Omega Altise O14B User manual

O14B
35cm Turbo Tilt
Box Fan
Instruction
Manual

omega altise
2
Important Safety Instructions
1. Read all instructions.
2. Disconnect the power plug before dismantling, assembling or before cleaning.
3. Avoid touching mobile parts of the fan.
4. Make sure the fan is on a dry and even surface.
5. Never insert fingers, pencils or any other objects through the guards whenever
the power plug is connected, especially while running.
6. The appliance is not intended for use by young children or infirm persons unless
they have been adequately supervised by a responsible person to ensure that
they can use the appliance safely.
7. Young children or infirm persons should be supervised to ensure that they do not
play with the appliance.
8. Do not use the appliance for any other purpose than its intended use.
9. The fan must not be used if the guards are not fastened according to
instructions.
10. When the power cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
11. Do not use your appliance with an extension cord unless it has been checked
and tested by a qualified electrician or electrical supplier.
Read all instructions before using this unit. Keep them for future reference.
Specifications
Model O14B – Turbo Tilt Settings 3 speed, louvre control
Rated Voltage 220-240V / 50Hz Fan blade size cm 35
Watts 70 Tilt action Tilting fan body
Dimensions
(h x w x d) mm 520 x 450 x 200 Oscillation Rotating grille
Weight (carton) kg 5.1 Warranty 2 year replacement

omega altise
3
Parts List
1. Push control switch
2. Rear Guard
3. Cord
4. Plug
5. Foot
6. Fan blade
7. Front cover
8. Grille hub
9. Grille
10. Fan body
Operating Instructions
1. Use in a dry place, free of excessive humidity and water.
2. To set the fan in motion push the switches to obtain desired fan speed:
0 = OFF 1 = LOW 2 = MEDIUM 3 = HIGH
The fifth button operates the rotating louvre
3. The direction of the airflow is vertically adjustable by tilting the fan body as
shown above.
4. To stop the fan and rotating louvre push the 0 button.

omega altise
4
Care and Maintenance
1. Always disconnect the cord from the electrical outlet when cleaning your fan.
2. Light accumulated dust may be removed from the fan with a soft cloth or vacuum
cleaner using the dusting brush attachment.
3. Wipe the exterior surfaces of the fan occasionally with a cloth moistened (not
dripping wet) with a mild soap solution. Dry the case thoroughly with a soft dry
cloth before operating the fan.
4. Avoid the use of gasoline, benzine, thinner etc as they may result in damage to
the fan.
5. To clean the fan blades use a screwdriver to remove the rear guard (3 screws),
unscrew the blade fixing screw to take the blade off. Clean the blade with a soft
cloth moistened with a mild soap solution. Replace by tightly securing the blade
with the blade fixing screw. Place the rear guard back into position and fix with
the screws.
6. Store the fan in a clean dry place when not in use.
CAUTION! Do not immerse the fan in water or allow water to drip into
the interior of the fan housing as this could create a fire or electric
shock hazard.
WARNING! Do not attempt to repair the fan yourself. Doing so could
void the warranty and cause damage or personal injury.
Omega Altise products are distributed in Australia by MEA,
(A Division of Hagemeyer Brands Australia Pty Ltd)
ABN 28 001 375 686
Locked Bag 4013, Kingsgrove NSW 2208
Phone: [phone]
Fax: [phone]
Email: [email protected]
Web: meaappliances.com.au
