONS AND GENERAL RULES FOR USE ..............7
INSERTING THE PAPER ROLL .............................................................8
REGULATING THE NEAR-END-OF-PAPER SENSOR .......................10
PRINTING UNIT ....................................................................................10
GETTING TO KNOW YOUR CASH REGISTER ............................. 11
MAIN COMPONENTS .............................................................................. 11
CUSTOMER DISPLAY ............................................................................. 13
HOW TO USE THE TOUCH SCREEN ..................................................... 13
TECHNICAL SPECIFICATIONS ...................................................... 14
CASING.................................................................................................14
CUSTOMER DISPLAY.......................................................................... 14
MODULE SPECIFICATIONS ................................................................14
BUILT-IN THERMAL PRINTER ............................................................15
POWER UNIT........................................................................................15
ELECTRICAL SPECIFICATIONS .........................................................15
POWER SUPPLY DATA .......................................................................15
ENVIRONMENTAL SPECIFICATIONS ................................................15
SIZE AND WEIGHT...............................................................................15
SOFTWARE AVAILABLE ......................................................................15

DIRECTIVE
1. FOR COUNTRIES IN THE EUROPEAN UNION (EU)
The disposal of electric and electronic devices as solid urban waste is
strictly prohibited: it must be collected separately. The dumping of
these devices at unequipped and unauthorized places may have
hazardous effects on health and the environment. Offenders will be
subjected to the penalties and measures laid down by the law.
TO DISPOSE OF OUR DEVICES CORRECTLY:
a) Contact the Local Authorities, who will give you the practical
information you need and the instructions for handling the waste
correctly, for example: location and times of the waste collection
centres, etc.
b) When you purchase a new device of ours, give a used device similar
to the one purchased to our dealer for disposal.
The crossed dustbin symbol on the device means that:
- When it to be disposed of, the device is to be taken to the
equipped waste collection centres and is to be handled
separately from urban waste;
- Olivetti guarantees the activation of the treatment,
collection, recycling and disposal procedures in
accordance with Directive 2012/96/EC (and subsequent
amendments).
2. FOR OTHER COUNTRIES (NOT IN THE EU)
The treatment, collection, recycling and disposal of electric and
electronic devices will be carried out in accordance with the laws in
force in the country in question.

1
INTRODUCTION
The cash register described in this manual can be used for registering, for fiscal
purposes, the data related to the sales of goods and services, and represents an
indispensable tool for managing a sales point.
Key features of the product and its performance are a 10.1” touch screen monitor
with adjustable tilt, a printing unit with an automatic cutter for issuing tickets of widths
80 mm, 57.5 or 60 mm.
The machine has two serial interfaces, four USB interfaces and an Ethernet
connection port for connecting over the network to external devices such as barcode
readers and additional printers for issuing receipts and tickets.
ENGLISH

2
INSTALLATION
PACKAGE CONTENTS
The cash register is delivered in a single package containing the following
components:
Cash register
External power unit with power cord
Quick Start guide with instructions for use
Roll of thermal paper in initial supply
Drawer fixing kit
Adapter for handling paper rolls of widths 57.5 and 60 mm.

3
INSTALLATION PREREQUISITES
The installation steps for the cash register are:
- connect the cash register to the mains electricity supply
- power on the cash register
- insert the paper
- connect the barcode reader (not indispensable for general use)
- connect the drawer (not indispensable for general use)
- connect other external peripherals (not indispensable for general use).
For the cash register to be operational, the paper roll must be
loaded.
Warning
ENGLISH

4
CONNECTING THE CASH REGISTER TO THE POWER SUPPLY
Connect the external power unit first to the cash register (A) and then to the 220V
mains power supply (B).
B
A

5
General Warnings:
Do not insert foreign bodies into the cash register.
If the cash register is to remain unused for a long period, disconnect it from the
mains power socket.
To disconnect the appliance from the electrical power supply, remove the plug
from the mains power socket; remember to use a power socket near to the
machine that can be reached easily.
The appliance is certified as safe to use and compliant with applicable standards
only if used with an external power unit meeting the following specifications:
Power Supply Unit (alternative)
Input: 100-240V, 50/60Hz-1.2A
Output: 24 V DC 3.75A
The appliance is certified as safe to use and compliant with applicable standards
only if used with an external power unit of type:
Power Unit specifications:
Power Supply Unit (alternative)
Input: 100-240V, 50/60Hz-1.2A
Output: 24 V DC 3.75A
ENGLISH

