olympia electronics GR-1935/15L User manual

Page 1 from 4923193601_09_008
GENERAL
T h e s e l u m i n a i r e s a r e u s e d w h e r e
emergency light is needed. Each luminaire
must be permanently connected to the
mains power supply. In normal operation
the battery is charging, the green LED and
2 yellow LED’s light in non-maintained
operation. The green LED and the LED
strip light in maintained operation. In case
of a mains power supply failure the
lum i n a i r e wil l l i g h t the L E D s t r ip
automatically in emergency mode. When
the mains power supply is restored the
device turns to normal operation.
Non maintained / maintained operation
There is an option to select the non-
maintained or maintained operation by
placing the jumper to the appropriate place
(page 2).
INSTALLATION
To install the luminaire follow the installation
instructions on page 2.
ΑΤΤΕΝΤΙΟΝ!!!
1. Operations for installation, maintainance
or testing must be done by authorized
personnel only.
2. The luminaire must be connected to the
mai ns po wer supp ly th roug h a fu se
dependent on the total amount of the line’s
power load.
3. It is suggested to check every month the
indication LED for battery charging, and by
placing the test card (page 3) an (A-1900)
operation test is initiated, to check the
emergency cirquit. The illumination source
should light as long as the card is present.
In the opposite condition contact the
installer.
4. It is suggested to check every 6 months
the minimum autononous duration by
disconnecting the mains power supply.
Count the time that the led strip lights and
in case of less time than the minimum
autonomous duration the battery must be
r e p l a c e d . I f t h e m e a s u r e d t i m e i s
considerably less than the minimum
autonomous duration contact the installer.
In case of battery or led strip replacement,
WATERPROOF NON MAINTAINED / MAINTAINED EMERGENCY LUMINAIRES WITH WHITE LEDs
220-240V AC/50-60Hz
3.3W/3.5VA
TECHNICAL CHARACTERISTICS (for LED MODULE Specs see page 4)
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
EXTERNAL DIMENSIONS
CONSTRUCTION MATERIALS
TYPICAL WEIGHT
GUARANTEE
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERIES (Ni-Cd)
CHARGING TIME
INDICATIONS
BATTERY PROTECTION
MINIMUM AUTONOMOUS DURATION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
ILLUMINATION (MAINS / EMERGENCY)
ILLUMINATION SOURCE
90min
24h
Charge indication LED
From overcharge and deep discharge
IP65
3.6V/3Ah
40lm / 210lm
30 white LEDs
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3
o
5 to 40 C
Up to 95%
3 years (1 year for the battery)
810gr.
3.1W/3.3VA
3.6V/0.6Ah
40lm / 105lm
15 white LEDs
180min
4.5W/4.8VA3.4W/3.6VA
3.6V/1.5Ah
40lm / 105lm
30 white LEDs
40lm / 210lm
15 white LEDs
630gr. 710gr.
313 x 118 x 66 mm
Bayblend FR3010, transparent polycarbonate
Thank you for your trust in our products.
Olympia Electronics - European manufacturer.
GR-1935/15L GR-1936/15L GR-1936/30LGR-1935/30L

Page 2 from 4
these must be replaced by parts of the
same type, by the manufacturer or by a
competent person.
5. In case of inactive use for a period
greater than 2 months, disconnect the
battery by p u l l i n g o u t the battery’s
connector.
6. I s not allowed to discard batteries in t i
to common trash bins, they must be
discarded only in battery recycling
points. Do not incinerate.
NOTE: LED= Light Emitting Diode
LABELING EXPLANATION:
X: Self contained
1: Maintained (*)
A: Including test device
G: Internally illuminated
*90: 1.5 hour duration
180: 3 hours duration
(*) Maintained operation: The luminaire
lights its illumination source, when it is
powered by the mains power supply or not.
Non Maintained operation: The luminaire
lights its illumination source, only in power
supply’s failure.
Note!! The installer should fill in, on the
specification label, the letter G if the luminaire
is used as a safety sign.
NOTE!! After finishing the installation
you must power the luminaire at least for
24 hours for battery charging to perform
the nominal autonomy.
Battery replacement
It can be done only by a competent
person and after the mains interruption.
1. Follow the step 1 of the installation
insrtuctions and remove the diffusor.
2. Remove the reflector (step 1 of the
installation instructions).
3. Remove the old battery and place a new
on of the same type and characteristics.
4. Replace the removed parts (previous
steps 1, 2).
The light source contained in this
luminaire shall only be replaced by
the manufacturer, or his agent, or a
similar qualified person.
NOTE! The light source is non-user
replaceable.
WARRANTY
Olympia Electronics guarantees the quality,
condition and operation of the goods. The
period of warranty is specified in the official
catalogue of Olympia Electronics and also
in the technical leaflet, which accompanies
each product. This warranty ceases to exist
if the buyer does not follow the technical
instructions included in official documents
given by Olympia Electronics or if the buyer
modifies the goods provided or has any
repairs or re-setting done by a third party,
unless Olympia Electronics has fully agreed
to them in writing. Products that have been
damaged can be returned to the premises
of our company for repair or replacement,
as long as the warranty period is valid.
Olympia Electronics reserves the right to
repair or to replace the returned goods and
to or not charge the buyer depending on the
reason of defection. Olympia Electronics
reserves the right to charge or not the buyer
the transportation cost.
HEAD OFFICE
72nd km. O.N.R. Thessaloniki-Katerini
P.C. 60061 Greece
www.olympia-electronics.gr
[email protected]
923193601_09_008
X1 81 0A G

Page 2 from 3923193601_09_008
Indications
Charge
6
8
NON MAINTAINED/MAINTAINED OPERATION
JUMPER SELECTION
You can choose the luminaire’s operation. When the
jumper is installed (by default) in the middle and left pins
maintained operation is selected.
When the jumper is installed in the middle and right pins
non-maintained operation is selected.
Maintained
operation
Non Maintained
operation
INSTALLATION INSTRUCTIONS FOR WALL OR CEILING MOUNTING
1 Unclip the plastic latches with a flat blade screwdriver, unfasten the 2 screws (not all the
way, step 8 B) and remove the diffusor. Place simultaneously 2 flat blade screwdrivers to
the recesses and pull up gently the reflector.
2 Install the base plastic (with the included mounting screws and plugs). WARNING!! To
preserve the ΙΡ65 rating, fit the screws with the metallic washers and plastic rings
which are included.
3 Always use in any case round mains cable, with external diameter of 5-10mm
(H05RN-F type 2x1mm² or any other type, at least equal to it’s mechanical and
electrical properties).
ATTENTION!! The cable must not be deformed in any way (This requirement is
important to ensure the ΙΡ65 rating). Install the gasket and make a hole in the center by
using a small screwdriver. Pass the round cable through the gasket. Install the second
included gasket in to the unused hole.
4 Place the battery’s connector to the corresponding connector on the P.C.B.
5 Connect the mains cables to the respective terminal block Ν for neutral, L for live wire.
6 Install the included tie to fasten securely the power cables.
7 Refit the reflector (mind the holes of the indications).
8 Finally place the diffusor (mind the holes of the indications). Attention!! First the plastic
latches (A) must be secured (click sound) and then fasten the 2 screws (B)
(tightening torque 1.2 Nm).
4
5
N
N
L
L
Mains connection
BB
A
A
7
1
2
3

A-1900
Test card
Manual TEST with the A-1900 Test
card (not included). This card is
available only after request. In order to
test the device, you must place the
card on the side of the indications.
This operation lasts as long as the
card is present.
Page 4 from 4923193601_09_008
LED MODULE CHARACTERISTICS
Olympia Electronics S.A.
Non reversible connection between main pcb and led module
2.9-3.6 V DC
980mw 1960mw
2502159/15L 2502159/30L
GR-1935/15L
GR-1936/15L GR-1935/30L GR-1936/30L
47 °C max. across the board
Manufacturer
Model Number
Voltage Range
Connections
Nominal Power
Temperature (tc)