6
Power on key
On-Off
Togglet
switch
POWERING ON THE CASH REGISTER
To power on the cash register, you must first have connected the power unit to the
cash register as previously described, then positioning the Toggle switch On and
then press the key. When the key is pressed the cash register powers on
and, after a brief interval, displays the sales environment. The cash register is now
operational.
When the cash register is on ( key lighted), it can be powered off by pressing the
key for about 1second. This starts the power off phase if no other operations
are in progress.
the key remains lighted.
To return the cash register at any time to operating mode and use it again just
touch the touch screen.
Warning If the cash register is not used for a certain amount of time, it
automatically enters energy saving mode. The touch screen is switched off but

7
INSERTING PAPER
Exclusively approved thermal paper should be used on the
cash register. If other types of thermal paper are used, in
particular paper that is too thin, the ticket may not be fed
correctly. Also the writing and logos on the back of the paper
must not be visible due to the transparency of the paper.
SAFETY PRECAUTIONS AND GENERAL RULES FOR USE
before using the product, read this section carefully.
Make sure that the electrical specifications of the power unit used with the cash
register (230 V AC, 50/60 Hz) correspond with those of the mains power supply.
Connect the cash register to a standard-compliant electrical installation.
Do not expose the printer to direct sunlight, or install it near heat or water
sources, or in environments that are very damp or dusty.
Should smoke, odours or unusual noises be detected coming from the cash
register, disconnect it from the mains power supply and contact the Technical
Services desk.
To avoid the risk of injury, do not touch any of the parts indicated in these figures:
Do not pull the paper out of the output slot with the cover of the cash register
closed.
Do not open the cover of cash register while it is printing.
Do not carry out any other interventions on the cash register apart from those
described for problem resolution.
Do not attempt to disassemble or modify the product.
The procedures described in the following can be used when you
are inserting a paper roll on the cash register for the first time, or when replacing a
used paper roll. Paper rolls of widths 80 mm, 60 mm and 57.5 mm can be used on
the printer, however before using 57.5 and 60 mm rolls, you must first install the
paper roll Adapter Kit. When a paper roll must be replaced you are informed by a
message that appears on the monitor.
Note
Printhead:
very hot
Automatic cutter blade:
very sharp Manual cutter blade: very sharp
Cutter counterblade:
very sharp:
Warning
Warning
ENGLISH

8
INSERTING THE PAPER ROLL
1. Open the printer cover.
2. Press the release lever (A)
on the control mechanism
downwards (until you hear
an opening click), then lift
the upper part of the printer.
3. Orienting the paper roll as
indicated in the figure here,
unwind about 20 cm of the
paper, then insert the roll
into its bay making sure to
keep hold of the unwound
paper.
A

9
4. Still keeping hold of the
unwound paper, close the
printer by pressing
simultaneously on both right
and left sides of the paper
output slot. Make sure that
the unit closes fully on both
sides (you should hear a click
from the closing mechanism).
5. Pull through the paper and
cut it using the manual cutter.
6. Close the top cover of the
printer.
ENGLISH

10
REGULATING THE NEAR-END-OF-PAPER SENSOR
The near end-of-paper sensor is set up in the factory to function correctly for
the most common types of paper roll.
If you notice that when the near end-of-paper condition is notified, there is either too
little or too much paper left, you can adjust the sensor setting.
The setting of the sensor depends on the diameter of the paper roll hub. For a hub of
a given diameter, moving the lever towards the rear of the machine will result in less
paper being present on the hub when notification is given, while moving the lever
towards the front will result in more paper being present. To regulate the near end-of-
paper sensor, proceed as follows.
1. Open the cover of the cash
register by pressing fully
down the release button.
2. If a roll of paper is loaded,
remove it.
3. Move the green adjustment
lever in the direction of the
cash register operator panel
to be notified earlier
(for hubs of larger
diameters).
Move the lever towards
the rear of the main module
to be notified later
(for hubs of smaller
diameters).
4. Load the paper roll.
PRINTING UNIT
The printing unit is composed of a single thermal printer. It comprises of a bay for
holding a paper roll of 80 mm width or, installing the adapter supplied, of 57.5 or 60
mm widths.
Note

11
ENGLISH
GETTING TO KNOW YOUR CASH REGISTER
MAIN COMPONENTS
The cash register and its principal components.
Alphanumeric
Customer LCD Display
Ticket output slot
Touch screen
Paper advancement
key
Power on key

12
Customer display
connection
interface
(built-in)
External power
supply DC IN
RJ12
Remote Display
RS232
Serial Interfaces
Ports 1 and 2
USB Connectors
(master)
RJ45
Drawer
Connection
VGA Display
port
RJ45 Ethernet
network port
USB Connectors
(master)
On-Off
Togglet
switch
HDMI
Display port
Microphone
jack
Line-out
jack
